ARG ARG-TX72BP Guide

Talk & Listen Systems
ARG-TX72BP Transmitter
Part #ARG-TX72BP
Manual and User Guide
User Guide Part # ARG-OM-028 Rev E
Updated: 1/5/2017
Audio Resource Group, Inc. • 405 Main Ave W, Unit 4G • West Fargo, ND 58078 • ©2016 Audio Resource Group, Inc. • All Rights Reserved •
www.argaudio.com

Page 2
IMPORTANT SAFETY INSTRUCTIONS
Audio Resource Group products are engineered and manufactured with the highest priority on
safety. However, improper use can result in electric shock and/or fire. To ensure your safety and
prolong the service life of your equipment, please read the following precautions and all
collateral materials carefully before using the product.
1. Read and keep these instructions.
2. Follow all instructions.
3. Do not use this device near water. Avoid direct contact with liquids of anykind.
4. Clean only with dry cloth.
5. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
6. Do not place the device in direct sunlight.
7. Do not place, store or install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including powered amplifiers) that produceheat.
8. Do not defeat the safety purpose of the polarized or grounding type plug for products
that use wall power sources. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsoleteoutlet.
9. Protect power cords from being walked on or pinched: especially at plugs, convenience
receptacles, and the device’s exit point.
10. Only use attachments/accessories specified by themanufacturer.
11. Unplug devices from wall outlets during lightning storms or when not in use for long
periods of time.
12. Refer all servicing to qualified service personnel. Servicing may be required when the
apparatus has been damaged in any way or performs in an abnormal fashion.
(Examples may include, but not be limited to: equipment has been dropped or suffered
an impact, liquid has been spilled or objects have fallen into or on top of the unit, or the
unit has been exposed to rain ormoisture.)
13. The device should be protected from exposure to dripping or splashing: do not place
objects filled with liquids, such as water bottles or drink containers directly near or on
equipment.
CAUTION: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE PRODUCT TO RAIN OR MOISTURE

Page 3
CAUTION!
HEARING SAFETY
Many of ARG’s products are designed to amplify sounds to a high volume level which could
potentially cause hearing damage if used improperly. To protect your hearing and the hearing
of others:
1. Set the volume level at the minimum setting, then place the listening accessory
(headphones, earphones or earbuds) on your ears and finally adjust the volume to a
comfortable level.
2. If feedback (a high-pitched squealing sound) occurs, immediately move the receiver
away from the transmitter and reduce the volumelevel.
3. Do not allow children or other unauthorized persons access to thisproduct.
BATTERY SAFETY AND INSTRUCTIONS
RECYCLING INSTRUCTIONS
Please help ARG protect our environment by taking time to properly dispose of your used
batteries. Do NOT throw into household trash: Please recycle by taking them to a local
recycling collection center.
NON-RECHARGEABLE BATTERIES
In normal use, two AA 1.5V alkaline batteries will last about 30-40 hours in the ARG-
TX72BP. If the sound becomes distorted or weak, it is time to replace the batteries.
RECHARGEABLE BATTERIES
The TX72BP transmitter can use 1.25V AA NiMH rechargeable batteries. After charging for
5-6 hours, these NiMH batteries are designed to operate a TX72BP transmitter for
approximately 30-40 hours.
IMPORTANT RECHARGEABLE BATTERY INFORMATION
Batteries MUST BE CHARGED for a complete cycle before the first use.
Rechargeable batteries will normally need to be replaced after 1-2 years ofuse.
Do not leave batteries installed for long periods of inactivity as they may leak. (Battery
leakage is not covered by warranty)
CAUTION!
Do not attempt to recharge disposable batteries, which may explode, release
dangerous chemicals, cause burns or other serious harm to the user orproduct.
Avoid shorting the batteries by placing plus and minus battery terminals together with
metal objects. Battery damage and burns can result!
Do not dispose of batteries in fire.
Do not open batteries as they contain toxicchemicals.

Page 4
SYSTEM OVERVIEW
The Talk & Listen® System is a portable, high-performance communication system designed to
be used for many types of communication applications. It is composed of five principal
components: transmitter, microphone, receiver, listening equipment (headphone, earphone, ear
bud, etc.) and batteries.
The TX72BP Transmitter broadcasts a high-quality one-way audio signal to an unlimited
number of receivers providing crystal clear FM quality audio to each listener. Much like a
miniature radio station, the speaker uses a transmitter to broadcast a radio signal while the
listeners use a receiver to hear the signal. The transmission range of this system is 100m LOS
(Line of Site).
ARG’s updated 72MHz Talk & Listen® System showcases many new features including
adjustable RF levels; user-friendly scroll-and-click commands; mono and stereo input; and
durable, attractive housing.
HINTS to Using the TALK & LISTEN® Wireless System
Maximum operating distance between the transmitter and receiver is 100m (LOS). The
operating range will vary in different environments. In some locations, the signal may
momentarily disappear. This is called a drop-out signal and is due to reflection and cancellation
of the radio signal. Moving a few feet in any direction should restore thesignal.
Getting transmitters too close to one another may cause signal interference, even when they
are set to a different channel. Maintain at least three feet of separation between transmitters to
avoid signal interference.
Receivers are not subject to interference when in close proximity to one another therefore
listeners may sit close together whether on the same or different channels. If a receiver gets too
close to a transmitter, interference may occur. Maintain three feet of separation between a
transmitter and receiver to avoid interference.
Transmitter/Receiver Group Separation

Page 5
OPERATING INSTRUCTIONS
1. Before installing batteries, determine if they are carbon zinc, heavy duty, alkaline or rechargeable. Open the
battery compartment door and locate the “ALK/NiMH” switch. If using carbon zinc, heavy duty or alkaline
batteries slide the switch to the “ALK” position; if using NiMH rechargeable batteries slide the switch to the
“NiMH” position.
2. Install (2) AA style batteries by pressing them into place, observing the proper battery polarity. Incorrect insertion
may cause both mechanical and electrical damage not covered by the limited lifetime warranty. Units will not
work if the batteries are incorrectlyinstalled.
3. Plug the microphone into the 3.5mm audio input jack located on the left side of the transmitter housing. The
microphone cable is the transmitter antenna. Do not bunch up the cord, wrap it tightly around your body or wrap
it around the transmitter. For maximum range, the cord should hang loosely from the microphone to the
transmitter. Use only Talk & Listen approved microphones, substitutions can greatly affect the overall
performance therefore causing poor audio quality or reduced transmission range between the transmitter and
receiver(s).
4. Turn the power switch on top of the transmitter to “ON”. The LCD backlight will appear and stay on until it detects
10 seconds of inactivity, it will then automatically shut off to save battery power. The LCD backlight will
automatically turn back on once any of the control buttons are pressed.
5. Channel setting (1–17): Confirm the channel number on the transmitter matches the number on the receiver (s).
To adjust the channel number, turn the transmitter OFF; open the battery door, press and hold the “Lock” and
“Set” buttons simultaneously while turning the transmitter power ON, the green backlight on the LCD display will
illuminate showing the current channel number programmed; press the “-” or “+” buttons to scroll through and
select one of the 17 available channels. When finished, close the battery door and turn the transmitter off. The
transmitter is now programmed to your desiredchannel.
6. Audio Mute: To temporarily silence during use, press and hold the “-” button until the “Gain Indicator” (number
on the right of the screen under the LCD display) starts to flash, this indicates the audio has been muted.
Repeat the process to restore the audio signal. The “Gain Indicator” icon will stop flashing.
7. Gain Setting: When using the line input for auxiliary equipment (such as CD player or iPOD™), turn the “Gain
Control” to “1”; higher levels will distort audio. To adjust the gain setting, turn the transmitter ON; open the battery
door, press and hold the “Lock” button till the Lock icon disappears from the LCD display; press the “Set” button
to scroll through and select 1 for microphone or 2 for line levelaudio.
8. RF Level Adjustment: turn the transmitter off; open the battery door, press and hold the “Set” button and
simultaneously turn the transmitter ON to enter into the RF Level Programming mode. There are 5 individual RF
level settings. The signal meter icon on the LCD display is used to indicate the current programmed RF level.
Settings are -1dBm (no signal bar-lowest setting); +3dBm (1 signal bar); +7dBm (2 signal bars); +11dBm (3
signal bars); and +15dBm (4 signal bars-the highest RF Level Setting). Press the “SET” button to scroll through
and select the RF level setting. When finished, close the battery door and turn the transmitter OFF to exit
programming mode.
9. When finished using Transmitter, make sure to poweroff.

Page 6
TX72BP TRANSMITTER PRODUCT FEATURES

Page 7
Transmitter LCD Display

Page 8
ARG-TX72 Transmitter FCC Compliance
The ARG-TX72BP is authorized by rule under the Low Power Radio Service (47 C.F.R. part 95) and must not
cause harmful interference to TV reception or United States Navy SPASUR installations. You do not need an
FCC license to operate this transmitter. This transmitter may only be used to provide: auditory assistance to
persons with disabilities, persons who require language translation, or persons in educational settings;
healthcare services to the ill; law enforcement tracking services under agreement with a law enforcement
agency; or automated maritime telecommunications systems (AMTS) network control communications. Two-way
voice communications and all other types of uses not mentioned above are expresslyprohibited.
Operation is subject to the following two conditions:
1) this device may not cause interference
2) this device must accept any interference, including interference that may cause undesired operation of
the device
TROUBLESHOOTING
1. Read through the manual and user guide carefully to verify proper setup and installation of the transmitter
and receiver(s).
2. Make sure the batteries are fresh or completely charged and that the “plus” and “minus” terminals are
correctly placed.
3. If the rechargeable batteries will only work for a short period of time (less than 1 hour) even after they have
been fully charged; they must be regenerated. Turn the transmitter(s) on until the batteries are completely
dead, and then fully charge again. This should restore normal battery life. Rechargeable batteries will
gradually lose their capacity over time and should be replaced every 1 to 2years.
4. Make sure the microphone is plugged into the TX72BP transmitter and the earphone/headphone is plugged
in the RX72BP receiver.
5. Move the transmitter and receiver closer together as you may be out of range. When using the system
indoors, it is normal for the signal to momentarily disappear in certain locations. This is called a “drop-out”.
Moving a few feet in any direction may restore thesignal.
6. When using two or more transmitters simultaneously do not use adjacent channels if possible, for example:
if you have a 3-channel system and you want to use two transmitters simultaneously, set TRANSMITTER
ONE to channel 1 and TRANSMITTER TWO to channel 3; leaving channel 2 as an unused channel. This
creates more spacing between the channels and reduces the likelihood ofinterference.
7. If you are still hearing interference, turn the transmitter off and listen to a receiver. If you hear the
interference with the transmitter off, you need to change to a clearchannel.
8. If you are still experiencing difficulties, call ARG888-468-4552.
OPERATING FREQUENCIES
Available Frequencies:
72.1MHz (1) 72.5MHz (2) 72.9MHz (3) 75.7MHz (4) 74.7MHz (5) 75.3MHz (6) 75.9MHz (7) 72.2MHz (8) 72.3MHz
(9)
72.4MHz (10) 72.6MHz (11) 72.7MHz (12) 72.8MHz (13) 75.4MHz (14) 75.5MHz (15) 75.6MHz (16) 75.8MHz
(17)

Page 9
Warranty Statement
Audio Resource Group, Inc. (ARG) develops, designs and distributes only high quality products that will provide
users with many years of trouble-free service. Some of the products we distribute are sold exclusively by ARG.
The following Warranty Statement defines the warranty periods for each product line and model of equipment
distributed by Audio Resource Group, Inc.
Talk and Listen™Systems
ARG warrants the following transmitters and receivers (TX72BP, TX72M, TX900BP, TX900HH, TX900M,
RX72BPS, RX72BPM, RX72BP, RX72M, RX900BP, RX900M) to be free from defects in workmanship and material
under normal use and conditions for five years from date of purchase.
ARG warrants the following charging systems (CHGR12, CHRG24) to be free from defects in workmanship and
material under normal use and conditions for two years from date of purchase. Rechargeable batteries in the
TX72M, TX900M, RX72M, and RX900M are warrantied for 2 years. Power Supplies are warrantied for 90 days.
All other parts and accessories are warranted for 90 days from date of purchase.
VoiceAmp® Portable Amplifiers
ARG warrants the following VoiceAmp portable amplifiers (VA20WB, VA20T, and VA30SE) to be free from defects
in workmanship and material under normal use and conditions for five years from date of purchase. Batteries for
these listed products are warranted for two years from date of purchase.
All other parts and accessories are warranted for 90 days from date of purchase.
Fitness and Cardio Entertainment Products
ARG warrants the following transmitters (ARG-CV-FMT, ARG-CV-900T, ARG-900AT, and ARG-CV-2.4T) to be free
from defects in workmanship and material under normal use and conditions for four years from date of purchase.
ARG warrants the following receivers (ARG-CV-FMR, ARG-CV-900R, ARG-900AR, ARG-CV-2.4R and ARG-2.4R)
to be free from defects in workmanship and material under normal use and conditions for two years from date of
purchase.
ARG warrants the following personal viewing screens and accessories (ARG-PVS15LED, ARG-PVS19LED, ARG-
PVSC) to be free from defects in workmanship and material under normal use and conditions for two years from
date of purchase.
All other parts and accessories are warranted for 90 days from date of purchase.
The Warranty is only available to the original end purchaser of the product and cannot be transferred. Warranty is
void if damage occurred because of deliberate or accidental physical damage, neglect, misuse or if the product has
been repaired or modified by anyone other than a factory authorized service technician. Warranty does not include
normal wear and tear on the product or any other physical damage unless the damage was the result of a
manufacturing defect. ARG is not liable for consequential damages due to any failure of equipment to perform as
intended.
The above stated warranty is exclusive and replaces all other warranties express of implied, including those of
merchantability and fitness for a particular purpose. ARG will not be held liable for any other damages or loss
including incidental or consequential damages and loss of profit or revenues from whatever cause including breach
of warranty or negligence.
The terms of the warranty are governed by the laws of the state of North Dakota. This warranty, prices, and the
specifications of products are subject to change without notice. Revised 1/4/2017

Page 10
Repairs and Returns
If you are experiencing difficulty with your system please review the Troubleshooting section of your
manuals and user guides for tips and techniques to correct your issues. If you continue to experience
problems with your equipment, please call Audio Resource Group, Inc. (ARG) toll-free Customer Service
Assistance number at [phone].
If it is necessary to return your system for service, you must first be issued a Return Authorization
Number (RMA) by our Customer Service Technician prior to sending the system to ARG. All returns
must be prepaid by the sender (no freight collect shipments will be accepted). Make sure to clearly mark
the RMA number on the outside of the package and ship to:
Ship To:
Audio Resource Group, Inc.
Attn: Repair Department
405 Main Ave W Unit 3A
West Fargo, ND 58078
Out-of-Warranty Repairs:
We can service/repair most Out-of-Warranty products. These repairs will be charged in accordance with
our Flat Rate Repair Schedule. Please contact your sales representative or customer service for a repair
quotation under our Flat Rate Repair Schedule.
Repair Quotes:
In some cases, if your product is not listed on the Flat Rate Repair Schedule, we can provide you with a repair
price based on an individual repair cost estimate.
Warranty Repairs:
The ARG warranty period begins from date of purchase. Warranty is only available to the original end
purchaser of the product and cannot be transferred. We will, at our option, repair or replace any part or
product found to be defective in workmanship or material under normal use and condition. Warranty is
void if damage occurred because of deliberate or accidental physical damage, neglect, misuse or if the
product has been repaired or modified by anyone other than a factory authorized service technician.
Warranty does not include normal wear and tear on the product or any other physical damage unless
the damage was the result of a manufacturing defect.
Returns for Credit:
Items returned for credit, in “like new” condition (unopened, or original packaging intact), will be issued a
full credit (minus applicable shipping charges). Items returned for credit after 30 days are subject to a
restocking fee. We are unable to issue credit for any items after 90 days from the date of purchase.
Additional fees or partial credit may occur due to missing or damaged items.
Ship To:
Audio Resource Group, Inc.
405 Main Ave W Unit 3A
West Fargo, ND 58078
Phone: [phone] Fax: [phone]
[email protected]
ARG Repairs and Return policies, programs, and pricing are subject to change without notice.

Page 11
