Argox AS-8060 User manual

AS-8060
Barcode Scanner
User Manual
http://www.argox.com
[email protected]
Version: 1.1
Date: Oct. 18, 2019
V1.0-23-08-2
017

AS-8060
User Guide
ii
Regulatory Compliance
FEDERAL COMMUNICATIONS
COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/ TV
technician for help.
CAUTION:
Any changes or modifications not expressly
approved by the grantee of this device could void the
user's authority to operate the equipment.

AS-8060
User Guide
iii
Note: All brands and trademarks are the
property of their respective owners.
Note: The specifications contained herein
are subject to change without notice.
警告使用者:
這是甲類的資訊產品，在居住的環境中使用時，可
能會造成射頻干擾，在這種情況下，使用者會被要
求採取某些適當的對策。

AS-8060
User Guide
iv
Contents
Introduction ............................................................ 1
Unpacking ............................................................... 3
Get started............................................................... 4
Installation ........................................................... 4
How to scan ......................................................... 5
Controls and settings.............................................. 6
Version information setting code ......................... 6
Interface mode setting code ................................. 7
Scan mode setting code........................................ 8
Sound setting code............................................... 8
Character delete / insert / replacement setting ..... 9
Serial port setting............................................... 12
Normal function setting code............................. 14
Prefix / suffix setting.......................................... 16
Multi-language setting code............................... 17
Character table................................................... 20
Enable / disable barcodes................................... 32
Specifications......................................................... 56

AS-8060
User Guide
1
Introduction
Your AS-8060 is a 1D CCD scanner that has
been configured at the factory with default
settings.
Since many host systems have unique
formats and protocol requirements, Argox
provides a wide range of configurable
features that may be selected using this bar
code based configuration tool. Once the
configuration is completed, the scanner
stores the settings in nonvolatile memory.
The embedded memory saves the settings
when the power is turned off.
Turn off the computer’s power before
connecting the scanner, and then power up
the computer once the scanner is fully
connected.
You can change a parameter value in the
way described below:
Scan the appropriate bar codes in this
guide. These new values replace the
standard default values in memory.
NOTE: Most computer monitors allow scanning the
bar codes directly on the screen. When
scanning from the screen, be sure to set the
document magnification to a level where
you can see the bar code clearly, and bars
and/or spaces are not merging.

AS-8060
User Guide
2
Application Field:
Jewelry Tag
Manufacturing
Transportation & Logistics
Healthcare
Feature:
Rich to make daily work simple and easy
2500 pixels CCD image sensor
Scan Speed≧270 times/sec
Max. reading resolution: 3mil (0.762mm)
Depth of Field: 15~330mm
(EAN, 13mil/0.33mm, PCS 90%)
Drop resistance: 1.5 meters onto the
concrete
Auto-sensing (presentation) mode
available

AS-8060
User Guide
3
Unpacking
Make sure all of the following items
are included in your package.
Scanner x1
Stand x1
Quick Start Guide x1
USB Cable x1
When you receive your scanner, open the
package immediately and inspect for
shipping damage. If you discover any
damage, contact the shipping company and
file a claim.Argox is not responsible for any
damage incurred during shipping. Save all
package materials for the shipping company
to inspect.
Note If any item is missing, please
contact your local dealer.

AS-8060
User Guide
4
Get started
This chapter provides information about
how to install, connect and use your scanner
to do your work.
Installation
This section describes how to set up your
scanner.
Set up your scanner
1. Plug the RJ45 connector into your
scanner’s RJ45 port, until you hear a
click.
2. Connect the USB connector to your
computer.
3. Turn on your computer. It detects your
scanner automatically.
4. To test your scanner, start a text
processing program like Notepad or
Microsoft Word. Scan a bar code and see
if the data can be sent to your computer.
If it’s successful, you’ll hear a beep and
the bar code data shows in the program.

AS-8060
User Guide
5
How to scan
AS-8060 emits a light bar when it is scanning.
To scan a barcode, make sure the aiming
beam crosses every bar and space of the
barcode. This bar needs to cross the bar code
horizontally to decode it.

AS-8060
User Guide
6
Controls and settings
Customize your scanner to work efficiently.
AS-8060 offers many features to match your
preferences. This chapter provides
information about how to change controls
and settings of your scanner.
Version information setting code
Version (custom)
000A0
Display internal string (custom)
000A1
Display serial number (custom)
000A2
Factory default
000B0
Enable the code setting function
09990
Disable the code setting function
09991

AS-8060
User Guide
7
Interface mode setting code
AS-8060 supports USB HID and virtual
COM. By default, your scanner is able to
detect the interface automatically. When it
detects USB, it selects HID as your
scanner’s interface.
USB-HID (Default)
000602
USB Virtual Com
000603
Note: If you use the scanner that communicates with your
computer via a serial interface (e.g. COM1...COM8), but
your computer does not have any serial port, you will
require a so-called virtual COM port driver. This virtual
COM port driver allows you to assign a virtual COM port
connection number to your computer connected via a USB
port and enables bidirectional communication between your
computer and this scanner.
To download the USB virtual COM port driver of AS-8060
scanner, go to the Argox global website
(http://www.argox.com/).
After downloading the driver, start to install it. When you
finish installing the driver, it is suggested to restart your
computer. The system will automatically detect the scanner.

AS-8060
User Guide
8
Scan mode setting code
Trigger mode (default)
013300
Continuous scan mode
013304
Presentation mode
02311
Key delay
013302
Single not triggered
013301
Key delay not triggered
013303
Auto flashing
013305
Sound setting code
Sound on (default)
014201
Sound off
014200

AS-8060
User Guide
9
Buzzer frequency 2048
0145800
High volume sound
014300
Low volume sound
014301
Buzzer frequency 2731
0145AAA
Character delete / insert / replacement
setting
Code ID off (default)
01400
Code ID on
01401
Rear code ID on
01402
Display code front character
(default)
0201x
Hide code front blank
0200[SPACE]

AS-8060
User Guide
10
Display code rear character
(default)
0203
Hide code rear character n
(“n” indicates a blank key.)
0202[SP]
Display characters inside code
(default)
0205-
Hide –inside code
0204-
Disable A replace 0 in code
(default)
020600
Enable A replace 0 in code
02060A
Display rear characters (default)
023300
Hide rear 5 characters
023305
Hide rear 1 characters
023301
Display front characters (default)
023400

AS-8060
User Guide
11
Hide front 5 characters
023405
Display middle characters
(default)
023900
Hide 5 middle characters
023905
Forward start from 4th character
024004
FUNC1 replace with 1
0160049
FUNC2 replace with 2
0161050
FUNC3 replace with 3
0162051
FUNC4 replace with 4
0163054
Disable enter replace (default)
0182013
Enter replace with 5
0182055

AS-8060
User Guide
12
Serial port setting
Baud rate 600bps
000701
Baud rate 1200bps
000702
Baud rate 2400bps
000703
Baud rate 4800bps
000704
Baud rate 9600bps (default)
000705
Baud rate 19200bps
000706
Baud rate 38400bps
000707
Baud rate 57600bps
000708
Baud rate 115200bps
000709
Serial Port: No Check
001200

AS-8060
User Guide
13
Serial port: XON/OFF
001201
Serial port: RTS/CTS
001202
Serial port handshake timeout 2s
0013020
Serial port handshake timeout 5s
0013050
Serial port 8-bit data
00080
Serial port 7-bit data
00081
Serial port 1 stop bit
00090
Serial port 2 stop bits
00091
Serial port No parity check
001000
Serial port odd parity check
001001

AS-8060
User Guide
14
Serial port even parity check
001002
Normal function setting code
Enable upload setting barcodes
02501
Disable upload setting barcodes
(default)
02500
FUNC cast light upon cancel
(default)
01640
Disable change
02510
All uppercase
02511
All lowercase
02512
Uppercase interchange
with lowercase
02513
Enable command beep
01411

AS-8060
User Guide
15
Disable command beep
01410
Forward image identify (default)
00161
Reverse image identify
00160
Fastest transmit rate
001500
Medium transmit rate (default)
001502
Lower transmit rate
001504
Lowest transmit rate
001506

AS-8060
User Guide
16
Prefix / suffix setting
CR
0212@\r
CR+LF
0213@\r\n
All barcodes (rear) add ETX
0211@[ETX]
All barcodes (front) add F2
02160081
All barcodes (rear) add F2
02110081
Cancel all barcodes (rear)
format character
0210@
Add STX before barcodes
0217@[STX]
Cancel all boots before
barcodes
0215@
Add prefix
02240
Add suffix
02241
