Argox AS-9300 User manual

AS-9300
User Manual
v1.4-s

1
Connection
Connect the scanning gun to the special connector from the cable,
inserted the other end of cable into the corresponding port of the PC.
Please open the bar code configuration switch on the second page
if the bar code configuration switch has been turned off
Interface Mode
This scanning gun supports three kinds of interface modes，RS232 port
and USB keyboard and USB turning to RS232.
Scan the following bar code can be configured as the RS232
scanning mode. (Default mode)
RS232
Scan the following bar code can be configured as the USB keyboard
scanning mode.
USB (default)

2
Scan the following bar code can be configured as the USB turned to
USB keyboard mode
USB turning to RS232
Enable / Disable configuration code
When the configuration code is open, you can scan all the configuration bar code for
scanning gun configuration. When the configuration code is closed, the other
configuration bar code can not be scanned. Need to re open before scanning the
configuration code to scan the gun configuration
Enable configuration code（Default）
Disable configuration code

3
Product default configuration
Scan the following bar code can be returned to the factory default configuration.
returned to the factory default configuration
Product user configuration
Scan the following bar code to save the current parameters of the product to the user
configuration.
Save user configuration
Scan the following bar code to recovery the user configuration.
Recovery user configuration
The RS232 baud rate configuration
Baud rate 4800
Baud rate 9600（Default）

4
Baud rate 19200
Baud rate 38400
Baud rate 57600
Baud rate 115200
Auto-sensing Scan Mode
This product has auto-sensing scan mode. Scan the following bar code to configure
the switch
Disable Automatic Recognition Mode
When the self sensing mode is configured to be closed, Decoded by the trigger of the
scanning gun.Default configuration.
Disable auto-sensing scan Mode (Default)

5
Enable Automatic Recognition Mode
When the self sensing mode is configured to be open,The scanning gun
can decode automatically by scanning lens before the bar code
Enable auto-sensing scan Mode
Screen Reading Mode
When you turn on this mode, Scanners can be decoding the codes on
phone or computer. However, Turn on this code will be cause lower speed when
scanning printing codes. The default is turn off.
.
Disable screen reading mode（Default）
Enable screen reading mode
Focus Mode
When focus mode is turn on, The scanner only identified the focus codes
scanners lens covering, The default is turn off.

6
Disable Focus Mode（Default）
Enable focus mode
Suffix Setting
Cancel / enter Tab
Add Enter

7
Add Tab
Add Enter+Tab（Default）
BUZZER volume
Volume-low
Volume-high(default)
Scanner launch prompt tone
Enable
Disable ( default mode)

8
Successful decoding prompt tone ON-OFF
Off
On (default)
Successful decoding prompt tone GHZ(volume)
Volume-low
Volume-middle(default)
Volume-high
Successful decoding prompt tone time
LONG(default)

9
Short
Error Warming
Volume-low(default)
Volume-middle
Volume-high
LED Indicating
Lamp
Successful decoding LED light off
Successful decoding LED light on

10
Same barcode Scanning interval Setting
By default,the interval time between first scanning and second
scanning for same bar code is 700ms. To avoid unwanted repeat scanning, you can
scan the configuration bar code to set the interval time.
500ms
700ms (default)
1S
2S
USB keyboard transfer speed
The speed of transferring data using USB connecting mode.
To obtain accuracy of the data transmission, if the PC performance is poor
relatively, slow transfer speed is suggested.
Slow(default)

11
Middle
Fast
Keyboard Layouts
English (United States)
French (France)
Italian (Italy)

12
Italian 142 (Italy)
German (Germany)
Spanish (Spain)
Russian (MS)

13
Russian (typewriter)
Portuguese (Portugal)
Portuguese (Brazil)

14
Bar code selection
Turn on/off all kinds of bar code reading
Turn on the mode of all kinds of bar code may slow the scanning decoding
speed，you can select some bar code you nee. The mode of all kinds of bar code is
on by default.
Enable all bar codes
Disable all bar codes
Codabar
Enable Codabar

15
Disable Codabar
Don’t send Codabar began/over CH（default）
Send Codabar began/over Ch
Code 39
Enable Code 39
Disable Code 39
Code 39 check digit

16
Disable Code 39 Check digit（default）
Enable Code 39 check but don’t send check digit
Enable Code 39 check and send check digit
Code 32 (code 39 opening needed)
Enable Code 32
Disable Code 32
Interleaved 2 of 5（ITF25）
Enable ITF25

17
Disable ITF25
Interleaved 2 of 5（ITF25）Digits
Disable ITF25（default）
Enable ITF25 check but don’t send digit
Enable ITF25 and send digit
Interleaved 2 of 5（ITF25）length
ITF25 random length（4-24）（default）

18
ITF25 Length of 8 Digits
ITF25 Length of 6 Digits
ITF25 Length of 10 Digits
ITF25 Length of 12 Digits
ITF25 Length of 14 Digits
ITF25 Length of 16 Digits

19
ITF25 Length of 18 Digits
ITF25 Length of 20 Digits
ITF25 Length of 22 Digits
ITF25 Length of 24 Digits
Industrial 2 of 5（4-24）
Enable Industrial 2 of 5
