PRODUCT: DISHWASHER
MODEL: L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: i
This Repair Manual is intended for persons having electrical and mechanical training and a level of knowledge
of these subjects generally considered acceptable in the Appliance Service Industry. Ariston cannot be
responsible, nor assumes any liability for injury or damages of any kind arising from the use or misuse of
the information contained in this Repair Manual.
If you have any questions regarding the proper diagnosis, repair or operation of any Ariston Appliance, please
contact the Ariston Customer Care Center or your Service Representative.
SERVICING SAFEGAURDS:
To avoid personal injury and/or property damage, it is important that safe servicing practices be observed at all times. Examples of
safe service practices are listed below but are not limited to the following:
1) Never attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and
satisfactory manner.
2) Before servicing or removing an appliance:
- Disconnect power to the appliance.
- Turn off the gas / LP supply.
- Turn off the water supply.
3) Never interfere with the proper operation of any safety device.
4) Use only genuine factory replacement parts as substitutions may interfere with compliances to home safety codes or standards.
5) It is extremely important that all safety ground connections be reestablished prior to the completion of the service call. Failure to
do so will result in a hazardous condition being created.
6) Prior to returning the appliance back into active service, ensure the following:
- All electrical connections are correct and secure.
- Electrical leads are properly dressed and secured away from sharp edges, high temperature components and moving parts.
- All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from metal parts or panels.
- All safety grounds (both internal and external) are correctly and securely connected.
- All access panels are properly and securely reassembled.
SAFE SERVICE PRACTICES

REPAIR MANUAL
Page: ii
Page
1. Model and Serial Number Location ................................................................................................ 1
2. Rack Rollers - Upper & Lower........................................................................................................ 2
3. Upper Spray Arm............................................................................................................................2
4. Lower Spray Arm............................................................................................................................3
5. Outer Door Panel............................................................................................................................ 4
6. Control Panel..................................................................................................................................5
7. Outer Door Skin..............................................................................................................................6
8. Soap Dispenser and Water Temperature NTC............................................................................... 7
9. Door Spring Adjustment and Door Latch........................................................................................7
10. Kick Plate ....................................................................................................................................... 8
11. Door Extension............................................................................................................................... 9
12. Water Valve.................................................................................................................................. 10
13. Float Switch and Pressure Switch................................................................................................ 11
14. Lower Component Access - Base Pane Removal........................................................................ 12
15. Lower Components...................................................................................................................... 13
16. Drain Motor................................................................................................................................... 14
17. Main Motor and Pump.................................................................................................................. 15
18. Heater Assembly.......................................................................................................................... 17
19. Turbidity Sensor (LI 670 / LI 700 Models Only)............................................................................................ 18
20. Water Softener............................................................................................................................. 19
TABLE OF CONTENTS
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: iii
Page
21. High Pressure Switch................................................................................................................... 20
22. Fan Motor (LL 65 / LI 700 Models Only) ...................................................................................................... 20
23. Water Inlet and Turbine................................................................................................................ 21
24. Fault Codes.................................................................................................................................. 22
25. Schematics................................................................................................................................... 23
TABLE OF CONTENTS Cont.
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: iv
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
This Dishwasher Repair Manual uses the LI 700 S model for all repair instructions and demonstrations. The
technical similarities between the LI 700 S and the other LI , L and LL models will allow the repair techniques
described and demonstrated to be applied without difficulty to the other models not shown.
LI 700 S LL 64 S

REPAIR MANUAL
Page: 1
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
1. MODEL and SERIAL NUMBER LOCATION
• The Model and Serial Number Tag is located on the right side of the Inner Door Panel (Fig. 1-1). The Model shown is a LI 700 S
with a Serial Number of 407292454 (Fig. 1-2).
Note: Numbers located to the left of the nine (9) digit Serial Number are not required on the Warranty Claim Form.
Fig. 1-1
Fig. 1-2

REPAIR MANUAL
Page: 2
3. UPPER SPRAYARM
• To remove the Upper Spray Arm (Fig. 3-1) gently grasp the Locking Ring with a Channel Locks and turn Counter-Clockwise
(Fig. 3-2); note the Tab and Slot locking configuration (Fig. 3-3).
TECH NOTE: When Replacing the Spray Arm make sure that it is tightened completely onto the Locking Ring.
Fig. 3-1 Fig. 3-2 Fig. 3-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
2. RACK ROLLERS - Upper & Lower
• The Lower Rack Roller Assemblies are held in place using three (3) tension clips (Fig 2-4). Grasping the Roller Assembly and
applying downward force will disengage the Roller Assembly from the Rack.
Fig. 2-1 Fig. 2-2 Fig. 2-3
• The Upper Rack can be removed by releasing the Rail Clip and sliding the
Rack out from the Rail (Fig. 2-1). If the Upper Rack Roller Assembly must be
replaced (Fig 4-2) first remove the Side Panel (see Section 22) and then
remove the four (4) 8mm bolts that mount the Roller Assembly to the Tank.
• Once the Upper Rack has been removed, the Rack Roller Wheels can be
replaced by gently prying the Hub Clips inward with a small screwdriver and
then moving the Roller Wheel out and off the Hub (Fig. 2-3).
Fig. 4-4

REPAIR MANUAL
Page: 3
4. LOWER SPRAYARM
• To remove the Lower Spray Arm (Fig. 4-1) hold the Spray Arm Locking Ring with a Channel Locks and then turn the Spray Arm
Clockwise (Fig. 4-2). The Locking Ring Assembly can also be removed by rotating it Counter-Clockwise; note the Tab and Slot
locking configuration (Fig. 4-3).
TECH NOTE: When Replacing the Spray Arm make sure that it is tightened completely onto the Locking Ring.
Fig. 4-3
Fig. 4-1
Fig. 4-2
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 4
5. OUTER DOOR PANEL
Fig. 5-2
Fig. 5-1
B
B B
A A
• The Outer Door is held in place using four (4) Phillips screws (Fig. 5-1). Screw “A” is a
single screw located on the bottom left and right corners of the Inner Door Panel. Screw
“B” is just below the Phillips screw that holds the Outer Door Skin (Fig. 5-2).
• With the four (4) screws removed raise the Door to an upright position and then slide
the Outer Door Panel down and out from the Alignment Channel (Fig. 5-3).
• When replacing the Outer Door insert the Alignment Pin into the Channel and then raise
the Door Panel up until it is even with the top of the Control Panel (Fig. 5-4).
TECH NOTE: To prevent damage to the Outer Door, Alignment Pins, or Channel, make
sure to support the weight of the Door as you remove or replace it.
Fig. 5-3
Fig. 5-4
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 5
6. CONTROL PANEL
Fig. 6-1
Fig. 6-2
Fig. 6-3
• To remove the Control Panel (Fig. 6-1), remove the six (6) Phillips Control Panel screws from the Inner Door Panel (Fig 6-2). With
the screws removed the Control Panel will lay forward and is now accessible for repair (Fig. 6-3).
TECH NOTE: The Outer Door must be removed first (see Section 5) before removing the Control Panel Screws.
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 6
7. OUTER DOOR SKIN
• To remove the Outer Door Skin, first remove the Outer Door Panel ( see Section 5). Now remove the four (4) remaining Phillips
screws. Two (2) screws “A” are located half way up the Inner Door Panel and screws “B” are located above the Outer Door Panel
screws (Fig. 7-1 & 7-2). With the Outer Door Skin removed you have access to the Soap Dispenser (Fig. 7-3) and Door Hinges.
Fig. 7-2
B
Fig. 7-1
B B
A A
Fig. 7-3
TECH NOTE: The Control Panel does not have to be
removed to remove the Outer Door Skin.
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 7
8. SOAP DISPENSER and WATER TEMPERATURE NTC
• To remove the Soap Dispenser (Fig. 8-1), first remove the Actuator Solenoid wiring and then the six (6) Phillips screws that mount
the Dispenser to the Inner Door. The Dispenser can then be removed and replaced as a complete assembly.
OPERATION: The Actuator Solenoid is energized twice during a complete cycle. The first actuation releases the Detergent and
also aligns the Dispenser Linkage for the second actuation which releases the Rinse Agent.
TECH NOTE: Located on the upper right corner of the Dispenser is the Water Temperature NTC. The NTC is hard wired to the
Main Control Board. If the NTC proves faulty the Main Control Board must be replaced. Also, Dishwasher Models
L63 / LL64 / LI 640 / LI 670 incorporate a Magnetic Reed Switch to activate the Rinse Aid LED. Models LL 65 &
LI 700 use a Turbidity Sensor, see Section 19 for details.
Fig. 8-1
9. DOOR SPRINGADJUSTMENT and DOOR LATCH
• To adjust the tension on the Outer Door turn the two (2) 5mm Allen Screws Clockwise for
more spring tension and Counter Clockwise for less spring tension (Fig. 9-1).
• The Door Latch can be adjusted using a 7mm Nut Driver (Fig. 9-2)
Fig. 9-2
Fig. 9-1
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 8
10. TOE KICK
• The Toe Kick is a tension fit and mounts into the Side Support Plates “A” located on the left and right lower corners of the
Dishwasher. The Toe Kick is held in place and adjusted using a dimple stamped into the Toe Kick (Fig. 10-1). Once the Toe Kick is
inserted into the Support Plate you can adjust the Toe Kick to the required height by simply sliding it up or down (Fig. 10-2).
To remove the Toe Kick firmly pull it toward you.
TECH NOTE: When installing the Toe Kick remember that it fits inside the left and right Side Support Plates (Fig. 10-2).
Fig. 10-1 Fig. 10-2
A A
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 9
11. DOOR EXTENSION
• The Door Extension (Fig. 11-1 & 11-2) is secured to the Dishwasher using two
(2) tension clips (Fig. 11-3 & 11-4) on both the left and right sides. The tension
clips insert into cut-outs on the left and right Side Support Plates (Fig. 11-5).
• To remove the Door Extension, first release the center clip (Fig. 11-2). Then
push out on the right side, this will disengage the locking clips.
TECH NOTE: Access to the Door Extension can be made easier if the
Dishwasher Door is opened slightly. Do not attempt to pull the
Door Extension forward to remove, this may damage the
locking clips.
• When re-installing the Door Extension make sure to align the lower corners
onto the small rail that is located on the bottom of the Side Support Plate
(Fig.11-6). Once in position on the rail, the Door Extension can be pivoted into
place and the tension clips locked it into position.
Fig. 11-1 Fig. 11-2
Fig. 11-3 Fig. 11-4 Fig. 11-5
Fig. 11-6
INSIDE LEFT CORNER
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 10
12. WATER VALVE
• To access the Water Valve, first remove the Toe Kick (see Section 10) and the Door Extension (see Section 11) (Fig. 12-1). The
Water Valve is held in place with two (2) Phillips screws (Fig. 12-2), remove the two screws and the Valve can be easily accessed.
TECH NOTE: A new Valve Hose Clamp (Fig. 12-3) is included with the replacement Water Valve, but the old Clamp can be
reused if carefully removed.
Fig. 12-2
Fig. 12-1
Fig. 12-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 11
13. FLOAT SWITCH and PRESSURE SWITCH
• To access the Float Switch or Pressure Switch, first remove the Toe Kick (see Section 10) and the Door Extension (see Section
11) then remove the four (4) Phillips screws that hold the Lower Access Panel to the Dishwasher (Fig. 13-1). With the screws
removed the Lower Access Panel can be moved down and out allowing access to the two components (Fig. 13-2).
Float Switch: (Fig. 13-3) Can be checked for continuity or for water in the Base Pan.
Pressure Switch: (Fig.13-4) Can be checked for continuity.
Fig. 13-1
Fig. 13-2
Fig. 13-3 Fig. 13-4
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 12
14. LOWER COMPONENT ACCESS - BASE PAN REMOVAL
• TO ACCESS THE LOWER
C O M P O N E N T S T H E
DISHWASHER MUST BE
REMOVED FROM THE
CABINET.
• With the Dishwasher removed
from the cabinet, remove the
Base Pan Screws, there are
three (3) Phillips screws on the
lower front of the unit (Fig. 14-1)
and three (3) Phillips screws on
the rear (Fig. 14-2).
• Carefully place the Dishwasher
on its back and remove the
Base Pan (Fig. 14-3). The
Lower Components are now
accessible.
Fig. 14-1
Fig. 14-2
Fig. 14-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
FrontAdjustable Rear Legs (7mm)
Rear View

REPAIR MANUAL
Page: 13
15. LOWER COMPONENTS
Fig. 15-1
• With the Bottom Pan removed you have access to the following components:
A: Water Softener.
B: Main Motor and Pump.
C: Heater.
D: Drain Motor.
E: Turbo Dry Fan Motor (only on the LL 65 / LI 700 Models).
A
B
D
C
E
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 14
16. DRAIN MOTOR
Fig. 16-1
• To remove the Drain Motor (Fig. 16-1), first loosen the Drain Hose Clamp and Drain Hose, then remove the single Phillips
mounting screw. (Fig. 16-2). The Drain Motor is secured to the Sump using a tab and slot twist lock mount. With the Drain Hose
and mounting screw removed twist the Drain Motor Clockwise to remove (Fig.16-3).
TECH NOTE: For a better seal lubricate the new Drain Motor Gasket beforeinstalling, and make sure all three (3) Tabs are
secured into the corresponding slots, then twist the motor into position.
Fig. 16-2 Fig. 16-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700

REPAIR MANUAL
Page: 15
17. MAIN MOTOR and PUMP
• To remove the Main Motor and Pump Assembly (Fig. 17-1), first remove the Vibration Damper from the rear of theMotor by prying
it away from the Motor with a screwdriver (Fig. 17-2). Next remove the Motor and Pump Assembly from the three (3) hose
connections (Fig. 17-3) See TECH NOTE below.
TECH NOTE: The Motor Assembly can be removed from the three (3) hoses without undoing the Hose Clamps. Easily work the
Pump out and off the Hoses, the Clamps can now be reused if necessary.
Fig. 17-1
Fig. 17-2 Fig. 17-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
