Ariston EUROPRISMA EP 10 OR User manual

Supplied By www.heating spares.co Tel. [phone]
WATER HEATERS
5 TO 30 LITRES
EFFICIENT AND VERSA TILE
ELECTRIC W ATER HEATERS

Supplied By www.heating spares.co Tel. [phone]
Mains Cold Feed
C
H
C
H
Mains Cold Feed
C
H
C
H
C
H
Mains Cold Feed
C
H
OPEN OUTLET INSTALLATION
UNVENTED SINGLE INSTALLATION
UNVENTED MULTIPLE INSTALLATION MERLONI TERMOSANITARI GROUP
THE SMART CHOICE
The Merloni T ermoSanitari Gr oup, owner of the Ariston
brand name, is the leading world manufactur er of
unvented water heating and storage pr oducts with
more than 50 years experience. The pr oduction of
water heaters is distributed between five pr oduction
plants in Eur ope. Continuous r esearch into new
technology and design ensur es that Ariston’s quality
and reliability r emain at the high standar d its
customers have come to expect. Ever y detail of water
heater production is contr olled by qualified personnel,
using the latest technology , quality materials, and
continuous testing thr oughout the pr oduction cycle. By
applying such stringent conditions, the MTS Gr oup has
attained ISO Corporate Cer tification, “joining a few
elite companies within the EU to achieve this A ward”.
5 - 30 LITRE WATER HEATERS
There are many installations wher e hot water is r equired
but where it is not convenient to enlar ge the existing
central hot water system or wher e there is no central
system at all.
This br ochure introduces a range of Ariston water
heaters, fr om 5 litr es to 30 litr es capacity , designed to
deliver hot water for localised use such as in small
industrial units, war ehouses, dentists’ and doctors’
surgeries, cafés, and cer tain residential situations, e.g.
additional bathr ooms, loft conversions, etc.
Ariston’s Eur eka and Piccolo water heaters ar e suitable
for vented or gravity cold feed. The Ariston Eur oprisma is
designed for installation with an unvented cold feed. The
specifier and installer should note the dif ferent
regulations and r equirements for the two categories of
unvented systems:
- over 15 litr es, and
- 15 litr es and under .
These ar e detailed in ‘a guide to Unvented Cylinder and
Water Heater Systems’, available FREE fr om Ariston,
tel [phone].
A sister br ochure, Unvented Cylinders, intr oduces Ariston
products fr om 50 litr es to 500 litr es designed for dir ect
or indirect heating applications.
Further technical advice is available fr om the technical
advice line, tel [phone] . Training courses ar e
available at various centr es nationwide which can qualify
the installer as a “competent person” to install unvented
systems with a capacity over 15 litr es.

Supplied By www.heating spares.co Tel. [phone]
THE SMART CHOICE
5 - 30 LITRE WATER HEATERS
INSTALLATION FLEXIBILITY
Thanks to their compact sizes, the range of Ariston electric
water heaters can be installed vir tually anywher e. Ther e
are under-sink and over-sink models to suit demands fr om
low-usage single basin installations, to heavy-usage 2-3
basin installations. Installations of unvented water heaters
of 15 litr es or less ar e treated dif ferently by r egulations
and guidelines fr om those of mor e than 15 litr es.
Guidance is of fered in a fr ee leaflet fr om Ariston, tel:
01494 755600, e-mail: [email protected] oup.com
ANTI-CORROSION
SYSTEMS
Ariston Eur oprisma water heaters ar e
vitreous enamel coated, high-str ength steel
for per formance and durability . All ar e
factor y fitted with an active magnesium
anode to give guaranteed long tank life. The
magnesium anode system is a sacrificial
anode positioned inside the tank in such a
manner as to ensur e easy inspection and
replacement
when necessar y.
RELIEF VALVES
All Ariston Eur oprisma unvented water heaters ar e supplied
with either a factor y fitted temperatur e and pr essure relief
(T&P) valve (model EP30 R only), or a separate pr essur e
relief (PR) valve. The T&P valve pr events the stor ed water
from exceeding 100°C in the event of the failur e of the
other safety devices. The PR valve is supplied as standar d
with Europrisma 10 and 15 litr e models and pr otects fr om
over pressurising. See over for details of Eur oprisma
optional expansion vessel and check valve, or pr essur e
reducer, and
line strainer .
THERMOSTAT
All Ariston water heaters ar e equipped with quality
thermostats, which guarantee high per formance and safety .
THERMAL CUT-OUT
All Ariston Eur oprisma water heaters ar e also equipped with a
manual reset ther mal cut-out. This device over rides the main
thermostat in the case of failur e. (In the case of the Eur eka
and Piccolo a ther mal fuse is fitted).
TOP QUALITY HEA TING ELEMENTS
Built with first grade materials to guarantee a long life, the
elements incorporated in most Ariston water heaters ar e all
produced “in-house” at one of the MTS gr oup’s ISO 9001
certified factories.
EFFICIENT INSULA TION,
LOW POWER CONSUMPTION
A high density , thick polyur ethane foam layer guarantees all
Ariston Eur oprisma water heaters excellent insulation, whilst at
the same time drastically cutting power consumption.

Supplied By www.heating spares.co Tel. [phone]
62
203
a
100
100
b
d
c20
62
203
ab
d
c20
1/2" BSP
150
b
d
c20
1/2" BSP
1/2" BSP
62
203
a
100
*Typical application
•A: Low usage 1/2 basins/1 sink;
(small kitchens, en suite bathrooms,
loft conversions and cloakrooms
•B: Low usage 2/3 basins/1 sink;
(kitchens, garages, factories and WCs)
•C:Low usage 4/5 basins/2 sinks;
(WC blocks)
•D: Medium usage 2/3 1/2 basins/1 sink
•
E: Medium usage 2/3 basins/2 sinks
• F: Medium usage 4/5 basins/2 sinks
• G: Heavy usage 1/2 basins/1 sink
• H: Heavy usage 2/3 basins/1 sink
• Unvented cold water feed : see
A Guide to Unvented Cylinders
and Water Heater Systems,
available free from Ariston
• Extra thick steel-plated tank,
pressure tested and double
coated vitreous enamelled
• Large magnesium anode
• CFC free polyurethane
thermal insulation
• Regulation thermostat equipped
with safety thermostat
• External temperature control
• Heating indicator light
• Front access for ease of
maintenance
• Simple installation
• 3 year tank guarantee (1 year
guarantee on electrical
components)
OVER-SINK AND UNDER-SINK
WATER HEATERS
EUROPRISMA
3 YEAR GUARANTEE
Steel
tank High quality
enamel coating Magnesium
anode Polyurethane
insulation
10,15 & 30 litres
Capacity litres 10 10 10 15 15 15 30
Power kW 3 3 2 3 3 2 3
Voltage V 240 240 240 240 240 240 240
Reheat time (∆T = 50°C) minutes 12 12 17 18 18 26 58
Maximum temperature °C 80 80 80 80 80 80 75
Heat loss (kWh in 24 h) 60°C 0.50 0.67 0.67 0.70 0.87 0.87 0.90
Typical application* D D A C/E/G C/E/G B F/H
EUROPRISMA
EP 10 O R EUROPRISMA
EP 10 U R EUROPRISMA EP 10 U R/2kW EUROPRISMA EP 15 O R EUROPRISMA EP 15 U R EUROPRISMA EP 15 U R/2kW EUROPRISMA EP 30 R
TECHNICAL INFORMATION
DIMENSIONS
EUROPRISMA OVER-SINK
EUROPRISMA UNDER-SINK
EUROPRISMA OVER-SINK 30 litre
0063
EUROPRISMA
EP 10 O R EUROPRISMA
EP 10 U R
EUROPRISMA
EP 10 U R/2kW
EUROPRISMA
EP 15 O R
EUROPRISMA
EP 15 U R
EUROPRISMA
EP 15 U R/2kW
EUROPRISMA
EP 30 R
a mm 350 350 350 350 350 350 440
b mm 255 255 255 300 300 300 365
c mm 350 350 350 350 350 350 440
d mm 90 90 90 80 80 80 110
EP30 R only
Temperature
regulation
EP30 R only

Supplied By www.heating spares.co Tel. [phone]
10,15 & 30 litres
EUROPRISMA
15 LITRE
15mm pipe 2.8m 4.2m
22mm pipe 1.5m 2.2m
OPTIONAL KIT A: EXPANSION VESSEL
AND CHECK VALVE OPTIONAL KIT B: PRESSURE REDUCER WITH INTEGRAL LINE-STRAINER OPTIONAL KIT C: TUNDISH FOR 10 AND 15 LITRE UNITS
EUROPRISMA
3 YEAR GUARANTEE
0063
USING FEED PIPE TO ACCOMMODATE EXPANSION
DIELECTRIC
JUNCTIONS
HOT COLD
PRESSURE RELIEF VALVE
(6 bar)
DISCHARGE
NEAREST COLD WATER
DRAW-OFF PRESSURE REDUCING VALVE
(SET AT 3.5 bar) ISOLATING VALVE
(FIXED JUMPER OR
1/4 TURN BALL TYPE)
COLD
WATER
MAINS
EXPANSION VESSEL
(CHARGE SET AT 3.5 bar)
NON-RETURN
VALVE
SUPPLY TO OTHER PARTS
OF PLUMBING SYSTEM
DIELECTRIC
JUNCTIONS
HOT COLD
PRESSURE RELIEF VALVE
(6 bar)
DISCHARGE
NEAREST COLD WATER
DRAW-OFF PRESSURE REDUCING VALVE
(SET AT 3.5 bar)
(IF MAINS 6 BAR) ISOLATING VALVE
(FIXED JUMPER OR
1/4 TURN BALL TYPE)
COLD
WATER
MAINS
SUPPLY TO OTHER PARTS
OF PLUMBING SYSTEM
2.8 m (10l) OR 4.2m (15l) OF 15 mm PIPE
IS REQUIRED FOR EXPANSION
USING AN EXPANSION KIT
The Europrisma 10 and 15 litr e capacity units can be installed in one of
two ways. The following guidelines ar e designed to help select the
correct items prior to installation.
Current Water Regulations and
Byelaws per mit unvented water
heaters with capacity of 15 litr es or
less to accommodate the expansion
of water that occurs during the
heating cycle in the system pipe
work. To achieve this the pipe work
between the last cold water draw of f
and the water heater must be of
suf ficient volume to accommodate
the expansion.
If it is not possible to accommodate
the expansion in the system pipe
work, it is then necessar y to use an
expansion vessel and non-r eturn
valve (Kit A). If the mains water
pressur e may exceed 3.5 bar a
pressur e reducing valve (Kit B)
should also be installed. The
dischar ge from relief valves must be
made in a safe and conspicuous
manner; ther efore a tundish (Kit C) is
available for 10 and 15 litr e units
if required.
The Europrisma EP 30 R is cover ed by the Building Regulations and it is not possible to accommodate the expansion
water within the system pipework. Expansion contr ols must be installed. The EP 30 R is supplied with a tundish as
standard.
LENGTH OF PIPE EUROPRISMA
10 LITRE

Supplied By www.heating spares.co Tel. [phone]
OPEN OUTLET ELECTRIC STORAGE
WATER HEATER
• Open outlet - suitable for mains
or gravity feed
• Manufactured from a corrosion
proof plastic material
• Completely recyclable and
completely ecologically sound
• External temperature control
• Heating indicator light
• Equipped with directional spout
• Illuminated on/off switch
• Ceramic disc mixing valve
• 10 year tank guarantee (1 year
guarantee on electrical
components)
EUREKA
10 YEAR GUARANTEE
Capacity litres 13
Power kW 2
Voltage V 240
Reheat time (∆T= 50°C) minutes 30
Maximum temperature °C 75
Heat loss (kWh in 24 h) 60°C -
TECHNICAL INFORMATION - DIMENSIONS
a mm 320
b mm 490
c mm 230
d mm 130
Typical application
Low usage 1/2 basins/1 sink; (small kitchens,
ensuite bathrooms, loft conversions + cloakrooms)
0063
EUREKA
EUREKA
ac
d
b
1/2"BSP 3/8" BSP
EUREKA

Supplied By www.heating spares.co Tel. [phone]
• Open outlet - suitable for mains
or gravity feed
• Manufactured from a corrosion
proof plastic material
• Completely recyclable and
completely ecologically sound
• External temperature control
• Heating indicator light
• Equipped with directional spout
• Illuminated on/off switch
• Certified to IP25D (splash proof)
and impact resistant
• Vacuum safety
• 10 year tank guarantee (1 year
guarantee on electrical
components)
OPEN OUTLET ELECTRIC STORAGE
WATER HEATER
PICCOLO
10 YEAR GUARANTEE
EXPRESSO
G 1/2"
30
54.5
9.5
100
d
d
b
c
62
a
PICCOLO
ARKS 5 0
a mm 251
b mm 385
c mm 174
d mm 270
Capacity litres 5
Power kW 2
Voltage V 240
Reheat time (∆T= 50°C) minutes 9
Maximum temperature °C 85
Heat loss (kWh in 24 h) 60°C 0.25
PICCOLO
ARKS 5 O
TECHNICAL INFORMATION - DIMENSIONS
Typical application
Low usage 1/2 basins/1 sink; (small kitchens,
ensuite bathrooms, loft conversions +
cloakrooms)

Supplied By www.heating spares.co Tel. [phone]
0063
ARISTON
QUALITY PRODUCTS
EXCEPTIONAL SER VICE
REGIONAL
TRAINING
CENTRES
• Plymouth
• High Wycombe
• Gt. Manchester
COMPREHENSIVE
TRAINING
Programmes acr oss the entir e
Ariston pr oduct range covering all
theoretical and practical aspects.
Designed for commer cial heating
installers, mer chants and
independent gas-heating ser vice
organisations: courses ar e of fered
at 3 fully equipped training centr es
in the UK. In addition per manent
training facilities ar e available at a
number of technical colleges
nationwide.
TECHNICAL HOT LINE
Immediate and ef fective
technical assistance is only
a phone call away .
Assistance is also available
for any infor mation or advice
on the pr oduct most suitable
for your needs and the
requirements of your system
installation.
PROFESSIONAL
SERVICE
Ariston ser vice technicians ar e
swift and pr epared for any
eventuality. They of fer you and
your customers a high level of
assistance, comprising the
best technical, logistic and
human resour ces available.
Ariston invests a gr eat deal in
this field to guarantee a
decisive advantage that
others cannot of fer.
MTS (GB) Limited
MTS Building
Hughenden Avenue
High W ycombe
Bucks, HP13 5FT
Tel: [phone]
Fax: [phone]
Technical Advice 0870 241 8180
Customer Ser vice 0870 600 9888
Technical Advice & Customer Ser vice Fax [phone]
E-mail: [email protected]
www.ariston.co.uk
E-mail: [email protected] oup.com
In the inter ests of our customers, MTS (GB) Limited is continually developing these pr oducts to impr ove both
performance and design. W e therefore reser ve the right to change specification without prior notice. This br ochure is accurate at the date of printing. Consumer statutor y rights ar e not af fected. Month & Year Printed by V ario Press
