Arkiplot DCP-100B User manual

Digital Cap Heat Press Manual
Arkipress DCap
Prensa manual para gorras
Model No.: DCP-100B
CONTENTS
I. Assembly Drawing -----------------------------------------------------------------------------------2
II. Technical Parameters ------------------------------------------------------------------------------2
III. Operation Process -------------------------------------------------------------------------------3-4
IV. Maintenance ------------------------------------------------------------------------------------------4
V. Trouble Shooting For Transfer Print Quality------------------------------------------------5
VI. Circuit Diagram --------------------------------------------------------------------------------------6
VII. Explosion View -----------------------------------------------------------------------------------7-8

Digital Cap Heat Press Manual
- 2 -
I. Assembly Drawing
II. Technical Parameters
1. Model No.: DCP-100B
2. Machine Dimension: 525*540*225mm
3. Cap Heater Size: for normal caps
4. Printable Articles Max Size: 80*130*10mm
5. Voltage: 220V/1Phase; 110V/1Phase
6. Power: 0.5KW
7. Recommend Setting: 30~280s; 180~200°C
Time Range: 0~999s
Maximum Temp: 225 C°
8. Packing Size: 70*66*33cm
9. Gross Weight: 18.3kg
○
1Power Switch
○
2Power Socket
○
3Cap Heater
○
4Cap Under Plate
○
5Handle Bar Grip
○
6Handle Frame
○
7Digital Controller
○
8Rubber Foot
○
9Support Plate
○
10 Hat Rack
