Armada Technologies
Pro700 Wire and Valve Locator
Operating instructions
WARNING –Read and understand the instructions before
operating this unit. Failure to do so could lead to injury or
death.
English –Page 2
Español –Página 8

2
Description
The Armada Technologies Pro700 wire and valve locator is
designed to find lost valves and broken or severely damaged
wires, and trace their paths. The complete Pro700 kit consists of;
(1) Pro700R Receiving Wand
(1) Pro700T Transmitter and Carrying Case
(1) ProH3 Stereo Headset
(1) Pro-GS1 Ground Stake
(1) Set of Black/Red Connecting Leads
(1) Operating Manual
Please be sure that all items are included before operating the
Pro700.
Theory of Locating
Cable Locators consist of a transmitter and a receiver or wand.
In operation, a transmitter places a specific frequency signal onto
the metallic conductor you are trying to trace. This placing of an
AC signal onto a cable produces an electrical current and an
electromagnetic field around that cable. If the wand is close
enough, this signal is received and amplified by the wand.
It is very important to understand that the circuit you are creating
follows the laws of physics and electricity. A cable locator
transmitter creates an electrical current (AC) that travels down the
cable, through grounding to the earth, and then back to the
transmitter through the ground stake. The tracing signal will
always travel on the path of least resistance. If there is too much
resistance or no circuit path, no current will flow and no locate will
be possible. So keep in mind that when a signal is heard, it is
because the signal has a complete path that is creating an
electrically friendly way for the signal to travel back to the
transmitter. The signal doesn't just randomly wander through the
dirt. It follows a path provided for it, whether it is a pipe, wire, and
reinforcing bar. Etc.
It is also important to note that in the tracing circuits, a return path
needs to be present. Basically, the return path completes the
circuit. In most cases, this will be the earth ground as the signal
transmits down the cable and returns to the ground stake.
However, any return is possible, so a common wire could work.

3
Or if you have a looped wire, like a dog fence, the loop itself
returns to the start and therefore provides a 'ground' instead of the
ground stake. You don't have to use a ground stake but you do
have to give the signal a way to return to the transmitter.
Battery Installation
The Pro700 transmitter requires 8 “D” cell batteries. The Pro700
receiver requires one 9v battery. To install the batteries in the
Pro700 transmitter, open the case and remove the 2 holding
screws on the battery compartment located on the right side of the
unit. Place the batteries in the holder, orienting them in
accordance with positive and negative poles. Turn on the Pro700T
and push the red battery test button. A good reading of 8 or higher
on the analog meter while depressing the battery test button
indicates a successful battery install. If no response is seen, try
adjusting the batteries to insure good connection. If still no
response, be sure the batteries are good and fresh.
The Pro700 receiver battery compartment is located on the
underside of the Pro700R unit. Remove the 2 screws and the
battery compartment cover. Install the 9 volt battery and replace
the cover and screws. Turn the unit on and depress the battery
test button located on the backside or the Pro700R receiver. The
analog needle should peg to the right. If not, try a new battery.
WARNING –Do not touch the red and black clips that connect
the transmitter to the cable when the power is on. There is
danger of injury or death should this occur.
Operation
Disconnect the wire you wish to trace and the common wire from
the clock. With the transmitter off, connect the red alligator lead to
the wire you want to trace (common or station) and the black
alligator lead to the included ground stake. Insert the ground stake
into the soil or earth ground perpendicular to the path of the wire
and as far from the transmitter as possible. Do not connect to the
clock as signal may cause damage if the clock is not voltage
protected. Do not use common grounds such as pipes or electrical
grounds unless you have no choice. An independent ground stake
usually works better than a common ground.

4
Turn the Pro700 transmitter on. Adjust the power output knob and
increase the power until a reading between 4 and 8 is achieved. If
you cannot achieve a reading of 4, turn the unit off and retry
your grounding operation above. A good ground is crucial for
optimum operation. Soil conditions can also affect this and you
may wish to moisten the grounding area. Also, re-check batteries
for proper connection and operation.
Do not overpower the unit by turning it up past 10 on the meter.
You won't hurt the unit but you will waste battery power for no
additional performance.
Tracing Wire
After the Pro700 transmitter has been properly connected and
verified to have a good ground and power, turn on the Pro700
receiver by turning the volume knob on the front of the receiver.
Place the receiver near the operating Pro700 transmitter. A
beeping sound should be heard indicating that the receiver is
working properly. A high pitched tone could indicate that you are
too close to the receiver or your batteries are low. A fading signal
indicates low battery.
The volume control on the front of the receiver regulates the
loudness of the receiver, both headphones and external speaker.
Additionally, the analog meter on the front of the receiver will
indicate the reception power level visually. After connecting and
turning on the transmitter and turning on the receiver, point the
receiver toward the ground and listen for the beeping signal. The
closer you are to the cable, the louder the signal should be except
for directly over the cable. Directly over the cable, the Pro700
works on the NULL principle. This means that the signal nulls or
stops when the receiver is directly over the cable. If you are a little
to the left or right, the signal will be loud but directly pointing the
receiver at the cable produces virtually no signal. In this way, the
user will know the exact location of the wire or cable being traced.
Finding Faults
Breaks or severe wire damage can be found with the Pro700. The
setup of the unit is the same as when tracing wire. The difference
comes in the reception. Whereas the traced wire continues to emit
a signal along the path of the cable, a break will cause the signal
to stop at the point of break. A nick or damage will cause the

5
signal drop to a lower level but not necessarily end. Either the
speaker or the analog meter on the receiver will indicate this drop.
The faulted area will also produce a “hot spot” of signal right at the
cut as the signal is lost to ground.
Be sure the cable or wire you are tracking is grounded. The signal
needs a path to return to the ground stake and without it, you will
not get a good locate. A bad ground is indicated on the transmitter
analog meter when the needle cannot achieve a 4 or better even
at full power. In many cases, a direct buried cable fault will provide
this grounding and allow for a locate.
Do not let the receiver level go above 10. You are looking for a
drop in signal and you may not see it if the analog meter is
pegged to the right.
The greater the damage, the greater the drop off in signal.
Conversely, minimal damage or weak grounding will show little
change and are sometimes so small as to be un-locatable with the
Pro700. Practice and experience will help immensely in this task.
Finding Solenoids and Valves
Finding solenoids and the attached valves is easy to do. If you
want to find a particular valve, connect the red lead of the
transmitter to the station wire leading to that valve and the black to
ground as described above. Connect the Pro700 as above and
begin your locate. When you reach the point where a
valve/solenoid is located, the signal will expand into a large
(approx 2-4ft) diameter area of signal. This is your indication that
you are over a valve or solenoid. Additionally, the signal should
not continue past this point.
There may be more than one valve on the cable being traced.
You may wish to continue past the first valve located to determine
if other valves are also located on this wire.

6
Helpful Hints
Increases in signal strength and/or the size of the area it is
occurring from usually indicates some type of anomaly in the
cabling. Things that could cause this are valves (as described
above), nicks, cuts, bad splices, or cut wires. Good condition
cable does not normally change the tone or strength, other than a
very gradual loss of reception over distance, but it is possible.
Slack loops of extra wire left in the ground at installation are an
example of a condition that would cause an increase of signal and
yet have no problem.
Also, ground condition makes a huge difference in the
performance of cable locators. Basically a path is being created
from the transmitter, through the cable, out through the ground
and back to the ground stake. Any mistake in any of these links
will cause the locator to not work properly. Be sure your ground
stake is secure and in the dirt and that the transmitter is
connected to the cable you want to track.
In addition, the more conductive the soil, the better. As moisture is
a good conductor, the wetter the better. Dry sandy desert soil is
not a good transmitter of signal and you will experience better
results in moist soil. If you are in the desert, a little water at the
ground stake may help.
The best way to really learn the Pro700 is to use it. Set up a test
site at your home or office and get used to how it works. There is
no substitute for experience in the art of locating. Good luck!
For more information on how to set up and operate the Pro700,
either click the YouTube link or scan our QR code below. For
more Armada troubleshooting videos, visit our YouTube channel:
ArmadaTech (one word).
https://www.youtube.com/watch?v=CS2VJQG2c-I

7
Warranty –Armada Technologies warranties all products for
12 months from manufacturing defects from the date of retail
purchase. Armada Technologies will repair or replace any
component that is returned to Armada Technologies within 12
months of purchase and does not exhibit signs of abuse or
misuse. It is Armada Technologies sole discretion to
determine this condition. Armada Technologies also reserves
the right to require a proof of purchase in order to determine
date and validity of purchase.
Armada Technologies Equipment Inc.
3596 76th St. SE
Caledonia, MI 49316 USA
+1 616-803-1080
www.armadatech.com
REV 02/18

8
Armada Technologies
Pro700 Localizador de Cables y
Válvulas
Manual de Instrucciones
ADVERTENCIA -- Lea y entienda las instrucciones antes de
operar esta herramienta. Utilizarla sin comprender cómo
manejarla podría ocasionar un accidente o la muerte.

9
Descripción
El Localizador de Cables y Válvulas Pro700 de Armada
Technologies está diseñado para encontrar válvulas perdidas y
cables rotos o severamente dañados, y localizar su trayectoria. El
equipo Pro900 completo consiste en:
(1) Varilla Receptora Pro700R
(1) Transmisor y Estuche Portátil Pro700T
(1) Audífonos ProH1
(1) Punta de Tierra ProGS
(1) Unidad de Conductores Rojo/Negro
(1) Manual de Instrucciones
Por favor, asegúrese que todos los equipos están incluidos antes
de operar.
Teoría de la Localización - El localizador de cables consisten en
un transmisor y un receptor. Al operar, un transmisor emite una
señal de localización específica al conductor metálica que quiere
localizar. Al colocar la señal de “AC” al cable produce un corriente
eléctrico y un campo electromagnético alrededor de dicho cable.
Si la varilla está suficientemente cerca, esta señal será recibida y
amplificada por la varilla receptora.
Es muy importante entender que el circuito que se está creando
sigue las leyes de la física y la electricidad. El transmisor de cable
emite una corriente eléctrica (AC) que va por el cable que
buscamos, por la tierra, y después vuelve al transmisor por la
punta de tierra. La señal de localización siempre seguirá el
camino de menor resistencia. Si hay mucha resistencia o no
hubiera trayectoria del circuito, la corriente no fluirá y la
colocación no será posible. Recuerde que cuando una señal se
recibe, es porque la señal tiene una trayectoria completa que está
proveyendo una manera cómoda electrónicamente para que la
señal vuelva al transmisor. La señal no vaga sin rumbo en la
tierra. Sigue una ruta proveída, no importa que sea un tubo o
caño, un alambre, una barra de refuerzo, etc.
Es importante también notar que en los circuitos de localización,
es necesaria una ruta de retorno. Básicamente, la ruta de retorno
completa el circuito. En la mayoría de casos, ésta será la tierra,
por lo tanto la señal va por el cable y vuelva a la punta de tierra.

10
No obstante, cualquier retorno es posible por lo que un cable
común podría funcionar. Si tiene un cable lazado o trenzado, por
ejemplo una valla para sujetar el correa de un perro, el circuito se
completa en sí y vuelve al principio y por tanto provee un medio
en lugar de la punta de tierra. No tiene que ocupar una punta de
tierra pero sí tiene que dar a la señal una trayectoria para volver
al transmisor.
Instalación de las Baterías
El transmisor Pro700 requiere 8 baterías D. El receptor Pro700
requiere 1 batería de 9 volts. Para instalar las baterías al
transmisor Pro700, abra el estuche y quite los 2 tornillos de
sujeción en el compartimiento de las baterías que está por el lado
derecho del equipo. Ponga las baterías en el compartimiento,
orientándolas de acuerdo con los polos positivos y negativos.
Encienda el transmisor y presione el botón rojo de prueba. Una
buena lectura de 8 o más que se da el medidor analógico al
presionar el botón de prueba de las baterías indica una
instalación exitosa de las baterías. Si no responde, intente ajustar
las baterías para asegurar una buena conexión. Si todavía no
responda, asegúrese que las baterías son buenas y nuevas.
El compartimiento de las baterías para el receptor Pro700 está en
la parte inferior del equipo Pro700R. Quite los dos tornillos y la
tapa del compartimiento de las baterías. Instale la batería de 9
volts y vuelve a poner la tapa y los tornillos. Encienda la unidad y
presione el botón de prueba de las baterías en el lado inferior del
receptor Pro700R. La aguja anológica debe fijar al lado derecho.
Si esto no pasa, intente con otra batería.
ADVERTENCIA - No toque los conductores rojos y negros de
los cables del transmisor cuando el equipo está encendido.
Si lo hace, hay peligro de una lesión o la muerte.
Operación
Desconecte el cable que quiere localizar y el cable común del
reloj. Con el transmisor apagado, conecte el conductor rojo al
cable que quiere localizar (común o estación) y el conductor
negro a la punta de tierra suministrada. Introduzca la punta en la
tierra perpendicularmente a la ruta del cable y lo más lejos del
transmisor que sea posible. No conecte al reloj porque la señal
podría causar daño si el reloj no está protegido contra el voltaje.

11
No use tierra tubos o neutros eléctricos a menos de que no tenga
otra opción. Una punta de tierra independiente en general
funciona mejor que una punta en un común eléctrico.
Encienda el transmisor Pro700. Ajuste la perilla de selección para
aumentar la salida hasta que el medidor indique entre 4 y 8. Si no
se puede lograr que el medidor indique 4, apague el equipo y
intente el proceso que está arriba de nuevo. Una buena tierra es
esencial para una operación óptima. Las condiciones de la tierra
pueden afectar esto y podría ser necesario humedecer la tierra.
También, revise de nuevo las baterías para la conexión y
operación sea correcta.
No sobrecargue el equipo y gire la perilla más que 10 en el
medidor. No dañará el equipo pero gastará las baterías sin un
beneficio adicional.
El Cable de Localización
Después de que el transmisor haya sido conectado correctamente
y esté verificado que hay buena tierra y energía, encienda el
receptor Pro700 al girar el control del volumen en el frente del
receptor. Ponga el receptor cerca del transmisor en operación. Un
sonido o pitido indica que el receptor está funcionando
correctamente. Un tono más alto podría indicar que está muy
cerca del receptor o que las baterías están con bajo nivel. Una
señal rascada o suave indica baterías de nivel bajo.
El control del volumen del receptor regula la fuerza del sonido del
receptor, en el audífonos y el altavoz externo. Adicionalmente, el
medidor analógico en el frente del receptor indicará el nivel de la
potencia de la señal visualmente. Después de conectar y
encender el transmisor y el receptor, señale el receptor hacia el
suelo en la dirección del cable y escuche el sonido. Mientras más
cerca del cable, más fuerte será el sonido con excepción de
cuando está directamente sobre el cable. Directamente encima
del cable, el Pro700 funciona en el principio de silencio. Esto
quiere decir que el sonido se para cuando el receptor está
directamente encima del cable. Si está un poquito al lado derecho
o izquierdo el sonido será fuerte, pero directamente señalando el
receptor al cable no produce ninguna señal o sonido. En esta
forma, el usuario sabrá exactamente dónde está el cable que
quiere localizar.

12
Localizando las Fallas
Mellas o daño del cable se pueden encontrar con el Pro700. La
forma de hacerlo es el mismo procedimiento que cuando está
localizando un cable. La diferencia es en la calidad de la señal. El
cable localizado sigue emitiendo una señal en la trayectoria del
cable pero una rotura o interrupción en el cable causará que la
señal se detenga. Una mella o daño causará que la señal se baje
pero no se detendrá por completo. Al perderse la señal en la
tierra, el área de la falla también producirá un foco de señal
exactamente donde está el corte.
Asegúrese que el cable que está localizando esté conectado a
tierra. La señal necesita una ruta trayectoria a la punta de tierra y
sin esta ruta, no se puede localizar bien. Conexión de tierra
inadequada estará indicada en el medidor anológico del
transmisor cuando no se puede lograr un 4, aún con la potencia
máxima. En muchos casos, una falla de un cable directo
aterrizado enterrado proveerá esta conexión y permitirá la
localización de un cable.
No permita que el nivel del receptor pase 10. Está buscando un
cambio en la intensidad de la señal y tal vez no lo vea o escuche
si el medidor anológico está totalmente del lado derecho.
Una regla en general es que cuando el cable está cortado o muy
dañado, la señal de silencio se anulara en la punta del daño e
iniciará el sonido en su lugar. En cambio, daño minimal o
conexión débil de tierra mostrará poco cambio en la señal y a
veces son tan pequeños los daños que el Pro700 no puede
detectarlos. La práctica y experiencia ayudarán mucho en este
trabajo.
Localizando Solenoides y Válvulas
Es fácil localizar los solenoides y las válvulas conectadas. Si
quiere encontrar una válvula en particular, conecte el conductor
rojo del transmisor al cable de estación que va a esta válvula y el
conductor negro a tierra como está explicado arriba. Conecte el
Pro700 como está explicado arriba y comience a localizar.
Cuando localice una válvula/solenoide, la señal expandirá a un
área más grande (aprox. 2-4 pies) de señal. Esto indica que ha
localizado una válvula o solenoide. Adicionalmente, la señal no
debe continuar después de esta punta.

13
Podría haber más que una válvula en el cable que está
localizando. Podría ser necesario pasar la primera válvula
localizada para determinar si hay otras válvulas también en este
cable.
Consejos Útiles
Los aumentos en la intensidad de la señal y/o el tamaño del área
que está ocurriendo indica alguno tipo de anomalía en los cables.
Cosas que podrían causar esto son válvulas (como explica
arriba), mellas, cortadas, o cables cortados. El cable en buena
condición normalmente no cambia el tono o la intensidad, aparte
de una pérdida de señal gradual con la distancia es posible.
Cables extras en el suelo son ejemplos de un factor que causaría
un aumenta de señal pero no tendría problema.
También, la condición de la tierra hace una gran diferencia en el
rendimiento del localizador de cables. Básicamente, un circuito
está siendo creado del transmisor, a través del cable, por la tierra
y de regreso por la punta de tierra. Cualquier discontinuidad entre
estas conexiones hará que el localizador no funcione. Asegúrese
que la punta de tierra está segura y en la tierra y que el
transmisor está conectado al cable que quiere localizar.
Adicionalmente, mientras más conductiva la tierra, más fácil será
la localización. Porque la humedad es muy conductiva, lo más
mojada que la tierra está de la mejor. La tierra seca o arenosa no
es un buen transmisor de señal y tendrá mejor resultados en
tierra húmeda. Si está en el desierto, un poco de agua donde está
la punta de tierra ayudará.
La mejor manera de aprender a usar el Pro700 es utilizarlo.
Prepárese un lugar de prueba en su casa o oficina y
acostúmbrese con cómo funciona. No hay substituto por
experiencia en el arte de la localización. ¡Buena suerte!

14
La Garantía - Armada Techologies tiene garantía para todos
sus productos contra defectos de fabricación por 12 meses
después de la compra minorista. Armada Technologies
reparará o reemplazerá cualquier componente retornado
dentro de los 12 meses siguientes a la compra siempre y
cuando no tenga evidencia de abuso o mal uso. Es el
discreción de Armada Technologies para determinar esta
condición. Armada Technologies también conserva el
derecho de requerir la prueba de compra para determinar la
fecha y la validez de la compra.
Armada Technologies Equipment Inc.
3596 76th St. SE
Caledonia, MI 49316 USA
+1 616-803-1080
www.armadatech.com
REV 02/18
Other manuals for Pro700
1
Table of contents
Languages:
