ARMATURA OmniAC30CAPQ User manual

OmniAC30CAPQ
Quick Start Guide
Version: 1.1

1
Overview
5-inch Touchscreen
Camera & Palm Collector
Flash
Speaker
Card Reading Area
Near-infrared Flash
Reset Button
Microphone
Terminal Block
AUX
GND
COM
NC
NO
SEN
BUT
AL-
AL+
GND
RS232-RXD
RS232-TXD
12V-OUT
GND
12V-OUT
GND
12V-OUT
WD0-OUT
WD1-OUT
IWD0
IWD1
GND
485B
485A

2
Installation Environment
Please refer to the following recommendations for installation.
AVOID DIRECT
SUNLIGHT
AND EXPOSURE
AVOID GLASS
REFRACTION
KEEP EFFECTIVE
DISTANCE
0.3-2.5m
KEEP DISTANCE
10ft
6.5ft
window
Recommended Palm Gestures
Note:
KEEP EFFECTIVE
DISTANCE OF
18 to 40 cm
DO NOT KEEP
YOUR FINGERS
CLOSE
KEEP SPACES
BETWEEN
YOUR FINGERS
DO NOT KEEP
PALM OUTSIDE
COLLECTION AREA
DO NOT KEEP
YOUR FINGERS
FOLD/CURLED
18 to 40cm
Make sure to keep space between your fingers.
Place your palm within 18 to 40 cm of the device.
Place your palm in the palm collection area, such that the palm is placed
parallel to the device.
1.
2.
3.

Device Installation
3
3
①
②
Fix the Backplate on the wall using wall mounting screws.
Attach the device to the Backplate.
Fasten the device to the Backplate with a security screw.
Attach the mounting template sticker to the wall, and drill holes according
to the mounting paper.
1.
2.
3.
4.
1 2
4
53.15" / 1.35m
With Backplate ★:
Note: Features and parameters with mark are not available in all devices. ★

1.
2.
3.
4.
Fix the Back Cover on the wall using wall mounting screws.
Attach the device to the Back Cover.
Fasten the device to the Back Cover with a security screw.
Attach the mounting template sticker to the wall, and drill holes according
to the mounting paper.
With Back Cover:
2
4
1
49.21" / 1.25m
3
①
②
4

12V
AC Adapter
DC12-3A
+12V
GND
5
Standalone Installation
Power Connection
TCP/IP
Alarm Smoke
Detector
Lock
Exit Button
Door Sensor
Reader
PC
12V ± 10%, at least 3000mA.
To share the power with other devices, use an AC Adapter with higher
current ratings.
1.
2.
Recommended AC Adapter

Ethernet Connection
Click on [COMM.] > [Ethernet] > [IP Address] , input the IP address and click on [OK].
IP address: 192.168.1.130
Subnet mask: 255.255.255.0
Default IP address: 192.168.1.201
Subnet mask: 255.255.255.0
Connect the device and computer software over an Ethernet cable. As shown in
the example below:
PC
Note: In LAN, the IP addresses of the server (PC) and the device must
be in the same network segment when connecting to the software.
6
Wiegand Reader and RS485 Connection
+12V
GND
485+
485-
12V-OUT
GND
12V-OUT
WD0-OUT
WD1-OUT
IWD0
IWD1
GND
485B
485A
+12V
GND
WD1
WD0
Wiegand
Reader
WD0
WD1
Access
Controller
485 Reader

7
Printer Connection
RS232-RXD
RS232-TXD
12V-OUT
GND
GND
RS232 Cable
Printer
Door Sensor, Exit Button, Auxiliary Connection
AUX
GND
COM
NC
NO
SEN
BUT
AL-
AL+
Smoke
Detector
NO
COM
Detector
Power
Door Sensor
ExitButton
Alarm
Alarm Power

Lock Relay Connection
The system supports Normally Opened Lock and Normally Closed Lock.
The NO LOCK (normally unlocked when power-on) is connected with 'NO'
and 'COM' terminals, and the NC LOCK (normally locked when power-on) is
connected with 'NC' and 'COM' terminals. Take NC Lock as an example
below:
1)Device not sharing power with the lock
AUX
GND
COM
NC
NO
SEN
BUT
AL-
AL+
Lock
FR107
12V
AC Adapter
DC12-3A
+12V
GND
2)Device sharing power with the lock
AUX
GND
COM
NC
NO
SEN
BUT
AL-
AL+
Lock
FR107
12V
AC Adapter
DC12-3A
+12V
GND
DC 12V
DC 12V
8

9
User Registration
When there is no super administrator set in the device, click on to enter the
menu. Add a new user and set User Role to Super Admin, then the system
requests for the administrator’s verification before entering the menu. It is
recommended to register a super administrator initially for security purposes.
Click on > [User Mgt.] > [New User] to register a new user. The options in-
clude entering the user ID and Name, setting User Role, registering a Palm,
Face, Card, Password and adding Profile Photo.
Main Menu
User Mgt. User Role COMM. System
Data Mgt.Personalize Attendance
Search
Autotest System Info
Access Control
L
Welcome
2021-04-27 12:00
2021-04-27
L
1
1
1
123456
*****
1
New User
User ID
Name
User Role
Palm
Face
Card
Password
PhotoProfile
Access Control Role
Normal User
Mike
Tuesday
Enrolled Successfully
Palm Registration

10
Ethernet and Cloud Server Settings
Click on > [COMM.] > [Ethernet] to set the network parameters. If the
TCP/IP communication of the device is successful, the icon will be
displayed in the upper right corner of the standby interface.
Click on > [COMM.] > [Cloud Server Setting] to set the server address
and server port, that is, the IP address and port number of the server after
the software is installed. If the device communicates with the server
successfully, the icon will be displayed in the upper right corner of the
standby interface.
Main Menu
User Mgt. User Role COMM. System
Data Mgt.Personalize Attendance
Search
Autotest System Info
Access Control
L
Server Mode
Enable Domain Name
Server Address
Server Port
Enable Proxy Server
HTTPS

Click on > [Access Control] to enter the access control management
interface and set relevant parameters of access control.
Access Control Settings
Main Menu
User Mgt. User Role COMM. System
Data Mgt.Personalize Attendance
Search
Autotest System Info
Access Control
L
Access Control Options
Time Rule Setting
Holidays
Combined Verification
Anti-passback Setup
Duress Options
Access Control
1
Password/Card/Face...
Gate Control Mode
Verification Mode
Door Available Time Period
Normal Open Time Period
Master Device
Slave Device
Auxiliary Input Configuration
Verify Mode by RS485
Speaker Alarm
Reset Access Setting
Access Control Options
None
In
Out
Card Only
Click on > [Attendance Search] > [Event Logs] to enter the records query
interface, input the user ID and select the time range, the corresponding
event logs will be displayed.
Records Query
L
Main Menu
User Mgt. User Role COMM. System
Data Mgt.Personalize Attendance
Search
Autotest System Info
Access Control L
Event Logs
Attendance Photo
Blocklist T&A Photo
Attendance Search
11

Health Protection
Click on > [System] > [Health Protection] to enable mask detection.
You can Enable Mask Detection function, and enable the Deny Access
Without Mask and the Trigger External Alarm, the device will send an alarm
prompt when the user doesn’t wear a mask, meanwhile the user will be for-
bidden to access, as shown in the following figure.
When the Allow Unregistered People to Access is enabled, you can also set
Enable Capture of Unregistered Person to save the user photo.
1
2
12:00
Successfully
verified
Name:Mike
User ID:2
Verify:Face
Mask Detected
11
12:00
Without mask
Failed to verify.
Verify:Face
Main Menu
User Mgt. User Role COMM. System
Data Mgt.Personalize Attendance
Search
Autotest System Info
Access Control
L
Enable Mask Detection
Deny Access Without Mask
Allow Unregistered People to Access
Enable Capture of Unregistered Person
Trigger External Alarm
Clear External Alarm
External Alarm Delay(s)
Health Protection
10
12
Palm Parameter
RFID Card Management
Access Logs Settings
Device Type Settings
