ARmedical CLASSIC AR-005 Guide

Technical data:
PARAMETER: AR-005 AR-006 AR-007 AR-020 AR-021 AR-022
Frame: steel aluminum aluminum steel aluminum and steel aluminum
burgundy, silver,
blue
Frame color: blue silver nickel blue graphite claret
Type/model: folding folding folding folding folding folding
Max. total width: 61 cm 59 cm 62 cm 49 cm 59 cm 60 cm
Seat height: 61 cm 52-60 cm 56 cm 52 cm 49 cm 54 cm USER MANUAL
WARRANTY CARD
Height adjustment
hands: 75-98 cm 94-101 cm 81-94 cm 75.5-92 cm 79-88 cm 79-91 cm
Product weight: 9.5kg 6kg 6.1kg 4.5kg 4.8 kg 8.2 kg
Maximum load: 136 kg 136 kg 136 kg 136 kg 136 kg 136 kg
Equipment: basket, tray mesh container bag - - basket REHABILITATION ROLLATORS
AR-005 Rehabilitation
rollator
4-wheel, steel,
CLASSIC
AR-006 Rehabilitation
rollator
4-wheel, aluminum,
PRESTIGE
AR-007 Rehabilitation
rollator
4-wheel, aluminum,
DYNAMIC
AR-022 Rehabilitation
rollator
4-wheel, aluminum,
COMFORT
WARRANTY CARD
The card must be accompanied by proof of purchase
Sale date Seller's stamp and signature
Purchase invoice number
LOT No
Guarantee period
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product name and catalog number
Is the product introduced into the
public reimbursement system?
* delete inappropriate
YES NO*
Order registration number
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. ARMEDICAL Sp. z o. o. 42-520 Dąbrowa Górnicza, al. Zwycięstwa 75 hereby grants a customary 12-month warranty for the products covered by this
document. If the product is introduced into the public refund system, the manufacturer provides a 30-month warranty period. The warranty period is
counted from the date of purchase of the product by the User. The warranty is valid only in the territory of the Republic of Poland.
2. During the warranty period, ARMEDICAL Sp. z o. o. undertakes to make the necessary repairs in order to restore the product to proper functioning within 14 days from
the date of receipt of the complained goods.
3. ARMEDICAL Sp. z o. o. reserves the right to replace the product with a defect-free one if it considers that the repair costs make it unprofitable.
4. If it is found that the product is not functioning properly, please immediately contact the point of purchase or send it to the manufacturer's
address. AR-021 Rehabilitation
rollator
two-wheeled,
DELUXE
AR-020 Rehabilitation
rollator
two-wheeled,
STANDARD
5. The warranty does not cover damage caused by mechanical factors. The warranty does not cover the subject of sale in terms of wear and tear
elements during normal use, plastic and rubber elements (i.e. abrasion of wheels, plastic/foam handles)
6. The warranty does not cover if the support is used contrary to its intended purpose or in accordance with the user manual, or if the user exceeds
the maximum permissible load specified by the manufacturer (applies to the structure of the support, trays and shopping bags).
7. The warranty does not cover defects resulting from unauthorized repairs, modifications or design changes to the product made by the User or other
unauthorized persons.
8. The warranty is valid only with the proof of purchase and this warranty card.
9. Complaints should be submitted only in the form of a written complaint protocol specifying the type of defects found and the circumstances in which the
defect was discovered. In case of failure to comply with the conditions for filing complaints specified in this manual, the guarantor's liability is excluded. The
advertised product must be in proper hygienic condition.
4Issue 5 of April 28, 2023.
Translated from Polish to English - www.onlinedoctranslator.com

USER MANUAL - REHABILITATION ROLLATORS COMPONENTS/UTILITY ELEMENTS
Ladies and Gentlemen,
Thank you for purchasing our product, we value the trust you have placed in us. We have made every effort to ensure that our equipment
meets your expectations, we hope that it will be a product that will make it much easier for you to move around at home as well as during
everyday walks. Before use, please read this user manual and strictly follow the safety regulations. Please keep this manual, which also
serves as a warranty card.
Intended use of the product:
The rehabilitation support is an auxiliary and rehabilitation equipment intended for disabled people with musculoskeletal disorders, problems with
standing or having problems maintaining balance while walking. It is also used to maintain balance while learning to walk after an illness or injury.
Contraindications:
Contraindications to vertical positioning, injuries and dysfunctions of the upper limbs that make it impossible to support oneself on a support,
impaired motor coordination, problems with the labyrinth, spinal instability.
Usage data:
Maximum patient weight ensuring safe use of the rollator –136 kg
Maximum permissible load of shopping containers (basket, bag) –5kg
Notes and warnings:
To avoid an accident, please:
1. Check whether all frame elements (7) are straight, not broken or damaged (e.g. during transport)
2. Check whether both handles/handles for pushing the support (1) are set at the same height
3. Check whether the handles/handles (1) of the supports are firmly "clamped" and screwed, making it impossible to remove them
4. Check whether the support has all four wheels (5) and (8) - AR-020 - 2 wheels.
5. Check whether the wheels (5) and (8) are securely fastened
6. Check whether all elements of the support frame are stably connected to each other (7)
7. Check whether the support is fully extended
8. Do not unfold the support in places where it may be slippery, e.g. spilled liquid or ice
9. Do not treat the support as a wheelchair - applies to the AR-022 model
ATTENTION!
NEVER STAND ON THE FOOTREST (9)
RISK OF ACCIDENT!
To avoid injuries:
1. The support must be fully unfolded (when properly unfolded, it must look exactly as in the photo)
2. It is necessary to check the stability of the support each time before use
3. The handles (push handles) (1) must be set at the same height
4. Use the support only on a flat, hard surface. Do not use on stairs!
5. Be especially careful on wet, slippery surfaces.
6. When moving, be especially careful about lying rugs, clothing items, toys, etc., as well as lying animals, uneven, cracked surfaces, uneven
sidewalks, curbs, etc.
7. The support must always be held with both hands! Hands hold the handles stably (1), you can quickly pull the brake handles (2). (does not apply to AR-020,
AR-021)
8. The support cannot be exposed to extreme weather conditions for a long time (e.g. very severe frost or direct sunlight).
9. Do not overload the support, exceed the maximum load allowed by the manufacturer.
10. Do not exceed the maximum permissible load of the basket/bag (3)
11. Consult your doctor before use.
12. Model AR-022 – NEVER STAND ON THE FOOTREST. RISK OF ACCIDENT!
1. Handles / Push handles
2. Brake handles with parking function
3. Basket/shopping bag
4. Seat
5. Wheels with brake
6. Clamps / Screws / Handle latches
7. Frame
8. Swivel wheels (fixed AR-020, AR-021)
9. Footstool
10. Backrest
11. Rubber feet
Preparation for use
1. Remove the support from the cardboard or foil packaging.
2. First, check the technical condition of the support in accordance with point Notes and warnings.
3. Insert the handles and push handles (1) into the holes in the frame (7). See the drawing above.
4. Clamp/screw the handles and push handles (1) to the frame (7) so that they cannot be removed
5. Adjust the height of the support and push handles (1) to the user's height. To do this, unscrew/remove the clamp (AR-005), the screw (AR-006,
AR-020, AR-021, AR-022), the latch ( (AR-007) (6) located in the frame (7). Set the required height by sliding or sliding. Re-insert the screw/latch into
the existing hole in the frame, tighten/clamp. Repeat the operation for both support handles. Push the handles ( 1) They must be at the same
height.
6. After disassembly, it is essential to check the correct operation of the brakes (does not apply to AR-020, AR-021). Place your hands on the handles (1), pull
the brake handles up (2) with your fingers and then check whether the clamps lock the wheels with brakes (5). Additionally, after the test, the brake handles
(2) should be pushed down as far as possible with your fingers until the latch "clicks". The brake should be in the parking position and then check
whether the wheels are locked by pushing the walker slightly forward.
7. Install the basket, tray (AR-005, AR-022), bag (AR-007) (3). See the drawing above.
Maintenance method:
The support should be cleaned regularly using only water and mild detergents. The support should be wiped/dried with a soft cloth. Do not use abrasive
products! Brake cables and elements (wheels, handles) are wearing parts and must be replaced with new ones if excessive wear is found. The above-mentioned
items are not subject to warranty. Any looseness in screw connections and brake adjustments are the responsibility of the user and do not constitute grounds
for complaint.
Maintenance schedule:
Every week Check brake for failure, check all wheels for loose bolts, nuts and axles
Periodically Check the grips for wear, check the frame bolts are tight, check the front and rear axle bolts are tight, check the "fatigue" components
for wear or cracks.
Troubleshooting:
If you encounter problems, please review this chapter. If this does not help, please contact the sales or service point. Repairing the support yourself
is FORBIDDEN!!! This may result in an accident.
I. The support is not stable.
a. Are both support handles (1) at the same height? If not, set them correctly.
b. Are the clamps/screws (6) firmly clamped/tightened? If not, tighten/tighten them.
c. Is the kickstand fully extended? If not, unfold it and check its stability.
d. Are all wheels (5) and (8) tightened securely? If not, tighten them securely.
e. Are all components of the support frame (7) securely connected to each other? If not, please contact your point of purchase. DO NOT USE A STAND!!!
Alternatively, please consult your doctor, rehabilitator or point of sale for detailed instructions on appropriate use.
End of use:
1. Fold the rollator by pushing the front wheels and rear wheels/legs together (AR-005, AR-006, AR-020, AR-021, AR-022).
2. In the AR-006, AR-020, AR-021, AR-022 models, the folding handle is located under the seat. Fold the support (AR-007) by pushing the right and left wheels together
by pulling the handle on the seat.
Incidents:
Everyoneserious an incident related to the device should be reported to the manufacturer, the Office for Registration of Medicinal Products, Medical Devices and Biocidal Products. Cleaning and storage:
1. Place the support in a place where it will not be exposed to mechanical damage.
2. In case of dirt, follow the "Maintenance method" section of this manual.
Utilization:
A product that is no longer suitable for further use should be disposed of in accordance with local environmental regulations regarding product disposal.
Cessation of use of the product:
In case of visible mechanical damage or material wear, stop using the product. THANK YOU FOR CHOOSING AND PURCHASING OUR PRODUCT
