Invacare Storm Series Instruction Manual

Yes, you can. ™
Formula™
Invisible Super Low™ Tilt
For
Storm Series® TDX®
Power Wheelchairs
Parts Catalog Issued: Apr 24, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 03-034. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
© 2012 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., the Blue Medallion Design, SureStep, Storm Series, TDX and Tarsys are registered
trademarks and Formula, Invisible Super Low, MKIV, MK5, GB, and TCD are trademarks of Invacare Corporation.
Otto Bock is a registered trademark of Otto Bock Orthopaedische Industrie GMBH & Co.. Tash is a registered trademark of Tash International Inc.. Therafin is
a registered trademark of
W/R/ Medical Electronics Co.. Bussman is a registered trademark of Cooper Industries. MIDI is a registered trademark of Littelfuse Inc.. Dynamic is a
registered trademark of Dynamic Controls Limited.
Parts Catalog Usage Guide
1
Form No. 03-034
To order call toll free 1-800-333-6900, or www.invacare.com

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!) ...................................................... 6
Accessories - Arm Pads - Otto Bock ........................................................................................ 182
Accessories - Headrest Support Assembly - ABS & Metal Curved Backs ............................... 184
Accessories - Headrest Support Assembly - Back Cane Only Option ..................................... 186
Accessories - Lateral Support Assembly .................................................................................. 188
Accessories - Power Wheelchair Tool Kit ................................................................................ 194
Accessories - Seat/Chest Positioning Straps ........................................................................... 191
Arms - Adjustable Height .......................................................................................................... 70
Arms - Fixed Height .................................................................................................................. 67
Arms - Mounting Front/Rear Arm Socket Asbly. & Hdwr. - For ADJASBA Seats (After 7/4/05) 74
Arms - Mounting Swingaway Hardware - For ASBA and ADJASBA Seats ............................. 72
Backs - ABS Curved Mounting Hardware ............................................................................... 48
Backs - ABS Curved Assembly ................................................................................................ 38
Backs - Contoura without Mounting Hardware - Before 5/15/09 .............................................. 51
Backs - Curve Contoura without Mounting Hardware - After 5/14/09 ...................................... 54
Backs - Metal Curved Assembly .............................................................................................. 43
Backs - Metal Curved Mounting Hardware ............................................................................... 50
Backs - Mounting Hardware - Curve Contoura - ADJASBA Only - After 5/14/09 ..................... 60
Backs - Mounting Hardware, Contoura - ADJASBA Only - Before 5/15/09 ............................. 58
Battery Box Hardware & Door Assembly ................................................................................. 12
Battery Tray Assembly & Wire Harnesses ............................................................................... 14
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Canes - Back & Attaching Hardware For ADJASBA Seats (After 7/4/05) ................................ 36
Canes - Back & Attaching Hardware For ASBA Seats (Before 7/5/05) .................................... 34
Cushions - Seat - Contoura Seating - ADJASBA Only ............................................................. 62
Electronics - 4-Way Switch and Mounting Hardware ............................................................... 168
Electronics - Dual Legs Integrated Actuator Module (DLIAM) MK6i For ELRPW Front Riggings 151
Electronics - General Tilt Actuator Module (GTAM) MK6i For GB TT Controller ..................... 153
Electronics - Limit Switch Harness and Mounting Hardware .................................................... 157
Electronics - MK5 SAC and Mounting Hardware ..................................................................... 159
Electronics - MK5 TAC and MK5 TRCM with Mounting Hardware After 2/27/06 ..................... 166
Electronics - MK5 TAC and MK5 TRCM with Mounting Hardware Before 2/28/06 .................. 164
Electronics - MK5 TAC and Mounting Hardware (For MK5 SAC Conversion) ......................... 161
Electronics - MK6i ~PLEASE READ THIS SECTION~ ............................................................ 150
Electronics - Quad Link (QLA) After 10/30/05 .......................................................................... 180
Electronics - Quad Link 1/13/04 Thru 10/30/05 ........................................................................ 176
Electronics - Quad Link Before 1/13/04 For 1556 Heavy Duty Joystick ................................... 174
Electronics - Quad Link Before 1/13/04 For MK5 MPJ Joystick ............................................... 172
Electronics - Quad Link Before 1/13/04 For MK5 SPJ-80 and DPJ Joystick ........................... 170
Electronics - Tilt Recline Single Switch (TRSS) ....................................................................... 155
Frames - Seat ADJASBA - Seat Pan & Hdwr. (16"-20" W x 16"-22" D) (After 7/4/05) ............. 24
Frames - Seat ADJASBA - Seat Pan & Hdwr. (20"-22" W x 16"-22" D) (After 7/4/05) ............. 26
Frames - Seat ADJASBA Mounting Hardware (After 7/4/05) ................................................... 30
TABLE of CONTENTS
Description
Page
Number
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Frames - Seat ADJASBA Mounting Hardware For TRBKTS Option ........................................ 32
Frames - Seat ASBA (Before 7/5/05) ....................................................................................... 22
Frames - Seat ASBA Mounting Hardware (Before 7/5/05) ....................................................... 28
Front Riggings - Adjustable Angle Footplate Assemblies - AT5543 ......................................... 98
Front Riggings - Calf Pads and Attaching Hardware ................................................................ 92
Front Riggings - Center Mount Rigging (CTMT/CTMT-F/CTMT-L/CTMT-FL) - Before 12/10/08 109
Front Riggings - Center Mount Rigging (CTMT-F with CTMTFB One PC Flip-Up Footboard)
After 12/30/09
122
Front Riggings - Center Mount Rigging (CTMT-F/CTMT-FL with CTMTFB One PC Flip-Up
Footboard) Before 12/31/09
120
Front Riggings - Center Mount Rigging (CTMTJ/CTMT-FJ) - Before 12/10/08 ........................ 107
Front Riggings - Center Mount Rigging (CTMT-J/CTMT-FJ/CTMT/CTMT-F/CTMT-L/CTMT-FL)
(After 12/09/08)
112
Front Riggings - Center Mount Rigging Kit (CTMT/CTMT-L) For ASBA Seat (Before 7/5/05) . 133
Front Riggings - Center Mount Rigging Kit (CTMTJ) For ASBA Seat (Before 7/5/05) ............. 130
Front Riggings - Center Mount Rigging Kit(CTMT-F/CTMT-FL/CTMT-FJ) For ADJASBA Seat -
After 7/4/05
136
Front Riggings - Center Mount Rigging Mtg. Hdwr. (CTMT/CTMT-L/CTMTJ) For ASBA Seat
(Before 7/5/05)
126
Front Riggings - Center Mount Rigging Mtg. Hdwr., (CTMT-F/CTMT-FL/CTMT-FJ) For
ADJASBA Seat (After 7/4/05)
128
Front Riggings - Footrest and Legrest Accessories ................................................................. 101
Front Riggings - Footrest Support Assemblies ......................................................................... 83
Front Riggings - Footrest Supports - (Hemi) - PHW93 ............................................................. 85
Front Riggings - Front Rigging Hanger Assembly - Pin & Sector Style For ASBA Seats (Before
7/5/05)
79
Front Riggings - Front Rigging Hanger Hdwr. - Pin & Sector Style For ADJASBA Seats (After
7/4/05)
81
Front Riggings - Legrest Supports - Articulating (Hemi) - PHAL4A .......................................... 89
TABLE of CONTENTS
Description
Page
Number
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Front Riggings - Legrest Supports - AT5544 ............................................................................ 87
Front Riggings - Pivot/ Slide Tube and 1650, 1350 Aluminum Footplates ............................... 96
Front Riggings - Pivot/ Slide Tube and 1651 Composite Footplates ........................................ 94
Front Riggings - Power Articulating Legrest - ELRPW (After 7/26/04) ..................................... 143
Front Riggings - Power Articulating Legrest - ELRPW (Before 7/27/04) .................................. 140
Front Riggings - Power Articulating Legrest - ELRPW Harness & Hdwr. For ADJASBA Seat
(After 7/4/05)
148
Front Riggings - Power Articulating Legrest - ELRPW Harness & Hdwr. For ASBA Seat (Before
7/5/05)
146
Front Riggings - Reference Chart - 70ST TAPER .................................................................... 78
Front Riggings - Reference Chart - AT5544, 70NHD, PHW93 ................................................ 76
Front Riggings - Reference Chart - PHAL4A ........................................................................... 77
Label Locations For TRBKTS Option ....................................................................................... 10
Packaging - Literature - Frame Finishes & Touch-Up Paint ..................................................... 7
Prop Rod Assembly .................................................................................................................. 20
Seat Pan & Mounting Hardware For ASBA Seats (Before 7/5/05) ........................................... 65
Tilt Actuator & Mounting Hardware .......................................................................................... 18
Tilt Assembly & Mounting Hardware ........................................................................................ 16
TRBKTS Option Clarification Reference .................................................................................. 11
TABLE of CONTENTS
Description
Page
Number
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!)
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Packaging, Literature, Frame Finishes and Touch-Up Paint
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Packaging, Literature, Frame Finishes and Touch-Up Paint
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1030364 Carton, Cover 1 11 A 1036028 Carton, Cover 1 11 B 40131X161 Insert, Plain Pad 1 22 40131X011 Carton, Front Riggings 1 13 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 14 1043198-NLA NLA - Tube, Paper 1 15 1012001 Carton, Joystick 1 16 1030362 Carton, Tray 1 27 A 1036027 Carton, Tray 1 27 B 1115174 Carton, Corner Reinforcement 1 48 00077X031-NLA NLA - Warranty Card 1 1C 1114809 Owner's Manual, TDX w/ MK5 Electronics 1 1C 1122132-NLA NLA - Owner's Manual, Invisible Super Low Tilt with
MK6i Electronics 1 1C
See Chart Frame Finishes and Touch-Up Paint For Front
Riggings 1 1C
1164348 Mailer, Return, Mercury Free 1 1D
A - 16" wide - 20" wide models
B - 21" wide - 22" wide models
C - Not Shown
D - For Massachusetts providers only
When a
djusting or replacing parts, please refer to your Owner's Manual for assistance.
NOTE:
Frame Finishes and Touch-Up Paint For Front Riggings
Color Number Part Number Bottle Size Color
Pink Pearl.6 oz103145202P Super Teal.6 oz103145406P Deep Purple.6 oz103145608P Cobalt Blue.6 oz104631917P Anthracite.6 oz103337622P Wet Black.6 oz103145024P White.6 oz103144729P Red.6 oz103145533P Flat Black.6 oz104632734P Electric Red.6 oz104632161P Electric Blue.6 oz104632062P Metallic Blue.6 oz104632464P Teflon Black.6 oz1101320-NLA69P Silver VeinN/AN/A71P Evergreen with Navy.6 oz107389280P Dark Olive with Copper.6 oz107389381P Fruit Punch with Fucshia.6 oz107389482P Royal Blue with Grape.6 oz107389583P
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Packaging, Literature, Frame Finishes and Touch-Up Paint
Frame Finishes and Touch-Up Paint For Front Riggings
Color Number Part Number Bottle Size Color
Lavender.6 oz107389684P Jeweled Green.6 oz1101325101P Denim Blue.6 oz1101327102P Mocha Frost.6 oz1101324103P Electric Teal.6 oz1101316104P Midnight Blue.6 oz1101326105P Twilight SparkleN/AN/A72P Gold SparkleN/AN/A73P Green SparkleN/AN/A74P Blue SparkleN/AN/A75P Red SparkleN/AN/A76P Wet Black with
Twilight Sparkle
N/AN/A88P
Black PrismN/AN/A115P Sunkissed OrangeN/AN/A116P Tangerine RedN/AN/A117P Fruit FusionN/AN/A118P Bubblegum PinkN/AN/A119P Grape MadnessN/AN/A120P Lolly Pop BlueN/AN/A121P Cosmic BlueN/AN/A122P Celestial PurpleN/AN/A123P Vivid VioletN/AN/A124P Emerald GreenN/AN/A125P Shamrock GreenN/AN/A126P Grasshopper GreenN/AN/A127P
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Label Locations For TRBKTS Option
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

TRBKTS Option Clarification Reference
TRBKTS Option was introduced 12/19/05 as an On-Chair option only.
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Battery Box Hardware and Door Assembly
For Formula Invisible Super Low Tilt Seating
The Battery Boxes are non-serviceable parts. Call Technical Services for assistance (1-800-832-4707)
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Battery Box Hardware and Door Assembly
For Formula Invisible Super Low Tilt Seating
The Battery Boxes are non-serviceable parts. Call Technical Services for assistance (1-800-832-4707)
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1133027-NLA Kit, Battery Box Hardware, 22NF Short Super Low 1 11 A NLA - Shroud, Battery Box 1 12 Tie Wrap (11-1/2" L) 1 23 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 24 Screw, Socket Head (#10-32 x 1/2") 1 25 1120248-NLA Kit, Battery Box Door Assembly, 22NF Short Super
Low 1 16 B,C
Label, 22NF Terminal Configuration Warning 1 17 NLA - Label, 22NF Battery Install/Remove 1 18 NLA - Decal, Blank Logo 1 19 Decal, Invacare Medallion - Large 1 110 Locknut (1/4-20) 1 211 NLA - Sleeve, Door Pivot 1 212
A - Includes items 2-5
B - Blank Logo Decal is no longer available and no longer required for item number 10 Invacare Medallion Decal.
C - Includes items 7-12
NOTE:
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Battery Tray Assembly and Wire Harnesses
22NF Batteries
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Battery Tray Assembly and Wire Harnesses
22NF Batteries
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1120263-NLA NLA - Harness, Battery Wire with Terminal
Hardware,
22NF, Rear
1 11 A,B
1121124 Battery Strap Assembly, 22NF and GP24 1 32 1120264-NLA NLA - Harness, Battery Wire w/ Terminal Hardware,
22NF, Front 1 13 A,B
16721X000 Locknut (1/4-20) 1 44 1096799 Screw, Hex Flange Whiz Lock (1/4-20 x 7/8") 1 25 98007X005 Tie Wrap (11-1/2" L) 1 66 1117186 Bracket, Battery Tray Stop, Black 1 17 90017X000 Screw, Phillips Pan Head (#10-32 x 5/16") 1 28 1120265-NLA NLA - Battery Tray Assembly, 22NF 1 19 C 50000X121 Strap, Battery Lift 1 110 1120237 Harness, Battery Extension 1 111
A - Individual components are not available for the battery wire harnesses
B - Includes items 4-6
C - Includes items 2 and 6-8
NOTE:
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Tilt Assembly and Mounting Hardware
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Tilt Assembly and Mounting Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1120175 Roller, Cam 1 21 1120214-NLA NLA - Roller, Cam, Seat Support 1 12 1018248 Nut (5/16-18) 1 23 1108437 Bumper, Rubber (1" Diameter x 5/8") 1 24 1120184 Mounting, Lower Pivot 1 15 1100023 Screw, Button Head w/ Patch (1/4-20 x 1/2") 1 46 1028410 Screw, Socket Button Head (1/4-20 x 7/8") 1 27 1120196 Sleeve, Pivot Joint, Front 1 28 1120169-NLA NLA - Bearing, Flange 1 29 1025195 Locknut (1/4-20) 1 510 1120195-NLA NLA - Spacer, Front Pivot Joint, Black 1 511 1071955 Screw, Socket Button Head (5/16-18 x 3/4") 1 212 1068039 Pin, Pull 1 113 A 1114308 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 114 1039860 Screw, Hex Head w/ Patch (5/16-18 x 3/4") 1 415 1079247 Washer, Flat (21/64 x 53/64 x 7/64") 1 416 1120229-NLA NLA - Rail, Side - Right 1 117 1113341-NLA NLA - Nut, Strap 1 218 1120230-NLA NLA - Rail, Side - Left 1 119 1120224 Screw, Shoulder Hex Socket Head (3/8" x 5/8",
5/16-18) 1 220
1120194 Link, Front 1 121 1072692 Lockwasher, Split (5/16") 1 222 1124299 Key, Ball Point T-Handle (3/16" Hex) 1 123 B
A - Pull Pin no longer used as of 11/12/04, see page titled "Prop Rod Assembly"
B - The T-Handle Hex Key is used to remove item 12 (Socket Button Head Cap Screw). Item 5 (Lower Pivot Mounting) can
then be raised up to provide clearance to remove the batteries.
NOTE:
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Tilt Actuator and Mounting Hardware
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034

Tilt Actuator and Mounting Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1120223 Pin, Quick Release with Lanyard ( 3/8" ) 1 11 1028410 Screw, Socket Button Head (1/4-20 x 7/8") 1 12 1025195 Locknut (1/4-20) 1 13 1120173 Actuator Motor w/o Hardware 1 14 A 1120221 Spacer, Ball Screw (7/8 x 1-1/4 x 3/16") 1 15 1120231-NLA NLA - Bracket, Lower Screw Pivot 1 16 1012371 Washer, Nylon (3/8 x 7/8 x 1/16") 1 17 1100023 Screw, Button Head w/ Patch (1/4-20 x 1/2") 1 18 A - Actuator does not includes items 5-8
NOTE:
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-034
