Decon wheel TNS Notos User manual

2021-01-22
Assembly instructions for TNS Notos.
MEM6409P and MEM6410P
1. Remove wheels and sleeves on both sides.
2. Check the correct placement for the eMove, and that it is axle Ø12,7 x 46 with
Part Number: XOE-2530E-00 and Stop pins are assembled with Part Number:
320003.
13

2021-01-22
3. Assembly of the plate according to picture.
Parts for right side mounting:
Item No. Part Number Qty Description
1 XSM6ML 1 Locknut M6
2 405239 1 Nordlock Washer
3 100 400 004 1 Spacer
4 XSM8ML 2 Locknut M8
5 XSM8X20 2 Screw M8x20
6 HW069 1 Sleeve
7 100 400 039 1 Spacer
8 100 400 020 1 Spacer
9 310022 1 Bracket
10 XSM6X35 1 Screw M6x35
11 300084 1 Bracket
12 Xklamma3 1 Clamp
13 320003 1 Bracket
Note! If you only order the mounting set, the axle is not included, for replacement see the
service manual.
4. Assemble the under placed battery bag.
1
7
8
3
10
2
4
9
6
5
11
12

2021-01-22
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsa.
Sleeve.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M16x1
30 Nm
M18x1
40 Nm
