USER INSTRUCTIONS
HEIGHT ADJUSTABLE TOILET FRAME
WITH SEAT
M11090 Height Adjustable Toilet Frame with Seat
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
Maximum User Weight
30st
190kg
1. INTENDED USE
To assist users when lowering onto and rising from the toilet. Primarily for use over the toilet using the
splash guard provided but also for use as a commode with the addition of a potty. The seat lid adds discreet
style and helps to improve cleanliness and hygiene.
Figure 1:
2. SAFETY
WARNING: The maximum user weight must not be
more than 190 kg (30 st).
DO NOT attempt to stand or climb on the product.
MAKE SURE all legs are set at equal height to avoid
rocking.
3. UNPACKING
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
4. INSTALLATION INSTRUCTIONS
Product arrives fully assembled.
To adjust the height:
• Remove the ‘E-clip’ and slide the legs to the
desired position.
• Align the holes and re-insert the ‘E-clip’.
• Repeat for all four legs.
Ensure that all four legs are positioned at the same
height to prevent rocking and instability.
Place the frame over the toilet ensuring that the
internal splash guard is positioned centrally over the
toilet bowl.
To t M20303 - Commode Pan
Figure 2: M20303 Commode Pan
Lift the seat and lid to slot the commode pan into
position on the frame, see gure 3.
Figure 3: M11090 with Commode Pan (M20303)
tted
5. OPTIONAL FLOOR FIXING KIT
The oor xing kit provides a permanent xing
solution for the Toilet Frame. It helps to prevent
the frame from moving out of position or becoming
unstable during use.

2
F11572 – Floor Fixing Kit
Available as an accessory from NRS Healthcare.
See the end of this document for contact details.
5.1 Fitting Instructions
Adjust the toilet frame to the desired width, see
Section 4.
To t the legs:
Remove the original leg extensions by removing the
‘E-clips’ and sliding them out of the frame.
Insert the four leg extensions and position at the
desired height.
Align the holes and insert the ‘E-clip’.
Ensure that all four legs are secured at the same
height to prevent rocking and instability.
Please note the height cannot be adjusted once the
legs are secured to the oor.
To x to the oor:
Choose a xing method which is suitable for the
construction of the oor. Use 3 screws per each of
the four legs. See gure 4.
Figure 4:
6. MAINTENANCE
Check that all xing clips are inserted correctly and
that there is no excessive movement.
If a oor xing kit has been tted, check the xing
screws are secure.
Inspect the product regularly for signs of wear or
damage, pay particular attention to the condition of
the ferrules.
Any suspected faults or damage should immediately
be reported to the supplier and the product taken out
of use.
7. CLEANING INSTRUCTIONS
Clean regularly using a general purpose, neutral
detergent and warm water. Pay particular attention
to the toilet seat hinges and underside of lid.
Please check the suitability of the cleaning products
before use. Do not use abrasive cleaners or cloths
as these could permanently damage the surface and
invalidate any warranty.
To disinfect, wipe with a dilute bleach solution and
rinse thoroughly with fresh water.
Allow the product to dry fully prior to use/storage.
8. PRODUCT DISPOSAL
This product must be thoroughly cleaned/sterilised
prior to disposal.
This product is manufactured from metal & plastic
and can be disposed of through Local Authority
Household Waste and Recycling Centres or through
Local Trade Waste Collectors.
9. PRODUCT GUARANTEE
NRS Healthcare guarantee this product for a period
of 24 months, from the date of purchase, against
faulty materials and workmanship.
This guarantee does not cover abuse, interference
or tampering with any part of the products. Issues
arising from fair wear & tear and customer misuse
are not covered.
This guarantee covers domestic use only. If the
product is used in commercial or semi-commercial
settings such as care homes, schools, rental or
communal accommodation etc, the guarantee is
valid for one year only. Consumable parts are also
guaranteed for one year only.
Any guarantee issued by NRS Healthcare does not
a󰀨ect your statutory rights.

3M11090-UI-6 07-08-2023
NRS HEALTHCARE Sherwood House, Cartwright Way, Forest Business Park
Bardon Hill, Coalville, Leicestershire, LE67 1UB, UK.
Tel: Customer Services: [phone] Email: [email protected]
