Arnica Merlin User manual

1
Instruction Manual
MERLİN

2

3
12
15
11
16
10
13
C3
6
7
8
4
3
2
5
1
9
14
USER’S MANUAL
Thank you for purchasing the Merlin 2-in-1 vacuum cleaner,
please read these instructions before use.
CONTENTS
1. Safety Rules
2. Description of appliance
3. Technical Specifications
4. Assembly and Preparation for use
5. Use
6. Cleaning and Maintenance
1. SAFETY RULES
•Thisapplianceisnotsuitableforthosewithphysical,sensorial
ormentaldisabilities;Userslackingexperienceandknowledge
oftheappliance,orthosewhohavenotbeengiventheuser’s
instructions, must be supervised by a person responsible for
their safety.
•Childrenmustbesupervisedatalltimestoensuretheydonot
playwiththeappliance.
•Before plugging your appliance into the mains socket, ensure
that the voltage shown on the rating plate matches the local
voltage supply.
•Make sure that your appliance is certainly unplugged before
moving, cleaning or servicing it.
•Donotpullthepowercordtounplugtheappliance.
•Avoid power cord being closely pressed, excessively bent and
passthroughplaceswithsharpedges.
•Donotusetheapplianceifthepowercordortheplugappears
to be damaged. Apply to the closest authorised service centre to
havethepowercableortheplugtoberepairedorreplaced.
•Neverleavetheapplianceunattendedwhenitisconnectedtothe
powersupply.Keepawayfromchildren.
•Payparticularattentionwhencleaningstairs.
•Donottrytouseapplianceifitisdamaged.
•Donotaimthesuctionendtowardshumansandpets.
•Donotimmersetheappliancebodyinwaterandpreventitfrom
anyspillingwater.
•Acids,acetoneand solventscausedamage andcorrosionson
theappliance.Donotusesuchagentswhilecleaningorwiping
your appliance.
•Useonlyoriginalpartsandaccessoriesfortheappliance.
•ContacttotheUKDistributorforrepairandspareparts.
WARNING:
1. Do not use the appliance to suck such flammable liquids as
gasoline, thinner, alcohol, kerosene and the like, dusts and
liquids with temperatures more than 60 °C and substances
that pose fire risk, and wastes hazardous for health.
2. The appliance you purchased has been designed for home
use only and must not be used for commercial or industrial
purposes.
2. DESCRIPTION OF THE APPLIANCE
1. Extension Pipe Holder
2. Cord Hook
3. Extension Pipe
4. Extension Pipe Locking Latch
5. PowerCord
6. Handle
7. On/OffSwitch
8. LatchforOpeningDustBag
9. Wrap-Around Cable Hook
10. DustBag
11. Crevice Tool
12. FloorBrush
13. HEPA Filter

4
14. Cloth Filter
15. PasspartùBrush
16. NozzleandSmallDustBrush
3. TECHNICAL SPECIFICATIONS
Voltage :230V~,50Hz
Power(IEC) :Max.1000W
ElectricalInsulation :ClassII
LengthofPowerCord :6meters.
Mark of Conformity : CE
4. PREPARATION FOR USE
WARNING:  Unplug the power cord before attempting to prepare
appliance for use.
Installing Extension Pipe to the Body:
•Openthelatchforextensionpipelocatedonthehandleofelectric
vacuum cleaner and push the extension pipe into the handle until
it is fitted firmly.
•Fixtheextensionpipeforthecleanerinitsplacebymeansof
locking latch.
Installing Crevice Tool and Floor Brush to the Cleaner Body:
•Installcrevicetoolorfloorbrushbypushingthemintothesuction
hose end.
Installing Nozzle and Brush to the Body:
•Inorderforthesmalldustbrushtobeinstalledtothehoseend,
pushitsnozzle into thesuction port first andlater attach the
smalldustbrushontothenozzle.
Winding and Unwinding the Power Cord:
•Usecordhookorwrap-aroundcablehookforwindingthepower
cord
5. ASSEMBLY & OPERATING THE VACUUM CLEANER
Dry Cleaning:
•Attachthemostproperaccessoriesforthetaskyouplanned.
•Followingaccessoriescanbeemployedforapropercleaning:
-FloorBrushforcarpet,rugandthefirmgrounds.
- Crevice Tool for cleaning dust, crumbs and the like in such
narrowplaceshardtoaccessasradiators,drawersandso
on.
- Nozzlealone(withoutbrush)forcleaningsoil,crumbs,featherand
so on
-Small Dust Brush for cleaning surfaces such as shelves,
books, cloths, electronic gadgets, lampshades, curtains and
so on.
•Plugthepowercordtomainsandoperatethevacuumcleaner
pressingOn/OffSwitch.
6. CLEANING & MAINTENANCE OF VACUUM CLEANER
•Make sure that your appliance is certainly unplugged before
startinganycleaningormaintenanceworks.
•Donotimmersethepowerplug,cordorapplianceinwaterorany
other liquid to prevent potential electric shock.
•Cleanyourvacuumcleaneraftereachuseforhygienicpurposes
and to extend its service life.
•CleanlinessoftheHEPAfiltermustbecheckedperiodically.Itmust
bewashedwithwarmwaterifrequired.
•Itisnecessarytouseonlyoriginalaccessoriesandpartsinorder
to guarantee effective cleaning and long service life. Procure
accessoriesandpartsfromtheclosestauthorizedservicecentre
whenrequired.
WARNING:
Warranty deed must be absolutely ratified by the authorized
dealer as of the date of sale (Its stamp and date of sale)
2 years Guarantee
Thank you for choosing the Merlin 2-in-1 vacuum cleaner. This
product is covered for 2 years against a manufacturer’s fault.
To register for your guarantee, please send back the customer
tear-off portion of the guarantee slip provided at point of sale
to:
L.C.C. Show & TV Promotions
P.O.Box 185
Borehamwood
Herts WD6 3XL
This guarantee only applies to customers within the UK and
Eire.
No claims will be considered if not registered.
