Art LP-10 User manual

No part of this manual may be reproduced or transmitted, in any form or by any
means, electronic or mechanical, including photocopying, recording, or
information storage and retrieval systems, for any purpose other than the
purchaser's personal use, without the prior written permission of Programming
Systems B.V.
Programming Systems B.V. specifically disclaims all warranties, either express or
implied, including but not limited to implied warranties of merchantability and
fitness for a particular purpose, with respect to the hardware, firmware, manual,
written materials and any other accompanying items. Programming Systems B.V.
reserves the right to revise or make improvements to the product at any time and
without obligation to notify any person of such revisions or improvements.
Using the product implies acceptance and understanding of all guidelines and
safety issues stated in both installation and user manual and all commonly
accepted rules and safety issues for using electronic equipment. In no event shall
Programming Systems B.V. be liable for any consequential or incidental damages
or injuries, including any loss of profits and loss of data, or any other damages,
arising out of the use or misuse of the product's hardware, firmware, software,
manuals, written materials and any other accompanying items. LP-10 UniversalLP-10 Universal
Programmer / TesterProgrammer / Tester
Installation ManualInstallation Manual
Programming Systems B.V.:Programming Systems B.V.:
Telephone: [phone]
Fax: [phone]
WebSite: www.artbv.nl
E-mail: [email protected]
PS000513-LP10I-E

Programming Systems Programming Systems
LP-10 Universal Programmer & Tester Installation Manual LP-10 Universal Programmer & Tester Installation Manual
Dear UserDear User
Thank you for buying the ART LP-10 Universal Programmer and Tester.
This product is designed to program many programmable devices
and to test digital IC's for correct functional operation.
Software InstallationSoftware Installation
To install the LP-10 software you have to take the following steps:
1. Create a destination directory on your hard disk.
2. Insert disk 1 of 3 into your floppy drive.
3. Windows 95/98:
a. Select ‘Run’ in the Windows start menu and type
‘A:\INSTALL.EXE’ or
b. Browse with Windows explorer to your floppy drive and start
the installation program by double clicking the ‘INSTALL’
program.
4. Press ‘Enter’ on the start up screen of the installation program.
5. Type in the destination directory as created in step 1 and press
the ‘Enter’ key.
The program will install the software for you. Please take care to insert
the floppy disks 2 and 3 when asked.
Getting StartedGetting Started
When you start using the LP-10, take the following steps:
1. Make sure both PC and LP-10 are switched off.
2. Connect the 25 pin printer cable to the LP-10 and the PC’s printer
port. Never exchange the printer cable when either the LP-10 orNever exchange the printer cable when either the LP-10 or
the PC is switched onthe PC is switched on.
3. The LP-10 can be powered in two ways:
a. Insert two 9 Volt (PP3) batteries in the bottom of the LP-10.
b. Connect the DC adapter to the power connector at the
back.
Do not use batteries or adapters with other plug types, polarity or
voltages, your equipment may be damaged.
4. Remove any device from the ZIF socket, if present.
5. Switch on the power of the PC.
Switch on the LP-10 (the power switch is located at the back).
6. Browse with Windows Explorer to the directory where you have
installed the LP-10 software. Start the program by double clicking
the ‘LP-10.EXE’ program.
When either of the following two situations occur, you must
re-initialise the LP-10:
1. The LP-10 was switched off and on, while the software was
running.
2. The LP-10 was switched on after the software had been started
(software is in demo mode).
To re-initialise the LP-10 hardware, press the ‘F5’ key.
NOTENOTE:Remove devices from the ZIF socket before switching on the
LP-10, before starting the program and before
(re-)initialisation of the programmer (‘F5’ key).
To stop working with the LP-10, first switch off the LP-10, then switch off
the PC. Remove any devices from the ZIF socket.
Standard AccessoriesStandard Accessories
•ART LP-10 Universal Programmer / Tester
•Special 25 Pin printer cable for the LP-10
•Power supply: 100-240V AC (47-63 Hz) – 12V DC 2.0 A
2.1 mm plug, negative pole outside (N).
•LP-10 software on disks (3)
•Installation Manual
•User Manual
•Warranty Card
HowHow To Get More InformationTo Get More Information
The WebSite (http://www.artbv.nl) contains a wide variety of
information, links, software and tools that are useful to every user. Also
you will find information on the complete product line of
Programming Systems.
When you have questions or problems, you can always e-mail
Programming Systems at: [email protected]
We hope you enjoy working with the ART LP-10 Universal Programmer
and Tester.
