WELCOME
Thank you very much for purchasing an Arthur Holm product.
Please, read these installation and operating instructions carefully and
keep them in a safe place for future consultations.
We remain at your entire disposal if you have any suggestions.
Henrik Holm
General Manager
[email protected]

ABOUT US
The Company
Arthur Holm has its origins in the Danish furniture designer Jorgen Alex
Jensen, who was active during the sixties and the seventies. His design
inspiration and his concept of ergonomics have been continued by his
family, who is the design force behind Arthur Holm product range. The
result of combining Scandinavian design tradition with Mediterranean
creativity, exibility and emotion is a wide product range built on more
than 25 years of craftsmanship.
Arthur Holm offers a professional product range where tomorrow’s
technology is shaped into valued materials with design exibility and
customisation, specially created to enhance communication in reception,
collaboration, conference and meeting areas.
The art of customisation
Arthur Holm offers a range of ingenious products whose designs are based
on quality materials and the latest technology. Products which endow
meeting and conference rooms with silent, ergonomic, innovative and
aesthetic solutions that integrate into the furniture, hang from the walls as
works of art or are used as interactive points of information.
The world of Arthur Holm
Arthur Holm offers a selection of unique, elegant, versatile, exible and
ergonomic products that are being used in meeting and conference
rooms, reception areas, huddle rooms, control rooms, auditoriums and
public zones of leading companies throughout the world.
The numbers speak for themselves! We currently own 33 product patents,
have presence in over 45 countries with products and solutions inmore
than 25,000 installations.
It will be our pleasure to work with you, designing your unique and
personalised environment. Our broadcast electronic engineers will
provide the latest technology while our design team will offer you the most
exclusive appearance.
Our team puts its heart, passion and pride in all our designs.

5
SAFETY INSTRUCTIONS
Plugs
• Do not dismantle any part of the monitor power connector.
• Disconnect the power plug from the AC outlet when the monitor is not
going to be used for an indenite period of time.
Power and extensions cords
• Use the appropriate power cord with the correct plug type.
• Do not overload wall outlets or power cords.
• Make sure the total ampere passed through an extension cord does not
exceed the maximum allowed by the cable used.
• Do not place anything on the power cord.
• Do not locate this product where a person may walk or trip over the
cord.
REGULATIONS AND SECURITY
ATTENTION: Do not disassemble or modify the device in any way.
This symbol warns of the presence of dangerous un-insulated
voltages inside some of the components, of sufcient magnitude
to expose people to risk of electronic shock.
This symbol draws attention to important use and maintenance
instructions in the manual that accompanies the unit.
This symbol indicates that the equipment conforms to the norms
established by the European Community.
This symbol indicates D.C. current.

6
Wiring connected to hazardous voltage requires installation by
qualied personnel or the use of ready-made exible cables.
For your security, your equipment must be connected to an
electrical outlet with grounding connection protection.
Since the plug is used to disconnect the device, the operating
electrical outlet must be in an easily accessible place.
Environment
• Install the equipment on an elevated, at surface.
• Install the equipment in a ventilated area.
• Avoid exposing the equipment to:
∙Rain or water
∙Excessive heat, cold or humidity
∙Area exposed to direct sunlight
∙Dirty areas
∙Equipment generating strong magnetic elds
• Avoid placing open containers of liquid, near the equipment.
• Keep a minimum distance of 30 mm in order to have good ventilation.
• Never place above the device any sources of ames such as lighted
candles, etc.
• If you are using the device in extreme weather conditions and/or
tropical climates, the equipment should be installed in a room which
ensures a reasonable level of temperature and humidity.
• To prevent damage the equipment must be rmly anchored to the
surface, as shown on the installation instructions.
SAFETY INSTRUCTIONS

7
SYSTEM DESCRIPTION
General
Gooseneck monitors have been designed to be installed on counters
or desks. These monitors have a brushed stainless steel support base
assembled to the table.
Very elegant screens designed for xed installation on tables are made
from milled aluminium with a stylish, protective glass panel. The cables
are neatly concealed inside the support and under the table to reach
the connection point.
Highlights
•Adjustable viewing angle
• Table integration monitor
• Rotatable 160°
• Below table connectivity
• No visible cabling
• Maintenance free
• Energy saving design
Box Contents
Before the installation of your monitor, please check the contents of the
shipping box, it must contain the following items:
• Monitor
• Power cord
• Power supply 100-2 40Vac, 50-60Hz. Output 12V
• User guide

8
SYSTEM DESCRIPTION
Available Models
MODEL DESCRIPTION
AH22NTT16
HDCP compliant 21,5" FULL HD aluminium monitor for xed
installation on desk. Arm made of stainless steel with adjustable
viewing angle and 160˚ horizontal rotation. DVI-I input.
Options
AH22NTT16
CL (Min.5 units)
Laser engraved logo
TS2216G
Projected capacitive multi-touch screen
PF
Privacy lter

9
INSTALLATION INSTRUCTIONS
Mounting Instructions
Mounting Instructions

10
CONTROLS
OSD monitor control
The OSD buttons, to control or congure the monitor, are located at the
lower body housing of the system.
MENU Activates the OSD menu on screen. Exits the OSD menu
when is active
SEL Selects the OSD menu function
DOWN Moves the cursor down in the OSD menu
UP Moves the cursor up in the OSD menu
LEFT Moves the cursor left in the OSD menu
RIGHT Moves the cursor right in the OSD menu
SOURCE Signal input selection
LED Indicates operation status
POWER Monitor power on/off

11
OSD MENU
Accessing the menu system
• With the OSD off, push the MENU button to activate the main OSD
menu.
• Press the UP and DOWN buttons to move from one function to another.
Please refer to the following sections below to view a complete list of
all the functions available for the monitor.
• Press the OK button to conrm.
• When a function is selected, press the LEFT and RIGHT buttons in order
to change the parameter of the function.
Press the MENU button to access to the main menu.
Picture Mode: Adjusts the mode of the image
∙Dynamic
∙Standard
∙Mild
∙User: Contrast - Brightness - Colour - Sharpness - Tint
Colour Temperature: Adjusts the colour of the image
∙Cool
∙Medium
∙Warm
∙Use: Red - Green - Blue
Aspect Ratio: Adjusts the image aspect on screen
∙4:3
∙16:9
∙Just scan

12
OSD MENU
Noise Reduction: Adjusts the image noise lter
∙Off
∙Low
∙Medium
∙High
∙Default
Screen: (Only for analogue signals)
∙Auto Adjust
∙Horizontal Position
∙Vertical Position
∙Size
∙Phase
Backlight: Adjusts the backlight screen's level
Colour Range: Adjusts the colour range
∙0 - 255
∙16 - 235

13
OSD MENU
Option
Language: OSD language selection
Restore Factory Default: Adjusts the parameters to the initial factory
parameters
Blending: OSD window transparency
∙Low
∙Medium
∙High
∙Off
OSD Duration: Adjusts the time that the OSD menu window remains on
the screen
Software Update (USB): Port to use for rmware's upgrade.
Mirror:
0. Image with no ip
1. Vertical ip
2. Horizontal ip
3. Rotate

14
Power connection:
1. Plug the power cable from the power supply into an AC socket of
100-240 Vac, 50-60Hz.
2. Plug the 12Vdc cable into the socket on the unit.
Signal connection:
1. Use high quality DVI cable to signal connection
Use high quality DVI cable with 2m maximum length
INPUT CONNECTORS

15
VIDEO SIGNALS
RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type
800x600@60Hz 37.879 60.317 Progressive
800x600@72Hz 48.077 72.188 Progressive
800x600@75Hz 46.875 75.000 Progressive
1024x768@60Hz 48.363 60.005 Progressive
1024x768@70Hz 56.476 70.070 Progressive
1024x768@75Hz 60.023 75.030 Progressive
1280x720@60Hz 44.772 59.855 Progressive
1360x768@60Hz 47.720 59.799 Progressive
1280x1024@60Hz 63.981 60.020 Progressive
1600x1200@60Hz 75.000 60.000 Progressive
1680x1050@60Hz 64.742 59.946 Progressive
1920x1080@60Hz 66.647 59.980 Progressive

16
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL &
ELECTRONIC EQUIPMENT
This symbol on the products and/or accompanying
documents means that used electrical and electronic
products should not be mixed with general household
waste.
For proper treatment, recovery and recycling, please
take these products to the designated collection
points, where they will be accepted on a free
of charge basis. Alternatively, in some countries,
you may be able to return your products to your
local retailer upon the purchase of an equivalent
new product.
Disposing of this product correctly will help save valuable resources
and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste
handling. Please contact your local authority for further details of your
nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact
your dealer or supplier for further information.
Information on disposal in countries outside the European Union
This symbol is only valid in the European Union. If you wish to discard this
product, please contact your local authorities or dealer and ask for the
correct method of disposal.

17
WARRANTY TERMS AND CONDITIONS
Albiral Display Solutions warrants this product against manufacturing
defects and workmanship for a period of two (2) years from the
date of purchase, subject to the conditions below.
1. LCD panel, inverter, controller, electrical, electronic boards, engine,
mechanical parts, accessories and power supply are warranted against
manufacturing defects and workmanship for a period of two (2) years
from the date of purchase.
2. LCD panels that present more than 3 defective pixels (15-19”) and
more than 4 defective pixels (20-24”) will be replaced under warranty.
3. l Labour costs: Albiral Display Solutions covers the labour costs to
replace any defective parts during the validity of this warranty.
4. Transport costs:
I) In the case that a manufacturing defect occurs within 90 days after the
purchase date, both freight and insurance costs will be paid by Albiral
Display Solutions.
Although Albiral Display Solutions pays for transport and insurance cost,
Albiral Display Solutions will not be responsible for the damages caused
by transport if the customer does not inform in writing immediately when
receiving the goods.
II) After 90 days of the purchase date, the beneciary of the warranty will
pay both freight and insurance costs.
Albiral Display Solutions will not be responsible for the damages caused
by transport, when the customer pays this.
5. This warranty does not cover the labour
costs of handling, diagnose, remove, replace, reinstall and/or program
any product, force majeure causes such as vandalism or stealing.

18
6. This warranty does not apply if the fault has been caused
by misuse, improper handling, electrical or mechanical abuse,
abnormal operation conditions, non-authorised modications, and
inadequate transport or as a result of atmospheric phenomeneons.
7. The warranty is not valid if persons other than authorised Service
Centre have handled the product and if the product has been
manipulated or warranty seals are removed or manipulated.
8. The beneciary of the warranty will have to send the devices with the
original packaging to warranty there are no damages during the transport.
9. The warranty is not valid if the beneciary of the warranty
does not include RMA form and copy of the purchasing invoice.
Please note that laws vary from country to country, and the same
provisions of this warranty may not apply to you.
If you have any doubts concerning the terms of this warranty, please
contact:
[email protected]
[phone]
Copyright ©
Nov. 2020. All rights reserved
Albiral Display Solutions SL.
Registered trademarks: Albiral, Arthur Holm
WARRANTY TERMS AND CONDITIONS

Patents
MU17180ES00
MU17301ES00
MU17322ES00
MU17413ES00
MU17445ES00
MU17854ES00
MU17868DEPC
MU17868RUPC
P24821DEEP
P24821ESEP
P24821GBEP
P24821USPC
P27178DEEP
P27178EPDV01
P27178EPPC
P27178ESEP
Fàtima 25, Sant Hipòlit de Voltregà
08512 Barcelona – Spain
tel: [phone] / 23 83
fax: [phone] / 23 72
web: www.arthurholm.com
e-mail: [email protected]
This manual can be modied without previous notice. ENG – November 2020
P27178ITEP
P27178RUPC
P27178USPC
P27284DEEP
P27284EPPC
P27284ESEP
P27284GBEP
P27284RUPC
P27284USPC
P27715ESEP
P28089DEEP
P28089ESEP
P28089ITEP
P28089USPC
P28090EP00
P31160ESES
P31160PCES
201116.10
