Article COTU User manual

Assembly Instructions
COTU
Bookcase
VERSION 1.0

Page 2 of 9
COTU Bookcase
WARNING!
ANTI-TIP RESTRAINT INSTALLATION
Serious or fatal crushing injuries can occur from furniture
tip-over. To help prevent tip-over:
• Install tip-over restraint provided.
• Do not set heavy objects on top of this product,
unless the product is specifically designed to
accomodate them.
• Never allow children to climb or hang on mirrors,
shelves, consoles, or cabinets with doors and/or
drawers.
Use of tip-over restraints may only reduce but not
eliminate, the risk of tip-over.
20 min
3
TIME
REQUIRED TOOLREQUIRED TOOL
# OF PEOPLE DIFFICULTY
PARTS INVENTORY
ID DESCRIPTION QTY
LEG FRAME LEFT 1
LEG FRAME RIGHT 1
SHELF FRAME 5
REAR SUPPORT BAR 5
ANCHOR 30
LOCK NUT 30
ALLEN KEY 1
SCREW 30
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
BRACKET 4
M4 ×20MM SCREW 4
M8 ×51MM PLUG 4
M6 ×70MM SCREW 4
STRAP 2
Hardware (K/L) to attach brackets to wall is
designed for drywall. To attach this unit to another
type of wall, consult with your local hardware store.

#
×15
1
Page 3 of 9
COTU Bookcase

#
2
Page 4 of 9
COTU Bookcase
×15

Page 5 of 9
4
3
× 10
Lines on lock nuts (F) must be parallel
with the length of the rear support bar (D).
!
Lines on lock nuts (F) must be parallel
with the length of the shelf frame (C).
!
× 20 × 20
COTU Bookcase

Page 6 of 9
5
COTU Bookcase
Note holes in anchors are
paralell with the legs as shown.
!

Page 7 of 9
6
COTU Bookcase
Note holes in anchors are
paralell with the legs as shown.
!

#
7
Page 8 of 9
8
Drill holes into drywall, in wall
using 8mm 5/16" drill bit.
× 4× 4× 4
Attach pair of brackets to top
corners of the back of the unit.
×4
Mark on wall where second pair
of brackets should be placed.
×2
COTU Bookcase

#
9
Page 9 of 9
COTU Bookcase
