Article CALIPER SKU3448 User manual

Assembly Instructions
CALIPER
Shelf
VERSION 1.0

ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.
CALIPER Shelf Page 2 of 8
20 min
2
PARTS INVENTORY
ID DESCRIPTION QTY
SHELF FRAME 2
TOP SHELF 1
SECOND SHELF 1
THIRD SHELF 1
BOTTOM SHELF 1
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
WRENCH 1
ACORN NUT 2
LARGE FLAT WASHER 2
M8 ×40MM BOLT 2
ALLEN KEY 1
M6 WASHER 16
M6 LOCK WASHER 16
M6 ×50MM BOLT 16
TIME # OF PEOPLE DIFFICULTY
ANTI-TIP
Installation Required

Page 3 of 8CALIPER Shelf
75%
75%
1
× 2
100%
85%
50%

Page 4 of 8CALIPER Shelf
75%
75%
75%
2A
2B
Ensure that pre-drilled holes
on shelf (E) align with frame.
Ensure that pre-drilled holes
on each shelf align with frame.
!
!
× 4
× 12
100%
85%
50%
100%
85%
50%

Page 5 of 8CALIPER Shelf
3
4
Fully tighten all bolts.
!
Adjust levelers on
legs as needed.
!
× 16
× 4
× 2
100%
85%50%

Page 6 of 8
WARNING!
ANTI-TIP RESTRAINT INSTALLATION
Serious or fatal crushing injuries can occur from furniture
tip-over. To help prevent tip-over:
• Install tip-over restraint provided.
• Do not set heavy objects on top of this product,
unless the product is specifically designed to
accomodate them.
• Never allow children to climb or hang on mirrors,
shelves, consoles, or cabinets with doors and/or
drawers.
Use of tip-over restraints may only reduce but not
eliminate, the risk of tip-over.
20 min
3
TIME
REQUIRED TOOL
# OF PEOPLE DIFFICULTY
REQUIRED TOOL
8MM / 5/16" DRILL BIT
CALIPER Shelf
PARTS INVENTORY
ID DESCRIPTION QTY
BRACKET 4
M4 ×20MM SCREW 4
M8 ×51MM PLUG 4
M6 ×70MM SCREW 4
STRAP 2
Hardware (C/D) to attach brackets to wall is
designed for drywall. To attach this unit to another
type of wall, consult with your local hardware store.

Page 7 of 8CALIPER Shelf
1
2
Attach pair of brackets to top shelf.
× 4
Mark on wall where second pair
of brackets should be placed.
× 2

Page 8 of 8CALIPER Shelf
3
4
Align brackets on unit
with brackets on wall.
Pull strap down until it snap-locks.
× 2 × 2
× 4× 4 × 4
