Assembly Instructions
LENIA
Paneled Bed
VERSION 1.1

ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.
LENIA Paneled Bed Page 2 of 10
1 hour
5
PARTS INVENTORY
ID DESCRIPTION QTY
HEADBOARD 1
FOOTBOARD 1
CENTER BEAM BRACKET 2
LEFT SIDE RAIL 1
RIGHT SIDE RAIL 1
CENTER BEAM 1
CENTER LEG BRACKET
PREINSTALLED 2
FLOATING CENTER LEG 2
SLAT CLIP 28
SLAT 28
SLAT CENTER BRACKET 14
TIME
# OF PEOPLE
DIFFICULTY
REQUIRED TOOL
Pozidriv screwdriver
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
FELT PAD 4
ALLEN KEY 1
M6 ×12MM BOLT 4
COMPRESSION FITTING
ANCHOR 10
M8 ×8MM SCREW 10
M6 ×20MM BOLT
PREINSTALLED 4
Structural integrity is warranted only if all
fasteners are properly installed & tightened,
and the bed is moved only per instructions.

Page 3 of 10
1
×4×4
LENIA Bed
DO NOT DRAG BED, ALWAYS LIFT WITH
AT LEAST TWO PEOPLE BEFORE MOVING

Page 4 of 10
2
LENIA Paneled Bed
×4
Ensure center beam brackets (C)
are level when installed.
!

Page 5 of 10
3
LENIA Paneled Bed
×10

Page 6 of 10
4
LENIA Paneled Bed
Labels on side rails indicate orientation.
THIS SIDE UP / THIS SIDE HEADBOARD
!
×10

Page 7 of 10
5
LENIA Paneled Bed
Unscrew bolts (Q) from center leg
brackets (G) and floating center legs (H)
before attaching to center beam (F).
Attach floating center legs (H) where labels are
situated on center beam (F). Ensure that legs
are straight, perpendicular to center beam.
!
!
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
CENTER LEG
×4

Page 8 of 10
THIS SIDE UP
THIS SIDE HEADBOARD
THIS SIDE UP
THIS SIDE HEADBOARD
6
Insert pins on center beam brackets
into center beam when installing.
Adjust levelers on floating center legs
to allow for a 3-5mm clearance.
!
!
×2×2
LENIA Paneled Bed

Page 9 of 10
LENIA Paneled Bed
7A
7B
THIS SIDE UP
THIS SIDE HEADBOARD
THIS SIDE UP
THIS SIDE HEADBOARD
×28
×28

Page 10 of 10
8
LENIA Paneled Bed
DO NOT DRAG BED, ALWAYS LIFT WITH
AT LEAST TWO PEOPLE BEFORE MOVING
×28 ×14
First, firmly insert pins on
slat clips into side rails.
Second, firmly insert pins on slat
center brackets into center beam.
!
!
