Article GEOME SKU15546 User manual

Assembly Instructions
GEOME
Cabinet
VERSION 1.0

ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.
GEOME Cabinet Page 2 of 7
20 min
2
PARTS INVENTORY
ID DESCRIPTION QTY
LEG FRAME 2
SUPPORT BAR 1
SHELF 2
ALLEN KEY 1
M6 ×15MM BOLT 12
M6 ×20MM BOLT 4
M6 LOCK WASHER 4
M6 WASHER 4
SHELF PIN
PREINSTALLED 8
TIME # OF PEOPLE DIFFICULTY
ANTI-TIP
Installation Required

#
Page 3 of 7
1
2A
!
×2
×4
×2
100%
85%
50%
100%
85%
50%
GEOME Cabinet

#
Page 4 of 7
2B
3
Fully tighten all bolts.
!
×6
×2
100%
85%
50%
100%
85%50%
GEOME Cabinet

Page 5 of 7
4
Adjust levelers on
leg frames as needed.
!
×4
If the magnet on the door locking mechanism isn’t catching properly, adjust
the lock mechanism by twisting the dial on the end to extend it further outward.
!
Adjust shelf pins (I)
to desired height.
!
×8
GEOME Cabinet

Page 6 of 7GEOME Cabinet
During shipping, the doors of your cabinet may have
shifted slightly. This can easily be corrected by tightening
a few screws. Always start by adjusting the top hinge on
the aected door.
REQUIRED TOOL
DOOR ADJUSTMENT INSTRUCTIONS
FIX A CROOKED DOOR
If the door is crooked, adjust hinge(s) up or down:

Page 7 of 7GEOME Cabinet
SIDEWAYS ADJUSTMENT
DEPTH ADJUSTMENT
If the door needs adjustment side to side:
If the door needs adjustment forward or backward:

Serious or fatal crushing injuries can occur from furniture
tip-over. To help prevent tip-over:
• Install tip-over restraint provided.
• Do not set heavy objects on top of this product,
unless the product is specifically designed to
accomodate them.
• Never allow children to climb or hang on mirrors,
shelves, consoles, or cabinets with doors and/or
drawers.
Use of tip-over restraints may only reduce but not
eliminate, the risk of tip-over.
20 min
3
TIME
REQUIRED TOOL
# OF PEOPLE DIFFICULTY
PARTS INVENTORY
ID DESCRIPTION QTY
BRACKET 4
M4 ×20MM SCREW 4
M8 ×51MM PLUG 4
M6 ×70MM SCREW 4
STRAP 2
ANTI-TIP RESTRAINT INSTALLATION
Page 1 of 3
CABINET Anti-Tip Installation
WARNING!
Hardware (C/D) to attach brackets to wall is
designed for drywall. To attach this unit to another
type of wall, consult with your local hardware store.
REQUIRED TOOL
8MM / 5/16" DRILL BIT
1010 Raymur Ave.
Vancouver, BC V6A 3T2

Page 2 of 3
12
3
Attach pair of brackets to top
corners of the back of the unit.
Mark on wall where second pair
of brackets should be placed.
× 4
× 4× 4 × 4
× 2
CABINET Anti-Tip Installation
Drill holes in wall using
8mm / 5/16"drill bit.

Page 3 of 3
4A
4B
Align brackets on unit
with brackets on wall.
CABINET Anti-Tip Installation
Pull strap down until it snap-locks.
× 2 × 2
