Article ZOLA User manual

Assembly Instructions
ZOLA
Dining Chair
VERSION 1.0

ZOLA Dining Chair
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
ALLEN KEY 1
M6 ×65MM BOLT 4
M6 LOCK WASHER 6
M6 WASHER 6
M6 CRESCENT WASHER 4
M6 ×45MM BOLT 2
M4 ×50MM SCREW 4
FELT PAD 4
PARTS INVENTORY
ID DESCRIPTION QTY
RIGHT FRAME 1
FRONT AND BACK RAILS 2
LEFT FRAME 1
BACKREST 1
SEAT 1
Page 2 of 5
20 min
3
TIME / CHAIR
REQUIRED TOOL# OF PEOPLE
DIFFICULTY
ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.

85%
ZOLA Dining Chair Page 3 of 5
85%
Smaller holes face up;
larger holes face down
Cutouts face in
!
!
1A
1B
!
× 2
100%
85%
50%

ZOLA Dining Chair Page 4 of 5
2
3
!
× 2
100%
85%
50%
85%
× 2

ZOLA Dining Chair Page 5 of 5
Curved edge of seat
is at back of chair
!
4
5
Fully tighten all bolts.
!
× 4
100%
85%50%
× 4
