Installation Guide
Floor Mount Tub Filler F502-4-1
50230411
This publication is for illustrative purposes only and we reserve the right to change details at anytime as deemed necessary.

Fig A DIMENSIONS
SPECIFICATIONS AND STANDARDS
Recommended flow pressure between 15 and 75 psi. Above 90 psi it may be
necessary to install a pressure reducer. Maximum operating temperature
176°F
50230411

Fig B INSTALLATION DETAILS
50230411
1. Insert the plug and secure with the 4 bolts as shown below.

INSTALLATION STEPS
50230411
2. Install rough-in a minimum of 2”, maximum of 3” below
finished floor surface. If installing onto a wood sub-floor, install a
wood support between the joists that is minimum 2” thick by 6”
wide (2”x6” pre-cut lumber is not sufficient).
NOTE: the rough-in can be placed at any orientation as the plate
that attaches the tub filler to the rough-in is adjustable.
3. Ensure that the rough-in is level by u sing the bubble on the
plug as reference and secure the rough-in to the floor.
4. Connect the water supply. Hot and cold inlets are clearly
marked, ensure that hoses are connected correctly.
5. Turn on water supply and check for any leaks.
6. Install finished floor, cut off any excess plastic from the rough-
in so that it is flush with finished floor surface.
Joist
Blocking
Finished
floor
surface

INSTALLATION STEPS
50230411
7. Push escutcheon onto faucet body then attach plate to bottom
of faucet.
8. Remove plug from rough-in.

INSTALLATION STEPS
50230411
9. Place the faucet into the rough-in, turn to correct orientation
and secure with the bolts provided.
10. Push the escutcheon down to cover the rough-in.
11. Attach handshower.
12. Enjoy!

CARE & MAINTENANCE
For best results, keep the following in mind to retain the high quality finish of your ARTOS faucet:
• Use a soft, dampened sponge or cloth. On no account should you use an abrasive material such
as a brush, scouring pad or steel wool to clean surfaces.
• Test your cleaning agent solution on an inconspicuous area before applying to the entire faucet.
• Wipe surfaces clean and rinse completely with water immediately after applying cleaning agent.
• An ideal cleaning technique is to rinse faucet thoroughly and blot dry any water from the surface
after each use.
LIMITED LIFETIME WARRANTY
50230411
Artos® Limited Lifetime Warranty
Artos® faucets have been manufactured under the highest quality and manufacturing standards. Artos®
faucets are guaranteed for life against leaks and manufacturing defects for as long as the original
consumer purchaser owns it. This warranty applies to installations in the US, Canada and Mexico
(North America). Commercial, Industrial or business uses are warranted for a period of one year from
the original date of purchase.
This warranty is non-transferable and applies exclusively to the original owner or end-user. If a defect is
found during normal use, Artos® will, at its election, repair, replace or make an appropriate adjustment.
Damage caused by accident, misuse, abuse, improper installation or alteration will void the warranty.
This warranty does not cover replacement parts where damage is caused by normal wear and tear.
Labor charges, installation or other incidental or consequential costs will not be covered.
Replacement parts that qualify for warranty repair can be obtained by contacting Artos® at
1-1-877-9ARTOS9 or by e-mail at [email protected]. Proof of purchase (original sales receipt) from the
original consumer purchaser must accompany all warranty claims. When submitting your claim in
writing, please provide your name, address and telephone number.
Please register this produc t online at WWW .A R T OS . US . COM
It em N o : F 502- 4-1
Se r i a l N o :
