Artos F907-47 User manual

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
INSTALLATION GUIDE
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019 e ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
OPERATING SPECIFICATIONS
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
FEATURES
Separate Water Outlet
60” Flexible Hose
OPERATING PRESSURE
Minimum: 15 psi
Maximum: 75 psi
Above 90psi it may be necessary to install a pressure reducer
OPERATING TEMPERATURE
Maximum: 176°
FLOW CAPACITY
2.0 USGPM
INLET/OUTLET
1/2” Male NPT
REQUIREMENTS
This unit requires a control

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019 e ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
TECHNICAL DATA SHEET
F907-4>
flexible hose shower kit with
slide bar and -*,.Qwater
outlet squ
HOSE LENGTH 60”
1/2” MALE THREAD
2-5/8”
2-5/8”
9”
2-3/8”
25-7/8”23-1/2”

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
STEP 1
STEP 2
MIXED WATER
FROM CONTROL
1-3/8” DIAMETER THROUGH
FINISHED WALL
1-3/8” DIAMETER
THROUGH FINISHED
WALL
MIXED WATER
FROM CONTROL
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
*ALL DIMENSIONS ARE APPROXIMATE

T:877.927.8679
WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 WWW.ARTOS.US.COM
©2019 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
INSTALLATION STEPS
STEP 3 STEP 4

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
STEP 5 STEP 6
BACK OF FITTING
FLUSH WITH FINISH
WALL SURFACE

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
INSTALLATION STEPS
STEP 7 STEP 8
23-1/2”
*ALL DIMENSIONS
ARE APPROXIMATE,
MEASURE UNIT
MARK HOLES WITH
PENCIL OR MARKER

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
STEP 9 STEP 10

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
INSTALLATION STEPS
STEP 11

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
PARTS BREAKDOWN
9
1
2
3
10
11
12
13
14
8
6
5
4
7
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
1
2
3
4
5
6
7
8
9
10
11
12
13
14
WALL BRACKET SET SCREW F907-46 XP1
SLIDE BAR F907-46 XP2
SLIDE BAR ADJUSTMENT HANDLE F907-46 XP3
HAND SHOWER HOLDER F907-46 XP4
HAND SHOWER HOLDER SCREW F907-46 XP5
SLIDE BAR INLET/OUTLET F907-46 XP6
INLET ADAPTER F907-46 XP7
SLIDE BAR INLET/OUTLET SET SCREW F907-46 XP8
WALL ANCHORS F907-46 XP9
WALL BRACKET F907-46 XP10
WALL BRACKET SCREWS F907-46 XP11
HAND SHOWER F907-46 XP12
HAND SHOWER CHECK VALVE F907-46 XP13
HAND SHOWER HOSE F907-46 XP14

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2019ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
CARE & MAINTENANCE
For best results, keep the following in mind to retain the high quality finish of your
shower kit:
Use a soft, dampened sponge or cloth. On no account should you use an abrasive
material such as a brush, scouring pad or steel wool to clean surfaces.
Test your cleaning agent solution on an inconspicuous area before applying to the
entire product.
Wipe surfaces clean and rinse completely with water immediately after applying
cleaning agent.
An ideal cleaning technique is to rinse faucet thoroughly and blot dry any water
from the surface after each use.
LIMITED LIFETIME WARRANTY
shower kits are guaranteed for life against leaks and finishing
defects for as long as the original purchaser owns it.
Damage caused by accident, misuse, abuse, improper installation, improper cleaning
or alteration will void the warranty. This warranty does not cover replacement parts
where damage is caused by normal wear and tear. Westover, Inc is not responsible
for labor charges, installation or other incidental or consequential costs. Proof of
purchase must be provided with all claims.
Please register this product online at WWW.ARTOS.US.COM
ITEM NO. F907-47
SERIAL NO.
®
®
F907-47
flexible hose shower kit with
slide bar and separate water
outlet square
