Operator's Manual
Allmäher®
AS65Scout
From serial number: 025817110001
Issued: 16.11.2017, V4.0
en-Translation of the Original Operator's Manual

2
dummy
Notes on the operating
manual
Dear customer,
Congratulations on your purchase. You have
acquired a reliable quality product by “AS-Mo-
tor Germany”.
This product has been manufactured according
to modern manufacturing methods and com-
prehensive quality assurance measures. Only
when you are satisfied with your device, we
have attained our goal.
These operating instructions contain important
information to help you avoid hazards and to
increase the reliability and the life span of the
device.
Read the operating instructions
before using the device. Share
these operating instructions and
the operating instructions of the
engine with other users of the
device.
Contact
If you have questions concerning your device,
please contact you dealer or call our customer
service ([phone]).
For international AS partners, please see:
www.as‑motor.de.
Device data
Please fill in all data referring to your device.
When ordering spare parts, provide your
dealer with the serial and engine numbers.
Serial number (see manufacturer’s certificate
or type plate):
Engine number:
Date of purchase:
Address of dealer:
Intended use
The device is exclusively intended for cutting
undergrowth and woody vegetation with a dia-
meter of max. 40mm in agriculture, forestry,
and rural conservation.
Only use attachments and cutting tools autho-
rised by “AS-Motor Germany”.
Any other use exceeding this purpose is inad-
missible.
Observe the instructions chapter for Mainten-
ance. Otherwise, operational safety is en-
dangered.
The user of the device is responsible for acci-
dents or damage that can happen to other per-
sons or their property.
The device must not be used:
– To cut hard objects, rocks, rubble, or pieces
of wood (diameter larger than 40mm).
– To trim bushes, hedges, and shrubbery.
– To cut plants in balcony boxes or tubs or on
rooftops.
– To clean (vacuum) footpaths.
– As shredder for shredding tree and hedge
cuttings.
– As drive unit for work tools and any type of
tools sets that are not authorised by "AS-
Motor Germany".

3
Contents
Notes on the operating manual............. 2
Contact .................................................... 2
Device data.............................................. 2
Intended use............................................ 2
Explanation of the symbols................... 4
Symbols in the instructions...................... 4
Symbole am Gerät.................................. 4
Type plate................................................ 5
Safety instructions ................................. 6
Get informed!........................................... 6
User restrictions and hours of operation.. 6
Safe handling of fuel................................ 6
Check the device prior to use.................. 7
Danger area............................................. 7
Use caution during operation................... 8
Prior to mowing........................................ 8
Use caution when mowing....................... 8
Caution when mowing slopes.................. 9
When work is completed......................... 10
Use caution during maintenance and re-
pair........................................................... 10
Device description.................................. 11
Control elements .................................... 12
Information on mowing.......................... 13
Prior to starting....................................... 14
Fuel.......................................................... 14
Tanking up............................................... 14
Checking the engine oil level................... 14
Adjusting cutting height........................... 14
Starting.................................................... 15
Starting the device................................... 15
Engaging the blade.................................. 15
Oil pressure switch.................................. 15
Driving ..................................................... 16
Driving..................................................... 16
Reverse gear........................................... 16
Turning.................................................... 16
Pushing.................................................... 16
Differential lock........................................ 16
Switching off and parking...................... 17
Transport ................................................ 17
Loading.................................................... 17
Unloading the device............................... 18
Maintenance............................................ 18
Maintenance overview............................. 19
Cleaning the device................................. 21
General inspection................................... 21
Chain lubrication...................................... 22
Transmission........................................... 22
Maintaining the engine............................ 22
Checking the engine oil level................... 22
Checking the spark plugs........................ 22
Maintaining the air filter........................... 23
Checking the drive................................... 23
Checking the parking brake..................... 23
Checking the blade.................................. 23
Checking the blade clutch....................... 24
Assembly................................................. 25
Scope of delivery..................................... 25
Unpacking................................................ 25
Guide bar and handlebar......................... 25
Storage .................................................... 25
Storing the device.................................... 25
Longer storage........................................ 25
Restarting................................................ 26
Spare parts.............................................. 26
Wear parts............................................... 26
Disposal................................................... 26
Warranty.................................................. 26
Troubleshooting ..................................... 27
Technical data......................................... 30
Accessories............................................. 31
Declaration of conformity...................... 32

4
dummy Inhaltsverzeichnis
Explanation of the symbols
Symbols in the instructions
In these operating instructions, the following
symbols are used to denote special dangers.
Warning.
These symbols denote special
dangers.
Prohibition sign.
These symbols denote inad-
missible procedures.
Directive sign.
These symbols denote required
protective measures.
Symbole am Gerät
The following symbols are placed on the
device to inform you must be careful and at-
tentive when using the device:
Working with the device requires
extreme cautiousness.
Read the operating instructions
before you use the device.
Min. 50 m.
Risk of injury!
Make sure that no one is within
the danger zone of the device.
Objects may be ejected. The
danger zone extends for at least
50 metres.
Min. 50 m
Identification of the danger
zone around the device.
The quickly rotating blade can
cause life threatening injuries or
immense property damage! Be
especially careful to keep your
hands and feet away from the
blade when the device is put
into operation.
Prior to any repair and mainten-
ance work, pull off the spark
plug connector.
Clean the ventilation grid!
The cooling air of the mo-
tor is sucked in through
the ventilation grid of the
engine cover. Always
keep the entire surface
open and free!
Risk of damage!
Mow growth with a dia-
meter of up to 40 mm
only.
Noise is causing health prob-
lems. Use personal ear protec-
tion to avoid hearing damage.
Do not clean the device with wa-
ter spray or high-pressure
cleaner!

5
Type plate
The type plate on the device provides you
with information on the device type and the
technical data.
1 Name and address of the manufacturer
2 Device designation
3 Type designation
4 Rates power output in kW / engine speed
5 Weight
6 Year of manufacture
7 Serial number
8 CE marking

6
Safety instructions
Get informed!
For your safety, read these operating instruc-
tions carefully. Familiarize yourself with the
control elements and the proper use of the
device. Share these operating instructions with
other users of the device.
Have skilled personnel who were trained by
AS-Motor show you the safe handling of the
device before you work with it for the first time.
Get familiar with the device in a wide, open
and flat terrain first.
User restrictions and hours of
operation
Never allow children or persons who are not
familiar with the operating instructions to use
the device. Persons under 18 years of age
may operate the device only under proper su-
pervision. Local regulations determine the min-
imum age of the operator und the operating
times.
Unsuitable for operation of the device are per-
sons who
– are under the influence of alcohol, drugs or
reaction retarding medicines.
– have physical and mental/emotional impair-
ments.
– are tired or sick.
People fitted with pace makers
are not allowed to touch any cur-
rent carrying parts of the ignition
system.
Safe handling of fuel
Fuel is toxic and highly flammable. There is a
burn and explosion hazard!
Keep fuel away from ignition sources and do
not smoke during handling.
Do not inhale fuel vapours, they are dangerous
to your health.
Use gloves and avoid skin con-
tact with the fuel.
Always refuel outdoors when the engine is cold
and standing still. When doing so, always use
a filler spout or a funnel.
Do not spill any fuel or do not let fuel enter
canalisation or drain away.
When fuel has overflown, do not start the
device until the fuel vapours have evaporated
(wipe dry). Move the device away from the
spilled fuel.
Always close the tank cap tightly and do not
open it while the engine is running or the
device is still hot.
Empty the fuel only when outdoors. Use the
approved container for this or run the fuel tank
empty.
Store the fuel away from children and keep it in
a suitable container in a dark, cool and dry
place.
Never store the device when there is fuel in the
tank inside a building where fuel vapours might
come into contact with open fire or sparks.
Immediately replace the fuel tank or tank cap if
they are damaged (authorised service centre).

7
First aid
When swallowing fuel or inhaling fuel vapours,
do not force vomiting and immediately consult
a doctor.
In case of skin contact, immediately wash with
water and soap. Change your soiled clothing
as soon as you can.
Measures in case of a fire
In case of a fire, use foam, dry powder extin-
guisher, or carbon dioxide (CO2). Never douse
with water!
Check the device prior to use
Prior to use, check the blade, protection skirt,
drive and fastening parts, cables and cable
connections for proper working condition and
firm seating by visual inspection.
Never use the device with defective or missing
covers or protection skirt or protection bow.
Do not remove, change or override any safety
devices or control elements.
Have an authorised service centre check your
device if the blade does not stop within
7seconds.
Observe the maintenance instructions (see
Maintenance).
Danger area
Min. 50 m
Fig.1:
The danger zone is an area of least 50 metres.
Set up clear warning signs around this area
which indicated that no one is to enter the
area.
Within the danger area of the device, there is a
risk of injury.
The rotating knife can cause injuries and ob-
jects can be thrown out. The area in front of
and to the right of the device is especially dan-
gerous.
On slopes, the device can topple over and
slide towards persons or run them over.
Make sure
– that nobody else is in the area that will be
mowed.
– that people are never positioned in the direc-
tion of travel in front of the device.
– that nobody is positioned on the slope below
the device.
– that you have a complete overview of the
danger area at all times.
– that you keep your hands and feet away
from the rotating parts.

8
Use caution during operation
Danger of injury during motor start
Do not start the engine
– if fuel was spilled.
– in closed or poorly ventilated rooms (danger
of poisoning!).
– if there are other persons nearby.
Start the device only when your feet are at a
safe distance to the blade.
When the engine is started, do not tilt the
device.
Risk of injury when the blade is running
Switch off the blade and wait until the blade
stops
– when you drive on surfaces other than
grass.
Risk of injury when the motor is running
Switch off the engine and wait until the blade
stops
– before you tilt or transport the device.
– before you step away from the device, even
for just a short time.
– before you adjust the cutting height.
– before you refuel.
Switch off the engine and wait until the blade
comes to a standstill, and pull off the spark
plug connector
– before you clean or check the device or be-
fore you carry out work on the device.
– before you unblock or unclog the discharge
area.
Risk of burns
Do not touch the engine or the silencer. These
parts become very hot during operation and
you can get burned. If a jumpy movement oc-
curs, the risk of additional injuries can result.
Prior to mowing
Personal protective measures
During mowing, always wear
safety shoes with good grip and
long trousers. Do not mow with
open sandals or while shoeless.
Wear safety gloves to protect
yourself against injuries and vi-
brations.
Noise is causing health prob-
lems. Use personal ear protec-
tion to avoid hearing damage.
Wear safety glasses and
headgear.
Ask your specialised dealer about suitable pro-
tective equipment.
Preparing the mowing area
Prior to mowing, carefully check the perimeter
of the lawn. Remove rocks, pieces of wood,
bones, wires, and other objects that could be
picked up and thrown out by the device.
Use caution when mowing
Risk of injury
Risk of injury caused by ejected objects.
Switch off the device if there are persons, chil-
dren, animals or objects are in the danger
area. Do not restart the engine until the danger
area is clear.
Keep your hands and feet away from the rotat-
ing parts. Keep a distance to the ejection area
while working with the device.
Make sure that help can be provided in case of
an emergency.
Only mow during daylight or with adequate arti-
ficial lighting. Never mow in the event of uncer-
tain weather conditions and risk of lightning.
Be especially carefully when mowing on soft
ground, nearby landfills, ditches, dikes and wa-
ter edges.

9
Fig.2:
Avoid mowing damp grass, there is a sliding
risk!
Be extremely cautious when turning the device
round or pulling it toward you and when mov-
ing in reverse.
Always walk slowly!
Never lift or carry the device when the engine
is running.
Pay attention to traffic when working close to
roads.
Vibrations
When the device is used over a longer period
of time, vibrations can cause disturbances in
the blood supply of the hands. A generally ac-
cepted usage time cannot be determined.
– Use gloves.
– Take breaks on time.
Have an authorised service centre check the
device
– when the blade has hit an object.
– if the device starts to vibrate unusually
severely.
Mowing surfaces with fire hazard
– Carry a sufficient amount of suitable extin-
guishing agent.
– If side inclination is too great, fuel may leak
from the carburetor or the tank. This poses a
fire hazard!
– Observe the mowed surface also after mov-
ing is completed to ensure that no fire will
start.
To avoid risk of fire, keep the following com-
ponents free of dirt, grass, hay, leaking oil,
grease, etc.:
– Engine
– Silencer (manifold, guard, clearances)
– Area around the fuel tank
Caution when mowing slopes
Risk of injury during mowing on slopes due to
tipping over or sliding.
– Mow on steep terrain only when safe opera-
tion can be guaranteed.
– Do not mow excessively steep slopes.
– Take suitable precautions on steep slopes,
e.g. by using step irons.
– Always mow crossways to the slope, never
upwards or downwards.
– Always make sure that you step safely, use
non-slip safety shoes.
– Be extremely cautious when changing the
direction.
– Mow only when the ground is dry and has a
good grip.
When facing downhill, the device can roll
away. Park the device on level ground only
and secure it against rolling away.
Observe the information regarding the oil pres-
sure switch in chapter Starting.
If the device tilts or slips
– If you attempt to stop a device that is tilting
or slipping, severe injuries can result. If tilt-
ing or sliding cannot be stopped in the be-
ginning without endangering anyone, do not
continue to try to stop the device.
– Remove leaking fluids (oil, fuel, battery acid)
from the device and the floor. Deposit of
contaminated soil environment friendly ac-
cording to the local regulation.
– Undetectable damage may have occurred to
the device. In case of malfunctions, there is
a risk of injury. Have an authorised service
centre check the device.

10
When work is completed
After mowing, always close the fuel valve and
the tank ventilation.
Prior to leaving the device, wait until the engine
comes to a standstill and pull off the spark plug
connector.
After switching it off, let the device cool down
for at least 20 minutes before you store it in a
dry, closed, sufficiently ventilated room.
Never store the device when there is fuel in the
tank inside a building where fuel vapours might
come into contact with open fire or sparks.
Use caution during maintenance
and repair
Only carry out work as described in these op-
erating instructions. Have an authorised ser-
vice centre perform all other work.
Only use the blades and spare parts author-
ised by “AS-Motor Germany”. Unauthorised
blades and spare parts can cause severe injur-
ies.
Prior to all maintenance work, wait until the en-
gine comes to a standstill and pull off the spark
plug connector.
We explicitly point out that, in accordance with
the Product Liability Act, we are not liable for
damages that were caused by our devices if
– worn or damaged parts were not repaired or
replaced on time.
– these damages were caused by improper
repair.
– when changing a part, our original parts or
parts authorised by us were not used.
– the repair work was not carried out by an au-
thorised service station.
The same applies for spare parts and
accessories.

11
Device description
3
6
4
7
8
9
14
10
12
13
15
11
2
1
5
16
1Protection bow
2Spark plug connector
3Silencer
4Ventilation grid
5Oil filler opening
6Starter grip
7Lever for lateral adjustment of handle-
bar
8Handlebar console
9Height adjustment of handlebar
10 Switching lever
11 Tank ventilation
12 Tank filler spout
13 Fuel valve
14 Type plate
15 Air filter
16 Cutting height adjustment

12
Control elements
C E A
FB
DGH
Accelerator lever with choke (A)
With the accelerator lever, you can change
the engine speed and thus control the engine
output.
Choke: Choke closed (only for
engine start when engine is
cold).
MAX: Full throttle
MIN: Idling
Start button (G)
Press and hold the start button during the start-
ing procedure (see Starting).
Drive lever and parking brake(B)
With the drive lever, you switch the drive and
the parking brake on and off.
Drive off/ parking brake
on(0):
Release the lever.
Drive on/ parking brake
off(I):
Press the lever towards
the handlebar and con-
tinue to hold.
Blade clutch lever (C)
The engine clutch lever is a guard device.
When you release the lever, the blade comes
to a standstill within 7seconds.
Uncouple blade (0):
Release the blade clutch
lever and set the acceler-
ator lever to MIN.
Couple blade(I):
Lift blade clutch lever, en-
gage latch knob(H) and
press the blade clutch lever
towards the handlebar. H
Engine stop switch(E)
Switch the ignition on and off with the
engine stop switch. When you switch
off the ignition, the engine is switched
off.
I: ON
0: OFF
Lever for lateral adjustment of
handlebar(D)
1. Release the eccentric tension lever.
2. Attention: Do not crush the Bowden cables
when pivoting the handlebar.
Swivel the handlebar to the side to the de-
sired position.
3. Clamp the handlebar with the eccentric ten-
sion lever.
Height adjustment of handlebar (9)
The height of the handlebar can be adjusted
via the screw of the handlebar height adjust-
ment (see Assembly).
Differential lock (F)
On (I):
Release the lever.
Off (0):
Press the lever towards
the handlebar and con-
tinue to hold.

13
Switching lever (10)
The transmission has 5 forward gears, idle and
a reverse gear. For shifting, release the drive
lever and shift to the next gear and start again.
R Reversing
N Idle speed
1-5 Moving forward
Fuel valve(13)
1
2
3
1: Reserve
2: Open
3: Closed
Information on mowing
Prior to mowing, check your device for com-
pleteness, proper functioning, and cleanliness.
A dirty ventilation grid causes overheating of
the engine, this can damage the engine. A dirty
protective grid at the silencer poses a fire haz-
ard.
Frequent engagement and disengagement of
the clutch increases wear of the blade drive
belt and the blade brake. Especially in case of
high grass, clutch engagement leads to over-
load.
To keep the area well maintained, mow fre-
quently and keep the grass short.
Only mow with a sharp and undamaged blade.
Have the blade sharpened and balanced regu-
larly (by authorised service centre).
Do not mow when the grass is wet or when it is
raining. The turf may be damaged and there is
a danger of slipping!
Turn the device around only in already mown
sections. Do not leave the device unattended
while the engine is running.
For mowing, always turn the accelerator lever
to full throttle to achieve the best mowing per-
formance.
To avoid blockage during ejection of the grass,
we recommend, for flat terrain, to proceed ac-
cording to the mowing patterns. The mulch is
shredded into much smaller pieces when you
mow the terrain once again in the opposite dir-
ection.

14
Prior to starting
Fuel
As fuel, use unleaded petrol (see operating in-
structions of the engine manufacturer).
You can use E10 petrol. Do not store E10 pet-
rol longer than 30 days.
Tanking up
Danger!
Fuel is ignited by hot engine parts.
Prior to filling up, switch off the en-
gine and wait for at least 20minutes
until the engine has cooled down.
Observe the safety instructions re-
garding the fuel!
Filling up with fuel
1. For filling, use a canister with filler spout or
a funnel.
2. Open the canister carefully so that existing
excess pressure is slowly reduced.
3. Open the tank cap carefully so that existing
excess pressure is slowly reduced and no
fuel sprays out.
4. Fill the fuel tank.
5. Tightly close the tank cap again.
Checking the engine oil level
Attention! Prior to each use, check the engine
oil level (see operating instructions of the en-
gine manufacturer).
Adjusting cutting height
Adjust the cutting height setting only when the
engine is switched off.
Set the cutting height so that the blade does
not touch the ground even in case of terrain
unevenness. If the cutting height is set too
high, objects can be ejected and the “clean cut
appearance” can be destroyed.
1
2
Fig.4:
The cutting height can be set to 2 positions.
1. Switch off the engine and wait until the
blade comes to a standstill.
2. Slacken 4 screws on each of the two
sides of the device.
3. Screw 4 screws into the desired position
on each of the two sides of the device.
(1) = higher cutting height
(2) = lower cutting height.

15
Starting
Danger!
During startup, there is a risk of in-
jury caused by the rotating blade.
Make sure that no one is within the
danger zone of the blade. Do not tip
the device over to one side during
startup.
Danger!
If after startup the carburetor does
not close properly, fuel will overflow
and a fire hazard occurs.
Close the fuel valve and contact an
authorised service centre.
Starting the device
1. Place the device onto a flat surface, not in
high grass.
2. Open the fuel valve and the tank ventila-
tion.
3. Plug on the spark plug connector.
4. Set the engine stop switch to "I".
5. For cold start, set the accelerator switch to
position "choke"; otherwise, set it to me-
dium speed.
6. With your left thumb, press the start button
and continue to hold.
7. Pull the starter point slowly out until you
feel resistance then pull out quickly – en-
gine starts to run.
8. Let the starter rope retract slowly.
9. Release the start button.
10. For mowing, set the accelerator lever to the
maximum speed.
Engaging the blade
1. Lift the blade clutch lever.
2. Press the latch knob at the blade clutch
lever.
3. Press the blade clutch lever towards the
handlebar – the blade starts to move.
Disengaging the blade when moving over
paths:
1. Release the blade clutch lever.
Oil pressure switch
The oil pressure switch ensures that the en-
gine is not damaged when the device is used
in steep terrain.
The oil pressure switch switches off the engine
when damage to the engine may occur due to
lack of oil pressure. This may occur when:
– Oil level is too low.
– The device is in too steep a sloping position
while in steep terrain.
How steep the gradient for the oil pressure
switch to switch off the engine may be de-
pends on the engine type, direction of inclina-
tion, and the oil level.
In order to restart the engine, push the device
while in idle state to terrain that is less steep.
In every case, check the oil level.

16
Driving
Driving
In case of a hazardous situation, switch off the
drive and declutch the blade.
Drive on:
1. Engage the desired gear.
2. Press the drive lever towards the handlebar
- device is moving.
Drive off:
1. Release the drive lever.
Adjusting the driving speed:
The driving speed depends on the quantity and
thickness of the growth. If the growth is espe-
cially high and thick, you can mow at low driv-
ing speed only.
1. Release the drive lever.
2. Engage the desired gear.
3. Press the drive lever back towards the
handlebar – device is moving.
Reverse gear
Danger!
Risk of injury caused by slipping or
tripping during moving in reverse or
turning.
When moving in reverse, always
switch off the blade!
Prior to switching on the reverse, make sure
that path is free of obstacles. Especially when
going over already mowed grass ensure safe
footing.
1. Release the drive lever.
2. Disengage the blade.
3. Set the accelerator lever to medium speed.
4. Set the switching lever to reverse (R).
5. Press the drive lever towards the handlebar
- device moves in reverse.
Turning
Turn the device round only where the grass
has been mowed already.
Turning round on an even surface:
1. Switch off the drive and the differential lock.
2. Turn the device to the desired side.
3. Switch the drive and the differential lock
back on.
Turning round on a sloping area:
1. Disengage the blade.
2. Keep the drive switched on.
3. Switch off the differential lock.
4. Turn the device upslope.
5. Hold back the handlebar and the inner
wheel.
6. Switch the differential lock back on.
The drive prevents sliding and supports the
turn manoeuvre.
Pushing
1. Release the drive lever.
2. Put the gear in neutral.
3. Press the drive lever again towards the
handlebar – device can be pushed or rolls.
Differential lock
The differential lock connects the rear wheels
rigidly to each other. This improves traction
and driving stability of the device. The danger
of slipping is reduced and safe braking is made
possible.
When the differential lock is released, the
device can be steered and turned with ease.

17
Switching off and parking
Caution!
On a slope, the device can roll
away.
Put the device on even ground only
or secure it against rolling away.
1. Release the drive lever.
2. Set the accelerator lever to the lowest en-
gine speed.
3. Release the blade clutch lever.
4. Set the engine stop switch to "0".
5. Wait until the engine comes to a standstill
before you step away from the device.
6. Close the fuel valve and the tank ventila-
tion.
7. Pull off the spark plug connector.
Transport
Warning!
Risk of injury due to the heavy
weight of the device. The device can
fall over and fall down and cause
severe injuries.
Observe the following notices.
Transport the device on a freight vehicle or a
trailer which is designed for a carrying capacity
of at least as great as the empty weight of the
device.
Prior to transport, let the device cool down for
at least 20 minutes. Close the tank ventilation
and the fuel valve.
For transport, you can fold up the handlebar.
Loading
Use suitable ramps for loading that
– can carry the empty weight of the device +
200 kg.
– are wider than the device.
– have a slip-free surface.
Notice!
Risk of damage due to incorrect
fastening of straps.
Fasten the straps only at the points
shown in the figure.
Do not overtighten the straps.
1. Put the device in front of the ramps and
make sure that the ramps
– are as wide as the wheel gauge of the
device.
– are tightly secured to the platform.
– are not steeper than 15°.
2. Carefully drive the device via the ramps
onto the platform.
3. Secure the device against rolling, sliding,
tilting, and fuel leakage. Use straps that
support the weight of the device.
Fig.5:

18
Fig.6:
4. Secure the device with belts to the frame
elements that can hold the weight
Unloading the device
1. Undo the transport fastenings.
2. Drive the device carefully down the ramps
of the platform.
Maintenance
Warning!
Risk of injury due to unexpected
movement. When inspections are
carried out, the device can move un-
expectedly.
Make sure that no persons or ob-
jects are in the danger area of the
blade.
Make sure that no further hazards
result from an unexpected move-
ment.
Warning!
Risk of injury during maintenance
and cleaning work when the engine
is running.
Perform maintenance tasks only
then with a running engine if this is
required in the Maintenance table.
Prior to all maintenance and cleaning work
when the engine is not running:
1. Let the device cool down for at least 20
minutes.
2. Pull off the plug connector.
3. Close the fuel valve and the tank ventila-
tion.
4. For work on the bottom side of the device,
flip the device to the silencer side.
Improper maintenance can make the device
unsafe for operation and result in accidents.
Regular maintenance keeps your device ready
for use.
Service the device according to the following
maintenance instructions.
Contact an authorised service centre if prob-
lems during maintenance occur or if you de-
termine deficiencies during one of the following
inspections.

19
Maintenance overview
Component Action Maintenance
interval
A B
Device Check for safe working condition (basic inspection). ■ ▲
Clean. ■
Customer service. ▲
Fuel Check fuel level. ■
Is the tank cap closed? ■
Tank, fuel valve,
and fuel line
Check parts for leaks and check for good condition. ■ ▲
Carburetor Does the carburetor close again after starting? ■ ▲
Ventilation grid Clean. ■ ▲
Engine cooling Clean. ▲
Spark plug Check/replace. ▲
Air filter Maintain. ■ ■▲
Blade and fasten-
ing components
Check for wear and damage. See chapter Checking the
blade.
■ ▲
Change. ▲
Blade brake Does the blade function safely and does the blade come to
a standstill within 7 seconds?
□ ▲
Release the drive
lever
Does the device stop when the lever is in zero position? □ ▲
Drive Check. ■ ▲
V-belt Are the belts tensioned correctly, without fissures, and in
good condition?
▲
Bowden cables Check for proper function and ease of movement. ■ ▲
Acceleration lever Check for proper function. □ ▲
Chassis and impact
protection
Check for rust and fissures and check the welding seams. ■ ▲
Are all protective devices and covers in place, fastened
correctly and properly functioning?
■ ▲
Label Condition of the labels. ■ ▲

20
Engine For reliable information, see the operating manual of the
engine manufacturer.
■ ▲
Check oil level (see operating instructions of the engine
manufacturer).
■ ▲
Oil change. ▲
Oil filter change. ▲
Parking brake Check. ■ ▲
Flammable material Remove easily flammable debris buildup from the engine
and the device.
■ ▲
Tyres Check tyres and, if necessary, the tyre pressure. ■ ▲
Skids Check/replace. ■ ▲
A
B
■
□
▲
Before and after each use.
Annually or every 50 h.
By the user when the engine is not running.
By the user when the engine is running.
By the authorised service centre.
