Asada 200SP User manual

RECIPROCATINGSAW
PIPESAW200SP
IM1402
【Pleasereadthismanualbeforeoperating.】
INSTRUCTIONMANUAL
WithChainVise

PIPE SAW 200SP
1
 SAFETYINSTRUCTIONS....................... 2
 OPERATINGINSTRUCTIONS.............. 5
 PARTSIDENTIFICATION....................... 7
  NameofParts............................................. 7
  Specications.............................................. 7
  StandardAccessories................................ 8
  OptionalAccessories................................. 8
 PREPARATIONSBEFORE
 STARTINGOPERATION......................... 9

ConrmationoftheEarthLeakageCircuitBreaker .... 9
  ExtensionCord ........................................... 9

MaintainingandCheckingtheWorkingEnvironment .... 9
 HOWTOOPERATETHEMACHINE
.........10
  HowtoSettheSawBlade........................10
  HowtoSettheSaberSawBlade............12
  CuttingwithChainVise............................13
  CuttingwithoutChainVise.......................15
  AdjustmentofSawBladeSpeed.............16
  TheOver-LoadProtector..........................16
 DAILYINSPECTIONANDCARE.........17
 TROUBLESHOOTING..............................18
Denotesthatincorrecthandlingcancausedeathorinjurytotheuserand
others.
Inthismanualandonthemachine,thesafetyinstructionlevelsareclassiedinto
asfollowingthreelevels.
SAFETY PRECAUTIONS
DEFINITIONS OF THE DANGER, WARNING, CAUTION SYMBOLS
CONTENTS
Denotesthatincorrecthandlingcancauseuserinjuryorphysicaldamage.
Denotesthatincorrecthandlingwouldcause immediatedeathorinjuryto
theuserandothers.
ThankyouforchoosingthePIPESAW200SP.
●Thismanualshouldbehandedovertotheenduser.
●Thecontentofthismanualmustbethoroughlyreadandunderstoodsecurely
beforeoperating.
●Pleasesavethismanualforimmediatereferencewhenrequired.
●Usethemachinefortheintendedapplicationonly.
Thismachineisdesignedtocutexistingpipesandanglesofsteel,stainless
steel,PVC,etc.
●Checkthefollowingassoonthemachineisdelivered:
 ・ Isthespecicationsameastheorderedproduct?
 ・ Isthereanydamageordeformationcausedduringdeliverytransit?
 ・ Isthereanyshortageofaccessories?
 Ifanydissatisfactionisfound,pleasecontactwiththestoreyouhavepurchasedorour
salesdepartment.
（Thecontentsofinstructionmanualwillbechangedwithoutnoticeforqualityimprovement.）
WARNING
CAUTION
DANGER

PIPE SAW 200SP
2
●Topreventaccidentssuchasre,electricalshockandinjury,alwaysfollowthe
"SAFETYINSTRUCTIONS"describedbelow.
●Beforeusingthemachine,readall"SAFETYINSTRUCTIONS"touseitcorrectly
accordingtotheinstructions.
●Afterreading theinstructions,savethismanualsothatyoucanreaditwhen
necessary.
SAFETY INSTRUCTIONS
◆ Operate the machine on the correct voltage.
 Alwaysusethemachineattheratedvoltageindicatedinthemachineplateor
instructionmanual.
Otherwise,themachinewilloverheat,emitsmokeorcatchre.
◆ Make sure that the switch is OFF before plugging the machine in.
 Beforepluggingthemachinein,alwaysmakesurethattheswitchisOFFtoavoid
accidentorinjury.IftheswitchisON,themachinewillstartsuddenly,leadingto
unexpectedaccident.
◆ Guard against electrical shock.
 Donottouchtheplugwithwethands.
Donotexposethemachinetorainandwater.
Alwaysgroundthemachinetoavoidelectricalshock.(Exceptthedouble-insulated
machine)
◆ Avoid dangerous environment.
 Donotexposethemachinetorainorwateranddonotuseitindamporwet
locations.Humiditywilldeterioratemotorinsulationorleadtoelectricalshock.
Donotusethemachineinthepresenceofammableliquidsorgasessuchas
gasolineandthinner.Otherwise,ignitionorexplosionmaytakeplace.
◆ Use safety goggles.
 Wearsafetygoggleswhileoperatingthemachine.Alsouseafaceordustmaskif
operationcreatesdust.Sawdustanddirtmayenteryoureyesandnose.
◆ Secure work piece.
 Useclampsoraviseasdescribedinthemanualtoholdaworkpiecesecurely.
Aninsecureworkpiecewillleadtoaccidentorinjury.
◆ Use only the specied accessories and attachments.
 Useonlytheaccessoriesandattachmentsgiveninthismanualandourcatalogs.
Afailuretodosowillleadtoaccidentorinjury.
◆ Never touch the saw blade and moving parts until you have
conrmed a complete stop.
 Thesawbladeandotherpartscoastforawhileaftertheswitchisturnedo󱐯.Never
touchthemwhiletheyaremoving.
Whenitisrequiredtotouchthesawbladeandmovingpartsforreplacement,etc.,
switcho󱐯themachineandunplugitbeforestartingtheoperation.
 Ifthemachineremainspluggedin,itwillstartsuddenly,leadingtoaccidentorinjury.
SAFETY INSTRUCTIONS
WARNING

PIPESAW200SP
3
◆Switchoffandunplugthemachineinthefollowingcases.
 ・Whennotinuseorwhenservicing,cleaning,checkingorreplacingparts.
・Whenreplacingaccessoriessuchassawblade.
・Whenhazardispredictable(includingapowerfailure).
 Ifthemachineremainspluggedin,itwillstartsuddenly,leadingtoinjury.
◆Ifyoufeelsomethingunusual,stopthemachineimmediately.
 Immediatelystopthemachineifsomethingiswrongwiththemachineoryou
havenoticedunusualsmell,vibration,soundetc.duringoperation.Referto"P.18
TROUBLESHOOTING"inthismanualandfollowthecorrespondinginstructions.
Ifyouusethemachinewithouttakinganyaction,itwilloverheat,emitsmokeortake
fire,leadingtoaccidentorinjury.
 Ifthemachinehasemittedsmokeortookfire,donotdisassembleitbuthaveit
inspectedorrepairedbyaqualifiedperson.
◆Keepyourworkareaclean.
 Keepyourworkbenchandareatidyandwelllit.
Clutteredareasandbenchesinviteinjury.
◆Keepvisitorsaway.
 Donotletvisitorstouchthemachineandpowercordoroperatethemachine.
Allvisitors,especiallychildren,shouldbekeptawayfromtheworkareatoavoid
injury.
◆Donotforcethemachine.
 Usethemachinefortheintendedapplicationonly.
Itwilldoabetterjobandbesaferattherateforwhichitwasdesigned.
Forcingthemachinewillnotonlyinviteproductdamagebutalsoleadtoaccidents.
Avoidforcibleusagewhichwillcausethemotortolock.Asmokeorfiremayoccur.
◆Wearproperapparel.
 Donotwearneckties,open-sleevedclothing,knittedgloves,looseclothingorjewelry
(suchasnecklaces).Otherwiseyoumaygetcaughtinmovingparts.
 Rubberglovesandnon-skidfootweararerecommendedwhenworkinginoutdoors.
Slipperyglovesandfootwearwillleadtoinjury.
 Wearcapsorprotectivehaircoveringtocontainlonghair.Otherwise,youmayget
caughtinmovingparts.
 Wearcrashhelmets,safetyshoes,etc.accordingtoyourworkingenvironment.
◆Donotoverreach.
 Keepproperfootingandbalanceatalltimes.Youmaytumbleandgethurt.
◆Removewrenchesandotherhandtools.
 Beforeturningonthemachine,makesurethathandtoolsusedforinspectionor
adjustmentareremovedfromthemachine.
Accidentorinjurymayoccurifyoustartthemachinewithhandtoolsonit.
SAFETYINSTRUCTIONS
WARNING

PIPE SAW 200SP
4
◆ Stay alert.
 Watchwhatyouaredoingandusecommonsensewhileworking.
Carelessnesswillleadtoaccidentorinjury.
Donotoperatethemachinewhenyoucannotconcentrateonyourwork,e.g.when
youaretiredorwhileundertheinuenceofalcohol,medicationordrugs.Otherwise,
accidentorinjurymayoccur.
◆ Do not abuse the power cord.
 Nevercarrythemachinebythecordoryankitfromthesocket.
Keepthecordawayfromheat,oil,grease,knivesandsharpedges.
Wirethecordwithcare.Donotrunthecordwhereitmaybestamped,caughtor
damagedbyanything.Otherwise,youmaygetelectricalshockorthecordmaybe
shortedtocauseare.
◆ Maintain the machine with care.
 Keepthesawbladesharpandcleanforbetterandsaferperformance.
Ifthesawbladeusedisworn,damagedorimproperforanintendedpurpose,the
motorandmachinewillbeoverloaded.Thismaycausethemachinetogenerateheat,
emitsmokeorcausere,oryoumaygetinjured.
Followinstructionsforreplacingaccessories.
 Inspectthepowercordandplugbeforeuse.Ifdamaged,havethemrepairedbyour
salesrepresentative.
Otherwiseyoumaygetelectricalshockorthemachinemaybeshortedtocausere.
 Keephandlesdry,cleanandfreefromoilandgrease,whichmayleadtoinjury.
◆ Check damaged parts.
 Beforefurtheruseofthemachine,aguardorotherpartthatisdamagedshouldbe
carefullycheckedtodeterminethatitwilloperateproperlyandperformitsintended
function.
 Checkthemachineforalignmentofmovingparts,bindingofmovingparts,breakage
ofparts,mountingandanyotherconditionsthatmaya󱐯ectitsoperation.
 Donotusethemachinewhenitsplugand/orcordisdamaged.
Youmaygetelectricalshockorthemachinemaybeshortedtocausere.
 Donotusethemachineifitsswitchdoesnotturnitonando󱐯.
 Aguardorotherpartthatisdamagedshouldbeproperlyrepairedorreplacedbyan
authorizedservicecenterunlessotherwiseindicatedinthisinstructionmanual.
◆ Store the idle machine tidily.
 Whennotinuse,machinesshouldbestoredindryandhighorlocked-upplace–
outofreachofchildren.
◆ Have your machine repaired by a qualied person.
 Ourproductsareinaccordancewiththerelevantsafetyrules.Donotmodifythem.
Repairsshouldonlybecarriedoutbyoursalesrepresentative.
Otherwisethemachinemaynotshowitsperformanceoryoumaygetinjured.
◆ If any label applied to the machine, etc. has come o󱐯, always ask for
a new label and apply it in position.
SAFETY INSTRUCTIONS
WARNING

PIPE SAW 200SP
5
◆ Do not cut a pipe which contains live gas or residual gas.
Sparksorcuttingheatfromthemotorcancauseignitionorexplosion.
◆ Do not operate the machine near hazardous materials such as
ammable gasoline, gas and thinner.
Theycancauseignitionorexplosion.
◆ In case to cut a pipe with water remaining inside, avoid being
splashed water onto the machine.
Ifthemachineissplashed,itwillleadtoelectricalshock.
Waterwillcomeintothegearbox,andthegearswillgetdamaged.
●Inadditiontothegeneralinstructiongivenabove,followtheprecautionsgiven
belowbeforeoperatingthePIPESAW200SP.
OPERATING INSTRUCTIONS
◆ Operate the machine with the voltage indicated in the machine plate.
 Iftheoperatingvoltageishigherthanindicated,themachinewillrunatabnormally
highspeed,causinginjury.Iftheoperatingvoltageishigherthanindicated,heat,
smokeorsparksmaybegenerated.
◆ Before starting operation, fully check for underground objects such as
conduit pipes, water pipes and gas pipes near the place of operation.
 Iftherearesuchobjects,thesawblademaytouchanyofthemandelectrical
shocks,electricleaksorgasleakswhichwillcauseaccidentsmayoccur.
◆ Hold the machine body securely during operation.
 Ifyoudonotholditsecurely,youmaygetinjured.
◆ If the machine is not in good order or generates unusual noise,
immediately switch it o󱐯 to stop operation and request your sales
representative for inspection or repair.
 Ifyoucontinuetousethemachine,youmaygetinjured.
◆ If you have dropped or hit the machine accidentally, carefully check
its saw blade, body, etc. for damage, crack or deformation.
 Damage,crackordeformationtothesawbladeormachinebodywillleadto
accidentorinjury.
◆ Before changing the saw blade, always disconnect the power cord.
 Otherwise,themachinewillstartrunningsuddenly,causinginjury.
◆ Install the saw blade to the machine correctly.
 Otherwise,ifthesawbladecomeso󱐯,youmaygetinjured.
◆ During operation, keep your hands, face, etc. away from the saw
blade and chip ejector.
 Otherwise,youmaygetcaughtbythesawblade,causinganaccidentorinjury.
OPERATING
INSTRUCTIONS
WARNING
DANGER

PIPE SAW 200SP
6
◆ When carrying the machine, disconnect the power cord.
 Otherwise,themachinewillrunsuddenly,causinganaccidentorinjury.
◆ Never touch the saw blade, chips and work piece immediately after
cutting operation.
 Immediatelyaftercuttingoperation,theyarehotandyoucangetburntorinjured.
◆ Pay attention not to cut the power cord by the saw blade.
 Youmaygetelectricalshock.
◆ Before starting operation at a high place, fully make sure that there
is no one under you.
 Anaccidentcanoccurifyoudropaworkpieceorthemachine.
◆ When you cut a pipe near an obstacle such as a wall or an adjacent
pipe, leave an enough clearance to prevent the nose of the saw blade
from making contact with the obstacle.
 Themachineorthesawblademaybebroken.
◆ Do not cut the work piece which requires more than capacity.
 Ifcuttheworkpiecewhichrequiresmorethancapacity thesaw blademay be
broken.
◆ Use the Asada genuine saw blade.
 Ifusetheothersawbladetheremaybeapossibilitytocauseaccidents
unexpectedly.
OPERATING
INSTRUCTIONS
CAUTION

PIPE SAW 200SP
7
PARTS IDENTIFICATION
PARTS
IDENTIFICATION
Name of Parts
Specications
Description PIPESAW200SP
Cutting
Capacity
Steelpipe 1/2"–8"
＊Abletocut8"pipewithoptionalsawblade（No.61471）
Stainless
Steelpipe
1/2"–4"（thickness:4㎜orless）
1/2"–6"（thickness:3㎜orless）
Motor
UniversalMotor;Single-Phase1500W50/60Hz
Stroke 26㎜
No-loadStroke/Min 700–2060min-1
（spm）
WeightandSize
MainBody 3.9kg/L480×W92×H93㎜
ChainVise 1.2kg
PlasticBox 1.9kg/L650×W305×H130㎜
MainBody
Motor
ChainVise
RubberCover
GuidePlate
SawBlade Dial TriggerSwitch
CarbonCap
＊Voltage:madetoorder.
＊Specicationswillbechangedwithoutnoticeforqualityimprovement.

PIPESAW200SP
8
StandardAccessories
OptionalAccessories
CodeNo. Description pcs/set
Cutting
Capacity
Remarks
61210 SawBlade140×8T 5pcs 2" SteelPipe,AngleSteel
61305 SawBlade200×8T 5pcs 4" SteelPipe,AngleSteel
61327 SawBlade200×6/8T 5pcs 4" SteelPipe,AngleSteel
61337 SawBlade290×6/8T 5pcs 6" SteelPipe,AngleSteel
61471 SawBlade320×6/8T 5pcs 8" SteelPipe,AngleSteel
61369 SawBladeSuperHSS140×14T 5pcs 2" StainlessSteelPipe
61370 SawBladeSuperHSS140×6T 5pcs 2" StainlessSteelPipe
61371 SawBladeSuperHSS200×8T 5pcs 4" StainlessSteelPipe
61372 SawBladeSuperHSS200×6T 5pcs 4" StainlessSteelPipe
61458 SawBladeSuperHSS270×6T 5pcs 6" StainlessSteelPipe
61459 SawBladeSuperHSS270×8T 5pcs 6" StainlessSteelPipe
61363 SaberSawBlade（BI-METAL）100×18T 10pcs 1" StainlessSteelPipe
61358 SaberSawBlade（BI-METAL）150×10T 10pcs 2" StainlessSteelPipe
61359 SaberSawBlade（BI-METAL）150×14T 10pcs 2" StainlessSteelPipe
61360 SaberSawBlade（BI-METAL）150×18T 10pcs 2" StainlessSteelPipe
61361 SaberSawBlade（BI-METAL）200×14T 10pcs 4" StainlessSteelPipe
61362 SaberSawBlade（BI-METAL）200×18T 10pcs 4" StainlessSteelPipe
61460 SaberSawBlade（BI-METAL）250×14T 10pcs 5" StainlessSteelPipe
61461 SaberSawBlade（BI-METAL）250×18T 10pcs 5" StainlessSteelPipe
PlasticBox1pce
（No.PS443）
ChainVise1pce
（No.61386）
AllenWrench(4)1pce
（No.86002）
SawBladeSuperHSS
200×8T1pce（No.61371）
270×8T1pce（No.61459）
●No.ST014ThreadingOilWhite1pce
●SAWBLADEFORPIPESAW200SP
PARTS
IDENTIFICATION

PIPE SAW 200SP
9
PREPARATIONS BEFORE STARTING OPERATION
Conrmation of the Earth Leakage Circuit Breaker
Maintaining and Checking the Working Environment
Extension Cord
Sincethisproducthasadouble-insulatedstructure,thelawdoesnotrequireitto
installanearthleakagecircuitbreaker.Topreventelectricalshock,however,itis
recommendedtoconnectthemachinetothepowersupplywhichisprovidedwith
anearthleakagecircuitbreaker.
Makesurethattheworkingareaiskeptproperasdescribedinthe"SAFETY
INSTRUCTIONS"and"OPERATINGINSTRUCTIONS".
①Whenanextensioncordisrequiredforusewithadistantpowersupply,it
shouldbethickenoughtocarrycertaincurrentandasshortaspossibleto
ensurethattheproductisusedwiththemaximume󱐰ciencywithoutafailure.
②Followingchartshowsmaximumlengthoftheextensioncorddependingonthe
thickness(sectionalareaofthecorewire)whichapplicabletothemachine.
●Beforeoperatingthemachine,makethefollowingpreparations:
◎Noiseiscontrolledassetforthinrelevantregulations.Themachinemustbe
operatedatlessthantheregulatednoisetoavoiddiscomforttotheneighborhood.
Soundbarriersmayberequiredundersomecircumstances.
Noise Prevention Control
◆ The extension cord used should be without damage.
 Afailuretodosomayresultinelectricalshockorshort,causingaspark.
Sectionalareaofthecorewire Maximumlength
1.25㎜210m
2.0㎜215m
3.5㎜230m
PREPARATIONS BEFORE
STARTING OPERATION
WARNING

PIPE SAW 200SP
10
HOW TO OPERATE THE MACHINE
①LoosentheClampBoltbyAllenWrench.
●
Beforestartingoperation,alwaysreadtheinstructionsin"SAFETYINSTRUCTIONS"
and"OPERATINGINSTRUCTIONS"(pages2to6).
◆ In order to prevent the accident, pull out the plug from the receptacle.
 Themachinewillstartrunningsuddenly,itwillleadtoaccidentsorinjuries.
◆ Never touch the saw blade, chips and work piece immediately after
cutting.
 Immediatelyaftercuttingoperation,theyarehotandyoucangetburntorinjured.
◆ Always use the power supply indicated in the machine plate.
 Iftheoperatingvoltageishigherthanindicated,themotorwillrunatabnormally
highspeed,whichmaydamagethemachine.
 Ifusethemachineatovervoltageindicatedinthemachineplateorinstruction
manual,themachinemaybecomehot,emitsmokeorcatchre.
◆ Make sure that the switch is o󱐯 before plugging the machine in.
 PulltheTriggerSwitchtoturnonandreleasetoturno󱐯.Alwaysmakesurethatthe
TriggerSwitchreturnswhenyoureleasethetriggerpulled.
 Ifyouinserttheplugintothereceptacle,notknowingtheswitchison,themachine
willstartabruptly,leadingtoanunexpectedaccident.
◆ In case to use engine generator, use the engine generator which
output capacity is more than 2.8KVA with inverter control type.
 Ifuseenginegeneratorwithoutinvertercontrol,themachinewillbebroken.
How to Set the Saw Blade
ClampBolt
loosen tighten
HOW TO OPERATE
THE MACHINE
WARNING
WARNING
CAUTION

PIPESAW200SP
11
②InsertthesawbladebetweentheBladeHolderandtheSawGuide,andputthe
projectionofholderintotheholeofblade.
③SoftlytightentheClampBolt,andaftertheconfirmationthatthesawblade
doesnotcomeoff,tightenitstrongly.
SawGuide
＊ThisillustrationshowsthemachinewithoutGuidePlate.
Positiontoinsert 
theSawBlade
SawBlade
(AsadagenuineParts)
Hole
BladeHolder
BladeHolder
Washer
ClampBolt
Projection
SawGuide
◆Ifthetighteningboltcomesloose,thesawbladewillcomeoffand
themachineorsawbladewillbedamaged,causingaccidentsor
injury.
HOWTOOPERATE
THEMACHINE
CAUTION

PIPESAW200SP
12
BladeHolder BladeHolder
SawGuide SawGuide
Asadagenuinesawblade Generalreciprocationsawblade
①RemoveClampBoltandGuidePlate.
②
LoosentheClampBolt,takeouttheWasher. 



③TakeouttheBladeHolder.
④ReversetheBladeHolderandtightenitbytheClampBolt.
HowtoSettheSaberSawBlade
ClampBolt
loosen tighten
ClampBolt
GuidePlate
HOWTOOPERATE
THEMACHINE

PIPE SAW 200SP
13
◆ Do not run the machine without the saw blade making contact with the
work piece.
 Thesawblade maybebrokenbyoscillationandthebrokensawblade mayhurt you.
Turnontheswitchwiththesawbladepressingagainsttheworkpiece.
◆ Do not remove the rubber cover. Always hold the machine body on the
rubber cover.
◆ Do not t the chain vise on the cut-o󱐯 end of the work piece.
 Otherwise,theworkpieceandthemachinewilldroptogetheraftercut.
◆ Do not cut a pipe of a large diameter which is over capacity.
 Otherwise,the noseof thesaw blademaymakecontactwith theinner wallofthe pipe,
breakingthesawblade.
◆ Do not force the machine during cutting. Put light force on it to cut.
 Otherwise,thesawblademaybebrokenoritsservicelifeshortened.
◆ Fix the work piece securely.
 Machineoperationwithoutxingtheworkpiecemaycauseofunforeseenaccidentorinjury.
◆ When cutting stainless steel pipe, use threading oil (Optional accessory:
Asada Threading Oil White, No.ST014).
 Cuttingstainlesssteelpipewithoutoilcauseofdrasticallyshortenedtheservicelifeofthe
sawblade.
◆ When operate the machine, take care that contamination like cutting chip,
mud, water and so on do not enter into the machine. When contamination
collects at Saw Guide, clean it each time.
◆ When cut steel pipe, use Chain Vise for stable operation and better
performance.
Cutting with Chain Vise
Hook
HooktheChainon
achainvisehook
1
2
tighten
Cuttingposition
＊Cuttingpointvariesdependingon
mountingpositionofthepipesaw.
＊
VisePin
①FixtheChainVisetotheworkpiecesecurely.Fixtheworkpiecesecurelyby
Vise,iftheworkpieceisnotxedunlikeinstalledpipe.
HOW TO OPERATE
THE MACHINE
WARNING
CAUTION

PIPE SAW 200SP
14
②PushtheMainBodyintoVisePin.Atthistime,conformtheVisePinintothe
holeofMainBody.
③LoosentheChainVise,conformthesawbladeatthecuttingposition,and
thenagainxitsecurely.
④PulltheTriggerSwitchtoturnthemachineonwiththesawbladepressing
againsttheworkpiece.Liftthegripupandcuttheworkpieceslowly.
Forcuttingspeed,refertothebelowchart.
⑤ForremovingthemainbodyfromtheChainVise,pulloutthemainbody
pushingtheendoftheVisePinwiththumb.
＊Indicatedcuttingtimesareaverages.Itmaytakelongerundertheconditionof
thesawbladeandalsothecuttingmaterial.
＊Adjustthesawbladespeedatcuttingcondition.Ifthewagglewidthofthe
sawbladeiswideorthesawbladechip,adjustthesawbladespeedslower.
Cuttingmaterial Size Dialindication Cuttingtime
SteelPipe
2"
6
15sec
4" 1min
6" 2min
8" 4min
StainlessPipe
2"(t=3)
1
2min
4"(t=3) 4min
6"(t=3) 9min
Grip
Workpiece
SawBlade
PulltheTriggerSwitchtoturnthemachineon
withpressingthesawbladeagainsttheworkpiece.
TriggerSwitch
VisePin
HOW TO OPERATE
THE MACHINE

PIPE SAW 200SP
15
◆ Please use Chain Vise when you cut large size of steel pipe (more
than 2 1/2").
 Cuttinglargesizeofsteelpipe(morethan21/2")ishardwithoutChainVise.
◆ Press the Guide Plate against the work piece at cutting.
 Thesawblademaybebrokenduetovibration.
◆ Hold the machine body and the Grip rmly during cutting.
 Ifnot,letgoofthemachineandcauseunforeseenaccident.
Cutting without Chain Vise
①Putthesawbladeatthecuttingpositionoftheworkpiece.
②PresstheGuidePlatehardagainsttheworkpiece,thenpulltheTriggerSwitch
toturnthemachineon.
Workpiece
GuidePlate
TriggerSwitch
HOW TO OPERATE
THE MACHINE
CAUTION

PIPE SAW 200SP
16
◆ Adjust the saw blade speed under no load.
 Itistoodangeroustoadjustthesawbladespeedduringcutting.
◆ Do not operate the machine for long time at low saw blade speed.
 Themotorwillbeforced,causingburnout.Especiallyavoidforcibleusagewhich
willleadtoasawbladestopduringcutting.Adjustthesawbladespeedsothat
themachinecuttheworkpiecesmoothly.
◆ In case of the saw blade chip, operate the machine at lower speed.
 Ifthebladespeedistoomuchhigh,thesawbladewouldbechipped.
◆ If the waggle width of the saw blade is wide, adjust the saw blade speed lower.
 Ifthewagglewidthofthesawbladeiswide,thesawbladewouldbebrokenbeforecutting.
Adjustment of Saw Blade Speed
The Over-Load Protector
●Thismachineisequippedwithanelectroniccontrolcircuitofvaluablesaw
bladespeedcontroller.
 Thedialindicationof"1"denotesthelowestspeedand"6"thehighestspeed.
 Highspeedissuitableforsoftsteelpipesandlowspeedforstainlesssteel
pipes.Usetheappropriatespeedinresponsetotheworkpieceandoperating
conditions.
●ThemachineisequippedwithOverLoadProtector.Whenthemotorgets
heateduptothecertaintemperatures,themotorautomaticallystopandyou
cannotturnthemachineonforawhile.
 Donotusethemachineuntilthemotorisfullycooleddown.
 Afterthemotorfullycooleddown,themachinecanbeusedagain,howeveras
themotorisstillheated,cutwithoutexcessiveforce.
Dial
Dialsettingposition
Indication
◎Whenyoucutstainlesssteelpipe,theOver-loadProtectormaybeworkedifyou
cutintotoofastasthesawbladespeedisslow.
HOW TO OPERATE
THE MACHINE
CAUTION

PIPE SAW 200SP
17
Maintenance&Inspaction Action
Checktheplugandpower
cordfordamage. Replaceifanydamageisfound.
Checkthesawbladefor
chippingordamage.
Replaceifchipping isfound.(Forthesawbladereplacing
procedure,refertopage10"HowtoSettheSawBlade".)
CheckCarbonBrushes.
IfthelengthofCarbonBrushes
weardownto around6mm, it
mustbechanged. Changeboth
ofleftandrighttonewonesat
thesametime.(CodeNo.PS413
CarbonBrushsetforPS200SP)
Howtochange
①Withaminusdriver,take
o󱐯theCarbonCapatthe
MotorCase.
②Takeout theCarbon
Brushesandchangethem
tonewones.
Checkifscrewsareloosen
andtightthemupifneeded.
Retightenanyloosedscrews.
Howtohandlethemotor.
Thecoilof themotor isthe heartof themachine.
Handlewithextreme careto protectit fromscratches
andnotto beexposed tocleaningoilandwater.Dirt
anddustaccumulating inthe motorwill causeafailure.
Afteroperationofabout 50hours, runthe motorunder no
loadandblownon-humid airthrough thewindholeofthe
housing.Thishelpsremovedirtanddust.
ChecktheSawGuidecarefully
thatthereisnochips,mud,
sand,waterandsoon.
Ifchips,mud,sand,water,etc.remain stickingto theSaw
Guide,theSawGuidewillrustandleadtoafailure.Always
cleantheSawGuidebeforestoringthemachine.
Removestainfromthe
machineandkeepclean.
Theouterframeof themachine ismadeof rigidsynthetic
resin.However itssurface willbedamaged bygasoline,
thinner,petroleumandkerosene.Whencleaning, wipeits
surfacewithadryclothoraclothimmersedinsoapsuds.
Keeptheminsafeanddry
places.
Donotstorethemachineatfollowingplaces:
・Atchildrencanreachandtakethemachineeasily.
・Atexposedtorainorhumidity.
・Atsuddentemperaturechanges.
・Underdirectsunlight.
・Nearvolatilematerialwhichmayigniteorexplode.
DAILY INSPECTION AND CARE
●Check,cleanandrepair/replacethefollowingareasregularly.
◆ Before starting inspection or maintenance, always turn the switch
o󱐯 and disconnect the attachment plug from the receptacle.
 Themachinewillstartrunningsuddenly,itwillleadtoaccidentorinjury.
6㎜
CarbonCap
DAILY INSPECTION
AND CARE
WARNING

PIPE SAW 200SP
18
TROUBLESHOOTING
Phenomenon Cause Measures
PowerIssue/
Machinenot
working
DamagedPowerCord Replacethepowercordifdamagesare
found.
Lowvoltage
Whentheextensioncordistoolongor
toothin, see"ExtensionCord"onP9
anduseaproperextensioncord.
WorkingOver-load
Protector
Makesure thatthemotoriscooled
downenough, and then turn onthe
switchagain.
Insu󱐰cient
power Lowvoltage
Whentheextensioncordistoolongor
toothin, see"ExtensionCord"onP9
anduseaproperextensioncord.
TheSawBlade
isbroken,and/
orisloose
LoosedClampBoltof
BladeHolder Re-tightenClampBolt.
Forcingthemachinetocut Donotcutbyforce.Cutslower.
UnxedChainVise Fixthe Chain Vise to the work piece
rmly.
Themachine
stopsduring
cutting
Lowvoltage
Whentheextensioncordistoolongor
toothin, see"ExtensionCord"onP9
anduseaproperextensioncord.
WorkingOver-load
Protector
Makesure thatthemotoriscooled
downenough, and then turn onthe
switchagain. Donotcutbyforce.Cut
slower.
WornoutCarbonBrushes IfCarbon Brushesareworndownto
around6mm,theymustbechanged.
Wornoutsawblade
Ifthesawbladeiswornout,cannotcut
properly.Changethesawbladetonew
one.
Obliquecutting
Wornoutsawblade
Ifthesawbladeiswornout,itcauses
ofoblique cutting.Change the saw
bladetonewonewhenit'swornout.
Jammedcontaminations
betweenChainViseand
theworkpiece
Removethecontaminationjammed
betweenChain Viseandthework
piece.
Forcingthemachinetocut Donotcutbyforce.Cutslower.
●Beforeaskingforrepairs,checkfollowingtroubleshooting.
Iftheproblemcannotbesolved,contactwiththeshopyoupurchasedorour
saleso󱐰ce.
●Troublesduetomisuseorimproperapplicationsarenotcoveredbywarranty.
TROUBLESHOOTING

● Customer Memo Please ll in for your record in the future
The information is helpful for inquiry and ordering parts.
Products Number：
Date Purchased：
Store Purchased the Unit：
Code No. IM0349
LE
