ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 1 -
GENERAL DESCRIPTION
The AK4589 is a single chip CODEC that includes two channels of ADC and eight channels of DAC. The
ADC outputs 24bit data and the DAC accepts up to 24bit input data. TheADC hasthe Enhanced Dual Bit
architecture with wide dynamic range. The DAC introduces the new developed Advanced Multi-Bit
architecture, and achieves wider dynamic range and lower outband noise. The AK4589 has a dynamic
range of 102dB for ADC, 114dB for DAC and is well suited for digital surround for home theater audio.
The AK4589 also has the balance volume control corresponding to the Dolby Digital (AC-3) system.
The also has digital audio receiver (DIR) and transmitter (DIT) compatible with 192kHz, 24bits. The DIR
has 8-channel input selector and can automatically detect a Non-PCM bit stream. The AK4589 provides
a compatibility of hardware and software with the AK4588.
*Dolby Digital (AC-3) is a trademark of Dolby Laboratories.
FEATURES
ADC/DAC part
•2ch 24bit ADC
- 64x Oversampling
- Sampling Rate up to 96kHz
- Linear Phase Digital Anti-Alias Filter
- Single-Ended Input
- S/(N+D): 92dB
- Dynamic Range, S/N: 102dB
- Digital HPF for offset cancellation
- Overflow flag
•8ch 24bit DAC
- 128x Oversampling
- Sampling Rate up to 192kHz
- 24bit 8 times Digital Filter
- Differential Outputs
- On-chip Switched-Capacitor Filter
- S/(N+D): 94dB
- Dynamic Range, S/N: 114dB
- Individual channel digital volume with 128 levels and 0.5dB step
- Soft mute
- De-emphasis for 32kHz, 44.1kHz, 48kHz
- Zero Detect Function
•High Jitter Tolerance
•Extenal Master Clock Input:
- 256fs, 384fs, 512fs (fs=32kHz ∼48kHz)
- 128fs, 192fs, 256fs (fs=64kHz ∼96kHz)
- 128fs (fs=120kHz ∼192kHz)
2/8-Channel Audio CODEC with DI
R
AK4589

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 2 -
DIR/DIT Part
•AES3, IEC60958, S/PDIF, EIAJ CP1201 Compatible
•Low jitter Analog PLL
•PLL Lock Range : 32kHz to 192kHz
•Clock Source: PLL or X'tal
•8-channel Receiver input
•2-channel Transmission output (Through output or DIT)
•Auxiliary digital input
•De-emphasis for 32kHz, 44.1kHz, 48kHz and 96kHz
•Detection Functions
-Non-PCM Bit Stream Detection
-DTS-CD Bit Stream Detection
- Sampling Frequency Detection
(32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz)
- Unlock & Parity Error Detection
-Validity Flag Detection
•Up to 24bit Audio Data Format
•Audio I/F: Master or Slave Mode
•40-bit Channel Status Buffer
•Burst Preamble bit Pc and Pd Buffer for Non-PCM bit stream
•Q-subcode Buffer for CD bit stream
•Serial µP I/F
•Two Master Clock Outputs: 64fs/128fs/256fs/512fs
TTL Level Digital I/F
4-wire Serial and I2C Bus µP I/F for mode setting
Operating Voltage: 4.75 to 5.25V with 5V tolerance
Power Supply for output buffer: 2.7 to 5.25V
80pin LQFP Package (0.5mm pitch)
AK4588 compatible w/o analog outputs

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 3 -
Block Diagram
In
p
u
t
Selecto
r
Cloc
k
Recovery Cloc
k
Generator
DAIF
Decode
r
A
C-3/MPEG
Detect
DEM
µP I/F
A
udio
I/F
X'tal
Oscillato
r
PDN
INT0
LRCK2
BICK2
SDTO2
DAUX2
MCKO2
XTOXTI
RPVDDPVSS
CDTI
CDTO
CCLK
CSN
DVDD
DVSS
TVDD
MCKO1
I2C
RX0
RX1
RX2
RX3
RX4
RX5
RX6
RX7
DIT
TX0
Error &
Detect
STATUS
INT1
Q-subcode
buffe
r
TX1
B,C,U,
VOUT
8 to 3
VIN
Audio
I/F
SCF
SCF
SCF
SCF
SCF
SCF
LOUT1+
ROUT1+
LOUT2+
ROUT2+
LOUT3+
ROUT3+
DAC DATT
DEM
ADC HPF
ADC HPF
RIN
LIN
LRCK1
BICK1
SDTI1
SDTI2
SDTI3
DAUX1
MCLK
LRCK
BICK
SDOUT
SDIN1
SDIN2
SDIN3
MCLK
SDTO1
Format
Converter
SDTI4
SDIN4
SCF
SCF
LOUT4+
ROUT4+
DAC DATT
DEM
DAC DATT
DEM
DAC DATT
DEM
DAC DATT
DEM
DAC DATT
DEM
DAC DATT
DEM
DAC DATT
DEM
A
VDD
A
VSS
LOUT1-
ROUT1-
LOUT2-
ROUT2-
LOUT3-
ROUT3-
LOUT4-
ROUT4-

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 4 -
Ordering Guide
AK4589VQ -10 ∼+70°C 80pinLQFP(0.5mmpitch)
AKD4589 Evaluation Board for AK4589
Pin Layout
(Top View)
CCLK/SC
L
CDTI/SD
A
CSN
DAUX1
SDTI4 SDTI3 SDTI2 SDTI1
XTL1 XTL0
PDN
MASTE
R
DZF2 DZF1
LOUT4
-
LOUT4
+
ROUT4
-
ROUT4
+
LOUT3
-
LOUT3
+
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
INT1
BOUT
TVDD
DVDD
DVSS
XTO
XTI
TEST3
MCKO2
MCKO1
COUT
UOUT
VOUT
SDTO2
BICK2
LRCK2
SDTO1
BICK1
LRCK1
CDTO
TEST1
RX1
NC
RX0
AVSS
AVDD
VREFH
VCOM
RIN
LIN
ROUT1+
ROUT1-
LOUT1+
LOUT1-
ROUT2+
ROUT2-
LOUT2+
LOUT2-
ROUT3+
ROUT3-
INT0 TX1 TX0 MCLK VIN DAUX2 I2C RX7 CAD1 RX6 CAD0 RX5 TEST2 RX4 PVDD R PVSS RX3 NC RX2

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 5 -
Compatibility with AK4588
Functions AK4588 AK4589
DAC output Single end Differentianl
DAC S/(N+D) 90dB 94dB
DAC S/N 106dB 114dB
DAC Output voltage Typ 3.0Vpp Typ ±2.7Vpp
DAC AOUT AOUT=0.6xVREFH AOUT=0.54xVREFH
Load Resistance 5k ohm 2k ohm
Frequency Response 80kHz ±1.0 +0/-0.6
Output pin #35,#37, #39,#41,#43,#45,#47,#49 #35 - #50
Power Supply voltage Min=4.5V, Max=5.5V Min=4.75V, Max=5.25V
(*) The AK4589 has two register maps including ADC/DAC part (compatible with the AK4588) and DIR/DIT part
(compatible with AK4588). Each register is selected by Chip Address.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 6 -
PIN/FUNCTION
No. Pin Name I/O Function
1 INT1 O Interrupt 1 Pin
2 BOUT O
Block-Start Output Pin for Receiver Input
“H” during first 40 flames.
3 TVDD - Output Buffer Power Supply Pin, 2.7V∼5.25V
4 DVDD - Digital Power Supply Pin, 4.75V∼5.25V
5 DVSS - Digital Ground Pin
6 XTO O X'tal Output Pin
7 XTI I X'tal Input Pin
8 TEST3 I Test 3 Pin
This pin should be connected to DVSS.
9 MCKO2 O Master Clock Output 2 Pin
10 MCKO1 O Master Clock Output 1 Pin
11 COUT O C-bit Output Pin for Receiver Input
12 UOUT O U-bit Output Pin for Receiver Input
13 VOUT O V-bit Output Pin for Receiver Input
14 SDTO2 O Audio Serial Data Output Pin (DIR/DIT part)
15 BICK2 I/O Audio Serial Data Clock Pin (DIR/DIT part)
16 LRCK2 I/O Channel Clock Pin (DIR/DIT part)
17 SDTO1 O Audio Serial Data Output Pin (ADC/DAC part)
18 BICK1 I/O Audio Serial Data Clock Pin (ADC/DAC part)
19 LRCK1 I/O Input Channel Clock Pin
20 CDTO O Control Data Output Pin in Serial Mode, I2C= “L”.
CCLK I Control Data Clock Pin in Serial Mode, I2C= “L”
21 SCL I Control Data Clock Pin in Serial Mode, I2C= “H”
CDTI I Control Data Input Pin in Serial Mode, I2C= “L”.
22 SDA I/O Control Data Pin in Serial Mode, I2C= “H”.
I Chip Select Pin in Serial Mode, I2C= “L”.
23 CSN I This pin should be connected to DVSS, I2C= “H”.
24 DAUX1 I AUX Audio Serial Data Input Pin (ADC/DAC part)
25 SDTI4 I DAC4 Audio Serial Data Input Pin
26 SDTI3 I DAC3 Audio Serial Data Input Pin
27 SDTI2 I DAC2 Audio Serial Data Input Pin
28 SDTI1 I DAC1 Audio Serial Data Input Pin
29 XTL1 I X’tal Frequency Select 0 Pin
30 XTL0 I X’tal Frequency Select 1 Pin

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 7 -
No. Pin Name I/O Function
31 PDN I Power-Down Mode Pin When “L”, the AK4589 is powered-down, all digital output pins go “L”, all registers
are reset. When CAD1/0 pins are changed, theAK4589 should be reset by PDN pin.
32 MASTER I Master Mode Select Pin
“H”: Master mode, “L”: Slave mode
DZF2 O
ZeroInputDetect2Pin (Table13)
When the input data of the group 1 follow total 8192 LRCK cycles with “0” input
data, this pin goes to “H”. And when RSTN bit is “0”, PWDAN bit is “0”, this pin
goes to “H”. It always is in “L” when P/S pin is “H”.
33
OVF O
Analog Input Overflow Detect Pin
This pin goes to “H” if the analog input of Lch or Rch overflows.
34 DZF1 O
ZeroInputDetect1Pin (Table13)
When the input data of the group 1 follow total 8192 LRCK cycles with “0” input
data, this pin goes to “H”. And when RSTN bit is “0”, PWDAN bit is “0”, this pin
goes to “H”. Output is selected by setting DZFE pin when P/S pin is “H”.
35 LOUT4- O DAC4 Lch Negative Analog Output Pin
36 LOUT4+ O DAC4 Lch Positive Analog Output Pin 470pF capacitor should be connected
between LOUT4- and LOUT4+.
37 ROUT4- O DAC4 Rch Negative Analog Output Pin
38 ROUT4+ O DAC4 Rch Positive Analog Output Pin 470pF capacitor should be connected
between ROUT4- and ROUT4+.
39 LOUT3- O DAC3 Lch Negative Analog Output Pin
40 LOUT3+ O DAC3 Lch Positive Analog Output Pin 470pF capacitor should be connected
between LOUT3- and LOUT3+.
41 ROUT3- O DAC3 Rch Negative Analog Output Pin
42 ROUT3+ O DAC3 Rch Positive Analog Output Pin 470pF capacitor should be connected
between ROUT3- and ROUT3+.
43 LOUT2- O DAC2 Lch Negative Analog Output Pin
44 LOUT2+ O DAC2 Lch Positive Analog Output Pin 470pF capacitor should be connected
between LOUT2- and LOUT2+.
45 ROUT2- O DAC2 Rch Negative Analog Output Pin
46 ROUT2+ O DAC2 Rch Positive Analog Output Pin 470pF capacitor should be connected
between ROUT2- and ROUT2+.
47 LOUT1- O DAC1 Lch Negative Analog Output Pin
48 LOUT1+ O DAC1 Lch Positive Analog Output Pin 470pF capacitor should be connected
between LOUT1- and LOUT1+.
49 ROUT1- O DAC1 Rch Negative Analog Output Pin
50 ROUT1+ O DAC1 Rch Positive Analog Output Pin 470pF capacitor should be connected
between ROUT1- and ROUT1+.
51 LIN I Lch Analog Input Pin
52 RIN I Rch Analog Input Pin
53 VCOM - Common Voltage Output Pin
2.2µF capacitor should be connected to AVSS externally.
54 VREFH - Positive Voltage Reference Input Pin, AVDD

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 8 -
No. Pin Name I/O Function
55 AVDD - Analog Power Supply Pin, 4.75V∼5.25V
56 AVSS - Analog Ground Pin, 0V
57 RX0 I Receiver Channel 0 Pin (Internal biased pin. Internally biased at PVDD/2)
58 NC - No Connect pin
No internal bonding. This pin should be connected to PVSS.
59 RX1 I Receiver Channel 1 Pin (Internal biased pin. Internally biased at PVDD/2)
60 TEST1 I Test 1 Pin
This pin should be connected to PVSS.
61 RX2 I Receiver Channel 2 Pin (Internal biased pin. Internally biased at PVDD/2)
62 NC - No Connect pin
No internal bonding. This pin should be connected to PVSS.
63 RX3 I Receiver Channel 3 Pin (Internal biased pin. Internally biased at PVDD/2)
64 PVSS - PLL Ground pin
65 R - External Resistor Pin
12kΩ+/-1% resistor should be connected to PVSS externally.
66 PVDD - PLLPower supply Pin, 4.75V∼5.25V
67 RX4 I Receiver Channel 4 Pin (Internal biased pin. Internally biased at PVDD/2)
68 TEST2 I Test 2 Pin
This pin should be connected to PVSS.
69 RX5 I Receiver Channel 5 Pin (Internal biased pin. Internally biased at PVDD/2)
70 CAD0 I Chip Address 0 Pin (ADC/DAC part)
71 RX6 I Receiver Channel 6 Pin (Internal biased pin. Internally biased at PVDD/2)
72 CAD1 I Chip Address 1 Pin (ADC/DAC part)
73 RX7 I Receiver Channel 7 Pin (Internal biased pin. Internally biased at PVDD/2)
74 I2C I Control Mode Select Pin.
“L”: 4-wire Serial, “H”: I2C Bus
75 DAUX2 I Auxiliary Audio Data Input Pin (DIR/DIT part)
76 VIN I V-bit Input Pin for Transmitter Output
77 MCLK I Master Clock Input Pin
78 TX0 O Transmit Channel (Through Data) Output 0 Pin
79 TX1 O Transmit Channel Output1 pin When DIT bit = “0”, Through Data.
When DIT bit = “1”, DAUX2 Data.
80 INT0 O Interrupt 0 Pin
Note: All input pins except internal biased pins and Analog input pins (RX0-7, LIN, RIN) should not be left floating.
VCOM
PVDD
PVSS
RX pin 20k(typ)
20k(typ)
Internal biased pin Circuit

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 9 -
Handling of Unused Pin
The unused I/O pins should be processed appropriately as below.
Classification Pin Name Setting
Analog RX0-7, LOUT1-4, ROUT1-4, LIN, RIN These pins should be open.
INT0-1, BOUT, XTO, MCKO1-2, COUT, UOUT,
VOUT, SDTO1-2, CDTO, DZF1-2, TX1-0 These pins should be open.
CSN, DAUX1-2, SDTI1-4, XTL0-1 These pins should be connected to DVSS.
Digital
TEST1-3 These pins should be connected to PVSS.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 10 -
ABSOLUTE MAXIMUM RATINGS
(AVSS, DVSS, PVSS=0V; Note 1)
Parameter Symbol min max Units
Power Supplies Analog
Digital
PLL
Output buffer
|AVSS-DVSS| (Note 2)
|AVSS-PVSS| (Note 2)
AVDD
DVDD
PVDD
TVDD
∆GND1
∆GND2
-0.3
-0.3
-0.3
-0.3
-
-
6.0
6.0
6.0
6.0
0.3
0.3
V
V
V
V
V
V
Input Current (any pins except for supplies) IIN - ±10 mA
Analog Input Voltage
(LIN, RIN pins) VINA -0.3 AVDD+0.3 V
Digital Input Voltage
Except LRCK1-2, BICK1-2, RX0-7, CAD0-1,
TEST1-2 pins VIND1 -0.3 DVDD+0.3 V
LRCK1-2, BICK1-2 pins VIND2 -0.3 TVDD+0.3 V
RX0-7, CAD0-1, TEST1-2 pins VIND3 -0.3 PVDD+0.3 V
Ambient Temperature (power applied) Ta -10 70 °C
Storage Temperature Tstg -65 150 °C
Notes:
1. All voltages with respect to ground.
2.AVSS, DVSS and PVSS must be connected to the same analog ground plane.
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normaloperationisnotguaranteedattheseextremes.
RECOMMENDED OPERATING CONDITIONS
(AVSS, DVSS, PVSS=0V; Note 3)
Parameter Symbol min typ max Units
Power Supplies
(Note 4) Analog Digital
PLL
Output buffer
AVDD
DVDD
PVDD
TVDD
4.75
4.75
4.75
2.7
5.0
5.0
5.0
5.0
5.25
AVDD
AVDD
DVDD
V
V
V
V
Notes:
3. All voltages with respect to ground.
4. The power up sequence between AVDD, DVDD, PVDD and TVDD is not critical. To save leak current in power
down mode, AVDD, DVDD, PVDD become the same voltage as much as possible.
WARNING: AKM assumes no responsibility for the usage beyond the conditions in this datasheet.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 11 -
ANALOG CHARACTERISTICS
(Ta=25°C; AVDD, DVDD, PVDD, TVDD=5V; AVSS, DVSS=0V; VREFH=AVDD; fs=48kHz; BICK=64fs;
Signal Frequency=1kHz; 24bit Data; Measurement Frequency=20Hz∼20kHz at fs=48kHz, 20Hz~40kHz at fs=96kHz;
20Hz~40kHz at fs=192kHz, unless otherwise specified)
Parameter min typ max Units
ADC Analog Input Characteristics
Resolution 24 Bits
S/(N+D) (-0.5dBFS) fs=48kHz
fs=96kHz 84 - 92 86 dB dB
DR (-60dBFS) fs=48kHz, A-weighted
fs=96kHz
fs=96kHz, A-weighted
94
88
93
102
96
102
dB dB
dB
S/N (Note5) fs=48kHz,A-weighted
fs=96kHz
fs=96kHz, A-weighted
93
88
93
102
96
102
dB dB
dB
Interchannel Isolation 90 110 dB
DC Accuracy
Interchannel Gain Mismatch 0.2 0.3 dB
Gain Drift 20 - ppm/°C
Input Voltage AIN=0.62xVREFH 2.90 3.10 3.30 Vpp
Input Resistance fs=48kHz
fs=96kHz 15 9 25 16 kΩ
kΩ
PowerSupplyRejection (Note7) 50 dB
DAC Analog Output Characteristics
Resolution 24 Bits
S/(N+D) fs=48kHz
fs=96kHz
fs=192kHz
86
84
-
94
92
92
dB dB
dB
DR (-60dBFS) fs=48kHz, A-weighted
fs=96kHz
fs=96kHz, A-weighted
fs=192kHz
fs=192kHz, A-weighted
104
98
104
-
114
108
114
108
114
dB
dB
dB
dB
dB
S/N (Note 8) fs=48kHz, A-weighted
fs=96kHz
fs=96kHz, A-weighted
fs=192kHz
fs=192kHz, A-weighted
104
98
104
-
-
114
108
114
108
114
dB
dB
dB
dB
dB
Interchannel Isolation 90 100 dB
DC Accuracy
Interchannel Gain Mismatch 0.2 0.5 dB
Gain Drift 20 -
ppm/°C
Output Voltage AOUT=0.54xVREFH ±2.5 ±2.7 ±2.9 Vpp
LoadResistance (ACLoad) (Note6) 2
kΩ
PowerSupplyRejection (Note7) 50 dB
Power Supplies
Power Supply Current
NormalOperation (PDN=“H”) (Note9)
AVDD fs=48kHz,fs=96kHz
fs=192kHz
PVDD
DVDD+TVDD fs=48kHz (Note 10)
fs=96kHz
fs=192kHz
Power-downmode(PDNpin=“L”) (Note11)
70
57
12
44
57
68
0.1
98
80
17
62
80
95
1
mA
mA
mA
mA
mA
mA
mA

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 12 -
Notes:
5. S/N measured by CCIR-ARM is 96dB(@fs=48kHz).
6. For AC-load. 4kΩfor DC-load
7. PSR is applied to AVDD, DVDD, PVDD and TVDD with 1kHz, 50mVpp. VREFH pin is held a constant voltage.
8. S/N measured by CCIR-ARM is 102dB(@fs=48kHz).
9. CL=20pF, X'tal=24.576MHz, CM1-0=“10”, CM1-0=“10”, OCKS1-0="10"@48kHz,"00"@96kHz, "11"@192kHz.
10. TVDD=13mA(typ).
11. In the power-down mode. RX inputs are open and all digital input pins including clock pins (MCLK, BICK,
LRCK) are held DVSS. FILTER CHARACTERISTICS
(Ta=25°C; AVDD, DVDD, PVDD=4.75∼5.25V; TVDD=2.7∼5.25V; fs=48kHz)
Parameter Symbol min typ max Units
ADC Digital Filter (Decimation LPF):
Passband (Note12) ±0.1dB
-0.2dB
-3.0dB
PB 0
-
-
20.0
23.0
18.9
-
-
kHz
kHz
kHz
Stopband SB 28.0 kHz
Passband Ripple PR ±0.04 dB
Stopband Attenuation SA 68 dB
GroupDelay (Note13) GD 16 1/fs
Group Delay Distortion ∆GD 0 µs
ADC Digital Filter (HPF):
Frequency Response (Note 12) -3dB
-0.1dB FR 1.0 6.5 Hz Hz
DAC Digital Filter:
Passband (Note12) -0.1dB
-6.0dB PB 0 - 24.0 21.8 - kHz kHz
Stopband SB 26.2 kHz
Passband Ripple PR ±0.02 dB
Stopband Attenuation SA 54 dB
GroupDelay (Note13) GD 19.2 1/fs
DAC Digital Filter + Analog Filter:
Frequency Response: 0
∼20.0kHz
40.0kHz (Note 14)
80.0kHz (Note 14)
FR
FR
FR
±0.2
±0.3
+0/-0.6
dB
dB
dB
Notes:
12. The passband and stopband frequencies scale with fs.
For example, 21.8kHz at –0.1dB is 0.454 x fs (DAC). The reference frequency of these responses is 1kHz.
13. The calculating delay time which occurred by digital filtering. This time is from setting the input of analog signal
to setting the 24bit data of both channels to the output register for ADC.
For DAC, this time is from setting the 20/24bit data of both channels on input register to the output of analog
signal.
14. 40kHz@fs=96kHz, 80kHz@fs=192kHz

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 13 -
DC CHARACTERISTICS
(Ta=25°C; AVDD, DVDD, PVDD=4.75∼5.25V; TVDD=2.7∼5.25V)
Parameter Symbol min typ max Units
High-LevelInputVoltage (ExceptXTIpin)
(XTIpin)
Low-Level Input Voltage (Except XTI pin)
(XTIpin)
VIH
VIH
VIL
VIL
2.2
70%DVDD
-
-
-
-
-
-
-
-
0.8
30%DVDD
V
V
V
V
Input Voltage at AC Coupling (XTI pin) (Table 15) VAC 40%DVDD - - Vpp
High-Level Output Voltage
(Except TX0-1, DZF pins: Iout=-400µA)
(TX0-1 pin: Iout=-400µA)
(DZF pin: Iout=-400µA)
Low-Level Output Voltage (Iout=400µA)
VOH
VOH
VOH
VOL
TVDD-0.4
DVDD-0.4
AVDD-0.4
-
-
-
-
-
-
-
-
0.4
V
V
V
V
Input Leakage Current Iin - - ±10 µA
Note:
15. In case of connecting capacitance (0.1µF) to XTI pin.
S/PDIF RECEIVER CHARACTERISTICS
(Ta=25°C; AVDD, DVDD, PVDD=4.75~5.25V; TVDD=2.7~5.25V)
Parameter Symbol min typ max Units
Input Resistance Zin 10 kΩ
Input Voltage (internally biased at PVDD/2) VTH 200 mVpp
Input Hysteresis VHY - 50 mV
Input Sample Frequency fs 32 - 192 kHz
VCOM
PVDD
PVSS
RX pin 20k(typ)
20k(typ)
Internal biased pin Circuit

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 14 -
SWITCHING CHARACTERISTICS (ADC/DAC part)
(Ta=25°C; AVDD, DVDD, PVDD=4.75∼5.25V; TVDD=2.7∼5.25V; CL=20pF)
Parameter Symbol min typ max Units
Master Clock Timing
Master Clock
256fsn, 128fsd:
Pulse Width Low
Pulse Width High
384fsn, 192fsd:
Pulse Width Low
Pulse Width High
512fsn, 256fsd, 128fsq:
Pulse Width Low
Pulse Width High
fCLK
tCLKL
tCLKH
fCLK
tCLKL
tCLKH
fCLK
tCLKL
tCLKH
8.192
27
27
12.288
20
20
16.384
15
15
12.288
18.432
24.576
MHz
ns
ns
MHz
ns
ns
MHz
ns
ns
LRCK1 Timing (Slave Mode)
Normal mode
Normal Speed Mode
Double Speed Mode
Quad Speed Mode
Duty Cycle
fsn
fsd
fsq
Duty
32
64
120
45
48
96
192
55
kHz
kHz
kHz
%
TDM 256 mode
LRCK1 frequency
“H” time
“L” time
fsd
tLRH
tLRL
32
1/256fs
1/256fs
48 kHz
ns
ns
TDM 128 mode
LRCK1 frequency
“H” time
“L” time
fsd
tLRH
tLRL
64
1/128fs
1/128fs
96 kHz
ns
ns
LRCK1 Timing (Master Mode)
Normal mode
Normal Speed Mode
Double Speed Mode
Quad Speed Mode
Duty Cycle
fsn
fsd
fsq
Duty
32
64
120
50
48
96
192
kHz
kHz
kHz
%
TDM 256 mode
LRCK1 frequency
“H”time (Note16)
fsn
tLRH
32
1/8fs
48 kHz
ns
TDM 128 mode
LRCK1 frequency
“H”time (Note16)
fsd
tLRH
64
1/4fs
96 kHz
ns
Power-down & Reset Timing
PDNPulseWidth (Note17)
PDN “↑” to SDTO1 valid (Note 18)
tPD
tPDV
150
522
ns
1/fs
Notes:
16. “L” time at I2S format.
17. The AK4589 can be reset by bringing PDN “L” to “H” upon power-up.
18. These cycles are the number of LRCK rising from PDN rising.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 15 -
Parameter Symbol min typ max Units
Audio Interface Timing (Slave Mode)
Normal mode
BICK1 Period
BICK1 Pulse Width Low
Pulse Width High
LRCK1 Edge to BICK1 “↑” (Note 19)
BICK1 “↑” to LRCK1 Edge (Note 19)
LRCK1 to SDTO1(MSB)
BICK1 “↓” to SDTO1
SDTI1-4,DAUX1 Hold Time
SDTI1-4,DAUX1 Setup Time
tBCK
tBCKL
tBCKH
tLRB
tBLR
tLRS
tBSD
tSDH
tSDS
81
32
32
20
20
20
20
40
40
ns
ns
ns
ns
ns
ns
ns
ns
ns
TDM 256 mode
BICK1 Period
BICK1 Pulse Width Low
Pulse Width High
LRCK1 Edge to BICK1 “↑” (Note 19)
BICK1 “↑” to LRCK1 Edge (Note 19)
BICK1 “↓” to SDTO1
SDTI1 Hold Time
SDTI1 Setup Time
tBCK
tBCKL
tBCKH
tLRB
tBLR
tBSD
tSDH
tSDS
81
32
32
20
20
10
10
20
ns
ns
ns
ns
ns
ns
ns
ns
TDM 128 mode
BICK1 Period
BICK1 Pulse Width Low
Pulse Width High
LRCK1 Edge to BICK1 “↑” (Note 19)
BICK1 “↑” to LRCK1 Edge (Note 19)
BICK1 “↓” to SDTO1
SDTI1-2 Hold Time
SDTI1-2 Setup Time
tBCK
tBCKL
tBCKH
tLRB
tBLR
tBSD
tSDH
tSDS
81
32
32
20
20
10
10
20
ns
ns
ns
ns
ns
ns
ns
ns
Audio Interface Timing (Master Mode)
Normal mode
BICK1 Frequency
BICK1 Duty
BICK1 “↓” to LRCK1 Edge
BICK1“↓” to SDTO1
SDTI1-4,DAUX1 Hold Time
SDTI1-4,DAUX1 setup Time
fBCK
dBCK
tMBLR
tBSD
tSDH
tSDS
-20
20
20
64fs
50
20
40
Hz
%
ns
ns
ns
ns
TDM 256 mode
BICK1 Frequency
BICK1Duty (Note20)
BICK1 “↓” to LRCK1 Edge
BICK1 “↓” to SDTO1
SDTI1 Hold Time
SDTI1 Setup Time
fBCK
dBCK
tMBLR
tBSD
tSDH
tSDS
-12
10
10
256fs
50
12
20
Hz
%
ns
ns
ns
ns
TDM 128 mode
BICK1 Frequency
BICK1Duty (Note21)
BICK1 “↓” to LRCK1 Edge
BICK1 “↓” to SDTO1
SDTI1-2 Hold Time
SDTI1-2 Setup Time
fBCK
dBCK
tMBLR
tBSD
tSDH
tSDS
-12
10
10
128fs
50
12
20
Hz
%
ns
ns
ns
ns
Notes:
19. BICK1 rising edge must not occur at the same time as LRCK1 edge.
20. When MCLK is 512fs, dBCK is guaranteed. When 384fs and 256fs, dBCK can not be guaranteed.
21. When MCLK is 256fs, dBCK is guaranteed. When 128fs, dBCK can not be guaranteed.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 16 -
Timing Diagram(ADC/DAC part) 1/fCLK
tCLKL
VIH
tCLKH
MCLK VIL
1/fsn, 1/fsd, 1/fsq
LRCK1 VIH
VIL
tBCK
tBCKL
VIH
tBCKH
BICK1 VIL
Clock Timing (Normal mode)
1/fCLK
tCLKL
VIH
tCLKH
MCLK VIL
1/fs
LRCK1 VIH
VIL
tLRLtLRH
tBCK
tBCKL
VIH
tBCKH
BICK1 VIL
Clock Timing (TDM 256 mode, TDM 128 mode)

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 17 -
tLRB
LRCK1
VIH
BICK1 VIL
tLRS
SDTO1 50%TVDD
tBSD
VIH
VIL
tBLR
tSDS
SDTI VIH
VIL
tSDH
Audio Interface Timing (Normal mode)
tLRB
LRCK1
VIH
BICK1 VIL
SDTO1 50%TVDD
tBSD
VIH
VIL
tBLR
tSDS
SDTI VIH
VIL
tSDH
Audio Interface Timing (TDM 256 mode, TDM 128 mode)

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 18 -
LRCK1
BICK1
SDTO1
tBSD
tMBLR
50%TVDD
50%TVDD
50%TVDD
DAUX1
tDXHtDXS
VIH
VIL
Audio Interface timing (Master Mode)

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 19 -
SWITCHING CHARACTERISTICS (DIR/DIT part)
(Ta=25°C; DVDD, AVDD, PVDD4.75~5.25V, TVDD=2.7~5.25V; CL=20pF)
Parameter Symbol min typ max Units
Master Clock Timing
Crystal Resonator Frequency fXTAL 11.2896 24.576 MHz
External Clock Frequency
Duty fECLK dECLK 11.2896 40 50 24.576 60 MHz %
MCKO1 Output Frequency
Duty fMCK1 dMCK1 4.096 40 50 24.576 60 MHz %
MCKO2 Output Frequency
Duty fMCK2 dMCK2 2.048 40 50 24.576 60 MHz %
PLL Clock Recover Frequency (RX0-7) fpll 32 - 192 kHz
LRCK2 Frequency
Duty Cycle fs dLCK 32 45 192 55 kHz %
Audio Interface Timing
Slave Mode
BICK2 Period
BICK2 Pulse Width Low
Pulse Width High
LRCK2 Edge to BICK2 “↑” (Note22)
BICK2 “↑”toLRCK2Edge (Note22)
LRCK2 to SDTO2 (MSB)
BICK2 “↓” to SDTO2
DAUX2 Hold Time
DAUX2 Setup Time
tBCK
tBCKL
tBCKH
tLRB
tBLR
tLRM
tBSD
tDXH
tDXS
80
30
30
20
20
20
20
30
30
ns
ns
ns
ns
ns
ns
ns
ns
ns
Master Mode
BICK2 Frequency
BICK2 Duty
BICK2 “↓” to LRCK2
BICK2 “↓” to SDTO2
DAUX2 Hold Time
DAUX2 Setup Time
fBCK
dBCK
tMBLR
tBSD
tDXH
tDXS
-20
20
20
64fs
50
20
15
Hz
%
ns
ns
ns
ns
Notes;
22. BICK2 rising edge must not occur at the same time as LRCK2 edge.

ASAHI KASEI [AK4589]
MS0339-E-00 2004/09
- 20 -
Timing Diagram(DIR/DIT part)
1/fECLK
tECLKL
VIH
tECLKH
XTI VIL
dECLK = tECLKH x fECLK x 100
= tECLKL x fECLK x 100
1/fMCK1
50%TVDDMCKO1
tMCKL1tMCKH1 dMCK1 = tMCKH1 x fMCK1 x 100
= tMCKL1 x fMCK1 x 100
1/fMCK2
50%TVDDMCKO2
tMCKL2tMCKH2 dMCK2 = tMCKH2 x fMCK2 x 100
= tMCKL2 x fMCK2 x 100
1/fs
LRCK2 VIH
VIL
tLRLtLRH dLCK = tLRH x fs x 100
= tLRL x fs x 100
tLRB
LRCK2
BICK2
SDTO2
tBSD
tBLR tBCKL tBCKH
tLRM
50%TVDD
DAUX2
tDXS tDXH
VIH
VIL
VIH
VIL
VIH
VIL
tBCK
Serial Interface Timing (Slave Mode)
