Ziton Wireless Manual Call Point Installation Guide
General
The Ziton wireless manual call point is available under
the following part number:
PART NO VARIANT TYPE
ZPR485-3 Ziton wireless manual call point
The address of the unit is set when programming the
device to the system (see commissioning manual for
details). The installation must conform to BS5839:Part 1
(or applicable local codes).
Installation of Ziton wireless manual call point
Remove the back plate xing screw. Retain this for future
use. Insert at bladed instrument into the removal slot
and remove the back plate from the transmitter/battery
section. (See Figure 1).
Mount the back box 1.4m from the oor, using suitable
xings and fasteners. A minimum of two mounting holes
must be used. Countersunk head screws must be used to
avoid the possibility of damage to the internal
components. (See Figure 2).
© 2015 EMS Security Group Ltd. All rights reserved 1 / 44 / 4 MK106 Iss7 24/07/15 AJM© 2015 EMS Security Group Ltd. All rights reserved
Figure 1
Power jumper
Figure 2
Figure 3
Wall mounting positions
To ensure correct operation, connect the power jumper
across the PIN header on the battery PCB located on the
rear of the call point as shown in Figure 3.
Specication
Operating
Temperature -10 to +70°C (ambient)
Storage
Temperature 0 to +35°C
Humidity Up to 95% non-condensing
Supply 6x AA Alkaline (Panasonic LR6AD
Powerline / Varta 4006 Industrial)
IP Rating IP24
Operating
Frequencies 868 MHz
Output Transmitter
Power Variable 0-14 dBm
Dimensions 89mm (W) 92mm (H) 70mm (D)
Weight 0.40kg
Regulatory information
Manufacturer EMS Security Group Ltd.
Technology House, Sea Street,
Herne Bay, Kent, CT6 8JZ,
United Kingdom
Year of
manufacture See serial number on unit
Certication
Certication body
CPD Certicate
DOP 0359-CPR-0168
Approved to EN54-11
EN54-25
Application Intended for use in re detection
and re alarm systems in and
around buildings. Indoor use only.
European Union
directives EMS Security Group Ltd hereby
declares that this device is in
compliance with the essential
requirements and other relevant
provisions of Directive 2014/53/EU
(R&TTE directive).
2012/19/EU (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling, return
this product to your local supplier
upon purchase of equivalent new
equipment, or dispose of it at
designated collection points.
For more information see
www.recyclethis.info
Dispose of your batteries in an
environmentally friendly manner
according to your local regulations.
Contact information
For contact information, see ww.utcreandsecurity.com
MK106 Iss7 24/07/15 AJM
12
0359

2 / 4© 2015 EMS Security Group Ltd. All rights reserved 3 / 4© 2015 EMS Security Group Ltd. All rights reserved
Please see commissioning manual for log on procedure
details.
Locate the transmitter/battery section onto the back
plate. This has a hinged connection and should be
located on the top edge rst.
Ensure that the tamper switch operates correctly. The
switch should make contact with the back plate. Replace
the original back plate xing screw.
Testing, resetting and replacement of
element on manual call point
To test or reset the wireless call point or replace the
glass/resettable element, please follow the appropriate
step by step drawings shown below.
To test and reset
1
2
3
To replace glass / interchange between resettable and
glass element
1
2
3
4
5
6
Notes
