INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
Contents
1 Symbols......................................................................................................................................... 1
2 Description....................................................................................................................................2
3 Installation.....................................................................................................................................3
4 ounting.......................................................................................................................................4
4.1 Mount the NIRC4-xMN base onto a backbox..........................................................................4
4.2 Mount the Base without a Backbox.......................................................................................5
5 Connections and DIP Switch Settings..............................................................................................7
6 Setting the Room Bus Type Selection............................................................................................. 9
7 Enabling Auxiliary Power Supply ................................................................................................... 10
8 Preparing the Room Bus Cables.....................................................................................................11
9 Terminating and ounting Room Bus Connectors for NU-series odules........................................ 12
9.1 To mount the active room bus connectors: ...........................................................................13
10 Terminating and ounting Room Bus Connectors for NI-series odules........................................ 15
10.1 To mount the active room bus connectors: .......................................................................... 16
11 LAN Connection (T-568B) ............................................................................................................ 18
11.1 Ferrite Clamp.................................................................................................................... 18
12 Optional Connections and Expansions ........................................................................................ 20
12.1 Auxiliary Power Supply via PoE Midspan .............................................................................20
12.2 NILDx LED Lamp Placement...............................................................................................23
12.3 NIRX Receiver Board Placement.........................................................................................24
12.4 NIVP Voice Module Board Placement .................................................................................25
12.5 Wireless Gateway Configuration.........................................................................................26
13 Document History.......................................................................................................................27
TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Symbols
1 Symbols
Important Safety Information
The Room Controller 4 (NIRC4-xMN) Installation Guide contains important instructions when installing and
maintaining the NIRC4-xMN. To ensure a safe working environment during the installation and operation of
the NIRC4-xMN, the following safety symbols appear throughout this document to indicate dangerous
conditions and important safety instructions.
Read the manual for more information.
Caution: Use extreme caution and follow instructions carefully.
Pay particular attention to statements referred to by a note.
TD 93351EN / 21 March 2022 / Ver. B 1

Description
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
2 Description
The Room Controller (NIRC4) is a teleCARE IP controller establishing a decentralized node on the IP
network. A teleCARE IP Room Controller acts as a gateway between the four digital room buses and the IP
network. The NIRC4 is compatible with the NU-series modules, allowing 12 NU-series modules per room
bus.
It has a connection for an optional wireless transceiver (NIRX) that supports wireless nurse calls and a
connection for an optional voice module (NIVP4) that supports speech for NU-series modules. The NIRC4
can also serve as a corridor lamp supporting up to four LED boards behind a translucent dome cover. The
LED boards supported are the NILD2 and the dedicated workflow LED board (NILD4–RGB). The NIRC4 has
an integrated USB 2.0HS Host Port and Device Port with integrated support for the connection of the
Wireless Gateway.
The NIRC4 connects to the IP network using a 100Mb Ethernet connection. The input power can be
provided through the LAN port using power over ethernet (PoE), or through an auxiliary power supply via a
PoE Midspan. The NIRC4 includes firmware upgrade support for connected NU-series modules.
Packing list:
• 1 x Room Controller NIRC4
• 1 x Cover rear
• 1 x Cover front
• 1 x Cover dome
• 1 x Ferrite core round cable snap
2TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Installation
3 Installation
The NIRC4-xMN has an IP40 ingress protection. The areas in which NIRC4-xMNs are to be installed must be
clean, dry, and weatherproof. The walls on which devices are to be installed should be finished (painted,
wall papered, etc.) before the devices are installed. It is important to have the appropriate length of free
cable available at every location where the NIRC4-xMN is to be installed. The length of stripped cable and
the length of exposed copper wire shall conform to the installation instructions for each module that is to be
connected.
TD 93351EN / 21 March 2022 / Ver. B 3

Mounting
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
4 ounting
The base of the NIRC4-xMN mounts to backboxes using an array of holes that allow for mounting on
various EU and North American-style backboxes. In areas where no backboxes are available, the base can
be mounted directly onto flat wall surfaces.
Caution: To prevent a fire hazard because of dust buildup inside the NIRC4-xMN, regular
inspection and/or cleaning of the NIRC4-xMN is required.
Take proper measures to avoid spreading dust and other particles when applying
maintenance to an NIRC4-xMN that is mounted inside a clinical area.
4.1 ount the NIRC4-x N base onto a backbox
1. Place the base over the backbox with the spring type holding clip (1) pointing to the left.
2. For EU-style backboxes, loosen the screws so that approximately 5mm extend from the backbox so
that the heads of the screws can pass through the key-hole slots.
For North American-style backboxes, insert the screws (included) through the backplate and into the 2-
gang backbox.
3. Position the base until its top is level.
4. Tighten the screws until they are snug. Do not overtighten.
5. Pull the cables from the backbox through the base hole.
4TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Mounting
4.2 ount the Base without a Backbox
When mounting the NIRC4-xMN on a drywall without a backbox, mount the base of the NIRC4-xMN directly
to a flat wall surface using four screws suitable for the wall type.
Cable wires should enter and leave the device’s housing through the hole in the center of the base, or
through the knockouts at the bottom or right side of the base. Depending on the number of wires entering
the base, you may need to remove a portion of the cable’s jacket to ensure it will fit through the knockout.
When choosing a wall location for an NIRC4-xMN, consider where the connecting cables are located. If the
connecting cables run inside the wall, locate the base of the NIRC4-xMN over the hole where the cables
exit from the wall. If the connecting cables are run in a channel outside the wall, locate the base above or to
the left of the channel, where the cables exit the channel. The cables should enter through the knockout
holes in the base of the NIRC4-xMN.
Do not distort or twist the base when mounting it to a wall. If the base is distorted, the NIRC4-xMN
dome cover will not fit properly and may fall off.
Figure 1. NIRC4-xMN base orientation and cutouts
Legend
1. Arrow indicator
2. Circuit board spring type holding clip
3. Cutouts
To remove the knockouts
1. Locate the knockouts to be removed from the bottom or right side of the base. See Figure 1. NIRC4-
xMN base orientation and cutouts, page 5, items 3.
2. Using a cutter or pliers, carefully remove the excess plastic from the knockouts.
TD 93351EN / 21 March 2022 / Ver. B 5

Mounting
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
To mount the NIRC4-x N base on a wall
1. Place the base against a flat wall and orient it so that arrow is pointing up and that the base is level.
(See Figure 1. NIRC4-xMN base orientation and cutouts, page 5, item 1.) Use a leveling device to check,
if necessary.
2. Make sure that the knockouts are pointing down and to the right. (See Figure 1. NIRC4-xMN base
orientation and cutouts, page 5, items 3).
3. Using the base as a template, mark four holes for the screws using the slotted fitting holes located in
the base.
4. Remove the base and drill holes for the screws that will be used, such as wood, concrete, or drywall
screws, or screws with anchors.
5. Place the base (with the knockouts removed) over the holes, insert the screws, and then tighten.
6. Pull the cables through the knockout holes and follow the directions in the following sections.
The NIRC4-xMN must be mounted in a way that the module is firmly attached to the background.
6 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Connections and DIP Switch Settings
5 Connections and DIP Switch Settings
Before attaching the PCB to its base, make all wire connections and DIP switch settings. Be sure that
required cables are properly connected. The following figures show the locations for each cable.
Figure 2. NIRC4-xMN circuit board - front
Legend
1. LED lamp (NILD2, NILD4–RGB) connections
2. Mode button
3. USB 2.0HS Device service port
4. Reset button
TD 93351EN / 21 March 2022 / Ver. B 7

Connections and DIP Switch Settings
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
Figure 3. NIRC4-xMN circuit board - back
Legend
1. Wireless transceiver (NIRX) expansion connectors
2. DIP switches for bus type selection (NI or NU-series modules)
3. Buzzer
4. RJ45 Ethernet connector with PoE support and LEDs
5. Jumper for enabling auxiliary power supply
The jumper is only available on the NIRC4 with circuit board revision D or later.
6. Active room bus connectors (0-3) for connecting NU-series or NI-series modules
7. USB 2.0HS Host port for Wireless Gateway
8. Voice piggy back module (NIVP4) expansion connectors
9. Status LED
Caution: Hot surface. When operational, various surfaces on the NIRC4 circuit board can
become too hot to touch.
Switch off and let the circuit board cool down before servicing.
8 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Setting the Room Bus Type Selection
6 Setting the Room Bus Type Selection
Before connecting any of the wires, first set the bus-type selection DIP switch to match the modules (NU-
series or NI-series) that are going to be connected to the NIRC4-xMN.
The following figure illustrates the DIP switch found on the back of a NIRC4-xMN circuit board.
Figure 4. Room bus type selection DIP switch
DIP switch settings for room bus type selection
(1) DIP switch 1 (OFF) = NU-series Modules
(2) DIP switch 1 (ON) = NI-series Modules
To set a DIP switch:
1. Set DIP switch 1 to the room bus type required for the connected modules. Use the bus type settings
above to determine the correct positions (ON or OFF) for DIP switch 1.
2. Using a small screwdriver, gently slide the switch up for “ON” or slide it down for “OFF”.
DIP switch settings only take effect after a power cycle.
TD 93351EN / 21 March 2022 / Ver. B 9

Enabling Auxiliary Power Supply
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
7 Enabling Auxiliary Power Supply
When using external power via a power injector (PoE Midspan), make sure that the jumper is present on the
board. See item 5 of Figure 3. NIRC4-xMN circuit board - back, page 8.
The jumper is only available on the NIRC4 with circuit board revision D or later.
If the module does not start when applying PoE, then you may need to remove the jumper.
Carefully remove the jumper with your fingers or a pair of tweezers.
Caution: Only use a power injector when connecting the room controller to a non-PoE LAN
switch port.
Connecting a power injector to a room controller that is connected to a PoE enabled LAN
switch port, may damage the room controller or LAN switch.
10 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) Preparing the Room Bus Cables
8 Preparing the Room Bus Cables
Prepare the room bus cables and guide the wires through the housing. Avoid pressing the wires against the
printed circuit board, as this could cause damage to the board and may also prevent the top section from
closing properly.
Stripping the Outer Jacket of the Cables
Strip the outer jacket of the cables to a length of 150mm or 6 inch, then position the cable in the backbox so
that only the stripped wires enter the room controller housing.
Figure 5. Stripping and positioning the cables for the NIRC4-xMN
TD 93351EN / 21 March 2022 / Ver. B 11

Terminating and Mounting Room Bus Connectors for NU-
series Modules
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
9 Terminating and ounting Room Bus Connectors for NU-series odules
The NIRC4-xMN includes four active room bus terminals. For the NU-series modules, ensure that each room
bus cable is identified and properly terminated with an 8-pin block connector (NICT-8AA). The following
figure shows the correct pinout for terminating the active room bus cables.
Figure 6. 8-pole connector (NICT-8AA) for active room bus connections
Optionally the 8-pin block connector (NICT-8CA) can be used.
Figure 7. 8-pole connector (NICT-8CA) for active room bus connections
The 8-pole connectors (P/N NICT-8AA or NICT-8CA) are not included and must be ordered
separately.
Caution: Because of the larger size of the NICT-8CA block connector, it will collide with the
wire holding clips of the NIRC4-xMN housing. Take proper measures to avoid collision by
removing (cutting) the wire holding clip from the base.
Figure 8. NICT-8CA colliding with the wire holding clips
12 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
Terminating and Mounting Room Bus Connectors for NU-
series Modules
9.1 To mount the active room bus connectors:
1. Ensure the active room bus cables are properly terminated with an 8-pin block connector.
2. Orient the block connector NICT-8AA such that the wires face down.
-or-
Orient the block connector NICT-8CA such that locking clips face down.
3. Seat the block connector on an active room bus terminal.
4. Repeat steps 2 and 3 for each remaining active room bus terminal, as shown in the following figures.
Figure 9. Room bus connections NICT-8AA (NU-series modules)
Figure 10. Room bus connections NICT-8CA (NU-series modules)
TD 93351EN / 21 March 2022 / Ver. B 13

Terminating and Mounting Room Bus Connectors for NU-
series Modules
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
The room bus wires should be guided around the sides of the room controller housing and held in place by
the wire holding clip, as shown in the following illustration:
Figure 11. NIRC4-xMN - NU-series modules connection overview
14 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
Terminating and Mounting Room Bus Connectors for NI-
series Modules
10 Terminating and ounting Room Bus Connectors for NI-series odules
For the NI-series modules, ensure that each room bus cable is identified and properly terminated with an 8-
pin block connector (NICT-8AA). The following figure shows the correct pinout for terminating the active
room bus cables.
Figure 12. 8-pole connector (NICT-8AA) for active room bus connections
Optionally the 8-pin block connector (NICT-8CA) can be used.
Figure 13. 8-pole connector (NICT-8CA) for active room bus connections
The 8-pole connectors (P/N NICT-8AA or NICT-8CA) are not included and must be ordered
separately.
Caution: Because of the larger size of the NICT-8CA block connector, it will collide with the
wire holding clips of the NIRC4-xMN housing. Take proper measures to avoid collision by
removing (cutting) the wire holding clip from the base.
Figure 14. NICT-8CA colliding with the wire holding clips
TD 93351EN / 21 March 2022 / Ver. B 15

Terminating and Mounting Room Bus Connectors for NI-
series Modules
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
10.1 To mount the active room bus connectors:
1. Ensure the active room bus cables are properly terminated with an 8-pin block connector.
2. Orient the block connector NICT-8AA such that the wires face down.
-or-
Orient the block connector NICT-8CA such that locking clips face down.
3. Seat the block connector on an active room bus terminal.
4. Repeat steps 2 and 3 for each remaining active room bus terminal, as shown in the following figures.
Figure 15. Room bus connections NICT-8AA (NI-series modules)
Figure 16. Room bus connections NICT-8CA (NI-series modules)
16 TD 93351EN / 21 March 2022 / Ver. B

INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
Terminating and Mounting Room Bus Connectors for NI-
series Modules
Each room bus requires four wires (NI-series modules). If the cable contains more wires than
required, the excess wires should be carefully stowed in the backbox, away from the printed
circuit board and other components to avoid causing short-circuits.
The room bus wires should be guided around sides of the room controller housing and held in place by the
wire holding clip, as shown in the following illustration:
Figure 17. NIRC4-xMN - NI-series modules connection overview
TD 93351EN / 21 March 2022 / Ver. B 17

LAN Connection (T-568B)
INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN)
11 LAN Connection (T-568B)
Connect a LAN cable using T-568B termination to the RJ45 Ethernet connector on the NIRC4 circuit board.
Power to the NIRC4-xMN is supplied using power over ethernet (PoE), plugging in the network
cable will automatically power on the NIRC4-xMN. Make sure all wire connections are made and all
optional expansion board(s) are placed before connecting the NIRC4-xMN to the LAN.
Figure 18. LAN connection
Make sure to connect the NIRC4-xMN to a quality PoE switch that complies with the EN 62368-1
product safety standard. In accordance to the IEEE 802.3af (PoE) standard, the PoE switch must be
able to support the delivery of power up to, but not exceeding a maximum of 15.4W per port
(NIRC4-xMN).
11.1 Ferrite Clamp
The NIRC4 comes with a ferrite cable clamp.
Figure 19. Ferrite cable clamp on the NIRC4 LAN cable
Place the ferrite cable clamp around the LAN cable close to the RJ45 connector entering the NIRC4.
18 TD 93351EN / 21 March 2022 / Ver. B
