SOLUTION SHEET
Platform: MONITOR MASTER
- Keep services available
- Bill customers correctly
- 24x7 monitoring for proactive fault fixing
MONITOR MASTER
FOR REVENUE ASSURANCE
STOP REVENUE LEAKAGE ... FOR GOOD!
Monitor Master is just one product in Ascom‘s SYMPHONY
portfolio, which also includes products for walk/drive testing,
benchmarking and optimisation.

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 2
YOUR CHALLENGES
nIncorrect billing upsets regulators, your CFO, partners, and
customers.
nNew services must be introduced ever more quickly, reducing
testing time.
nAs networks, platforms and services evolve or expand, unfore-
seen errors make the bill wrong.
OUR SOLUTION
nAscom’s Monitor Master platform for proactive revenue
assurance.
nUsed by Regulators, Operators and Content Providers.
nCall generator, CDR comparison and billing verification.
THE BENEFITS
nAccurate billing streamlined with CDR comparison.
nCarrier grade tools today for tomorrow’s services.
n24x7 monitoring for proactive fault fixing to minimize down-
time and maximize revenue.

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 3
THE CHALLENGE
Getting the bill right is important. Charging too much upsets your
customers and gets the undivided attention of regulators. Charging too
little upsets the CFO. Incorrect revenue sharing upsets your partners.
Proving that the bill is right is tough. New services must be in-
troduced ever more quickly, reducing testing time. New technical skills
are needed to keep up to date with the next generation of converged
technologies.
Keeping the bill right is also tough. Normal day-to-day operation
reveals errors. As networks and services evolve or expand, unforeseen
errors make the bill wrong.
Monitor Master has
nIndustry leading flexibility allows tests for new services to
be created quickly without product change.
nDetailed trace capabilities give more detail than a hand-
set alone and allow the right billing measurements to be
recorded.
nInteractive Mode to run ad-hoc real-time tests at any loca-
tion.
nPowerful user reporting and data export in the right format
for downstream systems.

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 4
Test modelling
Test planning
Ad-hoc testing
Resource allocation
Interactive Mode
Device
characteristics
Monitor Master Quality Manager
… Voice IVR WAP Web SMS MMS IM Email Video VoIP UMA …
… HSDPA UMTS GPRS GSM CDMA WiFi IP …
Device Profiles
Scalable
Central SIM storage
SIM Server
Stable appliance
probe
IP or OTA
X1000
Smaller
form factor
X200
North bound
Data warehouse
Reporting & Analysis
Alarm & Trap management
Alarms
Traps
Data Integration
OUR SOLUTION
Ascom’s Revenue Assurance solution is based on our award winning
Monitor Master platform. We focus on the end-to-end 24x7 validation
and monitoring of complex user transactions.
Tests to simulate users accessing different services are scheduled
to run at different locations, using different SIMs and APNs.
Monitor Master components are built using Ascom’s established
Quality Manager Architecture, to provide the level of flexibility, reliability
and performance demanded.
The platform supports distributed agents and centralized manage-
ment, and is extremely configurable and flexible.
A SIM Server provides centralized storage for all your SIMs. This
allows flexible call campaigns including roaming scenarios.
Interactive Mode allows you to use a probe in any location like a
phone on your desktop for ad-hoc interactive voice and data testing.
A typical Monitor Master architecture

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 5
HOW IT’S USED
CDR Comparison
Monitor Master generates calls for voice and data services to pro-
duce test CDRs (Call Detail Records). Calls are scheduled to run auto-
matically or ad-hoc using Interactive Mode. The test CDRs are correlated
with the real CDRs using a third party system or by using tools within
Monitor Master. A number of options are available for reconciling test
and real CDRs.
Using a handset alone is not enough to give the detail needed about
what has been consumed during the test to reconcile with real usage.
Trace detail is needed to ensure accurate measurements.
Multi-modal transactions
With Monitor Master you can easily model complex user transac-
tions such as ring tone and game downloads. These services, accessed via
a WAP portal, can be monitored with automatic billing verification.
Billing
System
Test
CDRs
Real
CDRs
Reconciliation
Voice Text Games Location Photos
Video eMail Wi-Fi
Tones Payment Web i-Mode
IVR
WAP
Monitor Master Tests Simulated Users
Operator
CDR Comparison

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 6
Monitor Master’s flexibility allows the customer’s billing rules to be
checked in a test. For example, verify that the subscriber is charged for
a ring tone download and is not charged when downloading the same
ring tone again.
The future
It’s no longer enough to test basic voice and data. The next wave
of applications will include Web 2.0 and user generated content. The bill-
ing models for these services are not yet settled but one thing is clear,
Monitor Master’s flexibility will make testing easier.
Meeting your requirements
Whether your main billing concern is regulatory compliance, auto-
matic reconciliation, or partner revenue sharing, our highly professional
team of consultants can help you.
Example CDR Report

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 7
MEASUREMENT
Start
time
A Party
details
B Party
details
Duration
Bytes
up
Bytes
down
Success
fail
indicator
IP
address
Quality
of
Service
APN
Prepay
Postpay
SIM
URL
SERVICES
Voice n n n n n n n
WAP nn nnnnnnnnn
Web nn nnnnnnnnn
IM nnnnnnnnnnn
VoIP nnnnnnnnnnn
SMS nnnnnnnnnnn
MMS nnnnnnnnnnn
Content download nn n nnnnnn
Mobile TV nn n nnnnnn
Typical Metrics generated for CDR Reports

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 8
PROVEN BY REAL CUSTOMERS
A major US carrier uses Monitor Master
for revenue assurance testing. Their system
of 160 Monitor Master probes across the US
is used by more than 50 users who perform a
variety of checks for voice and data services.
Checks include ad-hoc interactive tests, pe-
riodic campaigns and network-wide checks.
This carrier uses their existing reconciliation
system, to which Monitor Master provides
data every 15 minutes.
Monitor Master has made a real saving for this carrier’s business.
Billing system tests
One customer uses Monitor Master to test upgrades to their billing
system. Monitor Master makes test calls to prove that each new change
is correct with no undesirable side effects.
Using Monitor Master gives them these advantages:
nRepeatability – identical tests can be performed again and
again. After each change is made, the test can be run again,
until the desired results are obtained.
nEfficiency – many more tests can be performed over a 24 hour
period without loss of accuracy than with a manual system.
nCoverage – thorough tests can be performed to exercise all
scenarios that might be encountered by real users.
nDetail – detailed results are stored for immediate use, to help
diagnose faults - but can also be used longer term, to demon-
strate compliance with regulatory requirements.
Network upgrade tests
One customer uses Monitor Master to prove that network changes
and upgrades have not upset their billing value chain. Monitor Master
runs a suite of tests to prove that services function and bill correctly after

SOLUTION SHEET: MONITOR MASTER FOR REVENUE ASSURANCE 9
11.2009 © Ascom Network Testing Ltd | monitor-master-for-revenue-assurance_solution-sheet_v15_scr
any network change. Changes are often quite localized to specific regions;
Monitor Master‘s distributed probes are therefore able to focus testing
on these regions as well as cover all possible service call types to ensure
complete coverage.
Monitor Master tests are repeatable and objective. Any test failure
can be seen at a glance; the detail available from the test helps resolve
any issues much more quickly than using an ad-hoc manual approach.
RAPID TIME TO VALUE
With estimates of the revenue loss through leaks as high as 10% for
new services, the rewards for finding and fixing leaks are clear.
Monitor Master provides the carrier-grade tools you need now and
in the future to give a very visible return on investment.
