Asgard GLADIATOR PLUS 1 User manual

It is always recommended to anchor the unit to the gorund. Drill through
the four holes in the base of the unit using 6mm dia masonry drill to a
depth of 70mm. Screw in the anchor fixings. (These have a self cutting
thread). If not anchoring the unit, fit the self seal plugs BEFORE
BUILDING to block the fixing holes from underneath.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill and a
10mm socket or spanner.
GLADIATOR PLUS 1
ZSCREW32 x12
ZSILCOL1 x2
ZSCREW04 x4
ZSCREW100 x410
ZSCREW340 x24
32670 x20
6mm
Dia.
10mm
Spanner
18V
ZCOMPPLZS02 x12
ZCOMPPLAS22-23-24 x18
6x 2mm, 6x 3mm, 6x 5mm
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 2410mm x 3790mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
ROOF BRACE 39897 x2
For maintenance instructions of this product visit www.asgardsss.co.uk
Warning: Please keep
this key card safe! Refer
to if replacement key is
required.
x2
Warning: some panels may weigh over
20Kg Beware of manual handling
SEALANT
00001
YOUR UNIQUE
KEY CODE
FRONT BASE PNL
039841 x1
TOP COVER CHANNEL 40063 X4
FLOOR COVER CHANNEL 40062 x4
FASCIA 39848 x1
RH DOOR
32944 x1
RH FRONT PANEL 039861 x1
LH FRONT PANEL 39860 x1
LH DOOR
32943 x1
RH FRT SIDE PANEL
39815 x1
SIDE COVER CHANEL 32916 x4
LH FRT SIDE PANEL
39814 x1
RH FRT TOP PANEL
39873 x1
LH FRT TOP PNL
39871 x1
LONG TOP CAP
39893 x1
SHORT TOP CAP
39892 x1
EXTENSION TOP CAP
40095 x1
RH EXT TOP PNL
40066 x1
LH EXT TOP PNL
40065 x1
RH REAR TOP PANEL
39869 x1
LH REAR TOP
PNL 39867 x1
ROOF JOINT
STRIP 40881 x4
LH BACK PANEL
39832 x1
LH REAR SIDE PANEL
32874 x1
RH REAR SIDE PANEL
32875 x1
REAR BASE PNL
39831 x1
RH BACK PANEL
39833 x1
TOP FRONT BACK CHANNEL
40094 x3
LH EXT SIDE PANEL
32853 x1
RH EXT SIDE PANEL
32854 x1
EXT BASE PANEL
40064 x1
Posi-Driv
Screwdriver

1
5 6
2
4
FLOOR COVER CHANNEL 40062
3
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x18
FIT OPTIONAL RAMP HERE.
REFER TO RAMP INSTRUCTIONS
x9 x9
x16 x4
x22 x22
x15
REAR BASE PNL
39831
EXT BASE PANEL
40064
x9
x4
x7
x4
x9
FRONT BASE PNL
39841
x8
x8
RH BACK PANEL 39833
RH REAR SIDE PANEL 32875
LH BACK PANEL 39832

7
9
8
10
11 12
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
RH FRONT PANEL 39861
FASCIA 39848
x5
x5
x15
x3
x15
x3
x22 x28
x32 x32
x36 x10
x15
x7
x7
x7
x7
x7
LH REAR SIDE PANEL 32874
LH EXT SIDE PANEL 32853
RH EXT SIDE PANEL 32854
RH FRT SIDE PANEL
39815
LH FRT SIDE PANEL
39814
SIDE COVER CHANELS 32916 x4
LH FRONT PANEL 39860
x9
x8
x8
x8
x8
x9
x7
x7

13
17 18
14
15 16
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x18
TOP FRONT BACK CHANEL
40094
x6
x6
x6
x6
x20
x54 x20
x6
x6
x4
x4
x6 x4
x4
32670
x18
LH REAR TOP PNL 39867
LH EXT TOP PNL 40065
LH FRT TOP PNL 39871
RH REAR TOP PNL
39869
LH REAR TOP PNL
39867
LH EXT TOP PNL
40065
RH EXT TOP PNL
40066
LH FRT TOP PNL
39871
RH FRT TOP PNL
39873 x1
x6
x6
x6
x7
x7
x4
x4

19
21
20
22
23 24
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x6
x3
x3
x6
x6
x6
x6
x6
x6
x6
x3
x3
x3
x3
x8
x24
x12
x4
x4
ROOF JOINT STRIP 40081
APPLY TO ALL
ROOF JOINT STRIP END
40081
TOP COVER CHANNEL 40063
ROOF BRACE 39897
LONG TOP CAP
39893
SHORT TOP CAP
39892
EXTENSION TOP CAP
40095
x3
x3

25 26
27 28
x4
x2
x2
www.asgardsss.co.uk
54946/10.05.17/KW/REV1
x30
x24 x12
RH DOOR
32944
LH DOOR
32943
ROOF STRIP
LONG TOP CAP 39893
SHORT TOP CAP 39892
EXTENSION TOP CAP 40095
x3
x3
x3
x3
x3
x3
