Asgard ACCESS User manual

It is always recommended to anchor the unit in to the ground. Drill
through the four holes in the base of the unit using 6mm dia masonry drill
to a depth of 70mm. Screw in the anchor fixings. (These have a self
cutting thread). If not anchoring the unit, fit the self seal plugs BEFORE
BUILDING to block the fixing holes from underneath.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill and a
10mm socket or spanner.
ACCESS
ZSCREW32 x4
ZSCREW381 x12
ZSCREW100 x60
ZSCREW340 x12
41843 x1 /41844 x1
ZHWMISC89 x2
ZHWHANDLE32 x1
ZSCREW42 x4
45767 x4
41824 x2
41459 x4
6mm
Dia.
Posi-Driv
Screwdriver
10mm
Spanner
18V
ZCOMPPLZS02 x8
ZCOMPPLAS22-23-24 x12
4x 2mm, 4x 3mm, 4x 5mm
BASE PANEL 40966 x1
LH BACK PANEL 41341 x1
RH BACK PANEL 41342 x1
RH SIDE PANEL 41331 x1
LH SIDE PANEL 41329 x1
LH FRONT PANEL 41452 x1
RH FRONT PANEL 41453 x1
RH DOOR S/A 41350 x1
LH DOOR S/A 41348 x1
LID S/A 40961 x1
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 2200mm x 1150mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
For maintenance instructions of this product visit www.asgardsss.co.uk
x2
Warning: some panels may weigh over
20Kg. Beware of manual handling
ZHWNUT41 x12
ZSCREW43 x10
2x 70mm disc padlocks
required. Not supplied.
Keys alike recommended.
All manuals and user guides at all-guides.com

PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
1
3
5 6
4
2
x3 x11
x16 x14
x12
BASE PANEL 40966
RH BACK PANEL 41342
LH BACK PANEL 41341
RH SIDE PANEL 41331
LH SIDE PANEL 41329
LH FRONT PANEL 41452
RH FRONT PANEL 41453
CORNER BRACES:
41843 and 41844
x3
x3
x4
x4
x4
x3
x4
x4
x3
x4
x3
x2
x2
x2
x2
x3
x3
x3
x12
RH DOOR S/A 41350
LH DOOR S/A 41348
x3
x3
x3
x3
All manuals and user guides at all-guides.com

7 8
910
11 12
x2
x12 x12
LID S/A 40961
x2
x2
ZHWHANDLE32
x2
41459
ZHWMISC89
ZSCREW381
45767
41459
All manuals and user guides at all-guides.com

13 14!
15!
ENSURE CORRECT ALIGNMENT
BEFORE ATTACHING SHROUDS
(41824)
FIT SHROUDS (41824)
AS HIGH UP AS
POSSIBLE
SHROUDS 41824
www.asgardsss.co.uk
41467/08.10.18/KW/REV5
x4
