Asgard COMPACT User manual

It is always recommended to anchor the unit in to the ground. Drill
through the four holes in the base of the unit using 6mm dia masonry drill
to a depth of 70mm. Screw in the anchor fixings. (These have a self
cutting thread). If not anchoring the unit, fit the self seal plugs BEFORE
BUILDING to block the fixing holes from underneath. Please note
product must be bolted down to comply with LPS1175.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill and a
13mm socket or spanner.
COMPACT
ZSCREW32 x4
ZSCREW100 x64
ZSCREW340 x18
6mm
Dia.
13mm
Spanner
18V
ZCOMPPLZS02 x4
ZCOMPPLAS22-23-24 x6
2x 2mm, 2x 3mm, 2x 5mm
LH SIDE PNAEL 31986 x1
LH DOOR 32253 x1
RH DOOR 32254 x1
BACK PANEL 31974 x1
FASCIA 32082 x1
RAIN GUARD 32030 x1
TOOL RAIL 32171 x1
BASE PANEL
32086 x1
TOP PANEL
31973 x1
RH SIDE PANEL 31987 x1
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 1280mm x 960mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
For maintenance instructions of this product visit www.asgardsss.co.uk
Warning: some panels may weigh over
20Kg. Beware of manual handling
Warning: Please keep
this key card safe! Refer
to if replacement key is
required.
x2
Posi-Driv
Screwdriver
00001
YOUR UNIQUE
KEY CODE

1
3
5 6
4
2
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x9
x16 x6
x15 x7
x11
RH SIDE PANEL 31987
BACK PANEL 31974
BASE PANEL
32086
LH SIDE PNAEL 31986
TOP PANEL 31973
FASCIA 32082
DO NOT TIGHTEN
SCREWS AT THIS
STAGE
!
RAIN GUARD 32030
x9
x4
x9
x6
x7
x4
x6 x4
x7
x7

7 8
910
x18
LH DOOR 32253
RH DOOR 32254
TOOL RAIL 32171
TOOL RAIL 32171
x4
www.asgardsss.co.uk
32234/11.12.15/KW/REV1
