Asgard Access Plus User manual

It is always recommended to anchor the unit to the ground. Drill through
the four holes in the base rails of the unit using 6mm dia masonry drill to
a depth of 70mm. Screw in the anchor fixings. (These have a self cutting
thread). Additional ZHWNUT42 and ZSCREW254 have been supplied for
bolting 2 units together using the side panels.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill and a
13mm socket or spanner.
DOUBLE ENDED BIKE LOCKER
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 1000mm x 2200mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
Warning: some panels may weigh over
20Kg. Beware of manual handling
13mm
Spanner
4mm
Allen Key
18V
For maintenance instructions of this product visit www.asgardsss.co.uk
x2
SEALANT
ZSCREW32 x6
ZSILCO1 x1
ZSCREW100 x58
ZSCREW254 X12
ZCOMPPLZS02 x8
ZCOMPPLAS22-23-24 x6
2x 2mm, 2x 3mm, 2x 5mm
6mm
Dia.
Posi-Driv
Screwdriver
ZHWNUT42 x4
35190 x2
FIXING CHANNEL 42655 x2
PARTITION PANEL 47381 x1 PARTITION END 046849 x2
SIDE PANEL 42172 x1
DOOR FRAME x1
LEFT HANDED: 43802 OR
RIGHT HANDED: 43801
LEFT HANDED SHOWN
DOOR FRAME x1
LEFT HANDED: 43802 OR
RIGHT HANDED: 43801
LEFT HANDED SHOWN
SIDE PANEL 42172 x1
TOP PANEL 46846 x1
TOP STIFFENER 42397 x1

1
3
5 6
4
2
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x1
x1
x5
x1
x1
x8
x8
x4
x4
x5
x5
x5
x2
x7
x24
x5
x10
x2
x1
x1
DOOR FRAME
LEFT HANDED: 43802 OR
RIGHT HANDED: 43801
DOOR FRAME
LEFT HANDED: 43802 OR
RIGHT HANDED: 43801
SIDE PANEL 42172
SIDE PANEL 42172
FIXING CHANNEL 42655 x2
TOP STIFFENER 42397
TOP PANEL 46846
UNIVERSAL HOOKS x2

7 8
910
x1
x1
x4
x4
x8
x4
x4
x6 x2 x8
x6
PARTITION END 046849 x2
PARTITION PANEL 47381

www.asgardsss.co.uk
047380/21.01.16/KW/R0
