Ashley AW180Bli User manual

SAFETY NOTICE:
If this heater is not properly installed, a house re
may result. For your safety, follow the installation
instructions. Never use make-shift compromises
during the installation of this heater. Contact local
building or re ofcials about permits, restrictions
and installation requirements in your area.
CAUTION!
Please read this entire manual before you
install or use your new room heater. Failure
to follow instructions may result in property
damage, bodily injury, or even death.
Improper Installation Could Void Your Warranty!
SAVE THESE INSTRUCTIONS
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
French version is available for download from the U. S. Stove website: http://www.usstove.com/
La version française est disponible pour téléchargement à partir du site U. S. Stove: http://www.usstove.com/
Approved for installation in the USA and Canada
CONFORMS TO UL 1482, AND CERTIFIED TO ULC-S627 AND ULC-S628
Also suitable for use in a Mobile or Manufactured home. (USA Only)
852396C-3201F
MODEL: AW180(BL)(i)
U. S. Stove
227 Industrial Park Road P.O. Box 151
South Pittsburg, TN 37380
[phone] • www.usstove.com
U.S. Environmental Protection Agency
Certied to comply with 2015 particulate emissions standards.

2
CAUTIONS:
• Hot while in operation. Keep children, clothing and furniture away. Contact may cause skin burns.
• Do not use chemicals or uids to ignite the re.
• Do not leave the stove unattended when the door is slightly opened.
• Do not burn garbage, ammable uid such as gasoline, naphtha or motor oil.
• Do not connect to or use in conjunction with any air distribution ductwork unless specically approved
for such installations.
• Always close the door after the ignition.
• Consult your municipal building department or re ofcials about permits, restrictions and installations
requirements in your area.
Combustible : Wood
Colors : Metallic Black
Flue Pipe Diameter : 6” (153cm)
Flue Pipe Type: (Standard Single Wall or Double Wall): Black or Blued Steel 2100°F (650°C)
Minimum Chimney Height : 12’ (3.7m)
Maximum Log Length : 17” (432mm)
Electrical 110 Volt, 60 Hz, 31 Watt
Dimensions
Overall : (without Pedestal)
Depth x Width x Height : 25.5” x 29.5” x 27” (655mm x 749mm x 685mm)
Combustion Chamber :
Width x Depth : 12.7” x 11.9” (322mm x 302mm)
Volume :
Cubic Feet: 1.7 cubic feet
Door Opening : Width x Height: 16.8” x 9” (406mm x 228mm)
Pyroceramic Glass Door : (Viewing) Width x Height: 17” x 10” (431mm x 254mm)
Weight (lbs): 433
Specications
Note: Register your product on line at www.usstove.com. See “Limited Warranty” section for specic
warranty information for your new purchase. Save your receipt with your records for any claims.
CONGRATULATIONS!
You’ve purchased a heater from North America’s oldest manufacturer of wood burning products.
By heating with wood you’re helping to CONSERVE ENERGY!
Wood is our only Renewable Energy Resource. Please do your part to preserve our wood supply. Plant at
least one tree each year. Future generations will thank you.
This manual describes the installation and operation of the Ashley, AW180(BL)(i) wood heater. This heater
meets the 2015 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters sold after
May 15, 2015. Under specic test conditions this heater has been shown to deliver heat at rates ranging from
9,550 to 25,696 Btu/hr.
Note: The BTU ratings mentioned above are based on the EPA test protocol burning dimensional Douglas
Fir lumber. Our advertised BTU’s are based on the rst hour of operation at high burn rate burning cordwood.

3
UNPACK AND INSPECT
Remove the packing from the appliance and inspect for any damage. Ensure that the bricks are positioned
correctly and not broken (see illustration for proper brick arrangement). Make sure that the bafe board,
above the air tubes, is in place and undamaged. DO NOT remove the bafe board.
Pre-Assembly
Brick Conguration

4
ASSEMBLY
ASSEMBLY INSTRUCTIONS
This appliance is offered in three different congurations of which you get to choose. You have the option
to install your new heater as a freestanding heater, on legs, as a replace insert, or on a pedestal. You must
purchase the desired kit separately from your appliance dealer.
Leg Kit
Fireplace
Insert
Pedestal

5
BLOWER INSTALLATION
2
1
4
3
Key Part No. Description Qty.
1 891492 Blower Assembly 1
2 27493 B36 Air Deector 1
3 27494 B-36 Mounting Plate 1
4 83172 #10AX1/2 Screws 4
The blower and deector panel for your stove come packed in the rebox.
1. Remove the blower and deector panel.
2. Attach the deector panel to the blower using the screws provided in the blower.
3. Attach the blower to the rear of the stove using four (4) screws (83172).
4. The mounting plate is installed on the stove from the factory.
�DO NOT REMOVE THE MOUNTING PLATE FROM THE STOVE THE
