Ashly VCM-88C Quick start guide

VCM-88C
The VCA unit shall contain 8 independent voltage controlled
amplifier channels capable of 20dB of amplification as well as
75dB of attenuation. Each channel shall also have a limiter with
a wide-range of threshold level adjustment and a limiter active
indicator. Each channel shall have a balanced input and servo-
balanced output. Each channel shall have the ability to combine
unbalanced input and output connections.
The VCA unit shall provide a master level control and a master
sum output connector for the unit to function as a stand-alone,
remote controlled line mixer.
The VCA unit shall be remotely controllable digitally over a stan-
dard RS-232 serial cable. The VCA unit shall provide phantom
power the remote controller and receive data over at least 1000
feet of 24 gauge shielded twisted pair. The unit shall also have
a data reception indicator and a remote disable switch. The VCA
channels and master level shall also be remotely controllable by
DC voltages through a euroblock connector using standard linear
taper potentiometers. The VCA channels and master level shall
also be remotely controllable by a PC connected by a standard
serial port and cable using Ashly Protea System Software, AMX
or Crestron control software. The unit shall have internal patch-
ing capabilities to route individual channel’s input and output to
any channel.
The output noise at unity gain on each channel shall be less than
-94dBu unweighted over 20Hz-20kHz. The total harmonic distor-
tion shall be less than 0.03% at 0dBu.
Crosstalk between adjacent channels shall be less than 80dB
over 20Hz-20kHz.
The frequency response shall be flat +/-0.2dB over 20Hz-
20kHz. The VCA unit shall weigh no more than 9 lbs. net and
mount into 1 rack space (1.75”) of a standard 19” rack. The
power requirement shall be 100-240VAC, 50-60Hz at less than
30W. The unit shall be the Ashly Audio VCM-88C.
The remote controller shall control 8 channels plus the master
level using slide faders. Each channel and the master shall have
an on/off switch with an indicator light. There shall also be a
remote disable indicator that illuminates when the remote con-
troller has been disabled at the VCA unit. The remote controller
shall be phantom powered by the VCA unit so that no batteries
or AC line cords are needed while controlling the VCA unit over
1000 feet of cable. The remote controller shall have a low pro-
file for desk-top operation and must have provisions to be rack
mounted where two remote controllers will occupy no more than
two 19” rack spaces (3.5” high).
The data signal shall not have characteristics which would cause
digital crosstalk noise into adjacent microphone-level chan-
nels in a multichannel snake cable. This data crosstalk noise
shall be less than -110dB along 1000 feet of adjacent 150 ohm
microphone lines. The remote controller shall be available in a
desk-top/rack-mount version as well as a wall-mount version for
permanently installing into a standard 4-gang electrical box. The
desk-top/rack-mount remote controller shall be the model RD-8C
and the wall-mount remote controller shall be the model RW-8C.
Features:
• Eight Channels of Remote Level
Control
• Bi-directional Communication
• Non-volatile Memory of Level
Settings
• RS-232 Interface Connector
• PC Control Using Protea System
Software, AMX or Crestron Control
Software
• Digital Control Over Shielded Twisted
Pair Cable
• DC Remote Control Using
Potentiometers
• Internal Channel Patching for
Flexible Signal Routing and Matrixing
• Internal Channel Pass-Through for
Cascading Multiple Units in Parallel
• Signal Present LED’s On Each
Channel
• RD-8C, RW-8C Compatible
• Works With Any Mixer With Channel
Insert Points
• Master Sum Output Jack
• +20dB to -75dB Level Control
• Individual Limiter Threshold
Adjustment for Each Channel
• Safety/Compliance: CE, RoHS
Technical Notes & Specifications
VCM-88C Eight Channel VCA Matrixing Level Controller
Architects Specications

Applications:
Remote control of stage monitors, personal monitor mixer, remote control of microphones in a church or
large meeting room, remote control of sound in a theme park or banquet facility. Dedicated 8-channel lim-
iter for speaker protection.
Specifications VCM-88C
INPUT TYPE: 1/4” TRS *
INPUT IMPEDANCE: 20kΩ balanced, 10kΩ unbalanced
MAX INPUT LEVEL: +23dBu
OUTPUT TYPE: Euroblock
OUTPUT IMPEDANCE: 132Ω Servo-balanced, 66Ω unbalanced
MAX OUTPUT LEVEL: +23dBu
NOMINAL GAIN: 0dB ± 0.5dB
GAIN RANGE: +20dB to -75dB
FREQUENCY RESPONSE: ± 0.2dB, 20Hz-20kHz
THD: < 0.03% @ 0dBu, 20Hz-20kHz
OUTPUT HUM AND NOISE: < -94dBu, 20Hz-20kHz unweighted
CROSSTALK: < -80dB @ 20Hz-20kHz
LIMITER THRESHOLD RANGE: -23dBu to +22dBu
LIMITER COMPRESSION RATIO: 10:1
DATA INPUT TYPE: 9-pin female D-Sub connector, 6 pin euroblock, 3-pin euroblock
DATA FORMAT: RS-232 using Protea System Software, 5V logic, RD-8C/RW-8C
DC CONTROL INPUT TYPE: 2x 6-pin euroblock
DC CONTROL VOLTAGE: -4V to +15V provided for external 10k ohm potentiometers
SIZE: 19”L x 1.75”H x 8”D
POWER REQUIREMENTS: 100-240VAC, 50-60Hz, 30W
SHIPPING WEIGHT: 13 lbs
RD-8C/RW-8C SPECS:
FADER RANGE: +10dB to -75dB (master fader @ 0dB)
DATA/POWER CONNECTOR: 3-pin
MAX DATA CABLE LENGTH: 1000ft
DATA FORMAT: 9600 baud, 5V
SIZE: 7.5”L x 3.5” H x 1.75”D
POWER REQUIREMENTS: Phantom powered by VCM-88C
SHIPPING WEIGHT: 3 lbs
*Input connector may be internally selected as a single in/out patch point.
