Ask Proxima M2+ User manual

User’s
Guide
>>>>>>>
6732ASK_M2_Cover.qxd 4/6/04 3:52 PM Page 1
Downloaded From projector-manual.com ASK Manuals

FCC Warning
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communi-
cations. Operation of this equipment in a residential area is likely to cause harm-
ful interference in which case the user will be required to correct the interference
at his own expense.
Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Can-
ada.
Safety Certifications
UL, CUL, TUV, GOST
Other specific Country Approvals may apply, please see product certification
label.
EN 55022 Warning
This is a Class A product. In a domestic environment it may cause radio interfer-
ence, in which case the user may be required to take adequate measures.
InFocus reserves the right to alter product offerings and specifications at any time.
M2+.book Page 1 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

Declaration of Conformity
Manufacturer: InFocus Corporation
27700B SW Parkway Ave. Wilsonville, Oregon 97070 USA
European Office: Strawinskylaan 585, 1077 XX Amsterdam, The Netherlands
We declare under our sole responsibility that the projector conforms to the follow-
ing directives and norms:
Directive 89/336/EEC, Amended by 93/68/EEC
EMC: EN 55022
EN 55024
EN 61000-3-2
EN 61000-3-3
Directive 73/23/EEC, Amended by 93/68/EEC
Safety: EN 60950: 1992 + A1 + A2 + A3 + A4: 1997
January, 2004
Trademarks
Apple, Macintosh, and PowerBook are trademarks or registered trademarks of
Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of
International Business Machines, Inc. Microsoft, PowerPoint, and Windows are
trademarks or registered trademarks of Microsoft Corporation. InFocus, ASK
Proxima, and LP are trademarks or registered trademarks of InFocus Corporation.
M2+.book Page 2 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

i
TABLE OF CONTENTS
Safety Instructions iii
Introduction 1
Image Resolution 1
Compatibility 1
Unpacking the Projector 1
Usage Guidelines 4
If You Need Assistance 4
Warranty 4
Setting up the Projector 5
Connecting a Computer 7
Connecting a Video Player 9
Powering up the Projector 11
Turning Off the Projector 14
Using the Projector 15
Basic Image Adjustment 15
Adjusting the Projector 15
Using the Remote Control 17
Using the Keypad and Remote Buttons 18
Using the On-Screen Menus 20
Basic Menu 21
Setup menu 23
Maintenance & Troubleshooting 29
Cleaning the Lens 29
Cleaning the Lamp Filter Screens 29
Replacing the Projection Lamp 30
Replacing the Batteries in the Remote Control 32
Using the Security Lock 32
Troubleshooting 33
Appendix 37
Accessories 37
Projected Image Size 38
Index 39
M2+.book Page i Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

ii
table of contents
M2+.book Page ii Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

iii
SAFETY INSTRUCTIONS
Please read and follow all safety instructions provided BEFORE
using your new projector. Failure to comply with safety instruc-
tions may result in fire, electrical shock, or personal injury and
may damage or impair protection provided by equipment. Please
save all safety instructions.
Safety Definitions:
•Warning: Statements identify conditions or practices that
could result in personal injury.
•Caution: Statements identify conditions or practices that could
result in damage to your equipment.
Safety Symbols:
Attention: For information about usage of a feature, please
refer to the User’s Guide.
Warning: Hot surface. Do not touch.
An arrow pointing to the lamp door on the projector.
Warning: Turn the projector off, disconnect the power cord,
and wait 60 minutes before opening the lamp housing.
Safety Terms:
•Warning: Don’t look directly into the lens when the projector is
turned on.
•Warning: To replace the lamp, turn the projector off
and unplug the power cord. To avoid burns, wait 60 min-
utes before opening the lamp door. Follow all instructions pro-
vided in this User’s Guide.
•Warning: Please use the power cord provided. Connect
the power cord to a receptacle with a protective safety
(earth) ground terminal.
•Warning: Refer all service to qualified service personnel. Ser-
vicing your own projector will void the warranty.
•Caution: Don’t block ventilation openings.
M2+.book Page iii Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

iv
Safety Instructions
•Caution: Don’t set liquids on the projector. Spilled liquids may
damage your projector.
•Caution: Don’t place the projector on a hot surface or in direct
sunlight.
•Caution: Do not drop the projector. Transport the projector in
an approved case; see page 37 for a list of cases.
Important Operating Considerations for Safety
•Place the projector in a horizontal position no greater than 15
degrees off axis.
•Locate the projector in a well-ventilated area without any
obstructions to intake or exhaust vents. Do not place the projec-
tor on a tablecloth or other soft covering that may block the
vents.
•Locate the projector at least 4' (1.2 m) away from any heating or
cooling vents.
•Refer to this manual for proper startup and shutdown proce-
dures.
•In the unlikely event of the lamp rupturing, discard any edible
items placed in the surrounding area and thoroughly clean the
area along all sides of the projector. Wash hands after cleaning
the area and handling the ruptured lamp. This product has a
lamp which contains a very small amount of mercury. Dispose
of it as required by local, state or federal ordinances and regula-
tions. For more information see www.eiae.org.
Follow these instructions to help ensure image quality and lamp
life over the life of the projector. Failure to follow these instruc-
tions may affect the warranty. For complete details of the war-
ranty, see the Warranty section at the end of this user's guide.
Do not place objects in
this area on the back of the projector
2ft(.6m)
M2+.book Page iv Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

1
INTRODUCTION
The ASK Proxima M2+™ is a projector specifically designed for
portability, connectivity, and collaboration. It is easy to connect,
easy to use, easy to transport, and easy to maintain.
Image Resolution
The XGA resolution of the projected image is 1024x768. The pro-
jector is compatible with screen resolutions up to 1280x1024. If
your computer’s screen resolution is higher than 1280x1024, reset
it to a lower resolution before you connect the projector.
NOTE: The projector automati-
cally expands 640x480 and
800x600 images to 1024x768.
Compatibility
The projector is compatible with a wide variety of computers and
video devices, including:
•IBM-compatible computers, including laptops, up to 1280x1024
resolution.
•Apple®Macintosh®and PowerBook®computers up to
1280x1024 resolution.
•Most standard VCRs, DVD players, camcorders, digital cam-
eras, and laser disc players.
Unpacking the Projector
The projector comes with the items shown in Figure 1. Check to
make sure all are included. Contact your dealer immediately if
anything is missing.
If you are experienced in setting up presentation systems, use the
Quick Start card that was included in the shipping box. For com-
plete details on connecting and operating the projector, refer to
this User’s Guide. Electronic versions of this user’s guide in mul-
tiple languages are available on the included CD and on our web-
site at www.askproxima.com.
M2+.book Page 1 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

2
Introduction
FIGURE 1
Shipping box contents
1. Projector + lens cap 6. Audio cable
2. Remote control with batter-
ies
7. Computer cable
3. User’s Guide, Quick Start
card, and CD
8. SCART adapter *
4. Audio/Video (A/V) cable
5. Power cord *
* country-dependent
123
45
6
7
8
M2+.book Page 2 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

3
FIGURE 2
Front view of projector
FIGURE 3
Rear view of projector
FIGURE 4
Bottom view of projector
keypad
zoom r
i
ng
focus ring
remote control sensor (IR)
connectors
power connector
security lock
remote control sensor (IR)
adjustable foot
speaker
f
oot re
l
ease
lamp housing
leveling foot
M2+.book Page 3 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

4
Introduction
Usage Guidelines
•Do not look directly into the projection lens when the projector
is turned on. The bright light may harm your eyes.
•Do not block the grills on the projector. Restricting the air flow
can cause it to overheat and turn off. If this happens, you must
wait a minute before attempting to turn it back on.
•Handle the projector as you would any product with glass
components. Be especially careful not to drop it.
•Avoid leaving the projector in direct sunlight or extreme cold
for extended periods of time. If this happens, allow it to reach
room temperature before use.
•Transport the projector in a vendor-approved hard or soft case.
Part numbers for these cases are listed on page 37.
If You Need Assistance
The first place to look for help is in this manual. Be sure to check
the guidelines in “Troubleshooting” on page 33. Or, check the
Service and Support section of our website at
http://www.askproxima.com/service.
Warranty
This product is backed by a limited warranty. The details of the
warranty are printed at the back of this manual. An extended
warranty plan may be purchased from your dealer. When send-
ing your projector in for repair, we recommend shipping the unit
in its original packing material, or having a professional packag-
ing company pack the unit for shipping. Please insure your ship-
ment for its full value.
M2+.book Page 4 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

5
SETTING UP THE PROJECTOR
1Place the projector on a flat surface.
•The projector must be within 6 feet (1.8 m) of your power
source and your computer.
•If you want to project from behind a translucent screen, set
up the projector behind your screen. See “Rear” on page 24
to reverse the image.
2Position the projector the desired distance from the screen.
NOTE: The projector must be at
least 4.9 feet (1.5 m) from the
projection screen.
•If the image is too big or too small, use the zoom ring to
adjust the size or move the projector forward or backward.
Figure 5 shows three projected image sizes. For more infor-
mation about image size, see “Projected Image Size” on
page 38.
FIGURE 5
Projected image size
3Make sure the projector and the computer are turned off.
3.3ft./1m
22.2ft./
6.7ft/
4.9 ft./
9.9 ft./
33 ft./
10m
6.8m
2m
3m
1.5m
M2+.book Page 5 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

6
Setting up the Projector
NOTE: Before you continue,
make sure the projector and all
other equipment is turned off. If
you’re connecting a computer,
make sure the distance between it
and the projector is 6 feet or less.
FIGURE 6
Connector panel
Wireless Projection
You can use the projector’s Computer connector along with the I
nFocusLiteShowwireless adapter and software for cable-free digital
projection. Contact an authorized InFocus dealer or visit our website at
www.infocus.com for more information.
Audio in
S-video
Composite video
Computer
M2+.book Page 6 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

7
NOTE: Many laptop computers
do not automatically turn on their
external video port when a sec-
ondary display device such as a
projector is connected. Refer to
your computer manual for the
command that activates the exter-
nal video port.
Connecting a Computer
The projector ships with an analog computer cable. If your com-
puter has a digital output, you can order the optional digital com-
puter cable. Using a digital source generates the highest quality
and brightest image possible. See “Optional Accessories” on
page 37.
1Plug the black end of the computer cable into the “Computer”
connector on the projector.
2Plug the blue end of the computer cable into the video connec-
tor on your computer. If you are using a desktop computer,
you need to disconnect your monitor cable from your com-
puter.
FIGURE 7
Connecting the projector to a computer
Do you want to play your computer’s audio on the projector?
1Plug either end of the audio cable into the audio connector on
your computer.
2Plug the other end of the audio cable into an “Audio in” con-
nector on the projector.
audio
computer
M2+.book Page 7 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

8
Setting up the Projector
Do you want to advance slides in PowerPoint with the projector’s
remote?
NOTE: The USB mouse is
supported for use with
Windows 98 or higher only.
1Plug the USB end of the computer cable into the mouse con-
nector on your computer.
You must have the appropriate USB drivers installed on your
computer to use the USB feature. Windows 98 ships with the
appropriate drivers. For more information, see “Powering up the
Projector” on page 11.
Now you’re ready to power up the projector and your computer.
Skip to page 11.
M2+.book Page 8 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

9
Connecting a Video Player
If your video device (VCR, DVD player, video camera) uses a
round, one-prong composite video connector, use the composite
audio/video (A/V) cable.
•If your video device uses a round, four-prong S-video con-
nector, use an S-video cable, ordered separately. S-video
generates a higher quality image.
1Plug the A/V cable’s round yellow connector into the “video-
out” connector on your video device (Figure 8). This connec-
tor may be labeled “To Monitor.”
•If you’re using an S-video cable, connect the round black
connector to the “S-video out” connector on the video
device.
2Plug the other yellow connector into the “Video” connector on
the projector.
•If you’re using S-video, plug the other end of the cable into
the “S-video” connector on the projector.
FIGURE 8
Connecting the projector to a VCR using the A/V cable
audio
video
L R
audio
video
M2+.book Page 9 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

10
Setting up the Projector
FIGURE 9
Connecting the projector to a VCR using the S-video cable and A/V cable
CAUTION: Your video player
may also have a “Video Out”
connector for a coaxial cable
connection. DO NOT use this to
connect to the projector.
3Plug the A/V cable’s white connector into the left “audio out”
connector on your video device. Plug the cable’s red connec-
tor into the right “audio out” connector on the video device.
4Plug the blue end of the A/V cable into the “Audio in” con-
nector on the projector.
•When you are using the S-video cable along with the A/V
cable, the A/V cable’s yellow connectors are not used.
The projector is compatible with these major broadcast video
standards: NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, and
SECAM. It automatically adjusts to optimize its performance for
the incoming video.
audio
S-video
S-video
LR
audio
M2+.book Page 10 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

11
Powering up the Projector
NOTE: Always use the power cord
that shipped with the projector.
1Remove the lens cap.
2Plug the power cord into the side of the projector, then plug it
into your electrical outlet. A surge-protected power strip is
recommended.
•The LED turns orange (Figure 6 on page 6).
3Press the Power button on the top of the projector.
NOTE: The first time you connect
your computer to the projector, the
computer may display a message
stating that new hardware was
found. The Add New Hardware
Wizard may appear. Use the Wiz-
ard to load the correct driver (the
computer considers the projector a
Plug and Play Monitor).
•The fans start to run, the LED on the top of the projector
(Figure 6 on page 6) lights solid green if the projector is con-
nected to a valid source, and the startup screen appears. It
takes about one minute for the image to achieve full bright-
ness.
4If you connected to a video player, turn it on.
•The video image should display on the projection screen. If
it doesn’t, press the Source/Select button on the keypad or
the Video button on the remote to display your video
image.
5If you connected to a computer, turn it on.
The first time you connect a particular computer to the projec-
tor, the computer recognizes the projector as “new hardware”
and the Add New Hardware Wizard appears. Follow these
instructions to use the Wizard to load the correct driver (which
was installed with your Windows operating system).
Click Next. Make sure “Search for the best driver” is selected,
then click Next.
M2+.book Page 11 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

12
Setting up the Projector
Uncheck any checked boxes, then click Next. Windows auto-
matically locates the driver. If this driver has been removed,
reload the driver using your Windows operating system CD.
When Windows finds the driver, you are ready to install it.
Click Next.
M2+.book Page 12 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals

13
Click Finish when installation is complete.
6The computer image should display on the projection screen.
If it doesn’t, press the Source/Select button on the keypad or
the Computer button on the remote to display your com-
puter’s image.
NOTE: With some computers,
the order in which you power up
the equipment is very important.
Most computers should be turned
on last, after all other peripherals
have been turned on. Refer to your
computer’s documentation to
determine the correct order.
•Make sure your laptop’s external video port is activated;
see your laptop’s documentation for details.
•If necessary, make adjustments to the image using the pro-
jector’s on-screen menus. To open the menus, press the
Menu button on the keypad or remote. For more informa-
tion about the menus, see page 21.
M2+.book Page 13 Thursday, April 8, 2004 8:10 AM
Downloaded From projector-manual.com ASK Manuals
