Askey SmartRouter IAD User manual

i
WHD0110 (RoHS)
SmartRouter IAD
Quick Guide
Version released: 1.0

SmartRouter IAD User Manual
ii
TABLE OF CONTENTS
____________________________________________________________________
Before You Use........................................................................................................... 3
Unpacking................................................................................................................... 3
Chapter 1: Overview................................................................................................... 4
Physical Outlook................................................................................................. 4
Chapter 2 : System Requirement and Installation................................................... 8
Connecting the SmartRouter IAD ...................................................................... 8
Setting up TCP / IPv4........................................................................................ 10
For Windows 7 ....................................................................................... 10
Renewing IP Address on Client PC.................................................................. 13
For Windows 7 ....................................................................................... 13
Brief introduction of UI on TV .......................................................................... 16

3
BeforeYouUse
Thank you for choosing the SmartRouter IAD WHD0110(RoHS) is dual-core
dual system with super memory about 1G RAM + 4G eMMC and built-in
removable hard disk up to 1TB. It supports gigabit WiFi with 802.11ac
double frequency (2.4GHz/5GHz). It can be used as Router and HD player at
same time. It has perfect user interface, so users can manage the files,
listen to music, play videos, view photos. It also has SD card and USB port;
it is convenient to manage external files for users. Now users can enjoy
various bandwidth-consuming applications via WHD0110 (RoHS)
SmartRouter.
Unpacking
Check the contents of the package against the pack contents checklist
below. If any of the items is missing, then contact the dealer from whom the
equipment was purchased.

SmartRouter IAD User Manual
4
Chapter1:Overview
This chapter provides you the description for the LEDs and connectors on
the front and rear surface of the router. Before you use/install this
SmartRouter IAD, please take a look at the information first.
PhysicalOutlook
①SD Card Slot Compatible with SD3.0, MMC ver4.41
②Hot Key for copy file from SD Card to HDD
③LED with White & Red, detail as follows

SmartRouter IAD User Manual
5
①Push button for WPS
②Push Switch for Power On
③Ports RJ45 10/100 for LAN Ethernet
④Port RJ45 10/100 for WAN Ethernet
⑤HDMI Port Support HDMI1.4 3D feature 1080P/720P
⑥Earphone Jack
⑦Ports USB2.0 for Mouse or key Broad or USB Storage
⑧Push button for Reset to default
⑨DC Jack for 12V Power Supply

SmartRouter IAD User Manual
6
①SATA2.5"HDDSwapable Slot with default 1TB HDD
①Home button
②Direction button
③OK button

SmartRouter IAD User Manual
7
④Back button
⑤Menu button
⑥Favorites button
⑦Play/Pause button
⑧Vol up button
⑨Vol down button

SmartRouter IAD User Manual
8
Chapter 2 : System Requirement and Installation
Connecting the SmartRouter IAD
Please follow the steps below to connect the related devices.

SmartRouter IAD User Manual
9

SmartRouter IAD User Manual
10
Setting up TCP / IPv4
In the following illustrations, we will set the PC to get an IP address
automatically at the same time.
For Windows 7 
1. Open the Start menu, point to Control Panel and click it.
2. Double click the Network and Sharing Center.

SmartRouter IAD User Manual
11
3. Click Local Area Connection and then click Properties.

SmartRouter IAD User Manual
12
4. When it returns to the General Tab on the Local Area Connection
Properties window, highlight Internet Protocol (TCP/IPv4) and then click
Properties.
6. Under the General tab, select Obtain an IP address automatically, and
Obtain DNS server address automatically. Then click Ok.

SmartRouter IAD User Manual
13
Renewing IP Address on Client PC
After the SmartRouter IAD gets on line, there is a chance that your PC does
not renew its IP address and thus causes the PC not able to access the
Internet. To solve this problem, please follow the procedures below to
renew PC’s IP address.
For Windows 7 
1. Open the Start menu, and search Run.

SmartRouter IAD User Manual
14
2. Type cmd in the text box that appears and click OK. Then you will see
the command prompt window.
3. Type ipconfig at the command prompt window and press Enter to view
the computer’s IP information from DHCP server.

SmartRouter IAD User Manual
15
4. If the computer is holding a current IP address, type ipconfig /release to
let go of the address, then type ipconfig /renew to obtain a new one.

SmartRouter IAD User Manual
16
Brief introduction of UI on TV
In the following illustrations, we will know the function on the User
interface.
①Date & time and location: Can show current location and date & time
②Weather: Can show current weather condition, humidity and light
intensity (based on the information from the Internet)
③Setting: Can set up SmartRouter
④Folder: Can read and write folder
⑤Photo & Video & Music: Can open picture, video and music directly
