Askia Kameleon K1-Solid Back User manual

Kameleon K1-Solid Back
ASSEMBLY INSTRUCTIONS
ACOUSTIC PODS

ASSEMBLY INSTRUCTIONS
Info.
Power drill needed.
Allen key needed.
Allen key and screws needed.
T-Handle hex key needed.
T-Handle hex key and screws needed.
Unlocked.
Lock.
Level check.
Steps.
Bag with screws.
Screwdriver needed.
Main Ethernet supply.
Main Power supply.
Ventilation coupling.
Power coupling.
Ethernet coupling.
Lighting coupling.
Motion sensor coupling.
Magnetic coupling element.
Whiteboard.
Pinboard.
VESA Adapter.
Pay attention to.
Pay attention not
to break the glass.
Ok.
Stop.
Do.
Don’t.
Pay attention to.
Move in place.
Position the door on pins.

Included
Assembly in 40 min. with 2 people
Not Included
x1 T-Handle Hex Key 4
Screwdriver
x1 T-Handle Hex Key 5 x1 T-Handle Hex Key 7 x2 Sucction cupsx1 Ceiling Panels Adjusterx1 Allen Key 2 x1 Allen Key 3
x6 x2
x16 x2

x1 Exterior Back
Panel
x1 Middle Structure Panel
x2 Middle
Back Panel
Elements
x1 Door Handle x1 Table
x3 Acoustic Felt Ceiling Panels
x1 Ceiling
x1 Carpet
x1 Floor
x1 Left & x1 Right Structure Panels x1 Door Frame
x1 Left & x1 Right Interior Panel
x2 Exterior Panel

1
T-Handle Hex Key 4

2
x16 with
T-Handle Hex Key 4

3
Inside
Outside
T-Handle Hex Key 7
Sucction cup handles

4
T-Handle Hex Key 7
Sucction cup handles
The door opening can
be oriented Left or Right
just by rotating the frame.
Outside

5
InteriorExterior
InteriorExterior
x6 with
T-Handle Hex Key 4
x2 with
Allen Key 3

6
Bottom
Top
Allen Key 3
Allen Key 2
Check if the door closes
properly and adjust the
door plates if needed.
Tighten or loosen the
plates when needed.
Adjust the glass door if
necessary.
Check if the glass door
hits the frame edge before
closing it.
To adjust the glass door the height must be
calibrated. If you need to raise the glass door,
you loosen the top hinge and tighten the
bottom hinge.
If you need to lower the
glass door, you loosen
the bottom hinge and
tighten the top hinge.
Pay attention not to
break the glass door.
Pay attention not to
break the glass door.

7
Main Power & Ethernet supply at the
back of the pod.
Check if the lighting, ventilation and
power sockets are connected properly.
Orange Black

8
How to remove
the Interior Panel.

9
Front
Back
How to remove
or adjust the
Acoustic Felt
Ceiling Panels.
How to place
the Acoustic Felt
Ceiling Panels.

10
How to remove
the Interior Panel.

11
x2 with
T-Handle Hex Key 5
T-Handle Hex Key 7
Screwdriver (Not Included)

12

12
If you want to reposition the
pod, you have to remove the
carpet, if needed, and unlock the legs. When you are satisfied
with the pod’s position, lock the legs and place the carpets.
If you are satisfied with the pod’s
position, you can place the carpets.

ON OFF
Adjustable FAN and LED
FAN 100%
OFF
OFF ON
OFF
80% 60%
ON
ON
1
2
ON OFF

Scan
Optional
You can watch an instructional video of the K1 assembly process.
Thanks to the modular design and limited number of components used
for each pod, many steps are similar between different Kameleon pods.
There are multiple features that you can personalize your
pod with. You can view them for each Kameleon on our
website www.askiafurniture.ro
Exterior Hanging
Whiteboard or Pinboard
Interior Hanging
Whiteboard or Pinboard
VESA Adapter Coat Hanger

Eliade Tower,
Mircea Eliade No.18
RO-Bucharest, 012015
T [phone]
[e-mail]
www.askiafurniture.ro
Last update: 06.02.2023
