Askia Kameleon K4 User manual

Kameleon K4
ACOUSTIC PODS
ASSEMBLY INSTRUCTIONS

Included
x1 T-Handle Hex Key 4 x1 T-Handle Hex Key 5 x2 Sucction cupsx1 Ceiling Panels Adjusterx1 Allen Key 1.5 x1 Allen Key 3
x6 x8
x32 x2

Elements
x1 Center Back Glass Wall
x1 Door Frame
x2 Ceiling
x1 Ceiling Coupling connection
x2 Media adjuster
x1 Door Handle
x6 Acoustic Felt Ceiling Panels
x6 Carpet, x4 Dividers
x2 Floor
x1 Floor Coupling connection
x4 Interior Panels x2 Left & x2 Right Structure Panels
x4 Exterior Panels x1 Left & x1 Right
Coupling connections
x1 Left & x1 Right Back Glass Walls x1 Left & x1 Right Front Glass Walls

1
T-Handle Hex Key 5

2
x16 with
T-Handle Hex Key 4

3
Top
Bottom
x8 with
T-Handle Hex Key 4
Bottom
Top

4
Top
Bottom
T-Handle Hex Key 4
Top
Bottom
Inside
Outside

5
T-Handle Hex Key 5
Intside

6
x16 with
T-Handle Hex Key 4
Inside
Outside

7
Recomandation
It is recomended to start with
the Center Back Glass Wall.
T-Handle Hex Key 4
Sucction cup handles
Inside
Up

8
T-Handle Hex Key 4
Sucction cup handles
Inside
Outside

9
The door opening can
be oriented Left or Right
just by rotating the frame.
Recomandation
It is recomended to start
with the Door Frame.
T-Handle Hex Key 4
Sucction cup handles

10
InteriorExterior
InteriorExterior
x6 with
T-Handle Hex Key 4
x2 with
Allen Key 3

11
Bottom
Top
Adjust the glass door
accordingly if needed.
Do not close until you
check the glass door not
to hit the door frame edge.
Pay attention not to
break the glass door.
Check if the door closes
properly and adjust the
door plates if needed.
Tighten or loosen the
plates when needed.
To adjust the glass door the height must be
calibrated. If you need to raise the glass door,
you loosen the top hinge and tighten the
bottom hinge.
If you need to lower the
glass door, you loosen
the bottom hinge and
tighten the top hinge.
Allen Key 3
Allen Key 1.5

12
T-Handle Hex Key 4
Sucction cup handles
Inside
Outside

13
Main Poewr & Ethernet supply at the
back of the pod.
Check if the lighting, ventilation and
power sockets are conected propperly.
Orange Black

14
How to remove
the Interior Panel.

15
Front
Back
How to remove
or adjust the
Acoustic Felt
Ceiling Panels.
How to place
the Acoustic Felt
Ceiling Panels.

16

17
If you want to reposition the
pod, you have to remove the
carpet, if needed, and unlock the legs. When you are satisfied
with the pod’s position, lock the legs and place the carpets.
If you are satisfied with the pod’s
position, you can place the carpets.
