Askia Kameleon K4 User manual

Kameleon K4 - Solid Back
ACOUSTIC PODS
ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS
Info.
Power Drill needed.
Allen key needed.
Allen key and screws needed.
T-Handle hex key needed.
T-Handle hex key and screws needed.
Unlocked.
Lock.
Level check.
Steps.
Bag with screws.
Screwdriver needed.
Main Ethernet supply.
Main Power supply.
Ventilation coupling.
Power coupling.
Ethernet coupling.
Lighting coupling.
Motion sensor coupling.
Magnetic coupling element.
Whiteboard.
Pinboard.
VESA Adapter.
Pay attention to.
Pay attention not
to break the glass.
Ok.
Stop.
Do.
Don’t.
Pay attention to.
Move in place.
Position the door on pins.

Assembly in 150 min. with 3 people
Included
x1 T-Handle Hex Key 4 x1 T-Handle Hex Key 5 x1 T-Handle Hex Key 7 x2 Sucction cupsx1 Ceiling Panels Adjusterx1 Allen Key 2 x1 Allen Key 3
x6 x8
x32 x2
x8
I

Elements
x2 Exterior Back
Panels
x1 Exterior Middle
Panel
x2 Back
Panels
x2 Middle
Back Panels
x2 Back Structure Panels x1 Middle Structure Panel
x4 Interior Panels x2 Left & x2 Right Structure Panels x4 Exterior Panels x1 Door Frame x1 Left & x1 Right Front Glass
Walls

x2 Ceiling
x6 Acoustic Felt Ceiling Panels
x6 Carpet, x4 Dividers
x2 Ceiling Coupling connection
x2 Floor Coupling connection
x2 Floor
Elements
x2 Media adjuster
x1 Door Handle
x1 Left & x1 Right
Coupling connections

1
T-Handle Hex Key 4

2
x16 with
T-Handle Hex Key 4

3
Top
Bottom
x8 with
T-Handle Hex Key 4
Bottom
Top

4
Top
Bottom
T-Handle Hex Key 7
Top
Bottom
Inside
Outside

5
T-Handle Hex Key 4
T-Handle Hex Key 7
Inside

6
x16 with
T-Handle Hex Key 4
T-Handle Hex Key 7
Inside
Outside

7
Inside
Recommendation
It is recommended to start with
the Middle Structural Panel.
T-Handle Hex Key 7
Sucction cup handles

8
T-Handle Hex Key 7
Sucction cup handles
Inside
Outside

9
x8 with
T-Handle Hex Key 4
Up
I

10
The door opening can
be oriented Left or Right
just by rotating the frame.
Recommendation
It is recommended to start with
the Door Frame.
Sucction cup handles

11
InteriorExterior
InteriorExterior
x6 with
T-Handle Hex Key 4
x2 with
Allen Key 3

12
Bottom
Top
Adjust the glass door if
necessary.
Check if the glass door
hits the frame edge before
closing it.
Pay attention not to
break the glass door.
Check if the door closes
properly and adjust the
door plates if needed.
Tighten or loosen the
plates when needed.
To adjust the glass door the height must be
calibrated. If you need to raise the glass door,
you loosen the top hinge and tighten the
bottom hinge.
If you need to lower the
glass door, you loosen
the bottom hinge and
tighten the top hinge.
Allen Key 3
Allen Key 2

13
T-Handle Hex Key 7
Sucction cup handles
Inside
Outside

Main Power & Ethernet supply at the
back of the pod.
Check if the lighting, ventilation and
power sockets are connected properly.
Orange Black
14

How to remove
the Interior Panel.
15
