Asko T754C User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs
for many years to come. Scandinavian design combines clean
lines, everyday functionality and high quality. These are key
characteristics of all our products and the reason they are
greatly appreciated throughout the world.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
Operating Instructions
Tumble dryer
ASKO T754C

3
Before using your machine for
the first time
4Safety instructions
4
Safety
4
Transport/Winter storage
4
Packing material
4
Recycling
5
To minimize the risk of fire in a
tumble dryer, the following should
be observed:
6Child safety
6
General
7Description of the tumble dryer
8
Advice and tips before you
tumble-dry
8
Materials that can be tumble-dried
8
Materials that must not be
tumble-dried
8
Static electricity
9Tumble drying
9
Sort your fabrics
10
Select the program
12
Selecting Options
12
Press the Start button
13
Drying program finished
14Care and cleaning
14
Cleaning the lint filter
15
Emptying the condensed water
container
15
Cleaning the outside of the
machine
16
Cleaning the condenser
18Troubleshooting
18
The machine will not start
18
The machine loses all power
during a program
18
Drying takes too long
18
Error messages
19Technical information
19
Technical data
19
Standard tests
20Service
20
Before contacting the service
division
21Installation
21
Positioning the tumble dryer
22
Adjusting the feet
23
Condensed water
23
Electrical installation
24Door hanging
25
Follow these instructions:
28Quick guide
2
Contents

Laundry labels
Certain materials are not suitable for
tumble-drying. Always check and follow the
instructions on each item’s laundry label. You can
find more information in the Advice and tips before
you tumble-dry chapter.
NOTE!
When starting the tumble dryer for the first time
or after a long period without use, you may notice
a slight thumping noise. This noise is completely
normal and will disappear after a few loads.
3
Before using your machine for the first time

Read the operating instructions and
keep them in a safe place!
• Electrical installation, if required, should be
carried out by a qualified electrician.
• The machine should only be used for
tumble-drying as described in these
instructions.
• Repairs and maintenance must be carried out
by a qualified professional.
•Damaged mains cables must only be replaced
by a qualified electrician.
• Sufficient ventilation is required to prevent
smoke from open fires or fumes from
equipment burning other fuels being sucked
into the room when the tumble dryer is running.
• Do not dry dirty laundry in the tumble dryer.
• Items that are stained with e.g. cooking oil,
acetone, alcohol, petrol, kerosene, stain
remover, turpentine, wax and wax remover
should be washed in hot water with extra
detergent before they go in the tumbler dryer.
• Items such as foam rubber, latex, plastic,
waterproof textiles, rubber-coated items and
clothes and foam-rubber filled cushions must
not be dried in the tumbler dryer.
• Fabric softener or similar products should be
used as per the recommendations of the
detergent manufacturer.
• The machine is not designed to be used by
persons (even children) that are physically or
mentally handicapped or lack experience and
knowledge. Such persons must receive
instruction in how to use the machine from the
person responsible for their safety.
• Children must be watched to ensure they do
not play with the machine.
Safety
•The machine must not be used for drying items
that have been dry-cleaned at home or fabrics
that may contain residues of flammable liquids.
• The tumble dryer is protected by an
overheating cut-out. This shuts off the machine
if the temperature gets too high.
•The appliance is not intended for use by young
children or infirm persons without supervision.
• The machine automatically cuts off if the
condenser water tank is full or outlet hose is
blocked.
WARNING!
When the tumble dryer is operating, the back of
the tumble dryer will get very hot. Leave the
machine to cool completely before touching the
back.
Installation
See the section Installation.
Transport/Winter storage
If you need to move your machine or store it over
the winter in unheated premises, make sure that
you drain the condensed water container
beforehand.
Packing material
Sort waste materials in accordance with local
guidelines.
Recycling
This machine is manufactured and labelled for
recycling. In order to prevent personal injury, the
machine must be made inoperable after deciding
to take it out of service. Contact your local
authority for information about where and how
your machine should be correctly recycled.
4
Safety instructions

To minimize the risk of fire in a
tumble dryer, the following should
be observed:
• Items that have been spotted or soaked with
vegetable or cooking oil constitute a fire hazard
and should not be placed in a tumble dryer.
Oil-affected items can ignite spontaneously,
especially when exposed to heat sources such
as in a tumble dryer. The items become warm,
causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot
escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected
items can prevent heat from escaping and so
create a fire hazard. If it is unavoidable that
fabrics that contain vegetable or cooking oil or
have been contaminated by hair care products
be placed in a tumble dryer they should first
be washed in hot water with extra detergent -
this will reduce, but not eliminate, the hazard.
The ’cool down’ cycle of tumble dryers should
be used to reduce the temperature of the items.
They should not be removed from the tumble
dryer or piled or stacked while hot.
• Items that have been previously cleaned in,
washed in, soaked in or spotted with
petrol/gasoline, dry-cleaning solvents or other
flammable or explosive substances should not
be placed in a tumble dryer. Highly flammable
substances commonly used in domestic
environments include acetone, denatured
alcohol, petrol/gasoline, kerosene, spot
removers (some brands), turpentine, waxes
and wax removers.
• Items containing foam rubber (also known as
latex foam) or similarly textured rubberlike
materials should not be dried in a tumble dryer
on a heat setting. Foam rubber materials can,
when heated, produce fire by spontaneous
combustion.
•Fabric softeners or similar products should not
be used in a tumble dryer to eliminate the
effects of static electricity unless this practice
is specifically recommended by the
manufacturer of the fabric softener or product.
• Undergarments that contain metal
reinforcements should not be placed in a
tumbledryer. Damage to the tumble dryer can
result if metal reinforcements come loose
during drying. When available a drying rack
could be used for such items.
•Plastic articles such as shower caps or babies’
waterproof napkin covers should not be placed
in a tumble dryer. Rubber-backed articles,
clothes fitted with foam rubber pads, pillows,
galoshes and rubber-coated tennis shoes
should not be placed in a tumble dryer.
Vented dryers
• There has to be adequate ventilation to avoid
the back flow of gases into the room from
appliances burning other fuels, including open
fires, when operating the tumble dryer.
• The exhaust air must not be discharged into a
flue which is used for exhausting fumes from
appliances burning gas or other fuels.
CAUTION!
Air from the tumble dryer must not be fed through
ducts used for equipment that burns gas or other
fuels.
5
Safety instructions

General
WARNING!
Do not allow children to play with
the tumble dryer.
• If the door is opened when a program is
running the garments may be very hot, with a
risk of burn injuries.
• The tumble dryer does not start automatically
when the door is closed (if a child pulls the
door shut from the inside, for example).
6
Child safety

12 3 4 5 6
7
Lint filter5.Main power switch1.
Outer door6.Condensed water container2.
Condenser7.Panel3.
Serial Number4.
7
Description of the tumble dryer

Here are some tips that may help you before you
begin tumble-drying.
Have the clothes been spun?
Items to be tumble-dried should be spun at 1000
rpm or faster. Higher spin speeds save energy
and reduce drying time.
Materials that can be tumble-dried
This symbol means that the material is suitable
for tumble-drying. Fabrics best suited to
tumble-drying are cotton fabrics, terry cloth and
synthetic fibres. Garments will be softer and lighter
when tumbled than when hung out to dry.
NOTE!
The tumble dryer does not cause any significant
wear on fabrics. The lint that collects in the lint
filter consists of dust and fibre residues formed
when the items are used.
Materials that must not be
tumble-dried
This symbol means that the material is not
suitable for tumble-drying. Certain materials may
melt or become a fire hazard if exposed to heat,
and others can lose their shape or shrink.
And do not tumble-dry
• materials labelled "Do not dry near heat".
•garments that have been dry-cleaned at home.
• plastic foam.
• fibreglass material.
• wool because of the risk of felting.
Static electricity
To reduce the risk of static electricity in the laundry
after tumble drying you can:
• Use fabric softener when washing.
•Wait five minutes after the drying program ends
before opening the door and removing the
laundry from the dryer.
NOTE!
You can stop the tumble dryer by pressing the
Stop button for three seconds or by opening the
door. In both cases the program is stopped and
starts from the beginning if restarted.
If you do not want to restart the program then
immediately remove all laundry and spread it out
to allow the heat to dissipate.
8
Advice and tips before you tumble-dry

Below are step-by-step instructions to help you
achieve the best possible tumble-drying results.
1Sort your fabrics
You will achieve the most uniform drying
results if the items are made of the same
type of material. Do up zips and buttons, fasten
belts, sort the items and adjust the load and
temperature.
2Press the main power switch
until the display lights.
3Open the door, load the items
and then close the door
9
Tumble drying

4Select the program
/
Main power switch
Program selector Start Stop
Display window
Options buttons
Select a program by turning the program selector. An LED lights next to the selected program. Use the
option buttons to select any options.
Guidelines as to what specific programs
can be used for:
Auto extra dry
This program is for items that are particularly
difficult to dry, e.g. jeans with very thick seams.
NOTE!
Knitted fabrics in particular are prone to
shrinkage. Use the Auto extra dry, Auto normal
dry or Auto Iron dry programs for these items.
Stretch clothes back into shape immediately
after drying.
Auto dry and Auto normal dry
These programs end automatically when the load
is dry. The Auto dry program gives slightly drier
laundry than Auto normal dry.
Auto Iron dry
This program shuts off the heat once the load is
just damp enough for ironing or pressing.
Timed dry
The most suitable program time depends on what
you intend to do with the items after tumble-drying
them. Use trial and error to find out what works
best. When you use Timed dry to tumble-dry a
load of mixed fabrics, some of the garments may
remain damp. Tumble-dry any damp garments
for a further 30 minutes or so using the Timed dry
program.
Select the desired time by pressing the Delayed
Start button. A program time between 30 minutes
and 3 hours can be selected and each button
press changes the time by 15 minutes.
NOTE!
When using the Timed dry program with a
program time that is too long, the garments can
become “over-dry”. This can cause items to
shrink or crease and feel rough to the touch.
Synthetic materials can also become charged
with static electricity.
Revitalise
Use the Air fluff program when you just want to
refresh, air or soften up items.
Select the desired time by pressing the Delayed
Start button. A program time between 15 minutes
and 3 hours can be selected and each button
press changes the time by 15 minutes.
10
Tumble drying

Program chart
Here we present the energy and time consumption of a few different programs. The table shows the
effect of using different spin speeds when washing the load. Consumption can vary depending on room
temperature, humidity, load, variations in the power supply and selected options.
For the consumption values given below, the requirements are as follows:
23 °CTemperature of intake air:
55 %Moisture content of intake air:
NormalDrying temperature:
1950W, 10AHeater output:
Program time, approx. (min)Energy consumption, approx.
(kWh)
Spin speed (rpm)LoadMaterialProgram
2:154,2800 rpm1/1Cotton, linenAuto extra dry
2:053,91000 rpm
1:503,41400 rpm
1:453,31600 rpm
2:054,0800 rpm1/1Cotton, linenAuto dry
1:553,61000 rpm
1:453,21400 rpm
1:403,01600 rpm
1:051,91000 rpm1/2Crease-resistant,
polyester/cotton
2:003,9800 rpm1/1Cotton, linenAuto normal
dry 1:503,61000 rpm
1:403,11400 rpm
1:252,61600 rpm
0:401,31000 rpm1/2Crease-resistant,
polyester/cotton
1:553,8800 rpm1/1Cotton, linenAuto Iron dry
1:403,31000 rpm
1:252,61400 rpm
1:052,01600 rpm
11
Tumble drying

5Selecting Options
By selecting options, you can tailor a drying
program to suit your requirements. The
available options depend on the selected
program. Once you have started the program, the
options you selected are saved for the next time
you use the same program. The exception is
Delayed Start, which is not saved for the next
time.
Energy Save
You can select Energy Save with all programs
except Revitalise.
• Select Energy Save by pressing the button
next to the symbol.
•The lamp next to the button lights when Energy
Save is selected.
Time saver
You can select Time saver with all programs
except Revitalise. The program is shortened by
about 12 minutes.
• Press the button next to the symbol.
• The lamp next to the button lights when Time
saver is selected.
Anti crease
This option means that the drum will rotate for
three seconds per minute for two hours after the
drying program has finished. The option prevents
the fabrics from remaining in the same position
and becoming creased, if you are unable to
remove them immediately after tumble-drying has
finished. Cannot be selected with the Air fluff
program.
• Select Anti crease by pressing the button next
to the symbol.
• The lamp next to the button lights when Anti
crease is selected.
Delayed Start
Select a program and then press Delayed Start.
Press the button to select a delayed start of 1 to
24 hours. The lamp next to the button lights when
this option is activated. Next press Start and the
machine counts down 1 hour at a time and starts
after the selected delay. To cancel Delayed Start
press and hold Stop for three seconds. Delayed
Start cannot be selected with Timed dry or
Revitalise.
6Press the Start button
Remaining drying time
An estimate of the remaining drying time
will be shown on the display a few minutes after
the drying program starts. 1:35 means that it will
take approximately 1 hour and 35 minutes for the
load to dry.
The actual remaining time may be longer than the
estimated time shown on the display. The
remaining time is then shown as 0:15 until the
load is sufficiently dry. If you selected Time saver
the display will show 0:05 instead.
You can stop the tumble dryer by pressing the
Stop button or by opening the door. In both cases
the program is stopped and starts from the
beginning if restarted.
NOTE!
The program will not be affected if you change
the program selector after the program has
started.
12
Tumble drying

7Drying program finished
The text End appears on the display when
the program is finished. If the Anti crease
option has been selected, the drum will rotate for
three seconds per minute for two hours after the
program is finished.
Condensed water
The condensed water container must be emptied
after each load. Remove the condensed water
container, empty out the water and replace the
container. If the condensed water container
becomes full to overflowing, the program is
interrupted. Empty the container and press the
Start button to start a new program.
TIP!
The condensed water is decalcified and can be
used in steam irons. Pour it through a coffee
filter.
NOTE!
•Clean the lint filter in the outer door after each
load. See the Care and cleaning chapter.
• Empty the condensed water container after
each load.
WARNING!
If the lint filter becomes clogged, the machine’s
automatic overheating cut-out may be triggered.
Clean the filter, wait until the machine has
cooled then try starting it. If it still does not start:
call the service division.
Once drying has finished
Turn off the main power switch. Remove the
clothes and close the door to prevent small
children from climbing into the machine.
13
Tumble drying

Cleaning the lint filter
The lint filter must be cleaned after each load.
1. Lift the filter from the holder in the door.
2. Open the lint filter. Use your thumb to press on
the edge as illustrated and pull it out.
3. Use your hand or a soft cloth to remove the lint
from all sides of the filter. If necessary, use a
damp sponge and a small amount of
washing-up liquid to remove any deposits. Dry
the filter thoroughly with a towel.
4. Close the lint filter and put it back in the
door.Close the lint filter before closing the door.
14
Care and cleaning

Emptying the condensed water
container
If you have not connected the machine to a
separate drain the condensed water container
must be emptied after each load. Remove the
condensed water container, empty out the water
and replace the container.
If the condensed water container becomes too
full, the program is interrupted and F10 is shown
in the display. Empty the container and press the
Start button to restart the program.
For connection to a separate drain, see the
installation instructions in the set of documents.
Cleaning the outside of the machine
Clean the outside of the machine and the program
panel with a mild cleaner. Do not use solvents,
as these can damage the machine. Do not hose
down or spray the machine with water.
NOTE!
Do not allow dust to accumulate around the
machine. Keep the area around the tumble dryer
clean and cool; dust, heat and moisture prolong
drying times.
15
Care and cleaning

Cleaning the condenser
The condenser should be cleaned at least three
times a year. If you have pets, the condenser must
be cleaned more frequently.
1. Turn off the tumble dryer with the main power
switch and open the outer door.
2. Remove the plinth.
3. Open the condenser panel by turning the two
knobs.
4. Remove the condenser and rinse the ribs
clean, such as with a hand-held shower. Do
not poke around in the rib gaps as you may
damage the condenser. Do not use pointed
metal objects when cleaning.
NOTE!
Do not clean the condenser in a dishwasher.
5. Wipe any lint from the channel in front of the
condenser and inside the condenser
compartment. Use a cotton bud or similar item
to remove any lint from the drain hole at the
front edge of the compartment.
NOTE!
It is quite normal for water to collect in the
channel in front of the condenser.
6. Replace the condenser with the handle facing
down as illustrated.
16
Care and cleaning

UPP
UP
OBEN
7. Reattach the plinth.
17
Care and cleaning

The machine will not start
Check
• that the door is properly closed.
• that the main power switch is on.
• that the Delayed Start option has not been
selected. To cancel Delayed Start, press the
Stop button for three seconds.
• that the plug is connected.
• that the main fuses have not blown.
• that the overheating cut-out has not been
triggered.
The machine loses all power during
a program
The overheating cut-out shuts off the tumble dryer
if the temperature is too high, e.g. because dust
is clogging the lint filter.
• Clean the lint filter.
•Check also that the condensed water container
is not full and, if necessary, clean the
condenser. See the Care and cleaning chapter.
• Wait until the machine has cooled then try
starting it. If it still does not start: Call the
service division.
Drying takes too long
• Check that the lint filter is not blocked. See the
Care and cleaning chapter.
• Empty the condensed water container and
check that the condenser is not blocked. See
the Care and cleaning chapter.
• Overly long drying times may also be due to
the tumble dryer being located in a confined
area or in a room that is too small, causing the
air to become too hot.
• Make sure that the tumble dryer has access
to more cold air, open doors and/or windows,
for example.
Error messages
If F10flashes in the display, the condensed water
container is full. Empty the container and restart
the program.
If F30 is flashing on the display, the maximum
permitted program time has been reached. Empty
the condensed water container and check that
neither the lint filter nor the condenser are
blocked. See the Care and cleaning chapter.
18
Troubleshooting

Technical data
850 mmHeight:
595 mmWidth:
585 mmDepth:
44 kgWeight (net):
112 lCylinder volume:
6,5 kgMax. drying capacity:
50-55 rpmSpeed:
See type plate.Rated power:
Stainless steelDrum material:
Powder-coated and hot-galvanized sheet steel or
stainless steel.
Outer casing material:
Stacking or freestandingSetup
Standard tests
For the standard test the machine’s condensed water hose must be connected to a drain.
Australia:
AS/NZS 2442.1:1996.Auto normal dry,6,5 kg cotton, temperature
Normal, Time saver.
Drying performance:
AS/NZS 2442.1:1996.Auto normal dry,
6,5 kg cotton, temperature Normal, Time saver.
Energy declaration:
IEC 60 704-2-6.Test method for noise measurement:
19
Technical information

Before contacting the service
division
See the Troubleshooting and Care and cleaning
chapters to see whether you can rectify the
problem. If you need to contact the service
division, make sure that you know the model
designation, type designation and serial number.
The model designation (1) can be found on the
first page of the operating instructions and on the
machine panel. The type designation (2) and
serial number (3) can be found on the type plate,
which is found on the front of the tumble dryer
inside the outer door.
1
TYPE TD70.1
2
3
20
Service
Other manuals for T754C
5
Table of contents
Other Asko Dryer manuals
Popular Dryer manuals by other brands

LG
LG DLEX7900 E Series owner's manual

Kenmore
Kenmore W10850306A installation instructions

Kenmore
Kenmore C60102 Use & care guide

Electrolux Professional
Electrolux Professional TD6-30 Compass Pro installation manual

Bosch
Bosch WTH83027SG User manual and installation instructions

Maytag
Maytag MD-24 Use & care guide
