Asko T761 User manual

Start Stop
P1 P2 P3 P4
We know you’re excited about owning an ASKO dryer and you’re anxious to get started, so here is a brief summary of the operating
procedures. To get the most of the features of your machine, we recommend that you read your Use and Care Guide.
THE CONTROL PANEL
Models T761 and T781 have ASKO’s state-of-the-art EasyControl™ panel, as illustrated below. To select a program, simply press one of the
preset program buttons then press Start. Refer to “Preset Programs” below for a definition of these programs.
StopButton
Press to stop
a program.
Preset Programs
Press one of these buttons
to select a program.
LCD Window
Displays the program, temperature settings,
and program run time.
Dryer Quick Start Guide T761/T781
Power Button
Press to turn on power
to the machine.
Program Selection Controls
These buttons allow you to customize the preset program settings,
such as temperature settings, turning the buzzer off, setting delay
start time, etc. Refer to the Use and Care Guide for instructions.
Power Indicator Light
Glows when the power
is turned on.
Power Button
The Power button turns the power to the machine on and off. When the power is on, the power indicator light glows red. The power
must be on before you can set the programs or start the machine.
Start and Stop Buttons
Once you have selected a program (P1–P4), press this button to start the dryer. If you open the door during a program, the dryer will
stop tumbling automatically. To continue the program from where it stopped, close the door and press Start.
To stop a program, press this button until the dryer stops (about three seconds). If you stop the dryer this way, you will have to select
a new program and press Start to restart the dryer.
Interrupting or Cancelling a Program
To interrupt a program, simply open the door. The dryer will stop tumbling automatically. To continue the program, close the door and press
Start. The program will continue from the point it was interrupted.
To stop or cancel a program, press and hold the Stop button until the dryer stops (about three seconds). To restart the dryer, you will have to
reselect a program and press Start.
Preset Programs
With ASKO’s Sensidry™ system, you need never worry about overdrying your laundry. Just select the proper program for the type of fabric
you’re drying and Sensidry does the rest. Once you select a program, Sensidry monitors the temperature and measures the humidity level.
When it detects the appropriate measurements, it automatically shuts off the machine.
There are four preset programs, as defined in the table below. To select a program, simply press one of the program buttons and press Start.
For additional programming options, refer to the Use and Care Guide.
Preset Dry
Program Program Types of Laundry Temp Anti-Crease Buzzer
P1 ExtraDry Heavy fabrics, such as denim jeans Normal 1 hour On
P2 Dry Towels, cotton, linen, etc. Normal 1 hour On
P3 Normal Dry Permanent press, synthetics, etc. Normal 1 hour On
P4 Iron Dry Washable silk, acrylics, etc. Low * 1 hour On
ASKO’s EasyControl™ panel makes it simple to customize the preset programs to perfectly fit your laundry needs. For example, you can
reprogram the dry temperature, change the cool-down time, set a delayed start, etc. For instructions, refer to “Customizing the Preset
Programs” in your Use and Care Guide.
Start Button
Press to start
a program.
* The dry temperature for Program P4 on Model T781 is Normal.
Start
Stop

P1 Extra Dry
P2 Dry
P3 Normal Dry
P4 Iron Dry
Q ICK START PROCED RES
NDERSTANDING THE LCD WINDOW
The LCD window is easy to read and understand. The illustration below explains what each item on the LCD window is.
Program Time
When you start a program, the total time the
program runs is displayed. As the program
progresses, the time remaining displays. The
program time toggles between minutes (e.g.,
23) and hours (e.g., 1h).
Stop
Indicates that the program has ended
or that you pressed Stop.
Start
Indicates that you pressed Start
and the program is running.
Preset Programs
Displays the program that
is selected/running.
Program
When you press the Power button,
the display toggles between the
program numbers and the wash
program names, (e.g., Extra Dry,
Dry, etc.)
CLEANING THE LINT FILTER
Although the lint in your ASKO dryer will be minimal, the lint filter should be cleaned after each load to ensure
maximum air flow and prevent possible overheating. To clean the filter, follow the steps below:
1. Grasp the handle and pull it toward you.
2. Remove the filter from the holder by pulling it up.
3. Open the filter and gently brush away any lint.
4. Fold the filter together and return it to the holder on the door.
5. Push the holder in until it snaps into place.
We recommend that you clean the lint filter after every load.
NOTE:
OVERHEATING PROTECTION
The dryer has a protection device that shuts the machine off if the temperature becomes too high. Overheating could occur if the lint filter is
clogged or if the fan or condenser unit (Model T781) needs to be cleaned. If the dryer shuts off during a program on Model T781, first, make
sure the condensation water container is empty. If that isn’t the problem, check the lint filter. Lastly, it could be the fan or condenser unit needs
to be cleaned. See page 3 in your Use and Care Guide for more details.
The LCD window also displays the menus and options available when you customize the preset programs. Refer to your Use and Care
Guide for more details.
1.
2.
3.
4.
5.
6.
Press the Power button to turn on the machine.
Load the dryer.
Clean the lint filter (see below).
Check that the door is clear of laundry then close it firmly.
Press the button for the desired program (P1–P4) and make any program changes.
Press Start. The machine will start.
EMPTYING THE CONDENSATION WATER CONTAINER (T781 only)
If Model T781 is not installed to pump out the condensed water into a drain or a sink, you should empty
the water container every three to five dryer loads, depending on the spin speed you use when you wash
the clothes. For example, clothes spun at 800 rpm will have more moisture when you take them out of the
washer than clothes spun at 1400 rpm. Therefore, the dryer will have to remove more water.
To empty the container, simply pull it out and pour out the water. This water is clean and can be used to
water plants.
If the container becomes too full, the machine will shut down. To restart the program, empty the container
and press Start. It may be a few minutes before the machine starts because it drains the excess water
from the sump before it restarts.
Do not remove the water container while the machine is running.
NOTE:
T761/T781
Art. No. 80 646 44 Rev. 03
