Asko T794 User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs
for many years to come. Scandinavian design combines clean
lines, everyday functionality, and high quality. These are key
characteristics of all our products and the reason they are
greatly appreciated throughout the world.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
Operating Instructions
Tumble dryer
Save these instructions for future reference
ASKO T794FI

3
Before using your machine for
the first time
3
Language selection
4Important safety instructions
5
Grounding instructions
5
Packing material
5
Disposal
6Child safety
6
General
6
Child safety catch
6
To deactivate Child-safe Start
temporarily:
7Description of the tumble dryer
8
Advice and tips before you
tumble dry
8
Materials that can be tumble dried
8
Materials that should not be
tumble dried
8
Static electricity
9Operating instructions
9
Sort your fabrics
10
Select the program
13
Selecting Options
14
Press the Start button
14
Drying program finished
15Settings
15
You can alter the following
settings:
15
How to choose the settings:
15
Clock
15
Buzzer Volume
15
Language
16
Child-safe Start
16
Back
17
Care and maintenance
instructions
17
Cleaning the lint filter
17
Cleaning the outside of the
machine
18Troubleshooting
18
The machine will not start
18
The machine loses all power
during a program
18
Drying takes too long
18
Error messages
19Technical information
19
Technical data
20Service and guarantee
22Installation instructions
22
Positioning the tumble dryer
24
Adjusting the feet
24
Built-in
25
Air exhaust
28
Electrical installation
31Reversing the door
34Fitting the wooden door
36Quick guide
Customer Care Center2
1-800-898-1879
www.askousa.com
Contents

Do you need this Use&Care Guide in Spanish? Log on to www.askousa.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askousa.com/customer-care
y descárguesela.
Language selection
You will be prompted to select the display
language when you have connected your machine
and start it for the first time. Do as follows:
1. Press the up or down arrow button and choose
from: US english, English, Svenska, Dansk,
Norsk, Suomea, Français, Deutsch, Italiano,
Espanol, Русский, Nederlands.
2. Press Start or Stop to save and continue to the
clock and time display settings.
Laundry labels
Certain materials are not suitable for tumble
drying. Always check and follow the instructions
on each item's laundry label. You can find more
information in the "Advice and tips before you
tumble dry" chapter.
NOTE!
When starting the tumble dryer for the first time
or after a long period without use, you may hear
a slight thumping noise. This noise is completely
normal and will disappear after a few loads.
3Customer Care Center
1-800-898-1879
www.askousa.com
Before using your machine for the first time

SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE
WARNING!
WARNING - To reduce the risk of fire, electric
shock, or injury to persons when using your
appliance, follow basic precautions, including
the following:
• Read all instructions before using the
appliance.
• Do not wash or dry articles that have been
previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning
solvents, cooking oils, other flammable or
explosive substances as they give off vapors
that could ignite or explode.
• Do not allow children to play on or in the
appliance. Children should be closely
supervised when near the appliance.
• Before the appliance is removed from service
or discarded, remove the door to the drying
compartment.
• Do not reach into the appliance if the drum is
moving.
• Do not install or store this appliance where it
will be exposed to the weather.
• Do not tamper with controls.
• Do not attempt to repair or replace any part
of the appliance or perform any servicing
unless specifically recommended in this
guide.
• Do not use fabric softeners or dryer sheets
unless the manufacturer gives written
assurance that the product will not damage a
tumble dryer.
•Do not heat dry items containing vinyl, plastic,
foam rubber or similarly textured rubberlike
materials, fiberglass, or wool unless the label
specifies “washable”.
• Clean the lint filter before or after each load.
• Keep the area around the exhaust opening
and adjacent surrounding areas free from the
accumulation of lint, dust and dirt.
•The interior of the machine should be cleaned
periodically by an authorized ASKO service
agent.
• Do not place items exposed to cooking oils in
your dryer. Items contaminated with cooking
oils may contribute to a chemical reaction that
could cause a load to catch fire.
• Electrical installation, if required, must be
done by a licensed electrician.
• Do not operate appliance while away from the
home.
• Do not heat dry items that have been
dry-cleaned.
• The dryer is made and marked to facilitate
recycling. When it is no longer useful, contact
your local refuse collection service for advice
on how to properly dispose of the dryer for
purposes of recycling.
• Damaged power cables should only be
replaced by a certified professional.
•Provide sufficient ventilation, otherwise smoke
from open fires or fumes from equipment
burning other fuels can be drawn into the
room.
CAUTION!
During the program, the back of the dryer will
get very hot. Let the machine cool completely
before touching the back.
WARNING!
This appliance must be properly grounded.
Customer Care Center4
1-800-898-1879
www.askousa.com
Important safety instructions

Grounding instructions
A) Grounding instructions for a grounded,
cord-connected appliance
In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock by
providing a path of least resistance for electric
current. This appliance (Canadian market only)
is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
WARNING!
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service
representative or personnel if you are in doubt
as to whether the appliance is properly grounded.
Do not modify the plug provided with the
appliance (Canadian market only). If it will not fit
the outlet, have a proper outlet installed by a
qualified electrician.
To reduce the risk of fire, this appliance must be
exhausted outdoors or the equivalent. Do not
exhaust into a chimney, wall, ceiling or concealed
space in a building.
B) Grounding instructions for a
permanently connected appliance:
This appliance must be connected to a grounded
metal, permanent wiring system, or an
equipment-grounding conductor must be run with
the circuit conductors and connected to the
equipment-grounding terminal or lead on the
appliance.
NOTE!
This manual does not cover every possible
condition and situation that may occur. Use
common sense and caution when installing,
operating, and maintaining any appliance.
Installation
See the "Installation instructions" chapter.
Packing material
Please sort waste materials in accordance with
local guidelines.
Disposal
This machine is manufactured and labeled for
recycling. In order to prevent personal injury, the
machine must be made inoperable after deciding
to take it out of service. Contact your municipality
for information about where and how your
machine can be recycled correctly.
5Customer Care Center
1-800-898-1879
www.askousa.com
Important safety instructions

General
WARNING!
Do not allow children to play with the
tumble dryer.
• If the door is opened when a program is
running, the garments may be very hot, with
a risk of burn injuries.
• The tumble dryer does not start automatically
when the door is closed (if a child pulls the
door shut from the inside, for example).
Child safety catch
By activating the Child-safe Start function, you
can prevent children from starting the tumble dryer
or changing the current program.
1. Press the up or down arrow button in the
program selector until Settings is highlighted
in the display window.
2. Press the program selector (the big arrow in
the middle).
3. Press the up or down arrow button in the
program selector until Child-safe is highlighted
in the display window.
4. Press the program selector again (the big
arrow) to access the options menu on the right
of the display.
5. Press the up or down arrow button to select
On or Off.
6. Press the program selector (the big arrow) to
activate
To deactivate Child-safe Start
temporarily:
Simultaneously press the program selector and
the Start button to deactivate Child-safe Start for
three minutes.
Customer Care Center6
1-800-898-1879
www.askousa.com
Child safety

1 2 3
4
5
Lint filter4.Main power switch1.
Outer door5.Panel2.
Serial number tag and rating plate3.
7Customer Care Center
1-800-898-1879
www.askousa.com
Description of the tumble dryer

Here are some tips that may help you before you
begin tumble drying.
Have the clothes been spun?
Items to be tumble dried should be spun at 1000
rpm or faster. Higher spin speeds save energy
and reduce drying time.
Materials that can be tumble dried
This symbol means that the material is suitable
for tumble drying. Fabrics best suited to tumble
drying are cotton fabrics, terry cloth, and synthetic
fibers. Garments will be softer and lighter when
tumbled than when hung out to dry.
NOTE!
The tumble dryer does not cause any significant
wear on fabrics. The lint trapped in the lint filter
consists of dust and fiber residues formed when
the items are used.
Materials that should not be tumble
dried
This symbol means that the material is not
suitable for tumble drying. Certain materials may
melt or become a fire hazard if exposed to heat
and others can lose their shape or shrink.
And do not tumble dry
• materials labeled "Do not dry near heat".
•garments that have been dry-cleaned at home.
• plastic foam.
• fiberglass material.
• wool must not be tumble dried due to the risk
of piling.
Static electricity
To reduce the risk of static electricity in the laundry
after tumble drying, you can:
• Use fabric softener when washing.
•Wait five minutes after the drying program ends
before opening the door and removing the
laundry from the dryer.
NOTE!
You can stop the tumble dryer by pressing the
Stop button for three seconds or by opening the
door. In both cases the program is stopped and
starts from the beginning if restarted.
If you do not want to restart the program,
immediately remove all laundry and spread it out
to allow the heat to dissipate.
Customer Care Center8
1-800-898-1879
www.askousa.com
Advice and tips before you tumble dry

WARNING!
To reduce the risk of electric shock or injury to
persons, read the "Important Safety Instructions"
section before operating this appliance.
Below are step-by-step instructions to help you
achieve the best possible tumble drying results.
1Sort your fabrics
You will achieve the most uniform drying
results if the items are made of the same
type of material. Close zippers and fasten buttons
or belts; sort the items and adjust load and
temperature.
2Press the main power switch
until the display lights.
3Open the door, load the items,
and then close the door
9Customer Care Center
1-800-898-1879
www.askousa.com
Operating instructions

4Select the program
Main power switch
Program selector Display window
Start Stop
Select a program by pressing the up or down arrow button. The name of the selected program and the
program time are shown in the display window. Press the button in the middle of the program selector if
you want to select any options.
Guidelines as to what specific programs
can be used for:
Auto Heavy
This program is for items that are particularly
difficult to dry.
NOTE!
Knitted fabrics in particular are prone to
shrinkage. Use the Auto Heavy, Auto Delicate,
or Auto Iron Dry programs for these items.
Stretch clothes back into shape immediately
after drying.
Auto Normal and Auto Delicate
These programs end automatically when the load
is dry. The Auto Normal program gives slightly
drier laundry than Auto Delicate.
Auto Iron Dry
This program shuts off the heat once the load is
just damp enough for ironing or pressing.
Jeans
Program for jeans and clothing with very thick
seams. Delayed Start can be selected as an
option.
Synthetic
Gentle program for synthetics. Delayed Start can
be selected as an option.
Terry cloth
Program intended for large and small loads of
thick terry cloth, such as towels and bathrobes.
Down
Gentle program that dries down items completely.
Can be used to dry up to three pillows or one quilt.
Timed Dry
The most suitable program time depends on what
you intend to do with the items after tumble drying
them. Use trial and error to find out what works
best. When you use Timed Dry to tumble dry a
load of mixed fabrics, some of the garments may
remain damp. Tumble dry any damp garments
for a further 30 minutes or so using the Timed Dry
program.
Select the program time by pressing the program
selector until the symbol is highlighted. Press
the up or down arrow button to set the desired
program time.
NOTE!
When using the Timed Dry program with a
program time that is too long, the garments can
become "over-dry". This can cause items to
shrink or wrinkle and feel rough to the touch.
Synthetic materials can also become charged
with static electricity.
Customer Care Center10
1-800-898-1879
www.askousa.com
Operating instructions

Air Fluff
Use the Air Fluff program when you just want to
refresh, air out,, or soften up items.
Select the program time by pressing the program
selector until the symbol is highlighted. Press
the up or down arrow button to set the desired
program time.
Depending on whether you have set the clock to
12h display, 24h display, or remaining program
time display, the start time will be displayed as
the actual time or the remaining time. To change
the setting, see the "Settings" chapter.
11Customer Care Center
1-800-898-1879
www.askousa.com
Operating instructions

Program chart
Here we present the energy and time consumption of a few different programs. The table shows the
effect of using different spin speeds when washing the load. Consumption can vary depending on room
temperature, humidity, load, variations in the power supply, and selected options.
For the consumption values given below, the requirements are as follows:
73 °F (23 °C)Temperature of intake air:
55 %Moisture content of intake air:
NormalDrying temperature:
3000W, 15AHeater output:
Program time, approx. (min)Energy consumption, approx.
(kWh)
Spin speed (rpm)LoadMaterialProgram
1:404.0800 rpm1/1Cotton, linenAuto Heavy
1:353.81000 rpm
1:253.31400 rpm
1:203.11600 rpm
1:303.9800 rpm1/1Cotton, linenAuto Normal
1:253.61000 rpm
1:153.11400 rpm
1:102.91600 rpm
0:501.81000 rpm1/2Wrinkle-resistant,
polyester/cotton
1:253.8800 rpm1/1Cotton, linenAuto Delicate
1:203.511000 rpm1)
1:102.81400 rpm
1:002.51600 rpm
0:351.301000 rpm1) 1/2Wrinkle-resistant,
polyester/cotton
1:353.7800 rpm1/1Cotton, linenAuto Iron Dry
1:253.031000 rpm1)
1:052.41400 rpm
0:502.01600 rpm
1) Test program in accordance with EN61121:2005. During testing, the tumble dryer must be set to 16A and Time Saver must be activated. After washing, the load must
be spun at 1000 rpm.
Customer Care Center12
1-800-898-1879
www.askousa.com
Operating instructions

5Selecting Options
By selecting options, you can tailor a drying
program to suit your requirements. The
available options depend on the selected
program. Once you have started the program, the
options you selected are saved for the next time
you use the same program. The exception is
Delayed Start, which is not saved for the next
time.
Temperature Low
1. Select Temperature Low by pressing the
program selector (the big arrow) until
Temperature Low is highlighted.
2. Press the up or down arrow button until
Temperature Low is displayed.
3. Press the Start button to start the program or
press the program selector to select more
options.
Time saver
You can select Time saver with all programs
except Air Fluff . The program is shortened by
about 12 minutes.
1. Press the program selector (the big arrow) until
Time saver is highlighted.
2. Press the up or down arrow button until Time
saver is displayed.
3. Press the Start button to start the program or
press the program selector to select more
options.
Anti Wrinkle
This is a useful feature if you cannot take the
laundry out as soon as the tumble dryer has
finished. The function prevents the clothes from
remaining in the same position and becoming
wrinkled. The drum will rotate for three seconds
per minute for two hours once the drying program
has finished
1. Select Anti Wrinkle by pressing the program
selector (the big arrow) until Anti Wrinkle is
highlighted.
2. Press the up or down arrow button until Off or
On is displayed.
3. Press the Start button to start the program or
press the program selector to select more
options.
Delayed Start
Choose the time you want the program to start.
This option cannot be selected with the Timed
Dry or Air Fluff program.
1. Press the program selector (the big arrow) until
Delayed Start is displayed.
2. Press the up or down arrow button to set the
start time for the program.
3. Press the Start button to activate the program
or press the program selector to select more
options.
Depending on whether you have set the clock to
12h display, 24h display, or remaining program
time display, the start time will be displayed as
the actual time or the remaining time. To change
the setting, see the "Settings" chapter.
13Customer Care Center
1-800-898-1879
www.askousa.com
Operating instructions

6Press the Start button
Close the outer door to start the tumble
dryer.
You can stop the tumble dryer by pressing the
Stop button or by opening the door. In both cases
the program is stopped and starts from the
beginning if restarted.
NOTE!
The program will not be affected if you change
the program selector after the program has
started.
7Drying program finished
The text "End" appears on the display when
the program is finished. If the Anti Wrinkle
option has been selected, the drum will rotate for
three seconds every minute for two hours after
the program is finished.
Backlighting
Two minutes after the drying program finishes the
backlighting on the display and option buttons
enters energy saving mode.
NOTE!
•Clean the lint filter in the outer door after each
load. See the "Care and maintenance
instructions" chapter.
WARNING!
If the lint filter becomes clogged, the machine’s
automatic overheating cut-out may be triggered.
Clean the filter, wait until the machine has
cooled, then try starting it. If it still does not start:
Call the Customer Care Center.
Once drying has finished
Turn off the main power switch. Remove the
clothes and close the door to prevent small
children from climbing into the machine.
Customer Care Center14
1-800-898-1879
www.askousa.com
Operating instructions

You can alter the following settings:
• Clock
• Buzzer Volume
• Language
• Child-safe Start
• Back
How to choose the settings:
1. Press the up or down arrow button in the program selector until Settings is highlighted in the display
window.
2. Press the program selector (the big arrow in the middle).
3. Press the up or down arrow button in the program selector until the setting you want to change is
highlighted in the display window.
Clock
Set to 12h display, 24h display, or remaining time display. If you select 12h or 24h, the start and end
times will be shown as actual times.
1. Press the program selector again (the big arrow) to access the options menu on the right of the display.
2. Use the up and down arrow buttons to choose whether 12h, 24h, or remaining program time is
displayed.
3. Press the program selector (the big arrow) to save your setting.
4. Once you have selected the 12 or 24 hour clock, you will automatically enter the clock setting menu.
Setting the clock
5. Press the up arrow button until the correct hour is shown.
6. Press the program selector (the big arrow) to save your setting.
7. Press the up arrow button until the correct minutes are shown.
8. Press the program selector (the big arrow) to save your setting.
9. If you do not want to select any more settings, press the arrow button down until you reach the program
you want.
Buzzer Volume
You can choose to have the machine notify you when a program has finished or when a fault has occurred.
1. Press the program selector again (the big arrow) to access the options menu on the right of the display.
2. Select the setting for the Buzzer Volume by pressing the up or down arrow button: Off, Low, Normal,
High.
3. Press the program selector (the big arrow) to save your setting.
Language
You can choose the language you prefer.
1. Press the program selector again (the big arrow) to access the options menu on the right of the display.
2. Press the up or down arrow button and choose from: US english, English, Svenska, Dansk, Norsk,
Suomea, Français, Deutsch, Italiano, Espanol, Русский, Nederlands.
3. Press the program selector (the big arrow) to save your setting.
15Customer Care Center
1-800-898-1879
www.askousa.com
Settings

Child-safe Start
You can activate the Child-safe option to prevent children from starting the machine. Pressing the program
selector (the big arrow) and the Start button at the same time for three seconds will temporarily disable
the Child-safe option for three minutes.
1. Press the program selector again (the big arrow) to access the options menu on the right of the display.
2. Press the up or down arrow button until Off or On is displayed.
3. Press the program selector (the big arrow) to activate
Back
Press the program selector or Start again to return to the program menu.
Customer Care Center16
1-800-898-1879
www.askousa.com
Settings

Cleaning the lint filter
The lint filter must be cleaned after each load.
1. Lift the filter from the holder in the door.
2. Open the lint filter. Use your thumb to press on
the edge as illustrated and pull it out.
3. Use your hand or a soft cloth to remove the lint
from all sides of the filter. If necessary, use a
damp sponge and a small amount of
washing-up liquid to remove any deposits. Dry
the filter thoroughly with a towel.
4. Close the lint filter and put it back in the
door.Close the lint filter before closing the door.
Cleaning the outside of the machine
Clean the outside of the machine and the program
panel with a mild cleaner. Do not use solvents,
as these can damage the machine. Do not hose
down or spray the machine with water.
NOTE!
Do not allow dust to accumulate around the
machine. Keep the area around the tumble dryer
clean and cool; dust, heat, and moisture prolong
drying times.
17Customer Care Center
1-800-898-1879
www.askousa.com
Care and maintenance instructions

The machine will not start
Check
• that the door is properly closed.
• that the main power switch is on.
• that the Delayed Start option has not been
selected. To cancel Delayed Start, press the
Stop button for three seconds.
• that any plug is connected.
• that the house fuses have not been tripped.
• that the overheating cut-out has not been
triggered.
The machine loses all power during
a program
The overheating cut-off shuts off the tumble dryer
if the temperature is too high, caused by lint
clogging the lint filter, for instance.
• Clean the lint filter.
• Wait until the machine has cooled, then try
starting it. If it still does not start: Call the
Customer Care Center.
Drying takes too long
• Check that the lint filter is not blocked. See the
"Care and maintenance instructions" chapter.
Error messages
• Read "Drying takes too long" in this chapter if
"Max Program Time" appears on the display.
• If "Clean Lint Filter " appears on the display,
clean the lint filter.
• Press the Stop button to close any error
messages.
Customer Care Center18
1-800-898-1879
www.askousa.com
Troubleshooting

Technical data
33 1/2'' (850 mm)Height:
23 1/2'' (597 mm)Width:
23 7/8" (606mm)Depth:
95 lb (43 kg)Weight:
29.6 gal (112 l)Cylinder volume:
15 lb (7 kg)Max. drying capacity:
50-55 rpmSpeed:
See serial number tag and rating plate.Rated power:
Stainless steelDrum material:
Powder-coated and hot-galvanized sheet steel or
stainless steel.
Outer casing material:
Stacking or freestandingSetup
19Customer Care Center
1-800-898-1879
www.askousa.com
Technical information

It is important to register your product warranty by logging onto "http://www.askousa.com/customer-
care/register-my-appliance/" and filling out all required fields within 90 days from the date of purchase.
After doing so, you will be e-mailed a certificate that will extend the original warranty for one additional
year. If you do not have access to the internet, complete the warranty card included with the product
and mail it to the address on the warranty card within 90 days from the date of purchase. Cosmetic
damage must be reported to your dealer within five days from the date of purchase. After unpacking
the washer, thoroughly check the unit for cosmetic damage.
ASKO Appliances Inc. will pay for:For residential installations only
ASKO replacement parts and/or repair labor to correct
defect in materials or workmanship. Service must be
provided by an authorized ASKO service agent.
Length of warranty Two-Year Full
From date of purchase.
ASKO replacement parts and/or repair labor to correct
defect in materials or workmanship. Service must be
performed by an authorized ASKO service agent.
Third Year Full
Complete your product warranty registration
online at "http://www.askousa.com/customer-
care/register-my-appliance/" within 90 days from
the date of purchase to extend the original war-
ranty one additional year. If you do not have
access to the internet, complete the warranty
card included with the product and mail it to the
address on the warranty card within 90 days
from the date of purchase.
ASKO replacement parts (labor cost not included) for
the stainless steel tank if it exhibits a manufacturing
defect such as cracking or rusting through. Service
must be provided by an authorized ASKO service
agent.
Lifetime
ASKO replacement parts and/or repair labor to correct
defect in materials or workmanship. Service must be
provided by an authorized ASKO service agent.
For non-residential installations One-year Full
Warranty
From date of purchase.
Customer Care Center20
1-800-898-1879
www.askousa.com
Service and guarantee
