Carefully read the instructions for use before using the dryer.

3Introduction ................................................
4Safety precautions .....................................
4.....................................................................
9Dryer description .......................................
9.....................................................................
10
Before using the appliance for the first
time ..............................................................
10.....................................................................
11Installation and connection ......................
11.....................................................................
23Advices before drying ...............................
23.....................................................................
26Drying process, step by step ....................
26.....................................................................
31Settings .......................................................
31.....................................................................
33Cleaning and maintenance .......................
33.....................................................................
40Errors –what to do? ..................................
40.....................................................................
44Service ........................................................
44.....................................................................
45Technical information ................................
45.....................................................................
47Program chart ............................................
47.....................................................................
49Removal ......................................................
49Disposal / recycling of packaging ............
50Quick guide ................................................
50.....................................................................
Contents

Dear Customer,
We thank you for purchasing this quality ASKO product.
We hope it meets all your expectations. Scandinavian design combines pure lines, everyday
functionality, and high quality. These are the key characteristics of all our products, and the reason
why they are highly appreciated across the globe.
We kindly recommend you to read these instructions before using the appliance for the first time.
The instruction manual also includes information on how you can help protect the environment.
The following symbols are used throughout the manual and they have the following meanings:
INFORMATION!
Information, advice, tip, or recommendation
WARNING!
Warning –general danger
ELECTRIC SHOCK!
Warning –danger of electric shock
HOT SURFACE!
Warning –danger of hot surface
DANGER OF FIRE!
Warning –danger of fire
Original instructions
See Quick guide on the last page.
3
Introduction

General
Please read the instruction manual and save it for future
reference.
•Please do not use the tumble dryer if you have not read and
understood these instructions or use first.
•Failure to observe the instructions for use or inappropriate use of
the tumble dryer may result in damage to the laundry or appliance,
or injury to the user.
•Instructions for use are available on our website at www.asko.com.
•Appliance is intended to be used in an area open to the public.
•Before connecting the dryer to the power mains, please read
carefully the instructions for use that describe the dryer and its
correct and safe use. The instructions apply to several appliance
types or models; thus, settings or equipment may be described
herein which is not available in your dryer.
•Leave any repairs and similar tasks on the dryer to an expert.
Unprofessional repair may result in an accident or major
malfunction.
•After installation, the dryer should stand still for two hours before
it is connected to the power mains.
•At least two persons are required to install the tumble dryer on
top of a washing machine.
•The dryer shall not be connected to the power mains using an
extension cord.
•Do not connect the tumble dryer to an electrical outlet intended
for an electric shaver or hair dryer.
WARNING!
If the power cord is damaged, it has to be replaced by the
manufacturer, an authorized service technician, or a similarly
qualified person, in order to avoid any hazards.
4
Safety precautions

•WARNING!
The appliance shall not be supplied through an external
switching device, such as a timer, or connected to a circuit that
is regularly switched on and off by a utility.
•After the drying process, unplug the dryer power cord from
the power outlet.
If you have a tumble dryer with a 3-phase connection, do not pull
the plug out of the power outlet.
•The appliance shall be disconnected from the power source
during servicing and replacement of parts. Removal of the plug
has to be such, that an operator can check, from any of the points
to which he has access that the plug remains removed.
•In case of incorrect appliance connection, incorrect use, or
servicing by an unauthorized person, the user shall bear the cost
of any damage.
•Air in the dryer environment should not contain dust particles. The
air where the dryer is installed should be thoroughly ventilated to
prevent reverse flow of gases released from the gas appliances
with open fire (e.g. fireplaces).
•Do not evacuate the air from the dryer through channels used for
appliances or devices that use natural gas or other fuels for their
operation (only applies to the evacuation dryer).
•Clean the door net filter after each drying cycle.
•Do not dry unwashed laundry in the dryer.
•Laundry stained with oil, acetone, alcohol, oil derivatives, stain
removers, turpentine, wax, and wax removers should be washed
in a washing machine with hot water and detergent before it is
dried in the dryer.
•Clothing that includes latex, rubber parts, shower and bathing
caps, and laundry or covers with rubber foam shall not be dried
in the dryer.
•Use laundry conditioners or similar products in compliance with
manufacturer's instructions.
5
Safety precautions

•Do not use any solvents, abrasive cleaners, glass cleaners, or
all-purpose cleaners.
•Do not place the dryer behind lockable or sliding door, or door
with a hinge on the opposite side of the dryer door hinge. Install
the dryer in such way that the door can always be freely opened.
•Never block the air vents.
•Do not place the dryer on a carpet with long fibres as this may
impede air circulation.
•The air in the room where the dryer is installed may not contain
dust particles.
•Make sure the fibres do not accumulate around the dryer.
•DANGER OF FIRE!
Remove all objects such as lighters and matches from the
pockets.
•After installation, wait for 24 hours before using the appliance. If
the dryer has to be laid down on one of the sides during transport
or servicing, place it with its left side, viewing from the appliance
front, downwards (only applies to dryers with a heat pump).
•The appliance shall not be in contact with a wall or adjacent
furniture.
•If the dryer is connected to an air exhaust system already used
for another appliance, a non-return valve must be installed.
Reverse flow into the dryer could damage the appliance, and the
non-return valve prevents such reverse flow (only applies to the
evacuation dryer).
•A float will switch off the appliance if the condensed water pipe
is clogged or if there is a risk of overflowing of the condensed
water accumulated in the condensed water tank (only applies to
the evacuation dryer).
•If you wish to move the dryer or store it in a non-heated room
during winter, it is essential that you first empty the condensed
water tank (only applies to the condenser dryers and dryers with
a heat pump).
6
Safety precautions

•Maximum drying capacity in kg is indicated on the rating plate.
Safety
•DANGER OF FIRE!
Only use the dryer to dry laundry that was washed with water.
Do not dry any laundry that was washed or cleaned with
flammable cleaners or substances (such as gasoline,
trichloroethylene etc.) as this may result in an explosion.
•If you have cleaned your clothes with industrial cleaners or
chemical substances, do not dry them in the dryer.
•If the air exhaust hose is connected to an opening in the wall,
influx of cool air may be prevented by installing a ventilation grille.
(Only applies to evacuation dryer.) .
•The air exhaust hose shall not be connected to an active chimney
used to evacuate smoke or waste gases; into a shaft intended for
ventilating rooms with combustion equipment; or into a chimney
used by third parties. If smoke or waste gases return to the room
where the dryer is installed, there is a danger of poisoning (only
applies to evacuation dryer).
•The dryer is protected with an automatic switch-off system in case
of overheating. The system switches off the heater if the
temperature is too high (only applies to evacuation and condenser
dryer).
•If the net filter is clogged, the automatic heater switch-off device
can be triggered. See chapter "CLEANING AND MAINTENANCE"
(only applies to evacuation and condenser dryer).
•HOT SURFACE!
WARNING! The back of the dryer may get very hot during
operation. Wait for the dryer to cool down completely before
touching its back side. (Observe the instructions in the
chapter "INSTALLATION AND CONNECTION")
7
Safety precautions

•HOT SURFACE!
Never stop a drying cycle or do not open the door before the
end of the program. If you do so for any reason, be careful when
taking the laundry from the drum as it can still be very hot and
there is a risk of burning.
Quickly remove the laundry from the drum and spread it to allow
it to cool down as quickly as possible.
Child safety
•Do not allow the children to play with the dryer.
•Prevent your children and pets from entering the dryer drum.
•Before closing the dryer door and running the program, make
sure there is nothing except laundry in the drum (e.g. if a child
climbed into the dryer drum and closed the door from the inside).
•Activate the child lock. See chapter: SETTINGS
•Do not let children younger than three years to come near the
dryer, unless they are under constant supervision.
•The dryer is made in compliance with all relevant safety standards.
This dryer may be used by children aged 8 years and above and
by persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, but only if they are
supervised during the use of the appliance, if they have been
provided relevant instructions regarding safe use of the dryer,
and if they understand the hazards of inappropriate use. Make
sure children do not play with the appliance. Make sure the
children do not clean the dryer or perform any maintenance tasks
without supervision.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
8
Safety precautions

1. Main switch (ON/OFF)
2. Program selector knob
3. Display unit
4. Program settings buttons
5. Button (start/pause)
6. Rating plate with information about the dryer
(on the inside of the drying machine door)
7. QR and AUID code (on the inside of the
drying machine door)
8. Dryer door
9. Door net filter
10. Condensate tank (depending on the model)
11. Condenser unit
12. Air vents
9
Dryer description

Packaging
Remove all packaging.
Please sort the materials in compliance with local recommendations (see chapter "Disposal").
Cleaning
Disconnect the dryer from the power mains and open the door towards you. Before using the dryer
for the first time, clean the dryer drum using a soft damp cotton cloth and water.
In the case of a 3 phase connection of the appliance, switch off the main socket switch.
INFORMATION!
No program can be started while the door is open.
Choosing the language
When the dryer is connected (see chapter "Installation and connection") and switched on for the first
time, choose the preferred language.
For further drying process, see chapter "DRYING PROCESS, STEP BY STEP".
INFORMATION!
When you run the dryer for the first time, or if the dryer has been out of use for a long time, slight
hitting noise may appear. This is normal and it will disappear after a few drying cycles.
10
Before using the appliance for the first time

Dryer placement
The dryer can be either free standing or installed on top of a washing machine.
INFORMATION!
At least two persons are required to install the tumble dryer on top of a washing machine.
The dryer emits heat. Therefore, do not place it in a very small room, as the drying process may be
longer due to limited amount of ambient air.
INFORMATION!
Do not place the dryer in a room where temperature can drop below 0 °C, as the machine may
not operate correctly at such low temperatures, or freeze, which in turn can result in damage to
the machine.
For optimum dryer operation, install it in a room with adequate ventilation and a temperature
between 15 °C and 25 °C.
WARNING!
Do not place the dryer behind lockable or sliding door, or door with a hinge on the opposite side
of the dryer door hinge. Install the dryer in such way that the door can always be freely opened.
INFORMATION!
Never block the air vents.
WARNING!
Do not place the dryer on a carpet with long fibres as this may impede air circulation.
11
Installation and connection

INFORMATION!
If the appliance is installed on a plinth or a similar structure, then the appliance must be fixed to
it, to avoid the risk of falling. ASKO original accessories are available for this purpose, complete
with fixing instructions.
Free-standing appliance
The dryer may be placed adjacent to a washing
machine.
If the friction between the dryer feet and the floor
is not sufficient, the dryer may move during
operation. To prevent sliding, use a non-slide mat
or install the supplied vacuum feet onto both front
feet.
Place the dryer so that it is stable. Use a spirit
level to level the dryer in longitudinal and traverse
direction by rotating the adjustable feet using a
No. 22 spanner (max. 15 mm). Then, firmly tighten
the jam nuts (counter nuts) by rotating them
towards the appliance bottom using a No. 17
spanner .
12
Installation and connection

Clearance around the dryer for optimum operation
INFORMATION!
The appliance shall not be in contact with a
wall or adjacent furniture. For optimum dryer
operation, observe the clearance from the wall
as shown in Fig.
Opening the dryer door (top view)
Stacking on top of a washing machine
To stack the dryer on top of a washing machine, use the extra vacuum feet and the tipping guard
(A+B), supplied in the cardboard box in the dryer drum. Tipping guard part B is designed to fit on
ASKO washing machines and it may be hard or impossible to mount on appliances of other brands.
If the washing machine and dryer are not of matching dimensions or if you have installed a hidden
helper between the two appliances, then binding plates are available as optional accessories at the
service center (…available only for HH (acessory Hidden Helpers) and TD75 stacked on top of
WM80 or WM85; not intended for any other combinations).
13
Installation and connection

All ASKO washing machines can bear the weight of the dryer.
INFORMATION!
Washing machine on which you wish to install the dryer must be able to bear the weight of the
dryer (see washing machine’s rating plate or technical information).
14
Installation and connection

How to stack a dryer onto the washing machine (ASKO):
There is a cardboard box in the dryer drum, containing the vacuum feet and the tipping guard.
1
The tipping guard consists of two metal
parts (A + B).
Use two screws to attach the A part to
the back of the dryer.
2
Undo the screw on the back side of the
washing machine.
3
Use the screw to attach the tipping
guard (B part) to the back of the
washing machine.
4
Level the washing machine so that it is
stable.
1. Level the washing machine in
longitudinal and traverse direction
by rotating the adjustable feet using
a No. 32 spanner. The feet allow
levelling by +/- 1 cm.
2. After adjusting the height of the
feet, firmly tighten the jam nuts
(counter nuts) using a spanner No
17, by turning them towards the
bottom of the washing machine .
3. Tighten the jam nuts (counter nuts).
15
Installation and connection

5
Set the dryer feet:
1. Tighten the front two feet all the way
in.
2. Undo the back feet by 3.5 turns or
5 mm; then, fasten the jam nuts
towards the bottom of the
appliance .
6
Place the dryer onto the washing
machine:
1. Lift the front part of the dryer by 5
to 10 cm.
2. Attach the vacuum feet onto the
front feet of the dryer.
3. Push the dryer into the tipping
guard (so that the B part is inserted
into the A part) and release it (See
figure on previous page).
INFORMATION!
Make sure the tipping guard is
"locked"!
Table continued from last page
16
Installation and connection

Changing the door opening direction
To change the direction of door opening, proceed as follows:
1
Open the door fully.
2
Undo the screws and remove the door.
3
Use a screwdriver to remove the door
lock cover and undo the screw on the
door lock.
4
Push the door lock upwards and
remove it. Move it to the other side and
push it downwards.
5
Fasten the screw on the door lock.
Replace the door lock cover.
17
Installation and connection

6
Undo the door hinge assembly (left)
and the door latch assembly (right),
switch their positions, and replace the
screws (door hinge assembly to the
right-hand side, door latch assembly
to the left-hand side).
INFORMATION!
Use a screwdriver to remove the
plastic part more easily.
7
Undo the door ring and remove it
temporarily.
8
Rotate the door cover by 90°so that the
sign indicating the opening of the door
is on the other side.
9
Rotate the door ring by 180°, install it
onto the door, and fasten it with screws.
18
Installation and connection

10
Install the door to the front and screw
the door.
Draining the condensate
The moisture from the laundry is extracted in the condenser unit and accumulated in the condensate
tank. Condensate tank has to be emptied regularly (see chapter "Cleaning and maintenance").
To simplified and avoid emptying and interruption of the drying cycle due to full condensate tank,
run the condensate discharge tube located at the back of the appliance directly into a drain (see
chapter "Settings/ Condensed water").
1
Remove the small short hose from the
attachment (A).
2
Connect the supplied drain hose to the
same attachment (A).
Run the condensate drain hose into a
drain. Tie the hose onto a tap (B) so
that it cannot slip during use.
The drain hose can also be fed into the
washbasin siphon (C) or directly into
the floor drain (D).
Then, the water is pumped directly into
a washbasin, a siphon, or a floor drain.
INFORMATION!
Do not pull the drain hose, and
make sure it is not under tension,
clamped, or bent.
19
Installation and connection

WARNING!
If you decide to run the condensate drain hose into a drain, siphon, or washbasin, make sure the
hose is securely fastened. This will prevent any water spillage that could result in unexpected
damage.
WARNING!
Always use hoses that are supplied with the appliance.
WARNING!
If the dryer is connected to an air exhaust system already used for another appliance, a non-return
valve must be installed. Return flow into the dryer could damage the appliance and the non-return
valve prevents such flow.
20
Installation and connection
