USER MANUAL
HS898 MOBILITY SCOOTER
LARGE

User ManualHS898
TABLE OF CONTENTS
INTRODUCTION
IMPORTANT PRECAUTIONS
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
SAFETY WARNING AND INSTRUCTION LABELS
IDENTIFICATION OF PARTS
CHARGING THE BATTERIES
DISASSEMBLING YOUR SCOOTER
ASSEMBLING YOUR SCOOTER
OPERATING YOUR SCOOTER
CARE AND MAINTENANCE
OTHER INFORMATION
TROUBLE SHOOTING
TECHNICAL SPECIFICATIONS
-------------------------------------------------------1
---------------------------------------2
---3
-------------5
---------------------------------------6
-------------------------------------11
----------------------------12
---------------------------------13
-----------------------------------13
---------------------------------------15
---------------------------------------------16
----------------------------------------------17
-----------------------------------18

HS898 User Manual
1
INTRODUCTION
Thank you and congratulation on purchasing your new Aspire mobility Scooter.
It is designed to provide you with transportation ability indoors and outdoors.
We pride ourselves on providing safe and comfortable products. Our goal is to ensure your
complete satisfaction. We sincerely hope you enjoy your Aspire mobility scooter.
Please read and observe all warning and instruction provided in owner's manual before you
operate with various convenient function of this scooter. Also, please retain this booklet for
future reference.
MANUFACTURED AND IMPORTED BY:
AIDACARE PTY LTD.
Building 3A, 1 Moorebank Avenue,
Moorebank NSW Australia 2170
1300 133 120 | www.aspirecare.com.au

HS898 User Manual
IMPORTANT PRECAUTIONS
2
•A slow speed must always be used when ascending, descending or traversing aslope
or incline and also on uneven terrain, ramps and soft or loose surfaces, such as gravel
or grass.
•To prevent any danger, do not turn around at high speed on ascending, descending ramp.
•Scooter may not operate well in high humidity.
•Do not leave the powered scooter in a rain storm of any kind.
•Do not use the powered scooter in a shower.
•Direct exposure to rain or dampness will cause the scooter to malfunction electrically
and mechanically; may cause the powered scooter to prematurely rust.
•Never put scooter in neutral when staying on slopes.
•Follow traffic laws when riding outside.
•When scooter on moving transport vehicles, do not sit or stay on scooter.
•Only one person at a time could ride an Aspire Mobility Scooter.
•Maximum load is 181 kgs / 400 pounds.
•Turn key off before getting on or off.
•Always drive carefully and be aware of others using the same area.
•Always use pedestrian crossings wherever possible. Take extreme care when crossing
roads.
• Do not drive on slope exceeding 10 degree, and take extreme care when turning on slope.
•Do not use full power when turning to sharp corner.
•Take great care and drive in low speed when backing up, riding downhill or on uneven
surface, and climbing curb.
•Please use the lowest speed when driving through the descending road or uneven terrain.
If speed is too fast, leave your hand off the handle bar, let the scooter stop. Make sure
safety and start again.
•The weight capacity limit at different ramp degree (please refer to following picture).
•The grade climbing degree will be affected by weight capacity, driving speed, and ramp degree, and scooter parameter.
•To prevent any danger from motor defected; please avoid to drive on long ramp or any uneven terrain.
52kg /
10 degree 91kg / 8 degree 136kg / 6 degree 160kg / 4 degree

HS898 User Manual
2.Medium-range mobile transceivers, such as those used in police cars, fire trucks,
ambulances, and taxis. These usually have the antenna mounted on the outside of the
vehicle; and
3.Long-range transmitters and transceivers such as commercial broadcast transmitters
(radio and TV broadcast antenna towers) and amateur (HAM) radios
Other types of hand-held devices, such as cordless phones, laptop
computers, AM/FM radios, TV sets, CD players, and cassette players,
and small appliances, such as electric shavers and hair dryers, so far as.
we know, are not likely to cause EMI problems to your motorized scooter.
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
3
CAUTION: It is very important that you read this information regarding the possible
effects of Electromagnetic Interference on your motorized scooter.
Powered wheelchairs and motorized scooters may be susceptible to electromagnetic
interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources
such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and
cellular phones. The interference (from radio wave sources) can cause the motorized
scooter to release its brakes, move by itself, or move in unintended directions. It can also
permanently damage the motorized scooter control system. The intensity of the interfering
EM energy can be measured in volts per meter (V/m). Each motorized scooter can resist
EMI up to a certain intensity. This is called its "immunity level." The higher the immunity
level, the greater the protection. At this time, current technology is capable of achieving
at least a 20 V/m immunity level, which would provide useful protection from the more
common sources of radiated EMI. The immunity level of this motorized scooter model is
not known.
There are a number of sources of relatively intense electromagnetic fields in the everyday
environment. Some of these sources are obvious and easy to avoid. Others are not
apparent and exposure is unavoidable. However, we believe that by following the warnings
listed below, your risk to EMI will be minimized.
Some cellular telephones and similar devices transmit signals while
they are ON, even when not being used
The sources of radiated EMI can be broadly classified into three types :
1.Hand-held portable transceivers (transmitters-receivers) with the antenna mounted
directly on the transmitting unit. Examples include: citizens band (CB) radios, "walkie
talkie," security, fire, and police transceivers, cellular telephones, and other personal
communication devices
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of
special concern. It is possible to unintentionally bring high levels of EM energy very close
to the motorized scooter control system while using these devices. This can affect
motorized scooter movement and braking. Therefore, the warnings listed below are
recommended to prevent possible interference with the control system of the motorized
scooter.
Motorized Scooter Electromagnetic Interference：
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones can affect motorized scooters.
Following the warnings listed below should reduce the chance of unintended brake release
or motorized scooter movement which could result in serious injury.
Warnings：

HS898 User Manual
4
There is no easy way to evaluate their effect on the overall immunity of
the motorized scooter.
1.Do not operate hand-held transceivers (transmitters-receivers), such as citizens band
(CB) radios, or turn ON personal communication devices, such as cellular phones, while
the motorized scooter is turned ON;
2.Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them;
3.If unintended movement or brake release occurs, turn the motorized scooter OFF as
soon as it is safe;
4.Be aware that adding accessories or components, or modifying the motorized scooter,
may make it more susceptible to EMI; and
1.20 volts per meter (V/m) is a generally achievable and useful immunity level against
EMI (as of May 1994). The higher the level, the greater the protection.
2.The immunity level of this product is at least 20/Vm.
5.Report all incidents of unintended movement or brake release to the distributor listed
on the inside front cover of this manual. Note whether there is a source of EMI nearby.
Important Information：

HS898 User Manual
1.Please read the instruction Booklet carefully before using your scooter.
2.Keep the scooter properly maintained.
3.Do not drive the scooter on slippery surfaces or on slopes over 10°
4.Do not drive on highways, crowded roads, or unfamiliar areas.
5.Do not tum at high speed in either forward or reverse.
6.Do not wash with water or leave scooter in a humid Environment since
water can damage the electric parts.
7.Always re-engage the emergency freewheel drive after use.
Information Sticker states the date of manufacture and serial number of the scooter.
This product has been supplied from an environmentally aware manufacturer. It may
contain substances that could be harmful to the environment. Recycling must be
carried out in accordance with the respective national legal provisions.
5
1
SAFETY WARNING AND INSTRUCTION LABELS
1
4
3
2
5
6
2
3
5
6
4
Warning Sticker
1.Please read the instruction booklet carefully before using your scooter.
2.Do not drive the scooter on slippery surfaces or on slopes over 10 degrees limit.
3.Do not drive on highway, crowded roads, or unfamiliar areas.
4.Do not turn at high speed in either forward or reverse.
5.Do no wash with water or leave scooter in humid environment since water
can damage the electronic parts.
Wiring diagram Label
Do not hang baggage or other objects on the tiller / tiller adjustment lever.
N-D Lever Adjustment label which instructs freewheel mode operation.
Tie-down points of the scooter. Do not sit or stay on the scooter during
transporting.

HS898 User Manual
Throttle
Tiller Angle Adjustment
Seat Sliding
Slide Lever
Swivel Seat
With Head Rest
Adjustable
Armrest
Seat Rotation
Lever
13" Front and Rear Wheels
Basket
Head light
Turn Signals
Figure 1 - HS-898 Front View
Figure 2 - HS-898 Control Panel
Figure 3 - HS-898 Rear View
IDENTIFICATION OF PARTS
6
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls, and how to operate
Battery Gauge
Armrest
Width
Adjustment
Thumbscrews
Rear Turn
Signals
Anti-tip Wheels
N/D
Lever
Reflectors
Hi/Lo Speed
Switch
Left
Turn Signal Headlight
Horn
Right
Turn Signal
Speed Dial Knob
Warning
Light
Power/Self-Diagnostic
Warning Light
Reflector
Rear Mirror
Rear Mirror

HS898 User Manual
7
FUNCTION OF PARTS：
Do not set the speed at maximum when operating the scooter.
Adjust the speed at maximum when inclining a slope, and adjust to minimum
speed when declining a slope.
Check battery's capacity before driving, and charging batteries when at low
power.
MAIN SWITCH (A)
1.By turning the key clockwise to NO to turn on the power
2.By turning the key anticlockwise to OFF to turn off the power.
Speed Dial Knob (B)
The Rabbit means fast and Turtle is slow.
By turning this you control total speed transferred to thumb controls.
Horn Button (C)
Pressing down the button to sound buzzer.
Battery Gauge (D)
There is a meter shows batteries capacity status.
When battery gauge's light trends to , it means sufficient power capacity.
When battery gauge's light trends to , it means insufficient power capacity.
Figure 4 Figure 5
Panel Control
Pressing down (2) to activate left turn signal.
Pressing down (3) to activate headlight.
Pressing down (4) to activate right turn signal.
Pressing down (5) to activate warning light.
※Right-hand/Left hand direction indicator
(switches itself off automatically after 30 seconds).
Hi/Lo (1)
High & Low Speed Switch allows speed to be changed from the normal maximum to half
for pavement use. Light means activated Hi/Lo speed.
(A)
(C)
(D)
(D1)
(B)
Figure 6
(1)
(2) (3) (4)
(5)

HS898 User Manual
Capacity
Display
Operation
Characteristic
Usage
Condition
LED blocks will only decrease gradually during driving.
Operation
Characteristic
Warning sound will signal, when battery capacity's lower
than 25%, after turn on the power, 2 short "Be" sounds
will signal 3 times (Be Be-Be Be-Be Be)
Remark Can be set as on or off.
D1、D2 : Red LED
D3、D4 : Amber LED
D5、D6、D7 : Green LED
Battery
Capacity%
LED
7
6
5
4
3
2
1
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆
☆ >80
<80
<65
<50
<35
<25
<20
D1 D2 D3 D4 D5 D6 D7
(1)When turn off power
(2)When charging, function will shut off.
8
Battery Gauge
Low Voltage Warning Sound
Operation
Characteristic Sound of turn signal, stop, low voltage, reversing can
be set as on or off
Description of
Volume
Setting Steps
1.Ensure power is turned off
2.Pressing left and right turn signal buttons downwards
simultaneously.
3.Turn on the power.
4.After 2 seconds, LED (D7) flashes to indicate the setting
start, if hold on buttons for 10 seconds without releasing
(left and right turn signal buttons) will automatically
leave setting mode.
5.Pressing volume setting button (As Stop (Warning) light
button) to access volume setting mode, by pressing
button (Ex: Stop (Warning) light button) to adjust volume.
6.Waiting for 10 seconds without action, or pressing left
and right turn signal buttons downwards simultaneously
for 2 seconds to return to normal operation mode.
Warning Sound (On, Off) Setting

HS898 User Manual
Examples
Reversing Warning Sound Volume Adjustment
1.Turn off the power (Key off)
2.Pressing left and right turn signal buttons downwards
simultaneously.
3.Turn on the power(Key on)
After 2 seconds, LED (D7) flashes (meaning accessed
in volume setting mode),
Release the buttons within 10 seconds (left and right
turn signal buttons).
4.Pressing Head Light button to access Reverse Warning
Sound.
5.Pressing Head Light button to adjust volume
6.After setting, waiting for 10 seconds without action, or
pressing left and right turn signal buttons downwards
simultaneously for 2 seconds to return to normal
operation mode.
Default
Turn Signal Warning Sound=Mid
Stop (Warning) Light Warning Sound=Mid
Low Voltage Warning Sound=Mid
Reversing Warning Sound=Mid
Horn Volume=Loud
9
Table of Warning Sound Settings
Function Volume Button Volume Adjustment
Reverse Warning Sound
P.S: Pressing volume button (ex:Stop (Warning) to access volume adjustment
mode, the LED displays to volume blocks and the volume (ex:Stop
(Warning) Sound signal, press (Stop (Warning) Light button again, the
volume and LED will decrease gradually, by pressing button once will
increase or decrease one block:
Head Light Button
Turn Signal Warning
Sound Left or Right Turn Signal Button
Stop (Warning) Warning
Sound Stop (Warning) Light Button
Low Voltage Warning
Sound Hi & Lo Button
Horn Volume Horn Button
Flash
Off
Minimum
Low
Mid
Loud
Except horn volume can
not be set as off
Loud >> Mid >> Low >> Minimum >> Off

HS898 User Manual
Figure 7
Figure 8 Figure 9
(G)
(F)
(a)
(H)
(I)
(E)
10
Throttle
Pulling right Throttle (E) moves scooter forward. Pulling
left Throttle (F) moves the scooter backward. (This can
be reversed if required by local dealer.) Releasing both,
engages automatic brake. These are also your accelerator.
The further you depress them, the faster you go. (Subject
to the position of the Rabbit/Turtle control).
Tiller Angle Adjustment
Pulling the tiller adjustment (G) downwards to adjust tiller's angle and release to lock at
a desired comfortable position.
Seat Swivel Adjustment
Setting at a comfortable angle by pulling lever (H) upwards to rotate seat (a) left and right.
Seat fore-aft Adjustment
Setting at a comfortable position by lifting lever (l) upwards to adjust the seat (a).
Figure 10
(J) (K)
Pull the armrest up when get on or off the scooter.
Do not hang heavy parts on the armrests to cause
tip over.
Armrest Adjustment Thumbscrews
1.Loosen the two thumbscrews (K) to adjust arm width
tighten again to lock in at desired position.
2.Adjust the attached screw (J)'s height, to control armrest's
angle.
Figure 11
(M)
Anti-tip wheels (M)
Helps keep scooter from tipping over.
Free-Wheeling Lever (L)
When lever is in N (Neutral) position, scooter can be moved
manually without power. When lever is in D (Drive) position,
scooter can be driven. Normal position is D.
(L)
Always ensure that the scooter is switched
off before getting on or off the scooter and
before removing any items of the scooter.
When driving the scooter, set the seat at foremost position to prevent tip
over.
Freewheel operation is only recommended on flat
surfaces, never on gradients. Never leave your
scooter on a gradient with its motors disengaged.
Always re-engage the motors immediately after
pushing the scooter.

HS898 User Manual
11
Batteries must be charged before using the scooter for the first time and should be
recharged after each day use. You will need the scooter and the battery charger.
1.Insert battery charger cord into the charger connector
on the charger output. Refer to above figure for correct
position
2.Plug the other end of the battery charger cable into a standard electrical outlet.
3.Turn the power on. Normally, The LED (Power) Light will turn on when electric current
passes.
4.Charging starts. During charging, LED (Charge) will indicate orange light, when it turns
to green light, that means well-charged.
5.LED indication
•LED(POWER) - GREEN LIGHT ON : Power On.
•LED(CHARGE) - ORANGE LIGHT ON : Charging / GREEN LIGHT ON : Fully Charged
6.Charger Trouble Shooting
(A)If LED (POWER) light is off
•Check the input voltage (115V/230V) is the same as you adjust.
•If light is still off, please check and repair the battery charger.
(B)If LED (CHARGE) light is off
•Check to see clips connection is correct.
•If the battery is fully charged, the LED (CHARGE) light will be off.
•If light is still off, the battery may be defective.
(C)If ORANGE light can turn to GREEN
•The battery can not be charged. Please check and recover it.
(D)If ORANGE light turns to GREEN immediately
•Check to see the battery is fully charged, if not, The battery may be defective
Check and recover it.
Each country may supply different charger. The
charging procedure may be different from below.
If you require more details, please contact your
authorized dealer.
Be sure the scooter key is in the OFF position.
Do not use extension cord to connect the charger.
Do not use other brand charger to charge the scooter.
The time needed to recharge will vary depending on the depletion of the
batteries. Charging for longer than necessary will not harm the batteries.
They can not be overcharged.
CHARGING THE BATTERIES
Figure 12
Keep in mind these rules：
•Fully charge batteries at least once a month, or more if you use scooter regularly.
Charge after each trip exceeding 3 kilometers.
•If storing your scooter for some time (1 month or more), make sure that batteries are
fully charged, and on returning, charge them again before using scooter.
•
Batteries will only give maximum performance after scooter has been used, and batteries
have been recharged up to 10 times. A bit like breaking in a new car.
Please be aware that the travelling range of your mobility scooter is impacted by how fast the batteries
are discharged. This will depend on many circumstances, such as ambient temperature, condition of the
surface of the road, tyre pressure, weight of the driver, driving environment (inclines etc.) and utilisation
of your lighting system if fitted. We recommend that you test your local ride with a family member to
ensure a safe journey.

HS898 User Manual
12
(O)
(H)
(a)
(b)
(Q)
(b) (b)
(R) (R)
(P)
Be careful when removing batteries, as batteries are heavy.
Do not contact battery terminal with any metals to avoid danger.
Figure 13
Figure 14 Figure 15
Figure 16
DISASSEMBLING YOUR SCOOTER
Disassembling Basket
By lifting the basket (O) upwards.
Disassembling Seat
By lifting lever (H) and seat (a) upward.
Rear Compartment Cover
Open the Compartment Cover (P) according to
arrow's direction.
Disassembling Batteries
Tear off battery straps (Q) and disconnect battery connectors (R) to remove the batteries (b).
-+

HS898 User Manual
13
ASSEMBLING YOUR SCOOTER
To assemble scooter, you can repeat disassembly directions in reverse. Abbreviated
directions are given below. Refer to Figures on pages 12 to locate parts.
1.Use the tiller adjustment to move tiller up and out of the way.
2.Place front basket.
3.Place battery pack in battery compartment.
4.Place seat on seat post and lift lever (H) to insert the seat into the seatpost, then swivel
the seat to lock at a desired position.
OPERATING YOUR SCOOTER
You could make the following adjustments to increase your comfort when driving.
•adjust seat position.
•adjust armrest width to comfortable position.
•adjust tiller's angle.
1.Before operating your scooter, check the following:
•free-wheeling lever in D
•speed dial knob is at turtle picture.
2.Sit on scooter and turn on key, Battery Gauge meter should be indicate at Full.
The Self-Diagnostic Warning Light should not be blinking.
3.When your hands rest comfortably on handlebars, the Throttle should be within easy
reach. The right lever moves scooter forward, the left one moves it backward. When
you release both levers, scooter will stop.
This scooter has automatic braking system. Release the Throttle and
brake will stop scooter.
4.Steer scooter by turning tiller toward the way you want to go.
5.Practice driving where there are is No obstacle. Start at the slowest speed and drive
forward and backward; make some turns. As you get more comfortable, you can increase
speed by turning speed dial toward picture of rabbit.
6.If Battery Gauge indicates , you should plan to recharge batteries very soon.
7.When you are finished riding, turn off the key before getting off.
8.If you are finished riding for the day, immediately recharge batteries.
See CHARGING THE BATTERIES, page 11.
Keep in mind these rules：
•Release Throttle and allow scooter to stop completely before changing from forward
to reverse, or reverse to forward.
•When turning to corner, swing front wheels widely, so back wheels will turn more tightly.
•Use scooter only where it is safe to walk.
•Drive in low speeds when reversing, riding dowhill, over rainp or curb, or on uneven
sukpace, downhills, ramps, curbs, or uneven surfaces.

HS898 User Manual
14
In unlikely event of a panel display error, you need to re-set the display
system by cycling the on/off main switch. The display circuitry is independent
of the motor control system. A display console error does not affect scooter
speed control.
Other Operating Information：
Hill climbing: You may need to use a higher speed. Turn to lower speed before going
downhill.
Down slopes: proceed with downward slopes slowly, and set speed control in proximity
of turtle. The closer speed control is set toward turtle, the slower scooter
travels. However, this scooter will not self accelerate down hills due to the
automatic braking, taking effect should you attempt to drive too fast.
Kerb climbing: Approach slowly from right angles to curb. A slight angle is permissible
with a 4-wheel scooter. Do not attempt greater than a 7cm curb.
If Self-Diagnostic Warning Light starts to blink, identify problem from
chart on page 16 and take action.
If the scooter breaks down and must be moved, get off scooter, engage
Free-Wheeling Lever to N, push scooter slowly to a safe location, and
push lever back to D.

HS898 User Manual
15
CARE AND MAINTENANCE
DAILY CHECK
Check point Inspection What to do if the inspection is failed
N-D lever
Horn
Throttles
Electro-
mechanical
brake and
Emergency
hand brake
Battery
Gauge
Rear
mirror (s)
Lighting
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
‧Contact your dealer if battery gauge is
not working.
‧Recharge the battery immediately if low
‧Clean up the dirt by damp cloth.
‧Tighten the screw or clamping stem that
holds the mirror(s)
Contact your dealer.
Check for correct function
Check for correct function
Pull the wigwag to test the scooter
movement
Pull the wigwag a little bit and
release it to test if brake works.
If your scooter comes with
emergency handbrake, please
check it as well.
Check if the battery gauge is
displayed and whether it is at
low power.
Check if the parts are clean and
firmly tighten to the scooter and
do not wobble.
Check if all lights, such as head
lights, rear lights, and turn signal
are functioning correctly.
WEEKLY CHECK
Check point Inspection What to do if the inspection is failed
Speed Dial
Knob
Armrests
Wheels/Tires
Motor
Battery
Charger
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
Check for correct function
Check if the parts are clean and
firmly tighten to the scooter and
do not wobble. Tighten the screw
knob that holds the armrest.
Inflate the tire to the correct
pressure and check that
1.Drive wheels rotate without
wobbling.
2.Tire tread depth is not less than
0.5mm.
3.No foreign objects in tires.
Check for correct function
Check if the charger is functioning
correctly and the batteries are
charged.
MONTHLY CHECK
Check point Inspection What to do if the inspection is failed
Seat /
Upholstery
Electronics
Contact your dealer.
Contact your dealer.
Check for movement and if it’s
worn
Check if all the battery cables and
connectors are firmly tighten to the
scooter
Please always check your scooter before you start your every journey.

HS898 User Manual
16
General driving posture
•Obstacle height approx. 7cm (Figure.17)
•Feasible groove width approx. 20cm, scooter must go straight line to across the groove.
(Figure.18) Suggest, not to across the obstacle over 5cm.
•When driving scooter on ramp, adjust body center of gravity to keep scooter more safety.
RECYCLING & DISPOSAL
•The equipment wrapping is potentially recyclable.
•The metal parts are used for scrap metal recycling. The plastic parts are used for plastic
recycling.
•Electric components and printed circuit boards are disposed of as electronic scrap.
•Exhausted or damaged batteries can be returned to your medical equipment supplier.
•Disposal must be carried out in accordance with the respective national legal provisions.
•Ask your city or district council for details of the local waste management companies.
SERVICE LIFE
We estimate a service life of five years for this product, provided it is used in strict
accordance with the intended use as set out in this document and all maintenance and
service requirements are met. The estimated service can be exceeded if the product is
carefully used and properly maintained, and provided technical and scientific advances
do not result in technical limitations. The service life can also be considerably reduced
by extreme or incorrect usage. The fact that we estimate a service life for this product
does not constitute an additional warranty.
OTHER INFORMATION
Remark :
Figure 17 Figure 18
On ramp, forward your body
will let scooter more safety.
Only use damp cloth and a little soap to wipe the seat. Do not use abrasive cleaners as
this will damage the seat.
Seat Upholstery :
CLEANING YOUR SCOOTER
•Do not use any abrasive or scouring liquids for cleaning. Only use a damp cloth and
gentle detergent.
•Do not use hose pipe or splash water directly onto the scooter as this may cause damage
to electronics.
MAINTENANCE
•User should inspect the scooter regularly to keep scooter in good running order.
•Check if the electrical cable connectors are fully connected.
•All maintenance and repair of scooter should be done by an authorized dealer.
•Please store the scooter in a dry location. If store the scooter in long time, please
disconnect the battery terminals.
•Do not store your scooter where it will be exposed to source of direct heat, damp, oil,
acid, alkaline, or where Ozone could be possibly generated. All of the above will minimize
scooter / tire cycle and shorten its lifetime.
Storage :

HS898 User Manual
17
TROUBLE SHOOTING
Here are some suggestions about solving problems you may have with your scooter. There
is a self-diagnostic warning light on the control panel. To check the self-diagnostic warning
light, turn on the key and count the number of blinks on the warning light.
SCOOTER WON’T MOVE WHEN KEY IS TURNED ON
ERROR CODE
Flash Description Initial check points
1 Battery Low
The batteries are running low.
•Recharge the batteries.
3 High Battery Fault
Battery voltage is too high. This may occur if overcharged and/or
traveling down a long slope.
•If traveling down a slope, reduce your speed to minimize the
amount of regenerative charging.
7 Speed Pot
The throttle, speed limit pot. SRW or their associated wiring may be faulty.
•Check the throttle and speed pot and associated connections and wiring.
8 Motor Voltage
The motor or its associated wiring is faulty.
•Check the motor and associated connections and wiring.
9 Other Error
The controller may have an internal fault.
•Check all connections and wiring.
6 Drive Inhibit
Either a stop function is active or charger inhibits or OONAPU
condition has occurred.
•Release the stop condition (seat raised etc.)
•Disconnect the battery charger.
•Ensure the throttle is in Neutral when turning the controller on.
•The throttle may require re-calibration.
5 Park Brake
Either a park brake release switch is active or the park brake is faulty.
•Check the park brake and associated connections and wiring.
•Ensure any associated switches are in their correct positions.
4
Current limit time-out
or controller overheat
The motor has been exceeding its maximum current rating for too long.
•The scooter may have stalled. Turn the controller off, leave for a few
minutes and turn back on again.
•The motor may be faulty. Check the motor and associated
connections and wiring.
2 Low Battery Fault
The batteries have run out of charge.
•Recharge the batteries.
•Check the battery and associated connections and wiring.
Check point
Check if the battery power is enough.
(Battery gauge is under 25%)
Check if the charger power cord is still
plugged in scooter
Check if the N-D lever is in Neutral position
Check if the power is off
1.Check Power Reserve Indicator on control panel, it should be lighting in green, yellow, and red
zones.
2.Check Self-Diagnostic Warning Light, it should be steady. If it is flashing, see chart below for
problem identification.
3.Check all electrical connections to be sure they are tight.
4.If none of above correct problem, contact your authorized dealer.
Solution
Recharge the battery and then retest.
Unplug the charger power cord.
Switch to D (drive) position. Turn off the power and
turn on again.
Turn the power on.
•TIRE : Low tire pressure: pump up tires to 30~35 psi.
•
Charger : During charging, light on charger doesn’t change to green. Contact your authorized
dealer.
OTHER PROBLEMS
The Low Battery Fault Flash code, described above, is a requirement of various safety standards.
The scooter will output a visible and audible low battery warning if the battery voltage drops below
90% of its cut-off voltage. The warning will be two short flashes, and will take priority over all other
flash codes in the system.

HS898 User Manual
TECHNICAL SPECIFICATIONS
18
*Subject to change without notice. ( Rev. 5, 2020/06/29 )
Overall Length
Overall Width
Overall Height
Front Wheels
Rear Wheels
Weight W/ Batteries
Max. Speed
Weight Capacity
Ground Clearance
Grade Climbable
Curb Climbable
Turning Radius
Suspension
Brake
Seat Type
Seat Width
Motor Size
Battery Size
Weight of Battery
Travel Range
Battery Charger
Electronics
1440 mm
720 mm
1360 mm
330 mm
330 mm
145 kg
10 kmph
180 kg
100 mm
10 degree
80 mm
1600 mm
Front & Rear
Hand Brake & Electro-Mechanical
Swivel Captain Seat With Seat Sliding Mechanism
& Back Angle Adjustment
520 mm
850W, 3450 r.p.m.
(2)2) . 75Ah
55 kg
40 km
8A Off Board
On / Off Key Switch, Battery Level Indicator,
Speed Control Knob
