USER MANUAL
MODEL #: JBZL17 | VERSION #: 1
BREEZE LIGHT

1Model #: JBZL17 | Version #: 1
• Scooter • Charger
• Manual • Pump
IN THE BOX
SPECIFICATIONS
• Range: Up To 15 Miles Per Charge
• Speed: Up To 18 Mph
• Weight Limit: 255 Lbs
• Braking System: Rear Drum Brake
• Motor: 300 Watt Brushless Electric Motor
• Charge Time: 4 Hours (Fully Charged)
• Battery: Lithium-Ion 36V
• Tire: 8.5 Inches
• Weight: 29 Lbs
SAFETY FEATURES
• Front and Rear Lights
• Anti-slid Grips For Foot Control
• Easy Grip Handlebars
• Energy-saving auto-shutdown
FEATURES
• No Assembly Required
• Backlit LCD Display With Speed,
Odometer and Battery Meter
• Thumb Throttle Speed Control
• Cruise Control
• Adjustable Maximum Speed
• Aluminium Alloy Frame With
Concealed Battery
• Protective Mudguard
• Built-in Kickstand Functionality
• Quick Release Lock + Fold
• Compact And Portable For Travel
• Collapsible Handlebars
• 3 Speed Modes
Congratulations on your new Jetson Breeze Light! Before your rst
ride, please check whether the wheels are damaged, or parts are
loose. If there are any abnormalities, please contact Jetson Custom-
er Support at customerser[email protected], or call 1-(888) 976-
9904.
This product manual can help you understand, assemble, use, and main-
tain your Jetson Breeze Light. In order to avoid danger caused by collisions,
falls, and loss of control, please use caution and learn how to ride the Jetson
Breeze Light safely. Falling, losing control, and collisions (including failure to
obey the Jetson Breeze Light manual) may cause injury. In order to minimize
the risk, ensure you read this manual carefully. Users ride at their own risk.
The user is responsible for consequences caused by violating warnings, local
laws, or improper operations.
If for any reason you want to return this product, please call us at 1-(888)
976-9904 or email us at [e-mail] before return-
ing it to the store.

2
Model #: JBZL17 | Version #: 1

3Model #: JBZL17 | Version #: 1
FOR YOUR SAFETY:
• This product is intended for riders ages 13 and up, and for use on pri-
vate property and closed courses, not on public streets and sidewalks.
Always drive defensively, and watch out for potential obstacles that may
catch your wheel or cause you to swerve suddenly.
• Always check any local laws or regulations which may a󰀨ect where the
Jetson Breeze Light may be used.
• Ride at your own risk and use common sense. Any rider that is unable to t
comfortably on the vehicle should not attempt to ride it. All decisions on who
is allowed to ride the Jetson Breeze Light should be made based on their
maturity, skill, and ability to follow the rules.
• Keep this product away from small children. It is intended for use by people
who are, at a minimum, comfortable and competent when operating the
Jetson Breeze Light.
• The Jetson Breeze Light is designed for one rider. Never carry passengers,
and do not attach the Jetson Breeze Light to other objects.
• This product was manufactured for performance and durability, but is not
impervious to damage. Jumping and aggressive riding can over-stress and
damage the Jetson Breeze Light. The rider assumes all responsibility and
risk associated with high-stress activity.
• Keep your hands on the handlebars at all times. Only activate the speed
control on the hand grip when you are on the Jetson Breeze Light and in a
safe environment suitable for riding.
• Do not wear headphones or use a cell phone while operating the Jetson
Breeze Light.
• Do not operate the Jetson Breeze Light in wet or icy weather, and never
immerse the product in water. The electrical components can be damaged
by water and create other unsafe conditions.
• Avoid excessive speeds when riding downhill, as it increases the risk of
accident and injury. Avoid wet, slick, bumpy, uneven or rough surfaces while
using the Jetson Breeze Light. Never risk damaging surfaces such as carpet
and ooring by using the product indoors.
• Do not ride at night, or when visibility is limited.
• Always wear proper protective equipment, such as a helmet, elbow pads,
and knee pads. Athletic shoes with rubber soles are best for riding the Jet-
son Breeze Light.
• Never operate the product barefooted or in sandals, and keep shoelaces
tied and out of the wheels, motor, and drive system.

4
Model #: JBZL17 | Version #: 1
INNER DRUM BRAKE/AUTO
POWER OFF
QUICK FOLDING MECHANISM
SELF LOCKING / RELEASE BUTTON
ELECTRIC MOTOR
(LOCATED IN REAR WHEEL)
ALUMINIUM DECK WITH ANTI-SKID GRIP
BATTERY CHARGER PORT
OVERVIEW OF PARTS AND POSITIONS:

5Model #: JBZL17 | Version #: 1
QUICK RELEASE SAFETY LOCK
FOLDED POSITION
SPEED CONTROL THROTTLE
WITH LCD DISPLAY AND FUNCTIONS
PLASTIC MAINTENANCE COVER

6
Model #: JBZL17 | Version #: 1
Write down the serial number of your scooter. Keep this information separately
and in a safe place.
Each Jetson Breeze Light has a unique serial number. These numbers can
provide information that may be useful later on for insurance claims and in
case of loss or theft.
Your Jetson Breeze Light serial number is located next to the Folding
Mechanism Release Button, on the top of the aluminium deck.
SERIAL NUMBER:

7Model #: JBZL17 | Version #: 1
OPENING & FOLDING
THE BREEZE LIGHT
Always follow the local laws and regulations.
Never ride your Breeze Light in conditions of poor visibility.
Do not do stunts, wheelies, or jumps. They will increase your chances
of injury and damage your Breeze Light.
Never carry passengers.
Jetson is not liable for incidental damages or consequential
damages due directly or indirectly to the use of this product.
Before starting up your Breeze Light, ensure that the Quick Release
Safety Lock is inserted all the way into the steering rod.
PLEASE NOTE
BEFORE RIDING
GENERAL WARNING

8
Model #: JBZL17 | Version #: 1
2
Press down on the RED Pedal using your hand.
1
Pull up the steering rod, and push out
until you hear the click of the locking mechanism.
Self Locking Pedal

9Model #: JBZL17 | Version #: 1
Unfold the handlebars and turn the RED side rings
to lock them in place.
Open the RED Quick Release Safety Lock
and slide the steering rod up to its locking position.
3
4
See tightening direction.
Make sure the safety latch is inserted into place.

Model #: JBZL17 | Version #: 1 10
5Last Step: ensure that the RED SAFETY LOCK
is securing the Folding Mechanism.
SAFETY LOCK positions ON
OFF

Model #: JBZL17 | Version #: 1
11
The Breeze Light has a unique folding mechanism, which enables a
quick and easy fold for carrying, transportation and storage.
FOLDING:
1
Push the steering bar firmly forward while
using your foot to push the RED pedal down
at the same time to release the folding
mechanism.
Push down using your foot.
To fold, press the RED safety lock down first.

Model #: JBZL17 | Version #: 1 12
2
3
4
Fold the Breeze Light using the same steps that you used to unfold it.

Model #: JBZL17 | Version #: 1
13
• Do not operate the scooter while charging.
• Do not store the Breeze Light for long periods of time with a fully charged
battery. If the scooter is not in use for more than one month, keep it under
halfway charged.
• From time to time, discharge the battery by riding the Breeze Light and
using all stored energy in the battery.
DO NOT USE THE BATTERY IF THE BREEZE LIGHT:
• Is broken.
• Emits an unusual odor or excessive heat.
• Presents any leakage.
Avoid contact with any substance oozing from the battery. Keep the battery
away from children and pets. Exposure to the battery voltage can cause death
or serious injury.
The use, storage, or charging of the Breeze Light battery outside the specified
limits may result in the annulment of the warranty, battery damage, and an
ineffective battery charge.
BATTERY:
CHARGING PORT

Model #: JBZL17 | Version #: 1 14
Your Breeze Light has an external charger. First, connect the charger’s electric
cable to an electrical outlet. Then, connect the charging cable to the Breeze
Light’s charging socket on the top left side of the deck.
When the Charging Light is Red, the battery is charging.
When the Charging Light is Green, the charging is complete.
If a light does not appear on the charger when it is first plugged into an
electrical outlet, the charger is damaged and must be replaced immediately.
To maximize your battery’s performance, fully charge it for 8 hours once a
month. Avoid long periods of time with an uncharged or fully charged battery.
Unplug the charger from the outlet before performing any maintenance. It
is dangerous to work on the Breeze Light when plugged into an AC outlet.
Electrical shock can cause serious injury and damage to the scooter.
Do not attempt to open the battery. Do not insert anything in the battery and
do not attempt to open its case with any tool. Inserting an object into openings
or in the battery can cause electrical shock, injury, burns, or fire. Any attempt
to open the battery case will damage it and cause release of dangerous toxic
substances.
Charge the battery only using the included charger.
CHARGING:

Model #: JBZL17 | Version #: 1
15
LCD DISPLAY THROTTLE FUNCTIONS
• Travel speed
• Cruise control
• Distance
• Battery status
• Speed mode
• Total trip
• Background light
• Automatic power-off
• ODO
ON/OFF button
Button
Button
ACCELERATE thumb button
THROTTLE AND CONTROLS:

Model #: JBZL17 | Version #: 1 16
THROTTLE POWER ON
THROTTLE POWER OFF
AUTO POWER OFF
After five minutes of non-use, the scooter will automatically shut down.
DRIVE / SPEED CONTROL
Start twisting the throttle with your thumb for accelerating. The maximum
twisting angle is 60° for full speed.
Press to power the scooter on.
Press and hold for three seconds to shut down the system.

Model #: JBZL17 | Version #: 1
17
When powered on, the default display is Speed Mode (“SPEED” will appear at
top right of the screen). You may change it using the and buttons.
This function limits the maximum speed of the scooter,
either for a beginner user or for more accurate riding in a
crowded surrounding:
• Speed Mode 3 - using full throttle will gain maximum
speed of the scooter, 20MPH at default.
• Speed Mode 2 - using full throttle, will accelerate at
70% top speed.
• Speed Mode 1 - using full throttle, the maximum speed will be under 10
MPH.
All Speed Modes can be manually adjusted.
LCD BACKLIGHT (first mode)
When power is on, press and hold to turn the LCD Backlight on and off.
Press to change the brightness level from 1 to 3 (low/middle/high).
Press and hold to save settings.
Press once to enter Speed Limit Mode (second mode).
SPEED LIMIT MODE (second mode)
The default highest speed is 15 MPH at full throttle.
You can define other speed limits (from 2 MPH to 20 MPH).
Press the or buttons to change the maximum speed.
Press and hold to save setting.
Press once to enter Cruise Control (third mode).
To enter the Display Mode settings:
Press and hold the buttons together for 2 seconds to enter the LCD
Backlight (first mode).
Press to switch between modes.
Press and hold to return to the Main Function Menu.
SPEED MODE:
DISPLAY MODE:

Model #: JBZL17 | Version #: 1 18
CRUISE CONTROL (third mode)
The default setting for Cruise Control is off (the letter "N" will appear to indicate Cruise
Control is off).
Press or to enable Cruise Control (the letter "Y" will appear to indicate Cruise
Control is on).
Press and hold to save the settings.
Press once to re-enter the first mode.
Wile riding at any same speed for more then Ten (10) seconds, the Cruise
Control will be turned on. If this option is defined in Settings, it does not
come as a default for safety reasons.
OTHER DISPLAY MODES INCLUDE:
TRIP - your trip distance since your last trip reset. Press and hold to
reset the trip.
ODO - your Breeze Light’s total distance since its factory assembly,
or since a new/repaired battery was placed.
BATTERY VOLTAGE - Your current battery state.
ERROR - Your system has encountered an error, please contact Jetson Cus-
tomer Support to find out what it is.
WARNING!
When using the Cruise Control system, releasing your thumb from
the throttle will not slow you down. To slow down, apply pressure
on the brake lever or release and push the throttle again, which
will turn off the Cruise Control system.

Model #: JBZL17 | Version #: 1
19
TIRES AIR PRESSURE
Air pressure in tires should be between 40psi and 50psi.
SAFETY GEAR
You must wear a helmet and proper safety gear while riding your Breeze Light.
The helmet must be worn according to its instructions.
MECHANICAL SAFETY TESTS:
Before using your Breeze Light, perform a visual inspection to ensure that
all screws and nuts are tight and in place. Note if anything looks wrong, or is
showing signs of wear.
Check the tires for signs of wear. To do this, spin them to make sure that they
are not yet in the need of replacing. Make sure that the wheels are freely
rotating from the brakes.
Before each ride, always check your brakes and the general mechanical
function of the scooter.
SAFE DRIVING:
1. Get to know your Breeze Light before driving it. Test your control over it.
Make your turns slowly and cautiously, and give yourself plenty of stopping
distance.
2. To learn how to control your Breeze Light, practice riding in an open space
without any hazardous conditions or obstacles.
SAFETY:
