Assa Abloy Yale HSA6060 User manual

Pack contents
•1xHSA6060 Remote Keyfob
controller.
•1x3V C2032 cell.
Keyfob description
LED: Red LED indicates keyfob state .
Arm button: Press for Away Arming.
Emergency button: Press for Personal
alarm.
Home Arm button: Press to partially arm.
Disarm: Press to switch alarm off or to
silence alarm.
Specification
Conforms to:
EN 300 220-1 / V2.1.1 (2006-04)
EN 301 489 -1, / V1.6.1 (2004-12)
EN 301 489-3, / V 1.4.1 (2002-08)
Environmental conditions:
-10°Cto 40°C, relative humidity
70% non-condensing
Radio: Microcontroller controlled
433.92MHz AM transmitter.
Battery: 3V
,CR2032 lithium
coin cell. 3 years typical domestic
service life
Wirefree Yale HSA6060
Remote keyfob controller
(Yale part number: 666060001001)
Battery
cover
Coin
slot
Locked
Unlocked
Yale
LED
Arm Button
Emergency
button
Home Arm
Button
Disarm
Button
HSA6000 series
Keyfob Manual 8/12/06 11:52 am Page 1

Battery installation
1Remove the battery cover by using a
coin to turn counter-clockwise until the
arrow is pointing to the round dot
(unlocked).
2Insert the battery with the positive (+)
side up.
3To replace the battery cover ensure the
arrow is pointing towards the dot and
turn the cover clockwise until the
arrows are pointing towards each other
(locked).
Programming & testing
Program your Keyfob before installation
and test afterwards. Please see your
current system instruction book.
Yale UK
School Street, Willenhall
West Midlands WV13 3PW
Tel [phone]
Fax [phone]
E-mail [email protected]
www.yale.co.uk E1 12/06
Keyfob Manual 8/12/06 11:52 am Page 2
