AssetScan ASB01 User manual

www.assetscan.com
Hardware Setup Instructions
Bearing Fault Transmitter - Model ASB01
2
4
5
6
7
3
2
Setting up the Transmitter
3
1Open transmitter case by pulling up on two latches on front of case.
Connect black wire to negative (top) battery terminal as shown. Ensure
red wire is seated on positive terminal.
Green LEDs on board will begin to light up.
Wait 2 minutes aer plugging in battery then press TEST button on board.
Transmitter will go through a data collection cycle that will last for 10
minutes before reverting to normal operation.
Call ATEK Technical Support at 877-847-7226 to ensure transmitter has
communicated with AIP or login if access is already available.
Shut and latch lid.
Connect accelerometer to ASB01 case by aligning cable connector with
case connector. Tighten collar until snug.
Slide washer off end of accelerometer located on end of armored cable.
1
7
TEST
