AssetScan ASM01 Manual

www.assetscan.com
Hardware Setup Instructions
Multipurpose Transmitter - Model ASM01
2
5
1
TEST
4
5
6
7
8
9
3
2
Setting up the Transmitter
NOTE: If using customer supplied sensors, refer to Sensor
Wire Connections section on page two before proceeding.
1Open transmitter case by pulling up on two latches on front of case.
Connect black wire to negative (top) battery terminal as shown. Ensure red wire is
seated on positive terminal.
Green LEDs on board will begin to light up.
Remove protective caps from sensor ports and connect sensor cable ends to
receptacles. Be sure connectors are snug to provide environmental seal.
Connect cables to sensors as needed. For proper AIP functionality, ensure sensor
port connections match configurations in AIP. Refer to product manual for detailed
instructions.
Wait 2 minutes aer plugging in battery then press TEST button on board.
Transmitter will go through a data collection cycle that will last for 10 minutes
before reverting to normal operation.
Call ATEK Customer Care Team at 800-523-6996 to ensure transmitter has
communicated with AIP or login if access is already available.
Shut and latch lid.
Login to AIPAssetScan.com to monitor data and edit device set-up as necessary.
Refer to the ATEK Intelligence Platform (AIP) for AssetScan Quick Start
Guide for further instructions:
assetscan.com/support or download the AIP AssetScan Quick Start Guide.
3
IMPORTANT: ATEK’s Customer Care Team (CCT) is ready
to assist with any setup help necessary to fully utilize the
AssetScan Transmitter. Site and contact information is needed
before data is properly managed by the ATEK Intelligence
Platform (AIP). CCT: 800-523-6996 or assetscan.com/contact

ATEK Access Technologies
10025 Valley View Road, Ste. 190
Eden Prairie, MN 55344 U.S.A.
PH: 1.800.523.6996
FAX: [phone]
+1.218.829.9797
www.atekaccess.com
223-0166-002 Rev. C 4/19
©2019 ATEK Access Technologies, LLC. All Rights Reserved. AssetScan images and marketing materials are protected by various patents, copyrights
and/or trademarks. ATEK assumes no responsibility for any errors which may appear in this document, reserves the right to change devices or
specifications detailed herein at any time without notice, and does not make any commitment to update the information contained herein. No licenses to
patents or other intellectual property of ATEK are granted by the Company in connection with the sale of AssetScan products, expressly or by implication.
Hardware Setup Instructions
Multipurpose Transmitter - Model ASM01
Recharging the Transmitter Battery*
2
3
4
5
1Charging port is located on right side of transmitter case.
Remove threaded plastic cap from charging port by turning counterclockwise.
Plug battery charger’s AC plug into a nearby outlet and screw charging jack into
charging port using silver nut.
LED on battery charger will turn red to indicate transmitter is charging.
Transmitter will begin charging. Full charge is achieved within 6-8 hours.
LED on battery charger will turn green when charging is complete.
Unscrew charging jack from charging port and secure attached plastic cap onto
charging port.
*Note: Battery should be charged between -10º C and 40º C (14º F and 104º F). See Product
User Manual for detailed information on battery use and care.
Sensor Wire Connections
2
3
4
5
6
7
1
3
4
5
1
2
Verify intended sensor is a 2 wire, loop powered, 4-20mA output device, capable of
operating at 24VDC with a 200 Ohm load resistor in return line.
Sensor Port 1 (located at the right side of cable connections) should be used for a
single sensor installation.
Sensor Port 2 can be connected to a 2nd sensor for an additional measurement
point. The measured variable can be different than Port 1 as long as the sensor
is a 2 wire, 4-20mA loop powered device. Both lines are measured and reported
simultaneously.
Pin 1 of the M12-4 ASM sensor connector is +24VDC and must be connected to the
Positive (+) terminal of the sensor.
On the ASM transmitter, pins 2 and 3 are both wired to the Negative (-) terminal
• If the sensor cannot have pins 2 and 3 wired together, contact ATEK CCT.
Sensor connections may be accomplished via:
• Field wire-able M12 connector (ATEK Accessory: ASA004) to allow the use of
direct cabled sensors, or custom cable length.
• M12-4 M-F extension cable (ATEK Accessory: ASA005 for 5m, and ASA006
for 10m) to connect to sensors with integral M12-4 Male connector.
• M12-4 to 1/2NPT connection adapter (ATEK Accessory: ASA020) for
sensors with 1/2NPT conduit entries.
• Other methods per installer’s choosing.
Refer to Setting up the Transmitter section to connect battery and start ASM
transmitter.
