ASTRO VG-876 User manual

Video Signal Generator
VG-876
Instruction Manual
Ver.3.40


i
Contents
Introduction.......................................................................................................................................... x
Safety precautions............................................................................................................................... x
What is packed with the generator......................................................................................................xii
Chapter1. CONCERNING THE VG-876............................................................................................................... 1
1.1. General description....................................................................................................................... 1
1.2. Features........................................................................................................................................ 1
1.3. Data configuration......................................................................................................................... 2
1.4. Panel parts and their functions ..................................................................................................... 3
1.4.1. VG-876 front panel ......................................................................................................... 3
1.4.2. RB-1870/RB-1871 panel................................................................................................. 4
1.4.3. Names of the keys and their functions............................................................................ 5
1.4.4. VG-876 rear panel.......................................................................................................... 7
1.4.5. Names of connectors and their applications................................................................... 7
1.4.6. Tools used to operate the VG-876.................................................................................. 8
1.5. Concerning VM-1876 module slots............................................................................................... 9
1.5.1. Overview......................................................................................................................... 9
1.5.2. Exchanging modules ...................................................................................................... 9
1.5.3. Firmware version up......................................................................................................11
1.5.4. Checking operation........................................................................................................11
1.6. Menu lists.................................................................................................................................... 12
1.6.1. Program Edit menu list ................................................................................................. 12
1.6.2. Group Edit menu list..................................................................................................... 14
1.6.3. Audio Edit menu list...................................................................................................... 14
1.6.4. DP Analysis menu list................................................................................................... 14
1.6.5. Data Copy/Erase menu list........................................................................................... 14
1.6.6. Configuration menu list................................................................................................. 15
1.6.7. Audio Flash Data Entry................................................................................................. 15
1.6.8. Maintenance menu list.................................................................................................. 15
Chapter2. OPERATION PROCEDURES............................................................................................................ 17
2.1. Flow of basic operations............................................................................................................. 17
2.1.1. Settings required for displays ....................................................................................... 17
2.1.2. Selecting the timing data .............................................................................................. 18
2.1.3. Selecting the pattern data............................................................................................. 19
2.1.4. Selecting the actions .................................................................................................... 22
2.2. Saving the program data............................................................................................................. 25
2.3. Setting the names....................................................................................................................... 26
2.4. Groups........................................................................................................................................ 27
2.4.1. Executing groups.......................................................................................................... 27
2.4.2. Setting and saving groups............................................................................................ 28

ii
2.4.3. Display change when Group execution........................................................................ 29
2.5. Automatic execution.................................................................................................................... 30
Chapter3. TIMING DATA SETTINGS ................................................................................................................. 32
3.1. Horizontal timing data editing...................................................................................................... 32
3.1.1. Horizontal timing data................................................................................................... 32
3.1.2. Restrictions on the horizontal timing parameters.......................................................... 32
3.1.3. Horizontal timing data setting procedure...................................................................... 34
3.2. Vertical timing data editing.......................................................................................................... 35
3.2.1. Vertical timing data....................................................................................................... 35
3.2.2. Restrictions on the vertical timing parameters.............................................................. 36
3.2.3. Vertical timing data setting procedure........................................................................... 38
3.2.4. Concerning the scanning modes.................................................................................. 39
3.2.5. Concerning the TV modes............................................................................................ 39
3.2.6. Concerning the Serration/EQP..................................................................................... 40
3.2.7. Concerning EQP-Fp and EQP-Bp................................................................................ 42
Chapter4. PATTERN SETTINGS........................................................................................................................ 44
4.1. Color bar patterns....................................................................................................................... 44
4.1.1. Types of color bar patterns........................................................................................... 44
4.1.2. Color bar pattern customizing....................................................................................... 45
4.2. Gray scale patterns..................................................................................................................... 47
4.2.1. Types of gray scale patterns......................................................................................... 47
4.2.2. Gray scale pattern customizing .................................................................................... 48
4.3. Ramp patterns............................................................................................................................ 50
4.3.1. Types of ramp patterns................................................................................................. 50
4.3.2. Ramp pattern type settings and customizing................................................................ 51
4.4. Sweep patterns........................................................................................................................... 53
4.4.1. Types of sweep patterns............................................................................................... 53
4.4.2. Sweep pattern selection ............................................................................................... 54
4.5. Monoscope patterns ................................................................................................................... 55
4.5.1. Types of monoscope patterns....................................................................................... 55
4.5.2. Monoscope pattern selection........................................................................................ 56
4.6. Raster patterns........................................................................................................................... 57
4.6.1. Types of raster patterns................................................................................................ 57
4.6.2. Raster pattern type settings and customizing............................................................... 57
4.7. Aspect ratio patterns................................................................................................................... 59
4.7.1. Types of aspect ratio patterns....................................................................................... 59
4.7.2. Aspect ratio pattern type settings and customizing....................................................... 60
4.8. Checkerboard patterns............................................................................................................... 62
4.8.1. Types of checkerboard patterns ................................................................................... 62
4.8.2. Checkerboard pattern customizing............................................................................... 63
4.9. Image/OPT ................................................................................................................................. 65
4.9.1. Types of Image/OPT..................................................................................................... 65

Contents
iii
4.9.2. Option and image patterns setting................................................................................ 66
4.9.3. 9-marker (OPT No.76) settings..................................................................................... 67
4.9.4. 3D Image Pattern (OPT No.100) setting....................................................................... 69
4.9.5. Setting the 3D pattern (OPT No.101)............................................................................ 72
4.9.6. Output setting of BMP files........................................................................................... 79
4.10. × ABC patterns................................................................................................................ 81
4.10.1. Color settings.............................................................................................................. 82
4.10.2. Character patterns...................................................................................................... 84
4.10.3. Crosshatch patterns.................................................................................................... 85
4.10.4. Dot patterns................................................................................................................ 86
4.10.5. Circle patterns ............................................................................................................ 88
4.10.6. Burst patterns............................................................................................................. 90
4.11. Window patterns ....................................................................................................................... 92
4.11.1. Types of window patterns........................................................................................... 92
4.11.2. Window pattern settings ............................................................................................. 93
4.12. Cursor patterns......................................................................................................................... 96
4.12.1. Cursor settings ........................................................................................................... 96
4.12.2. Cursor operations....................................................................................................... 99
4.13. Name/List................................................................................................................................ 101
4.13.1. Name/List display..................................................................................................... 102
4.13.2. Name........................................................................................................................ 103
4.13.3. EDID......................................................................................................................... 105
4.13.4. DDC/CI..................................................................................................................... 107
4.13.5. HDCP (High-bandwidth Digital Content Protection)...................................................110
4.13.6. HDMI list....................................................................................................................114
4.13.7. Timing data list...........................................................................................................115
4.13.8. Image pattern list.......................................................................................................116
4.13.9. OPT-USER pattern list...............................................................................................116
4.13.10. Subtitle.....................................................................................................................117
4.13.11. SCDC ......................................................................................................................119
4.14. Video black/white reversal ...................................................................................................... 122
4.15. Simple animation .................................................................................................................... 123
4.15.1. Creating and registering the images......................................................................... 123
4.15.2. Simple animation settings......................................................................................... 128
Chapter5. ACTION SETTINGS ........................................................................................................................ 130
5.1. Concerning the planes.............................................................................................................. 130
5.2. Window actions......................................................................................................................... 131
5.2.1. Scrolling...................................................................................................................... 131
5.2.2. Flickering.................................................................................................................... 133
5.2.3. Level up/down actions................................................................................................ 134
5.2.4. Level sequence action................................................................................................ 135
5.3. Graphic plane scrolling actions................................................................................................. 137
5.4. Character plane scrolling actions.............................................................................................. 139

iv
5.5. Subtitle scrolling........................................................................................................................ 141
5.6. 0.25- and 0.125-dot scrolling actions (option)........................................................................... 143
5.7. Motion blur................................................................................................................................ 146
5.8. Scroll Sequence........................................................................................................................ 149
5.9. LipSync..................................................................................................................................... 151
5.10. Black insertion ........................................................................................................................ 153
Chapter6. HDCP SETTINGS AND EXECUTION ............................................................................................. 154
6.1. HDCP settings.......................................................................................................................... 154
6.2. HDCP execution....................................................................................................................... 156
6.2.1. Execution procedure................................................................................................... 156
6.2.2. Screen displays during HDCP execution.................................................................... 158
6.2.3. HDCP/EDID/CEC collective display ........................................................................... 160
Chapter7. VG-876 SYSTEM SETTINGS (Config)............................................................................................ 164
7.1. System settings ........................................................................................................................ 164
7.1.1. Beep setting ............................................................................................................... 164
7.1.2. Key lock setting .......................................................................................................... 165
7.1.3. RS-232C settings ....................................................................................................... 166
7.1.4. LAN settings............................................................................................................... 168
7.1.5. INC/DEC continuity setting......................................................................................... 169
7.1.6. INC/DEC interval setting............................................................................................. 170
7.1.7. Color depth setting ..................................................................................................... 170
7.1.8. SAMPLE RGB/YPbPr setting ..................................................................................... 171
7.1.9. DDC clock setting....................................................................................................... 171
7.1.10. Trigger mode settings............................................................................................... 172
7.1.11. Image - priority settings ............................................................................................ 182
7.1.12. Image Position Setting.............................................................................................. 183
7.1.13. Cursor coordinate setting ......................................................................................... 184
7.1.14. Mouse speed setting ................................................................................................ 184
7.1.15. Digital Video Level Step setting................................................................................ 185
7.1.16. High-speed drawing mode setting............................................................................ 185
7.1.17. CUSTOM Key1, 2, RB-1871 CUSTOM Key 1, 2 ...................................................... 187
7.1.18. Operation mode at power-on.................................................................................... 188
7.1.19. USB Prg FolderNo. setting ....................................................................................... 189
7.1.20. Bit depth display in Name Pattern setting................................................................. 190
Chapter8. DATA COPY/Delete ......................................................................................................................... 192
8.1. Copy and delete data................................................................................................................ 192
8.1.1. Copying programs...................................................................................................... 192
8.1.2. Copying user characters............................................................................................. 194
8.1.3. Copying user optional patterns................................................................................... 195
8.1.4. Copying images.......................................................................................................... 196
8.1.5. Copying subtitle.......................................................................................................... 197

Contents
v
8.1.6. Copying groups .......................................................................................................... 198
8.1.7. Copying auto executions ............................................................................................ 199
8.1.8. Copying all data.......................................................................................................... 200
8.1.9. Erasing programs ....................................................................................................... 201
8.1.10. Erasing user characters............................................................................................ 202
8.1.11. Erasing user optional patterns.................................................................................. 203
8.1.12. Erasing images......................................................................................................... 204
8.1.13. Erasing subtitle......................................................................................................... 205
8.1.14. Erasing groups ......................................................................................................... 206
8.1.15. Erasing automatic executions................................................................................... 207
8.1.16. Erasing all data......................................................................................................... 208
Chapter9. USEFUL FUNCTIONS..................................................................................................................... 210
9.1. Short-cut keys........................................................................................................................... 210
9.2. Information................................................................................................................................ 212
9.3. Data initialization....................................................................................................................... 213
9.3.1. Initializing the system settings .................................................................................... 213
9.3.2. Initializing the short-cut data....................................................................................... 214
9.4. USB Unmount........................................................................................................................... 215
9.5. Formatting................................................................................................................................. 216
9.5.1. Internal memory formatting and data installation........................................................ 216
9.6. Delete the data of output interface unit and select version-up.................................................. 220
9.6.1. Confirm data size of each interface unit...................................................................... 220
9.6.2. Delete the data of output interface unit....................................................................... 221
9.6.3. Select the interface unit to version-up ........................................................................ 222
Chapter10. INTERFACE SETTINGS.................................................................................................................. 224
10.1. VG-876 interface units............................................................................................................ 224
10.1.1. HDMI unit (VM-1876A-M0)....................................................................................... 224
10.1.2. DisplayPort unit (VM-1876-M1) (this unit is discontinued)........................................ 224
10.1.3. DisplayPort Unit (VM-1876A-M1) ............................................................................. 225
10.1.4. V-by-One®HS unit (VM-1876-M2)............................................................................ 226
10.1.5. SDI IF BOARD(OUT)(VM-1876-M5)........................................................................ 226
10.1.6. HDMI 6G Unit (VM-1876A-M6)................................................................................. 227
10.1.7. HDMI HDCP2.2 Unit (VM-1876-M7)......................................................................... 228
10.1.8. HDMI 6G HDCP2.2 Unit (VM-1876-M8)................................................................... 228
10.1.9. iTMDS Unit (VM-1876-M9)....................................................................................... 229
10.1.10. Analog Unit (VM-1876-MA)..................................................................................... 229
10.1.11. Synchronizing Unit (VM-1876-MX) ......................................................................... 230
10.2. Output settings........................................................................................................................ 231
10.2.1. Setting the output interfaces to ON or OFF .............................................................. 232
10.2.2. Setting the sync signals to ON or OFF and setting the sync signal polarities........... 234
10.2.3. Setting the level mode.............................................................................................. 235
10.2.4. Setting the Dot clock operation mode(Dot Clock Mode)........................................... 236

vi
10.2.5. Setting the aspect ratio............................................................................................. 238
10.2.6. Setting the color depth (bit) for pattern drawing........................................................ 240
10.2.7. Selecting RGB or YPbPr and setting the color difference coefficients...................... 241
10.2.8. Setting the digital level.............................................................................................. 243
10.2.9. Audio sweep settings................................................................................................ 245
10.2.10. Setting the audio level (temporary settings)............................................................ 246
10.2.11. Digital level setting of 3D pattern............................................................................ 247
10.3. HDMI ...................................................................................................................................... 249
10.3.1. Connectors and pin assignments ............................................................................. 249
10.3.2. HDMI data transfer methods..................................................................................... 250
10.3.3. HDMI setting procedure............................................................................................ 258
10.3.4. InfoFrame/Packet..................................................................................................... 260
10.3.5. Scramble.................................................................................................................. 283
10.3.6. Send SCDC (Status and Control Data Channel)...................................................... 284
10.3.7. CEC function ............................................................................................................ 285
10.3.8. EDID......................................................................................................................... 287
10.3.9. HDCP....................................................................................................................... 287
10.3.10. DDC/CI................................................................................................................... 288
10.3.11. LipSync................................................................................................................... 288
10.3.12. ARC........................................................................................................................ 288
10.3.13. HPD Negate ........................................................................................................... 293
10.4. DisplayPort ............................................................................................................................. 294
10.4.1. Connector and pin assignment................................................................................. 294
10.4.2. Split setting............................................................................................................... 295
10.4.3. DisplayPort setting.................................................................................................... 299
10.4.4. Displaying the DisplayPort setting information.......................................................... 306
10.4.5. DP Analysis ...............................................................................................................311
10.4.6. Embedded audio ...................................................................................................... 315
10.4.7. EDID......................................................................................................................... 316
10.4.8. HDCP....................................................................................................................... 316
10.4.9. DDC/CI..................................................................................................................... 316
10.4.10. Select executing function........................................................................................ 316
10.5. V-By-One®HS......................................................................................................................... 318
10.5.1. Connector and pin assignment................................................................................. 318
10.5.2. V-by-One ®HS setting procedure............................................................................. 319
10.5.3. Data transfer method................................................................................................ 322
10.5.4. V-by-One®HS Control.............................................................................................. 379
10.5.5. V-by-One®HS Config setting.................................................................................... 380
10.6. SDI.......................................................................................................................................... 381
10.6.1. SDI output ................................................................................................................ 381
10.6.2. SDI setting................................................................................................................ 381
10.6.3. SDI transfer method ................................................................................................. 386
10.6.4. SDI TimeCode setting............................................................................................... 388
10.6.5. SDI ClockDelay setting............................................................................................. 389

Contents
vii
10.6.6. Embedded audio ...................................................................................................... 389
10.7. iTMDS..................................................................................................................................... 390
10.7.1. Connector and pin assignment................................................................................. 390
10.7.2. iTMDS setting method.............................................................................................. 391
10.7.3. Data transfer systems............................................................................................... 394
10.7.4. EDID......................................................................................................................... 422
10.7.5. HDCP ....................................................................................................................... 422
10.7.6. DDC/CI..................................................................................................................... 422
10.8. Analog Output......................................................................................................................... 423
10.8.1. Connectors and output signals ................................................................................. 423
10.8.2. Analog output setting method................................................................................... 424
10.8.3. Analog Output ON/OFF setting................................................................................. 425
10.8.4. General Setting......................................................................................................... 425
10.8.5. Audio OFF/ON setting............................................................................................... 426
10.8.6. Composite signal filter settings................................................................................. 426
10.8.7. Adjustment of Video Level of Component Output..................................................... 427
10.8.8. Adjustment of Video Level of Composite Output....................................................... 428
10.9. Digital audio............................................................................................................................ 429
10.9.1. Digital audio.............................................................................................................. 429
10.9.2. Audio sweep settings................................................................................................ 432
10.9.3. AAC,AC3 Audio Data Entry....................................................................................... 433
10.9.4. Flash Data Entry....................................................................................................... 434
10.10. Analog Audio......................................................................................................................... 435
10.10.1. Connectors and output signals............................................................................... 435
10.10.2. Analog audio signals............................................................................................... 435
10.11. Synchronization by several units operation........................................................................... 437
10.11.1. Outline.................................................................................................................... 437
10.11.2. Connection ............................................................................................................. 438
10.11.3. VM-1876-MX setting............................................................................................... 440
10.11.4. Control operation.................................................................................................... 441
10.11.5. Split Mode Image of 4 units synchronization .......................................................... 443
10.11.6. Split Mode Image of 2 units synchronization .......................................................... 447
10.11.7. Image of scanning direction.................................................................................... 449
10.12. Main specifications................................................................................................................ 455
10.12.1. Common specifications........................................................................................... 455
10.12.2. HDMI unit................................................................................................................ 456
10.12.3. DisplayPort Unit (VM-1876-M1).............................................................................. 457
10.12.4. DisplayPort Unit (VM-1876A-M1) ........................................................................... 458
10.12.5. V-by-One ®HS Unit ................................................................................................ 461
10.12.6. SDI Unit.................................................................................................................. 461
10.12.7. HDMI 6G Unit ......................................................................................................... 464
10.12.8. HDMI HDCP2.2 Unit............................................................................................... 465
10.12.9. HDMI 6G HDCP2.2 unit.......................................................................................... 467
10.12.10. iTMDS Unit........................................................................................................... 469

viii
10.12.11. Analog Unit........................................................................................................... 469
10.12.12. Synchronization Unit............................................................................................. 470
10.13. External Control.................................................................................................................... 470
10.14. General specifications .......................................................................................................... 470
10.15. Trademark............................................................................................................................. 470
10.16. Connector specifications....................................................................................................... 471
10.16.1. RS232C-Connector................................................................................................ 471
10.16.2. Trigger-Connector................................................................................................... 471
10.16.3. S-Trigger-Connector............................................................................................... 472
10.17. Relationships between the pattern drawing bit length, the dividing mode and the dot clock
frequency.............................................................................................................................. 473
10.17.1. HDMI Unit............................................................................................................... 473
10.17.2. DisplayPort Unit (VA-1876-M1)............................................................................... 477
10.17.3. DisplayPort Unit (VM-1876A-M1) ........................................................................... 480
10.17.4. V-by-One ® HS Unit ............................................................................................... 484
10.17.5. iTMDS Unit............................................................................................................. 486
10.17.6. SDI Unit.................................................................................................................. 488
10.18. Concerning the maximum current consumption of the DDC (DP_PWR) power supply ........ 488
10.19. License list............................................................................................................................ 489
Chapter11. FUNCTIONS AVAILABLE WITH TV STANDARD SIGNALS............................................................ 491
11.1. Macrovision............................................................................................................................. 491
11.1.1. Description and specifications.................................................................................. 491
11.1.2. Setting procedure..................................................................................................... 492
11.2. Closed captions/V-Chip........................................................................................................... 493
11.2.1. Description and specifications.................................................................................. 493
11.2.2. Closed caption settings ............................................................................................ 494
11.2.3. V-Chip settings ......................................................................................................... 499
11.3. Teletext.................................................................................................................................... 504
11.3.1. Description and specifications.................................................................................. 504
11.3.2. Setting procedure..................................................................................................... 505
11.4. WSS........................................................................................................................................ 509
11.4.1. Description and specifications.................................................................................. 509
11.4.2. Setting procedure..................................................................................................... 510
11.5. CGMS-A/ID-1.......................................................................................................................... 512
11.5.1. Description and specifications.................................................................................. 512
11.5.2. Setting procedure..................................................................................................... 513
Chapter12. LIST OF ERROR MESSAGES........................................................................................................ 515
12.1. Media-related error................................................................................................................. 515
12.2. General error .......................................................................................................................... 515
12.3. HDCP-related error................................................................................................................. 518
12.4. User-generated optional pattern-related error......................................................................... 518

Contents
ix
Chapter13. SCREEN SPLIT IMAGE LIST.......................................................................................................... 519
13.1. Single clock mode Image split.............................................................................................. 519
13.2. Dual clock mode Image split ................................................................................................ 520
13.3. Quad clock mode Image split............................................................................................... 522
Chapter14. Revision history ............................................................................................................................... 525

x
BEFORE OPERATING THE GENERATOR
Introduction
Thank you very much for purchasing this model VG-876 video signal generator.
This manual contains details on the operation procedures to be followed when the VG-876 is used, the checkpoints
and precautions to be observed, and so on. Improper handling may result in malfunctioning so before using the VG-
876, please read through these instructions to ensure that you will operate the generator correctly.
After reading through the manual, keep it in a safe place for future reference.
Safety precautions
WARNING
Concerning the generator
Do not subject the generator to impact or throw it. Doing so may cause the
generator to malfunction, explode or generate abnormally high levels of heat,
possibly resulting in a fire.
Do not use the generator where there is a danger of ignition or explosions.
Do not place the generator inside a microwave oven or other heating kitchen
appliance or inside a high pressure vessel. Doing so may heat up the generator to
abnormally high levels, cause smoking, running the risk of the generator’s catching
fire and/or damaging the circuit components.
This generator contains some high-voltage parts. If you touch them, you may
receive an electric shock and burn yourself so do not attempt to disassemble,
repair or remodel the generator.
If there is a thunderstorm while the generator is being used outdoors, immediately
turn off its power, disconnect the power cable from the main unit, and move the
generator to a safe place.
Concerning the power cord
Always take hold of the molded part of the plug when disconnecting the power
cord.
Do not use force to bend the power cord or bunch it up for use. Doing so may
cause a fire.
Do not place heavy objects on top of the power cord. Doing so may damage the
cord, causing a fire or electrical shock.
Concerning foreign matter
Do not spill liquids inside the generator or drop inflammable objects or metal parts
into it. Operating the generator under these conditions may cause a fire, electric
shocks and/or malfunctioning.

BEFORE OPERATING THE GENERATOR
xi
CAUTION
Concerning the generator
When connecting the generator to a display unit, use the FG cable provided to
connect the frame ground (FG) terminal on the generator to the frame ground
terminal on the display unit. If these terminals are not connected together, the
generator may fail. Take special care when connecting the generator to a display
unit which is under development.
When disconnecting the VG-876 from the display unit, first disconnects the
connecting cables, and then disconnects the FG cable.
When the generator’s power is to be turned ON or OFF, be absolutely sure to use
the POWER switch on the front panel. Turning the power on and off by plugging in
and unplugging the AC power cable may damage the USB memory.
Do not start using the generator straight away: instead, turn on the power of the
VG-876 and allow it to warm up for about 10 to 15 minutes before use so as to
ensure that the VG-876 will operate stably.
Never unscrew and open the cover on the side panel of the main unit while the main
unit power is turned on. Malfunctioning may result if the cover or the screw should
drop into the chassis of the main unit.
Concerning impact
This is a precision instrument and, as such, subjecting it to impact may cause
malfunctioning. Take special care when moving the generator.
Do not drop the generator.
Concerning installation
Install the generator in a stable location. Do not stand it on either of its side panels.
Doing so may cause the generator’s temperature to rise due to heat generation,
possibly resulting in malfunctioning.
When trouble or malfunctioning has occurred
In the unlikely event that trouble or malfunctioning should occur, disconnect the
generator’s power cable, and contact your dealer or an ASTRODESIGN sales
representative.

xii
What is packed with the generator
The generator comes with the following items.
Be absolutely sure to use only the genuine accessories which are supplied with this generator since the use of any
non-designated items may cause malfunctioning.
Standard accessories
VG-876 main unit
CD with VG-876 instruction manual (what you are now reading): 1 disc
USB Memory: 1 pc
SP-8870 software installation CD (for Windows): 1 pc
SP-8870 instruction manual: PDF version (packed with the SP-8870 software installation CD)
Power cable: 1 pc *1
FG cable (1.5 meters long): 1 pc *1
*1: These cables are designed to be used exclusively with the VG-876.
Optional accessories
RB-1870:
Remote control box used exclusively with the VG-876
RB-1871:
Simplified remote control box used exclusively with the VG-876
This remote control box is used exclusively for executing program data, timing data, pattern data and other
operations so it cannot be used for setting operations.

1
1
CONCERNING THE VG-876
1.1. General description
The VG-876 video signal generator supports applications in every field of display test and measuring.
It features a high level of expandability which is achieved by the installing video output interface units.
1.2. Features
16-bit high-speed imaging engine
This generator features a maximum 16-bit × RGB high-gradation imaging engine. It even draws
full HD images in an instant.
Wide dot clock frequency range
The VG-876 support a maximum dot clock frequency of 340MHz for digital outputs.
Windows-compatible editing and registration software (SP-8870) provided
as standard accessory
This software can be used to edit and register the program data and exercise control over the
signals output from the PC connected to the RS-232C/LAN/USB connector.
Full variety of sample data incorporated inside
A total of a thousand types of timing data and a thousand types of pattern data are registered
inside the VG-876 as sample data. They are categorized by standard, application and other
factors, and it is possible for the data required to be selected easily.
Registration of program data on USB memory
A total of a thousand program data can be registered on a USB memory. PC screens or natural
images can also be registered. On a PC equipped with a USB port, the data can be copied using
Explorer provided with Windows 98SE, Windows 2000, XP, Vista or 7.
Creation of user option patterns
In addition to the existing basic patterns (including character, crosshatch, color bar and gray
scale) and optional patterns, a function that allows users to create their own optional patterns has
been added. This function makes it possible to create the optional patterns which are useful for
developing and evaluating the next-generation displays.

2
1.3. Data configuration
The data output by the VG-876 is managed by the program data.
The program data consists of the pattern data which is used to set the data relating to the output images and the
timing data which is used to set the data relating to all other output timing data and output conditions.
The table below gives a breakdown of the data.
Block
Description
Timing data
Program Name
Program name
Timing
Timing
Output
Output condition
Audio
Audio output
Pattern data
Pattern
Pattern
Action
Pattern action
A number of types of program data, optional patterns and user character patterns are contained as
sample data inside the VG-876.
Number of data
Timing data
1556 (Timing # 1001 to 2556)
Pattern data
1556 (Pattern # 1001 to 2556)
Optional patterns
200(1 to 200)
User character patterns
16 (F0h to FFh)
The various data can be registered in the internal memory (approx. 60 MB) of the VG-876 or in USB
Memory.
Number of data
Program data
1000 (Program # 1 to 1000)
User option patterns
999 (1 to 999)
Images (image data)
999 (1 to 999)
* Number of data depends on the image data size,
memory capacity and card capacity.
User character patterns
16 (E0H to EFH)
Number of characters in program names
20 characters
* When displayed on the RB-1870.
* Only 16 characters can be displayed on the VG-
876.
Number of groups
99 (1 to 99)
* For further details on groups, refer to
“2.4 Groups.”
Number of group data
98 (1 to 98)
Number of characters in group names
20 characters
* For further details, refer to “7.1.11 Image - priority settings.”
When a USB Memory has been inserted, the data registered
on that USB Memory becomes valid, and the data registered
in the internal memory becomes invalid.
In the case of image data, both the data on a USB Memory
and the data in the internal memory can be made valid. *
CAUTION

Chapter 1 CONCERNING THE VG-876
3
1.4. Panel parts and their functions
1.4.1. VG-876 front panel
USB POWER
WINDOW
BR B/PG/YR/P
NAME/LISTCURSOR CATEGORY SAMPLE TIMING PATTERN GROUP
INV SYNC
ACTION LEVEL SET
DETAIL ESC SHIFT
SAVE
RASTER ASPECT CHECKER IMAGE/OPTION ABC MUTE SHORT CUT
0/STATUS
MENU
DEC
INC
13
2
4/A 6/C
5/B
7/D 8/E 9/F
HDCPGRAY MONOSCOPESWEEPRAMPCOLOR
DIGITAL VIDEO GENERATOR VG-876
(B)
(A)
(E)
(F)
(C)
(D) (G)

4
1.4.2. RB-1870/RB-1871 panel
RB-1870
RB-1871
Some restrictions apply to operating the RB-1871. The operable items are described below.
Selecting and executing programs
Execution of grouped programs (but group editing is not possible)
ON/OFF operations of R, G, B and INV keys
ON/OFF operations of CUSTOM (I, II) keys (default = I: HDCP, II: MUTE)
Change levels (digital video levels only)
* For further details on the keys, refer to “1.4.3 Names of the keys and their functions.”
REMOTE BOX RB-1870
MENU
SHORT CUT
9/F
6/C5/B4/A
7/D 8/E
SHIFT
SAVE 3
0/
1
INC
2
DECSTATUS
TIM
ESCGROUP
CATEGORY
SET
PATSAMPLE
GRAY
COLOR SWEEP MONOSCOPE
G/Y
CURSOR
ASPECTRASTER
WINDOW
R/P
ABC
LEVEL
IMAGE/OPTCHECKER
B/P
NAME/LIST
INV
ACTION
DETAILSYNC
R B
RAMP
X
□
(A)
(B)
(D) (C)
(E)
7 8 9
654
TIM
1 2 3
SET 0
PAT
GRP
INC DEC
R G B INV
SAMPLE LEVEL
Ⅰ Ⅱ
(E)
(D)
(A)

Chapter 1 CONCERNING THE VG-876
5
1.4.3. Names of the keys and their functions
(A)
Pattern keys
etc.
Used to display and edit the patterns.
Action key
Used when setting the scroll, flicker and other functions.
Level key
Used to set the digital video levels and audio levels.
RGB channel on/off
etc.
Used to set R, G and B on or off.
INV key
Used to invert the video signals.
SYNC key
Used to set the sync on or off.
Detail key
Used to perform the detailed settings of the pattern data,
timing data, etc.
HDCP key (custom key)
Used to set HDCP on or off.
(HDCP is a system for protecting content used by HDMI.)
MUTE key (custom key)
Used to set the audio on or off (muted).
* When setting HDMI AV-MUTE
This key functions as the HDMI AV-MUTE On/Off setting.
(Refer to “7.1.17 CUSTOM Key1, 2, RB-1871 CUSTOM
Key”.)
(B)
Menu operation screens
The menu screens are used to set and check the items
displayed on the fluorescent display tube.
(C)
Rotary switch
This is turned clockwise or counterclockwise to select the
setting items or parameters, change the level settings, etc.
(D)
Number keys
to
Used to input numerical values, select the menus, etc.
INC/DEC
Used to select the setting items or parameters, change the
level settings, change the program numbers, etc.
Menu
Used to display the menu screens.
When it is pressed while a menu screen is already
displayed, the initial screen is restored.
* When the menu key indicator is lighted
It is no longer possible to use any of the other keys.
Short-cut key
Used to move to a user-registered menu screen using
minimal key operations.
Save key
Used to save the data which has been set.
Shift key
Used to input letters of the alphabet with the number keys.
COLOR
ABC
ACTION
LEVEL
G/Y
INV
SYNC
DETAIL
HDCP
MUTE
0/STATUS
9/F
INC
DEC
MENU
SHORT CUT
SAVE
SHIFT

6
(E)
Category key
Used to select the internal sample data by category.
Sample key
Used when the internal sample data is used.
* When the sample key indicator is off
The data stored in the USB memory or stored in the
internal memory can be used.
Timing key
Used to display changeable lists when only the output timing
data is to be changed.
Pattern key
Used to display changeable lists when only the output
pattern data is to be changed.
Group key
Used to display user-registered groups, etc. and create
groups.
Escape key
This key can be used in the following situations
•When canceling parameter selections or numerical value
settings
•When returning the displayed menu screen to the
previous hierarchical level
Set key
Used to enter the setting items and parameters which have
been set.
(F)
USB
Used for inserting USB Memory or accessing the memory in
USB Memory.
(G)
Power switch
Used to turn the power of the VG-876 on and off.
CATEGORY
SAMPLE
TIMING
PATTERN
GROUP
ESC
SET
Table of contents
Other ASTRO Inverter manuals
