Asus TP370QL User manual

E14003
Revised Edition V2 / February 2018
User Guide

2
Notebook PC User Guide
NOTE: The keyboard's layout may vary per region or country. The top view may also
vary in appearance depending on the Notebook PC model.
Top View
Camera
Keyboard
Touchpad
Capital lock indicator
360°-adjustable
touch screen panel
Fingerprint sensor

Notebook PC User Guide 3
I/O ports and slots
Headphone/Headset/Microphone jack Power (DC) input port
HDMI port USB 3.1 Gen 1 port
Nano SIM/MicroSD combo card slot*
Getting started
1. Charge your Notebook PC
A. Connect the DC power connector into your Notebook PC’s power (DC) input port.
B. Plug the AC power adapter into a 100V~240V power source.
NOTE: The power adapter may vary in appearance, depending on models
and your region.
2. Lift to open the display panel
3. Press the power button
Charge the Notebook PC
for 3 hours before using
it in battery mode for the
rst time.
* Use only the bundled pin to eject the Nano SIM/MicroSD card tray.

4
Notebook PC User Guide
WARNING!
The bottom of the Notebook PC can get warm to hot while in use or while charging the battery
pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
IMPORTANT!
• EnsurethatyourNotebookPCisconnectedtoagroundedpoweradapterbeforeturningit
on for the rst time.
• WhenusingyourNotebookPConpoweradaptermode,thesocketoutletmustbeneartothe
unit and easily accessible.
• Locatetheinput/outputratinglabelonyourNotebookPCandensurethatitmatchesthe
input/output rating information on your power adapter. Some Notebook PC models may
have multiple rating output currents based on the available SKU.
• Poweradapterinformation:
 -Inputvoltage:100-240Vac
 -Inputfrequency:50-60Hz
 -Ratingoutputcurrent:3.42A(65W)
 -Ratingoutputvoltage:19V
Safety notices for your Notebook PC
CAUTION!
• ThisNotebookPCshouldonlybeusedinenvironmentswithambienttemperaturesbetween
5°C(41°F)and35°C(95°F).
• RefertotheratinglabelonthebottomofyourNotebookPCandensurethatyourpower
adapter complies with this rating.
• Thepoweradaptermaybecomewarmtohotwhileinuse.Donotcovertheadapterandkeep
it away from your body while it is connected to a power source.
WARNING!
ReadthefollowingprecautionsforyourNotebookPC’sbattery:
• OnlyASUS-authorizedtechniciansshould
remove the battery inside the device
(for non-removable battery only).
• Thebatteryusedinthisdevicemaypresent
a risk of re or chemical burn if removed or
disassembled.
• Followthewarninglabelsforyourpersonal
safety.
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Donotdisposeofinre.
• Neverattempttoshort-circuityour
Notebook PC’s battery.
• Neverattempttodisassembleand
reassemble the battery
(for non-removable battery only).
• Discontinueusageifleakageisfound.
• Thisbatteryanditscomponentsmustbe
recycled or disposed of properly.
• Keepthebatteryandothersmall
components away from children.

Notebook PC User Guide 5
Copyright Information
You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without
limitation,intheManualorwebsite,areandshallremaintheexclusivepropertyofASUSand/orits
licensors. Nothing in this Manual intends to transfer any such rights, or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOFANYKIND.SPECIFICATIONSAND
INFORMATIONCONTAINEDINTHISMANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND
ARESUBJECTTOCHANGEATANYTIMEWITHOUTNOTICE,ANDSHOULDNOTBECONSTRUEDASA
COMMITMENTBYASUS.
Copyright © 2018 ASUSTeK COMPUTER INC. All Rights Reserved.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages
resulted from omission or failure of performing legal duties under this Warranty Statement, up to the
listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
ThislimitalsoappliestoASUS’suppliersanditsreseller.ItisthemaximumforwhichASUS,itssuppliers,
and your reseller are collectively responsible.
UNDERNOCIRCUMSTANCESISASUSLIABLEFORANYOFTHEFOLLOWING:(1)THIRD-PARTYCLAIMS
AGAINSTYOUFORDAMAGES;(2)LOSSOF,ORDAMAGETO,YOURRECORDSORDATA;OR(3)SPECIAL,
INCIDENTAL,ORINDIRECTDAMAGESORFORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOSTPROFITSORSAVINGS),EVENIFASUS,ITSSUPPLIERSORYOURRESELLERISINFORMEDOFTHEIR
POSSIBILITY.
Service and Support
ForcompleteE-Manualversion,refertoourmulti-languagewebsiteat:
https://www.asus.com/support/
Avis concernant les batteries remplaçables
• Labatteriedel’appareilpeutprésenterunrisqued’incendieoudebrûluresicelle-ciest
retiréeoudésassemblée.
• Labatterieetsescomposantsdoiventêtrerecyclésdefaçonappropriée.

6
Notebook PC User Guide
Federal Communications Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
moreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changesormodicationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.

Notebook PC User Guide 7
FCC COMPLIANCE INFROMATION
Per FCC Part 2 Section 2.1077
Responsible Party:
Asus Computer International
Address: 800 Corporate Way, Fremont,CA 94539.
Phone/Fax No: [phone]/[phone]
hereby declares that the product
Product Name :
Notebook PC
Model Number :
TP370QL
compliance statement:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Ver. 180125

8
Notebook PC User Guide
FCC Radio Frequency (RF) Exposure Caution
Statement
WARNING!Anychangesormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the user’s authority to operate this equipment.
“ThemanufacturedeclaresthatthisdeviceislimitedtoChannels1through11inthe
2.4GHzfrequencybyspeciedrmwarecontrolledintheUSA.”
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled
environment.TomaintaincompliancewithFCCRFexposurecompliancerequirements,please
avoid direct contact to the transmitting antenna during transmitting. End users must follow the
specicoperatinginstructionsforsatisfyingRFexposurecompliance.
RF Exposure Information (SAR)
Thisdevicemeetsthegovernment’srequirementsforexposuretoradiowaves.Thisdeviceis
designedandmanufacturednottoexceedtheemissionlimitsforexposuretoradiofrequency
(RF) energy set by the Federal Communications Commission of the U.S. Government.
TheexposurestandardemploysaunitofmeasurementknownastheSpecicAbsorptionRate,
or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard
operating positions accepted by the FCC with the EUT transmitting at the specied power level
in dierent channels.
TheFCChasgrantedanEquipmentAuthorizationforthisdevicewithallreportedSARlevels
evaluatedasincompliancewiththeFCCRFexposureguidelines.SARinformationonthisdevice
is on le with the FCC and can be found at
www.fcc.gov/general/fcc-id-search-pageaftersearchingonFCCID:MSQTP370QL.

Notebook PC User Guide 9
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-003.
ThisdevicecomplieswithIndustryCanadalicense-exemptRSSstandard(s).
This device and its antenna(s) must not be co-located or operating in conjunction with any
otherantennaortransmitter,excepttestedbuilt-inradios.
Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
The Country Code Selection feature is disabled for products marketed in US/Canada.
Canada, avis d’Industrie Canada (IC)
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.
LeprésentappareilestconformeauxnormesCNRd’IndustrieCanadaapplicablesauxappareils
radioexemptsdelicence.
Cetappareiletsonousesantenne(s)nedoiventpasêtresituésprèsdeouutilisésconjointement
avecuneautreantenneouunautreémetteur,exceptionfaitedesradiosintégréesquiontété
testées.
Sonutilisationestsujetteauxdeuxconditionssuivantes:(1)cetappareilnedoitpascréer
d’interférenceset(2)cetappareildoittolérertouttyped’interférences,ycompriscelles
susceptiblesdeprovoquerunfonctionnementnonsouhaitédel’appareil.
Lafonctiondesélectiondel’indicatifdupaysestdésactivéepourlesproduitscommercialisés
auxÉtats-UnisetauCanada.

10
Notebook PC User Guide
Radiation Exposure Statement
This device has been tested for compliance with IC SAR values at a typical operating near
thebody.ToensurethatRFexposurelevelsbelowthelevelstested,useaccessorieswiththis
equipment to maintain a minimum separation distance of 0 cm between the body of the user
and the device. These accessories should not contain metallic components. It is possible that
the accessories used close to the body that do not meet these requirements are not consistent
with the SAR limits and it is advisable to avoid using them.
Déclaration d’exposition aux radiations
CedispositifaététestépourlaconformitéaveclesvaleursSARàunfonctionnementtypique
prèsducorps.Pourassurerquelesniveauxd’expositionauxradiofréquencesendeçàdes
niveauxtestés,utiliserdesaccessoiresaveccetéquipementpourmaintenirunedistancede
séparationminimalede0cmentrelecorpsdel’utilisateuretl’appareil.Cesaccessoiresne
doiventpascontenirdescomposantsmétalliques.Ilestpossiblequelesaccessoiresutilisésprès
ducorpsquinerépondentpasàcesexigencesnesontpascompatiblesavecleslimitesSARetil
estconseilléd’éviterdelesutiliser.

Notebook PC User Guide 11
Caution
(i)thedeviceforoperationintheband5150-5250MHzisonlyforindoorusetoreducethe
potential for harmful interference to co-channel mobile satellite systems;
(ii)themaximumantennagainpermittedfordevicesinthebands5250-5350MHzand5470-
5725MHzshallcomplywiththee.i.r.p.limit;and
(iii)themaximumantennagainpermittedfordevicesintheband5725-5825MHzshall
comply with the e.i.r.p. limits specied for point-to-point and non point-to-point operation as
appropriate.
(iv) the worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p elevation mask
requirement set forth in Section 6.2.2(3) shall be clearly indicated.
(v) Users should also be advised that high-power radars are allocated as primary users (i.e.
priorityusers)ofthebands5250-5350MHzand5650-5850MHzandthattheseradarscould
causeinterferenceand/ordamagetoLE-LANdevices.
Avertissement
(i)Lesdispositifsfonctionnantdanslabande5150-5250MHzsontréservésuniquementàune
utilisationenintérieuranderéduirelesrisquesd’interférencepréjudiciableauxsystèmesde
satellitesmobilesutilisantlesmêmescanaux;
(ii)Legainmaximald’antennepermispourlesdispositifsutilisantlesbandes5250-5350MHzet
5470-5725MHzdoitseconformeràlalimitedep.i.r.e.;
(iii)Legainmaximald’antennepermis(pourlesdispositifsutilisantlabande5725-5825MHz)
doitseconformeràlalimitedep.i.r.e.spéciéepourl’exploitationpointàpointetnonpointà
point, selon le cas.
(iv)Lespiresanglesd’inclinaisonnécessairespourresterconformeàlalimitedep.i.r.e.applicable
aumasqued’élévation,eténoncéeàlasection6.2.2(3),doiventêtreclairementindiqués.
(v)Deplus,lesutilisateursdevraientaussiêtreavisésquelesutilisateursderadarsdehaute
puissancesontdésignésutilisateursprincipaux(c.-à-d.,qu’ilsontlapriorité)pourlesbandes
5250-5350MHzet5650-5850MHzetquecesradarspourraientcréerdesinterférenceset/ou
desdommagesauxdispositifsLAN-EL.

12
Notebook PC User Guide
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Industry Canada (IC) radio
frequencyexposurelimits.TheWirelessDeviceshouldbeusedinsuchamannersuchthat
thepotentialforhumancontactduringnormaloperationisminimized.Thisdevicehasbeen
evaluatedforandshowncompliantwiththeICSpecicAbsorptionRate(“SAR”)limitswhen
installedinspecichostproductsoperatedinportableexposureconditions.
Canada’sREL(RadioEquipmentList)canbefoundatthefollowingwebaddress:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
AdditionalCanadianinformationonRFexposurealsocanbefoundatthe
followingwebaddress:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Informations concernant l’exposition aux fréquences
radio (RF)
Lapuissancedesortieémiseparcetappareilsanslestinférieureàlalimited’expositionaux
fréquencesradiod’IndustrieCanada(IC).Utilisezl’appareilsansldefaçonàminimiserles
contactshumainslorsd’unfonctionnementnormal.Cetappareilaétéévaluéetdémontré
conformeauxlimitesdeDAS(Débitd’absorptionspécique)d’IClorsqu’ilestinstallédansdes
produitshôtesparticuliersquifonctionnentdansdesconditionsd’expositionàdesappareils
portables.
Cepériphériqueesthomologuépourl’utilisationauCanada.Pourconsulterl’entrée
correspondantàl’appareildanslalisted’équipementradio(REL-RadioEquipmentList)
d’IndustrieCanada,rendez-voussur
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Pourdesinformationssupplémentairesconcernantl’expositionauxfréquencesradioauCanada,
rendez-voussurhttp://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Notebook PC User Guide 13
UL Safety Notices
• DONOTusetheNotebookPCnearwater,forexample,nearabathtub,washbowl,kitchen
sink or laundry tub, in a wet basement or near a swimming pool.
• DONOTusetheNotebookPCduringanelectricalstorm.Theremaybearemoteriskof
electric shock from lightning.
• DONOTusetheNotebookPCinthevicinityofagasleak.
• DONOTdisposetheNotebookPCbatterypackinare,astheymayexplode.Checkwithlocal
codes for possible special disposal instructions to reduce the risk of injury to persons due to
reorexplosion.
• DONOTusepoweradaptersorbatteriesfromotherdevicestoreducetheriskofinjuryto
personsduetoreorexplosion.UseonlyULcertiedpoweradaptersorbatteriessupplied
bythemanufacturerorauthorizedretailers.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg must use
approvedpowercordsgreaterthanorequalto:H05VV-F,3G,0.75mm2orH05VV-F,2G,0.75mm2.
Coating Notice
IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating
isappliedtoinsulatethedeviceexceptontheareaswheretheI/Oportsarelocated.
REACH
ComplyingwiththeREACH(Registration,Evaluation,Authorization,andRestrictionof
Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS
REACH website at http://csr.asus.com/english/REACH.htm.

14
Notebook PC User Guide
Global Environmental Regulation Compliance and
Declaration
ASUS follows the green design concept to design and manufacture our products, and
makes sure that each stage of the product life cycle of ASUS product is in line with global
environmental regulations. In addition, ASUS disclose the relevant information based on
regulation requirements.
Please refer to http://csr.asus.com/english/Compliance.htm for information disclosure based on
regulationrequirementsASUSiscompliedwith:Japan JIS-C-0950 Material Declarations, EU
REACH SVHC, Korea RoHS
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for
protecting our environment. We believe in providing solutions for you to be able to responsibly
recycle our products, batteries, other components as well as the packaging materials. Please
go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in dierent
regions.
Regional notice for California
WARNING
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Regional notice for India
Thisproductcomplieswiththe“IndiaE-Waste(Management)Rules,2016”andprohibitsuseof
lead,mercury,hexavalentchromium,polybrominatedbiphenyls(PBBs)andpolybrominated
diphenylethers(PBDEs)inconcentrationsexceeding0.1%byweightinhomogenousmaterials
and0.01%byweightinhomogenousmaterialsforcadmium,exceptfortheexemptionslisted
in Schedule II of the Rule.

Notebook PC User Guide 15
Simplied EU Declaration of Conformity
ASUSTekComputerInc.herebydeclaresthatTP370QLisincompliancewiththeessential
requirementsandotherrelevantprovisionsofDirective2014/53/EU.FulltextofEUdeclaration
of conformity is available at https://www.asus.com/support/.
TheWiFioperatingintheband5150-5350MHzshallberestrictedtoindooruseforcountries
listedinthetablebelow:
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
A minimum separation distance of 0 cm must be maintained between the user’s body and the
device,includingtheantennaduringbody-wornoperationtocomplywiththeRFexposure
requirements in Europe.
RF Exposure Information
This ASUS product has been tested and meets applicable European SAR limits. The SAR limit is 2.0
W/Kg in countries that set the limit averaged over 10 grams of tissue.
When carrying this device or using it while worn on the body, either use an approved accessory
such as a holster or otherwise maintain a distance of 0 cm from the body to ensure compliance
withRFexposurerequirements.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume levels for long
periods.

16
Notebook PC User Guide
RED RF Output table
Function Frequency Maximum Output Power
Bluetooth
(EIRP)
BT 6.96dBm
BTLE 5.56dBm
2.4GHz11b 18.49dBm
2.4GHz11g 17.32 dBm
2.4GHz11nHT20(MIMO) 18.73 dBm
2.4GHz11nHT40(MIMO) 19.27dBm
WLAN
(EIRP)
5GHz11a 19.23dBm
5GHz11anHT20(MIMO) 18.54dBm
5GHz11anHT40(MIMO) 19.01dBm
5GHz11anVHT80(MIMO) 16.44 dBm
WCDMA
Band 1 23.30 dBm
Band 3 23.59dBm
Band 8 23.6 dBm
LTE
Band 1 23.46 dBm
Band 3 23.25dBm
Band 7 22.82 dBm
Band 8 23.38 dBm
Band 20 24.25dBm
Band 38 22.85dBm
Band 42 24 dBm
